NS3-T058VSWireless Security Alarm / Auto Dialer System

(Fig.1B) Slave Unit From Main Unit Slave Extended Cable ( Fig.3 ) Main unit Black striped wire to negative (-) ( Fig.1A ) White Black Red ( Fig. 2) Terminal ( Fig. 5) PASSWORD - 2 - - 3 -- 4 -- 5 - MEMORY 1 2 3 4 5 MEMORY LOCATION (Fig.6) 7 TO PROGRAM AUTO DIALLING CYCLE. The auto-dialer has been factory set for auto dialling 3 cycles. (When system is triggered the auto dialer will call every stored numbers 3 times) You can change the cycle from 1 - 5 dialling times. a. Enter the pass number followed by [PROG] button six times. b. “CYCLE” will now flash on the LCD. c. Press [ARM/DISARM] button to confirm. d. Using the * /UP] and [#/DOWN] buttons to select 1 - 5 followed by the [ARM/DISARM] button to confirm the cycle (how many times the Auto-dialer will call you if the system will be triggered) e. You can press [#/DOWN] button or [ * /UP] button select other setup, or press the [PROG] button four times to exit setup mode. 8 TO PROGRAM CALL-IN RING DETECT CYCLE. The call-in ring detect cycle for how many call-in rings the Auto-dialer will answer, The auto-dialer has been factory set for 5 times, you can change this cycle from 3, 5, 7, 10 times. a. Enter the pass number followed by [PROG] button seven times. b. “ ” will now flash on the LCD. c. Press [ARM/DISARM] button to confirm. d. Using the * /UP] and [#/DOWN] buttons to select 3, 5, 7, 10 followed by the [ARM/DISARM] button to confirm. e. You can press [#/DOWN] button or [ * /UP] button select other setup, or press the [PROG] button three times to exit setup mode. 9 TO PROGRAM ENTRY DELAY TIME The auto-dialer has been factory set for a 20 seconds entry delay time. You can change this to 0,5,10,15, or 20 seconds: a. Enter the pass number followed by [PROG] button eight times. b. “ENTRY” will now flash on the LCD. c. Press the [ARM/DISARM] button to confirm. d. Using the * /UP] and [#/DOWN] buttons select the seconds 0,5,10,15 or 20. Press ARM/DISARM to confirm the number of seconds you required for the entry delay time. e. Press the [PROG] button twice to exit setup mode. 10 REAL TIME SETTING a. Enter the pass number followed by [PROG] button seven times. b. “ ” will flash on the LCD. c. Press the [ARM/DISARM] button to confirm. d. The date will show in the LCD as five sets of numbers, year-month-date, hour-minute by the real time. The first set of numbers will flash confirming that these can now be changed. e. Press the * /UP] and [#/DOWN] buttons to select the correct date and time followed by the [ARM/DISARM] button to confirm and store. You will now have the correct date and time. f. Press the [PROG] button once to exit setup mode. 11 REC/PLAY MESSAGE a. Enter your password followed by the [REC/PLAY] button. Speak your message for the unit. You have 20 seconds for your message.When you have finished recording your message, press the [REC/PLAY]button. You need to include instructions in your message on how to disarm the unit, as you will probably not remember all the remote control functions once the unit has been activated. b. Your message should be similar to: “[Your name’s ] security system has been activated. Please enter a command.” (Optionally you may wish to list the commands: “1#”-Monitor Room, “2#”-Broadcast, “3#”-End Call or “6#”-Disarm System.) c. To listen to your recorded message press the [REC/PLAY] button. TO TEST MEMORY DIALLING In standby mode, press and hold the [PROG] button for more than two seconds, hear a beep tone, then key in the test telephone number memory location, the telephone number stored in memory will automatically be dialed. TO TEST WIRELESS SENSOR TRANSMITTING RANGE After selecting a location for the unit, press [HOME] button of the Auto-Dialer, and wait 60 seconds and then trigger wireless sensor, The Auto-Dialer will receive trigger signal sound DING - DONG and LCD show sensor zone number. Press [HOME] button again to exit the home mode after test. OPERATION 1 TO ARM THE SYSTEM a. Enter the pass number followed by theARM/DISARMbutton. b. Three short beeps will sound and the "ARM" icon will show on the LCD. c. You can press and holdARMbutton 2 seconds on remote unit to “ARM” main unit. d. There will be a single beep after 60 seconds, the Auto-Dialer is at “ARM” mode now. e. Into arming, the system will detect door/window sensor state, when door/window is open, it will sound beep tone 5 seconds and LCD show “CLOSE PLEASE” and sensor zone number, if still not close door/window it will turn on alarm and auto-dialling after 60 seconds. (Fig.7) LEARN 123456789 REMOTE ZONE NUMBER 2 ALARM a. In ARM mode system receive wireless sensor trigger signal in the protected area，LCD will show trigger icon and trigger sensor zone number, after the entry time then sound a SIREN for 30 seconds on and 30 seconds off then 30 seconds on again, and will automatically dial the numbers stored, one by one, in the CYCLE you have chosen, (amount of times the numbers are dialed). You will hear notification message when the call is answered, you can call the Police or make the necessary arrangements, ie calling a neighbour. b. In ARM mode, if the Auto-Dialer is set at “SIREN OFF”, the numbers stored will be dialed silently, when the call is answered you will hear 1, 2 or 4 beeps and know what trigger the system, enable you to call the police or make necessary arrangements or calling a neighbour. Remember if the Auto-Dialer was calling you silently, the system will be quiet . NOTE: the system have the function that detect telephone line connect, when telephone line is not connect, it will sound four beep tone before sound siren and do not dial out. 3 TO DISARM THE SYSTEM a. Enter the pass number followed by the DISARM button. b. You will hear a long beep tone and the “ARM” icon will disappear on the LCD to confirm that the Auto-Dialer was “DISARMED”. c. You can press and hold [DISARM] button 2 seconds on remote control to “DISARM” main unit. 4 PANIC BUTTON a. Press [PANIC] button on main unit or press and hold [PANIC] button 2 …

Text truncated - open the document above for the full version.

Lelux Electronics Ltd. Unit 6, 10/F, TCL Tower, No.8, Tai Chung Road, Tsuen Wan, New Territories, Hong Kong Confidentiality Letter To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: NS3-T058VS We hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature : name / title: Luke Lo / President address: Unit 6, 10/F, TCL Tower, No.8, Tai Chung Road, Tsuen Wan, New Territories, Hong Kong

Label location

Antenna location

FCC ID: NS3-T058VS Keyway Testing Technology Co., Ltd. Report No. 14KWE071357F Page 1 of 32 FCC TEST REPORT for Lelux Electronics Ltd. Wireless Security Alarm / Auto Dialer System Model Number:T058VS, T058S FCC ID: NS3-T058VS Prepared for : Lelux Electronics Ltd. Address : Unit 6, 10/F, TCL Tower, No.8, Tai Chung Road, Tsuen Wan, New Territories, Hong Kong Prepared by : Keyway Testing Technology Co., Ltd. Address : Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 14KWE071357F Date of Test : Oct. 13~16, 2014 Date of Report : Oct. 17, 2014 FCC ID: NS3-T058VS Keyway Testing Technology Co., Ltd. Report No. 14KWE071357F Page 2 of 32 TABLE OF CONTENTS Test Report Declaration Page 1. GENERAL PRODUCT INFORMATION ............................................................................4 1.1. Product Function.................................................................................................................... 4 1.2. Description of Device (EUT) .................................................................................................. 4 1.3. Independent Operation Modes .............................................................................................. 4 1.4. Difference between Model Numbers...................................................................................... 4 2. TEST SITES .....................................................................................................................5 2.1. Test Facilities ......................................................................................................................... 5 2.2. List of Test and Measurement Instruments............................................................................ 6 3. TEST SET-UP AND OPERATION MODES......................................................................7 3.1. Principle of Configuration Selection ....................................................................................... 7 3.2. Block Diagram of Test Set-up ................................................................................................ 7 3.3. Test Operation Mode and Test Software ............................................................................... 7 3.4. Special Accessories and Auxiliary Equipment ....................................................................... 7 3.5. Countermeasures to Achieve EMC Compliance.................................................................... 7 3.6. Test Environment:.................................................................................................................. 7 4. EMISSION TEST RESULTS.............................................................................................8 4.1. Radiated Emission Test ....................................................................................................... 11 5. CALCULATION OF AVERAGE FACTOR.......................................................................17 6. 20DB OCCUPY BANDWIDTH ........................................................................................19 6.1. Limits.................................................................................................................................... 19 7. DWELL TIME..................................................................................................................20 7.1. Limits.................................................................................................................................... 20 8. PHOTOGRAPHS OF TEST SET-UP..............................................................................21 9. PHOTOGRAPHS OF THE EUT......................................................................................23 FCC ID: NS3-T058VS Keyway Testing Technology Co., Ltd. Report No. 14KWE071357F Page 3 of 32 Keyway Testing Technology Co., Ltd. Applicant: Address: Lelux Electronics Ltd. Unit 6, 10/F, TCL Tower, No.8, Tai Chung Road, Tsuen Wan, New Territories, Hong Kong Manufacturer: Address: Lelux Electronics Ltd. Unit 6, 10/F, TCL Tower, No.8, Tai Chung Road, Tsuen Wan, New Territories, Hong Kong E.U.T: Wireless Security Alarm / Auto Dialer System Model Number: T058VS, T058S Trade Name: Serial No.: ------ Date of Receipt: Oct. 13, 2014 Date of Test: Oct. 13~16, 2014 Test Specification: FCC Part 15, Subpart C: Oct. 1, 2013 ANSI C63.4:2009 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Oct. 17, 2014 Tested by: Reviewed by: Approved by: Andy Gao / Engineer Jade Yang/ Supervisor Chris Du / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Keyway Testing Technology Co., Ltd. FCC ID: NS3-T058VS Keyway Testing Technology Co., Ltd. Report No. 14KWE071357F Page 4 of 32 1. GENERAL PRODUCT INFORMATION 1.1. Product Function Refer to Technical Construction Form and User Manual. 1.2. Description of Device (EUT) Description : Wireless Security Alarm / Auto Dialer System M/N : T058VS, T058S Power Supply : DC 9V from adapter DC 9V Operation Frequency : 433.92MHz Modulation Technology : ASK Antenna Type : Integral Antenna Gain : 2dBi Adapter Manufacturer: GOLDEN PROFIT ELECTRONICS LTD. Model No.: GPE053A-090050-1 Power Input: 100~240V-50/60Hz 0.2A Power Output: 9V/500mA 4.5W DC Line: Unshielded, Undetachable 1.85m 1.3. Independent Operation Modes The basic operation modes are: 1.3.1. Transmitting mode 1.3.2. Normal mode. 1.3.3. Transmitting mode(Low voltage Mode) 1.3.4. Receiving mode Remark: For battery test, used new battery. 1.4. Difference between Model Numbers The models only different for model name and recording function. FCC ID: NS3-T058VS Keyway Testing Technology Co., Ltd…
