NQ2AM1010BWIRELESS BASE STATION TRANSCEIVER

ADVANCED MOBILE SOLUTIONS, INC AIR MAGIC WIRELESS HEADSET & BASE STATION USER’S GUIDE HOW TO USE THE HEADSET AND BASE STATION STEP 1 Plug base station into cigarette lighter outlet. SETP 2 Plug the right angle 2.5mm plug from the base station into the audio receptacle or adapter on the phone. STEP 3 Adjust microphone tip to point to the corner of your mouth and adjust the earhook for proper stability. SETP 4 Turn on the headset by pushing the ON button. During a call, should it be necessary to adjust the receiver volume, push the three step volume button to achieve the correct level. BASE STATION OPERATION • Make sure the second battery pack is in the base station charging receptacle. • The LED on the right side of the base station will display the charging status of the battery, Red is fast charge and Green fully charged. • If the battery power drops below sufficient power level, you will notice a slight increase in background noise. Remove battery pack from the headset and replace it with a freshly charged battery pack from the base station. Place the discharged battery pack from the headset into the base station charger. • The newly charged battery will have a 4 hour on time • Normal charging time for the battery is 2.5 hours. HEADSET OPERATION • During a call, should it be necessary to adjust the receiver volume, push the three step volume button to achieve the correct level. • Transmit and receive range is 5 feet from the base station. If you exceed this range, the headset will generate an out of range tone every four seconds, up to eight times for a total of 32 seconds. When you return back into range the headset will still be linked to the base station. If you stay out of range for more than 32 seconds, the headset will automatically turn off to conserve battery power. At that time the yellow LED will be off, indicating a broken link. • To establish the link, simply turn the headset back on and the yellow LED will be back on showing the link has been established. • If for some reason you experience some interference with other electronic devices such as labtop computer TV set or radio etc. you can change the frequency setting by removing the battery pack from the headset and changing the 2 channel select switch to the other position. CAUTION: • Do not attempt to put on your headset or change the battery while driving. • Only turn off the headset when you leave the car or when you do not wish to use your cellular phone. FCC COMPLIANCE STATEMENT: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the user’s authority to operate the equipment

BASE STATION BLOCK DIAGRAM AM1010 Wednesday, July 28, 1999 11 {Model Code} {Document Number} B Short Range Wireless Head Set AMB1010BLK-X0.DSN X0 Kevin Park July,26,1999 {Name} {Name} {Date} {Date} {Date} {Name} Base station schematic diagram Advanced Mobile Solutions Inc. 375 Rheem Blvd, Moraga, CA 94556Tel:1-925-377-3200 Web:www.advancedmobile.com Model Code & Name Doc. No: Size: Sheetof CONFIDENTIAL AND PRO- PRIETARY INFORMATION This material is for use only by the recipient thereof directly from Advanced Mobile Solutions, Inc. This is the property of Advanced Mobile Solutions, Inc. and shall not be made available or disclosed without the proper written authorization thereof. Date: Drawn by Checked by Checked by Approved by E.C.O. Rev.ECO No Fax:1-925-377-3400 Title File Name: Date Rev. 6V+ TX Antenna JP1 HEADER 3 1 2 3 S1 CHANNEL SW 1 2 3 4 8 7 6 5 Y1 3.58MHz 455K FILT CF2 AMP BUFFER C13 RX Antenna U5-1 RV2 100KB C21 MIXER LED1 PWR & CHG AMP RV3 100KB SUM 455K FILT CF1 AMP U5-1 LED2 YEL I-Q MODULATOR (X,Y,Z Axis) 6V DC REGULATOR U2,C18 L7,8,9 L12,13,14 C48,49,50 R25,26,27 Q1,2,3 C37,38,39 U6,R28, R20,40 3 OF AMPs & MIXERs EXCEPT THE COMPONANT WHICH HAS REFERENCE NUMBER INTERNAL BLOCK OF BASE ASIC(AB1002) CLA PLUG R22,23,24 C40,41,42 C45,46,47 LO1 AUDIO OUT . AM Modulation LO2 MUTE DC 12V IN GAIN CONTROL . AUDIO COMPRESSOR 3.6V DC REGULATOR U1,C4 LINE FILTER & PROTECTOR PS1,LF1,L11 C1,75,DZ1 TX PLL LO1 PLL LO2 PLL LO2 Transmit Driver XYZ BATTERY CHARGER CONTACT LO1 L1,L2,L3 CT53,59,65 C54,60,66 R29,32,34 LOOP FILTERS 3 OF RF AGCs L4,L5,L6 CT1,2,3 C57,63,69 C57,64,70 . PLL SYNTHESIZER XMIT 3 OF RF LOADs (X,Y,Z Axis) BATTERY CHARGER U7,Q8,9,10 D1,C79,RT1 Q54,6,7 3 TO 1 MUX OOR DETECTOR EXPANDER ADUION IN 3.6V DC SYSTEM POWER VCXO I-Q MODULATOR * WIDE LINE MEANS BUS LINE

PROPOSED FCC ID LABEL FORMAT AND LOCATION APPLICANT:ADVANCED MOBIL SOLUTIONS, INC. MODEL NO: AM1010B FCC ID: NQ2AM1010B FCC ID:NQ2AM1010B FCC ID LABEL AREA

Theory of Operation AM1010B and AM1010H Prepared by Kevin Park Version 1.1 1.0 Theory of Operation 1.1 System Abstract: The characterstics of AM1010 is that One Chip IC offers all functions. AURA IC’s Short Range Magnetic Induction ASIC, AB1002 and AH1002 provide audio signal and RF signal for BU(AM1010B Base Unit) and HU(AM1010H Headset Unit). AM1010 IC sends the signal using the method of PWM (Puls Width Modulation) and receives AM modulation signal through LC antenna. Wireless communication’s receiver and transmitter are created by Magnetic Induction and the power consumption is very low and the unwanted emission are minimized. Receiver signal is controlled by AGC(Automatic Gain Controller) and it creates audio signal by IQ-Modulator and Direct Conversion method. Audio signal transmits low noise signal though Compressor and Expender in the IC. ASIC has TX, LO1, LO2 derived by PLL and can choose maximum 2 channels. 1.2 Dimensional Antenna The biggest characteristic of AM1010 is that 3 receiver and transmitter antenna with X,Y,Z axis are built in BU. This method prevents from lowering signal output by the signal direction of Magnetic Induction. Each axis of receiver antenna and transmitter antenna are constructed in the same direction. ASIC of BU do summing the signals from each axis and combines communication signals and then sends the signal by transmitter antenna which finds the strongest signals among the 3 axis antenna. The selection of transmitter antenna continues during communication and BU’s transmitter antenna is selected automatically which is depends on the direction of HU’s transmitter antenna. 1.3 X-Tal, TX, Local Oscillator 1 and 2 The set up for AM1010 wireless frequency is determined by Channel Switch. The channel can have maximum 8. Transmitter frequency is controlled by the internal PLL, according to selected channel value and transmitter frequency is calculated according to the following table. Reference frequency is obtained from X-tal(3.58MHz). TX Oscillator and Fist Local Oscillator and Second Local Oscillator are created internal ASIC. Especially, HU’s wireless frequency can be automatically tracking according to Base’s transmitter frequency. HU’s wireless frequency Tracking can control automatically HU’s Reference frequency by Varactor Diode which is installed inside of HU’s ASIC AH1002. Therefore, for frequency variation due to the environment, HU and BU can maintain the same frequency. 1.4 Modulation After BU and HU pass Compressor equally, communication signals change the internal PWM. The changed signals become Buffering through Inverter IC which connects to external ASIC and AM signals are Radiated through LC antenna. 1.5 AGC(Automatic Gain Control) The signal received by antenna is amplified by input amplifier in internal ASIC. Because the amplifier gain is fixed by RF-load, when the over limit signal sends to antenna, the signal becomes saturated and it causes signal Distortion. To prevent this, AGC (Atomatic Gain Controller) using Transistor Switch is built between antenna and RF-Load. When the internal Gain Controller voltage becomes over the limit level, it will turn on Transistor Switch and reduce the impedance of Rf-load and lower the Gain 1.6 Demodulator After the receiver signal mixes with LO1(First Local Oscillator) inside ASIC and passes 455KHz IF filter outside, it makes communication signal though I-Q modulator. In I-Q modulator, it mixes with LO2 (second Local Oscillator). In BU, separate I-Q modulator is installed where 2 I-Q Modulator will inspect the third axis receiver signal and will transmit to the direction of the antenna which finds the strongest signal. 1.7 OOR (Out of Range Detector) Depending on the demodulated communication signal volume, it sets OOR by comparing the DC size for found Gain Error and externally fixed OOR Range with resistance. BU indicates the status of OOR in Yellow color LED and HU warns the distance Tone signal to the user through speaker. When OOR is set, it mutes the block of internal receiver communication output and prevents the noise signal to go outside through Audio Line. Table 1: Headset Transceiver Frequency Chart <FS2, FS1, FS0>SynthFreq (Hz)MN <1,0,0>TX LO1 LO2 RX 484238 2260992 455111 1805880 133 69 125 9 1 9 <1,0,1>TX LO1 LO2 RX 494796 2277376 455475 1821900 151 139 139 10 2 10 Table 2: Base Unit Transceiver Frequency Chart <FS2,FS1,FS0>SynthFreq (Hz)MN <1,0,0>TX LO1 LO2 RX 1805880 939349 455111 484238 496 86 125 9 3 9 <1,0,1>TX LO1 LO2 RX 1821900 950272 455475 494796 278 29 139 5 1 10

X3 AM1010B (Short Range Wireless Head set ) ADVANCED MOBILE SOLUTIONS.,INC. 375 Rheem Blvd. Moraga CA 94556 Tel : 925-377-3200 Fax : 925-377-3400 Web : www.advancedmobile.com C 11Wednesday, May 12, 1999 Title SizeDocument NumberRev Date:Sheetof VREF_RX +6V VDD +6V VDD VDD VDD AUDIO_OUT AUDIO_OUT GND R5 560K C26 224 R13 N.A. R10 2.2K R12 2.2K R15 N.A. R11 2.2K C25 681 R7 36K LED2C21 153 R9 8.2K C17 153 C19 153 C12 153 R14 2.2K C16 153 C24 103 R17 560K R16 10MY1 32.768K C29 5p C30 3.3p C13 104 C10 33p C15 1u/6.3VA C72 3.3u/6.3VA C32 103 C34 103 R19 47 C35 103 R22 100K C40 221 C45 682 R23 100K R24 100KC42 221 C46 562 C47 682 C41 221 U5-1 74ACT04 12 14 7 U5-2 74ACT04 34 U5-3 74ACT04 56 U5-4 74ACT04 98 U5-5 74ACT04 1110 U5-6 74ACT04 1312 C52 103 C51 22u/6.3VA R34 0 C66 181 CT65 50p C68 N.A. L3 36uH_H CT59 50p L2 36uH_V R29 0L1 36uH_H L10 22uH C48 152 C0G 0805 C37 681 Q1 MMBT4403 C38 681 Q2 MMBT4403 C43 22u/6.3VA C44 103 R33 OPEN C63 222 C0G 0805 C64 561 C0G 0805 L6 36uH_H R31 100K C62 N.A. U7 BQ2002 1 2 3 45 6 7 8 TM LED BAT VssTS Vcc INH CC R47 330K R48 560K C60 181R32 0 R41 10K R42 10K Q8 MMBT2907 Q10 MMBT2907 Q9 MMBT2907 R43 10K R44 33 R49 240K RT1 XND504JTR R46 100K R45 301K R53 330 Q6 MMBT3904 Q5 MMBT3906 Q7 MMBT3904 R54 330 R51 10K R52 100K LED1 U1 MIC5205-3.6BM5 1 2 34 5 Vin GND ENByp Vout C5 471 C23 3.3u/6.3VA C4 2.2/10VA U2 MIC5205BM5 1 2 34 5 Vin GND ENAdj Vout C20 471 R3 150K C18 2.2/10VA R2 39k C3 103 LF1 40mH 12 34 C6 103 L11 100uH C75 15u/20VD C14 104 C71 104 R50 100K C9 104 R39 330 C36 103 U3 AB1002 123457689101112 13 14 15 16 17 18 19 20 21 22 23 24 252627282930313233343536 37 38 39 40 41 42 43 44 45 46 47 48 D_VDDD_VSSTX_LFLO1_LFLO2_LFVMIMVREF_RXVDD_LNAX_RFLOADX_RXY_RFLOAD Y_RX Z_RFLOAD Z_RX CF_AI CF_AO CF_MI CF_MO M_I A_I A_AGC OOR_ADJ OOR REM_1REM_2 LINE_OUT EXPDR_IN EXPDR_TIME CMPRS_TIME CMPRS_AUDIO CMPRS_OUT DC_FB LINE_IN ADUIO_N AUDIO_P A_VDD A_VSS T_VSS T_VDD Z_TX Y_TX X_TX FS0 FS1 FS2 XTAL_IN XTAL_OUT R40 270K R28 2.2M Q3 MMBT4403 C33 471 R27 N.A. - + U6 LMV321 3 1 4 5 2 C31 471 C28 471 R20 100K C39 681 R35 OPEN C70 561 C0G 0805 C69 222 C0G 0805 DZ1 1N5258 C2 33p PS1 RXE017C1 15u/20VD C7 33p C8 33p CF2 455D 1 2 3 CF1 455D 1 2 3 J1 Molex 3 1 2 3 C77 104 L8 68uH 1214 LQS33N L9 68uH 1214 LQS33N C49 152 C0G 0805 C50 152 C0G 0805 C6515p C5915p CT53 50p C5315p C78 104 C79 1u/10V R18 27K CT2 50p C85 101 C0G 0805 C84 47p C0G 0805 C83 101 C0G 0805 C82 47p C0G 0805 JP5 Jumper CT3 50p JP6 Jumper JP3 Jumper JP4 Jumper C56 N.A. C54 181 L7 68uH 1214 LQS33N L12 300uH 1214 658AN-1094Z 1 3 L13 300uH 1214 658AN-1094Z 1 3 L14 300uH 1214 658AN-1094Z 1 3 S1 SW DIP-4 1 2 3 4 8 7 6 5 L5 36uH_V C67 121 C0G C61 121 C0G C57 222 C0G 0805 R30 OPENJP2 Jumper C58 561 C0G 0805 L4 36uH_H C55 121 C0G C80 47p C0G 0805 CT1 50p C81 101 C0G 0805 JP1 Jumper RV2 100KB Q4 MMBT4403 RV3 100KB C11 474 0806 R1 10K D1 MMBD4148 12 3 R26 N.A. R25 N.A. Batt+ Batt- DCIN+ DCIN- T GRNRED Charge * The TX antenna impedance should be close to 6.5ohms * The RF load impedance should be close to 3.8Kohms

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for INTENTIONAL RADIATOR 1.80 &1.82MHZ TRANSCEIVER MODEL NO: AM1010B FCC ID NO: NQ2AM1010B REPORT NO: 99U0393 ISSUE DATE: AUGUST 02,1999 Prepared for ADVANCED MOBIL SOLUTIONS, INC. 375 RHEEM BLVD. MORAGA, CA 94556 Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089, USA TEL: (408) 752-8166 FAX: (408) 752-8168 REPORT NO:99u00393 FCC ID:NQ2AM1010B DATE:JULY 06, 1999 COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4020B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE..................................1 2. Product Description.........................................2 3. Test Facility...............................................2 4. Measurement Standards.......................................2 5. Test Methodology............................................2 6. Measurement Equipment Used..................................2 7. RADIATED EMISSION LIMITS....................................3 8. SYSTEM TEST CONFIGURATION...................................3 9. Test Procedure..............................................3 11. TEST RESULT................................................6 TEST DATA REPORT NO:99u0393 FCC ID:NQ2AM1010B DATE:07/06/99 PAGE NO: 1 COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4020B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 1. VERIFICATION OF COMPLIANCE COMPANY NAME : ADVANCED MOBIL SOLUTIONS, INC. 375 RHEEM BLVD. MORAGA, CA 94556 CONTACT PERSON: SANDRA SOHN/ REGULATORY TEST ENGINEER TELEPHONE NO.: (925)377-3257 EUT DESCRIPTION: 1.8 & 1.82MHZ TRANSCEIVER MODEL NAME/NUMBER: AM1010B FCC ID: NQ2AM1010B DATE TESTED : JULY 6,1999 REPORT NUMBER: 99U0393 TYPE OF EQUIPMENTWIRELESS BASE STATION FOR CELL PHONE EQUIPMENT TYPE1.8 & 1.82MHZ TRANSMITTER MEASUREMENT PROCEDUREANSI C63.4 / 1992 LIMIT TYPECERTIFICATION FCC RULECFR 47, PART 15 The above equipment was tested by Compliance Engineering Services, Inc. for compliance with the requirements set forth in CFR 47, PART 15. This said equipment in the configuration described in this report shows that maximum emission levels emanating from equipment are within the compliance requirements. MIKE C.I. KUO / VICE PRESIDENT COMPLIANCE ENGINEERING SERVICES, INC. REPORT NO:99u0393 FCC ID:NQ2AM1010B DATE:07/06/99 PAGE NO: 2 COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4020B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 2. Product Description Fundamental Frequency 1.8 & 1.82MHZ Power Source 12VDC Usage Audio Antenna type Permanently attached No. of external connector and type 1, RJ11 Associated Transmitter FCC ID:NQ2AM1010H 3. Test Facility The 3/10/30 meter open area test site and conducted measurement facility used to collect the radiated data is located at 561F Monterey Road, Morgan Hill, California, U.S.A. A detailed description of the test facility was submitted to the Commission on May 27,1994. 4. Measurement Standards The site is constructed and calibrated in conformance with the requirements of ANSI C63.4/1992. 5. Test Methodology For an intentional radiator, the spectrum shall be investigated from the lowest radio frequency signal generated in the device, without going below 9 KHz, up to at least the tenth harmonic of the highest fundamental frequency or to 40 GHz, whichever is lower. (CFR 47 Section 15.33) 6. Measurement Equipment Used Manufacturer Model Number Description Cal Due Date H.P.8566BSpectrum Analyzer (100Hz – 22GHz) 09/99 EMCO6502Active Loop Antenna (.009-30.0MHZ) 2/00 H.P.8447DPreamplifier09/99 REPORT NO:99u0393 FCC ID:NQ2AM1010B DATE:07/06/99 PAGE NO: 3 COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4020B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without the written approval of CCS. (0.1 - 1300 MHz) 7. RADIATED EMISSION LIMITS GENERAL REQUIREMENTS SECTION 15.209. OPERATION IN THE BAND 1.705-10MHZ SECTION 15.223 8. SYSTEM TEST CONFIGURATION Support Equipment: DC Power Supply, Kenwood, PA36-3A Cellular Phone, Motorola Star Tac, 80067NABPA, FCC ID:IHDT5VG1 EE3 Head Set, Advanced Mobil Solutions, AH1010H Radiated Open Site Test Set-up 9. Test Procedure Radiated Emissions, 15.209 15.223 HeadsetBase-station 12VDC Power Supply Cellular Phone REPORT NO:99u0393 FCC ID:NQ2AM1010B DATE:07/06/99 PAGE NO: 4 COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4020B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without the written approval of CCS. Test Set-up for frequency range 0.4-20MHz Antenna mast Ground plane 1 - 4 meters 3 meters Antenna turntable preamplifier/spectrum analyzer Fig. 1 1. The EUT was placed on a wooden table on the outdoor ground plane. The search antenna was placed 3-meters from the EUT. 2. The turntable was slowly rotated to locate the direction of maximum emission. The EUT was moved throughout the. 3. Once maximum direction was determined, the search antenna was raised and lowered .The maximum readings so obtained are recorded in the data listed below. 4. Steps 1-3 were repeated at 5 and 10 meters. 3, 5 and 10 meter measurements were plotted on semi-log paper to extrapolate to 30 meter data. REPORT NO:99u0393 FCC ID:NQ2AM1010B DATE:07/06/99 PAGE NO: 5 COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4020B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall …
