NS915PX2Pico 2.4GHz High Speed 1W Module

Operating Manual pX2 Pico 2.4GHz High Speed 1W Module Revision 0.23, June 17, 2015 www.microhardcorp.com Microhard Systems Inc. ii PX2 Operating Manual Warranty Microhard Systems Inc. warrants that each product will be free of defects in material and workmanship for a period of one (1) year for its products. The warranty commences on the date the product is shipped by Microhard Systems Inc. Microhard Systems Inc.’s sole liability and responsibility under this warranty is to repair or replace any product which is returned to it by the Buyer and which Microhard Systems Inc. determines does not conform to the warranty. Product returned to Microhard Systems Inc. for warranty service will be shipped to Microhard Systems Inc. at Buyer’s expense and will be returned to Buyer at Microhard Systems Inc.’s expense. In no event shall Microhard Systems Inc. be responsible under this warranty for any defect which is caused by negligence, misuse or mistreatment of a product or for any unit which has been altered or modified in any way. The warranty of replacement shall terminate with the warranty of the product. Warranty Disclaims Microhard Systems Inc. makes no warranties of any nature of kind, expressed or implied, with respect to the hardware, software, and/or products and hereby disclaims any and all such warranties, including but not limited to warranty of non-infringement, implied warranties of merchantability for a particular purpose, any interruption or loss of the hardware, software, and/or product, any delay in providing the hardware, software, and/or product or correcting any defect in the hardware, software, and/or product, or any other warranty. The Purchaser represents and warrants that Microhard Systems Inc. has not made any such warranties to the Purchaser or its agents MICROHARD SYSTEMS INC. EXPRESS WARRANTY TO BUYER CONSTITUTES MICROHARD SYSTEMS INC. SOLE LIABILITY AND THE BUYER’S SOLE REMEDIES. EXCEPT AS THUS PROVIDED, MICROHARD SYSTEMS INC. DISCLAIMS ALL WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PROMISE. MICROHARD SYSTEMS INC. PRODUCTS ARE NOT DESIGNED OR INTENDED TO BE USED IN ANY LIFE SUPPORT RELATED DEVICE OR SYSTEM RELATED FUNCTIONS NOR AS PART OF ANY OTHER CRITICAL SYSTEM AND ARE GRANTED NO FUNCTIONAL WARRANTY. Indemnification The Purchaser shall indemnify Microhard Systems Inc. and its respective directors, officers, employees, successors and assigns including any subsidiaries, related corporations, or affiliates, shall be released and discharged from any and all manner of action, causes of action, liability, losses, damages, suits, dues, sums of money, expenses (including legal fees), general damages, special damages, including without limitation, claims for personal injuries, death or property damage related to the products sold hereunder, costs and demands of every and any kind and nature whatsoever at law. IN NO EVENT WILL MICROHARD SYSTEMS INC. BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, INCIDENTAL, BUSINESS INTERRUPTION, CATASTROPHIC, PUNITIVE OR OTHER DAMAGES WHICH MAY BE CLAIMED TO ARISE IN CONNECTION WITH THE HARDWARE, REGARDLESS OF THE LEGAL THEORY BEHIND SUCH CLAIMS, WHETHER IN TORT, CONTRACT OR UNDER ANY APPLICABLE STATUTORY OR REGULATORY LAWS, RULES, REGULATIONS, EXECUTIVE OR ADMINISTRATIVE ORDERS OR DECLARATIONS OR OTHERWISE, EVEN IF MICROHARD SYSTEMS INC. HAS BEEN ADVISED OR OTHERWISE HAS KNOWLEDGE OF THE POSSIBILITY OF SUCH DAMAGES AND TAKES NO ACTION TO PREVENT OR MINIMIZE SUCH DAMAGES. IN THE EVENT THAT REGARDLESS OF THE WARRANTY DISCLAIMERS AND HOLD HARMLESS PROVISIONS INCLUDED ABOVE MICROHARD SYSTEMS INC. IS SOMEHOW HELD LIABLE OR RESPONSIBLE FOR ANY DAMAGE OR INJURY, MICROHARD SYSTEMS INC.'S LIABILITY FOR ANYDAMAGES SHALL NOT EXCEED THE PROFIT REALIZED BY MICROHARD SYSTEMS INC. ON THE SALE OR PROVISION OF THE HARDWARE TO THE CUSTOMER. Proprietary Rights The Buyer hereby acknowledges that Microhard Systems Inc. has a proprietary interest and intellectual property rights in the Hardware, Software and/or Products. The Purchaser shall not (i) remove any copyright, trade secret, trademark or other evidence of Microhard Systems Inc.’s ownership or proprietary interest or confidentiality other proprietary notices contained on, or in, the Hardware, Software or Products, (ii) reproduce or modify any Hardware, Software or Products or make any copies thereof, (iii) reverse assemble, reverse engineer or decompile any Software or copy thereof in whole or in part, (iv) sell, transfer or otherwise make available to others the Hardware, Software, or Products or documentation thereof or any copy thereof, except in accordance with this Agreement. iii pX2 Regulatory Requirements - PLEASE READ THIS SECTION CAREFULLY WARNING: To satisfy FCC RF exposure requirements for mobile transmitting devices, a separation distance of 23 cm or more should be maintained between the antenna of this device and persons during device operation. To ensure compliance, operations at closer than this distance is not recommended. The antenna used for this transmitter must not be co-located in conjunction with any other antenna or transmitter. WARNING: Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation. WARNING: Changes or modifications not expressly approved by Microhard Systems Inc. could void the user’s authority to operate the equipment. This device has been tested with UFL to Reverse Polarity SMA connectors with the antennas listed in Appendix A When integrated in OEM products, fixed antennas require installation preventing end-users from replacing them with non-approved antennas. Antennas not listed in the tables must be tested to comply with FCC Section 15.203 (unique antenna connectors) and Section 15.247 (emissions). WARNING: MAXIMUM EIRP FCC Regulations al…

Text truncated - open the document above for the full version.

Tel: (403) 248-0028 Fax: (403) 248-2762 E-mail: [email protected] www.microhardcorp.com Leaders in Wireless Telecom June 1 2015 To Whom It May Concern Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: SUBJECT: FCC Application for FCC ID: NS915PX2 To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Verification Authorization procedure pursuant to Part 15, Subpart B - Unintentional Radiators, portion of this composite filing. Sincerely, Hany Shenouda Director of Engineering Microhard Systems Inc.

Tel: (403) 248-0028 Fax: (403) 248-2762 E-mail: [email protected] www.microhardcorp.com Leaders in Wireless Telecom June 1, 2015 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. Subject: Attestation to use Original Test Reports in New Filing Applicant: Microhard Systems Inc. Model: pX2 Product: Pico 2.4GHz High Speed 1W Module FCC ID: NS915PX2 IC: 3143A‐15PX2 Dear Sir/Madam, We, Microhard Systems Inc., hereby attest to the fact that the transmitter module(s) report(s) listed below, used in support of the co‐location RF exposure evaluation accurately represent test results under the new conditions. The integration of the module in co‐location configurations will adhere to conditions of the original filing. Associated FCC ID Associated IC ID Test Report Identifiers LN930 R17LN930 5131A‐LN930FA391111 L200 XPY‐TOBYL200 8595A‐TOBYL200MDE_UBLOX_1408_MPEa Rev 3 L100 R5Q‐TOBYL100 8595B‐TOBYL100 Yours truly, Hany Shenouda Director of Engineering Microhard Systems Inc.

Tel: (403) 248-0028 Fax: (403) 248-2762 E-mail: [email protected] www.microhardcorp.com Leaders in Wireless Telecom June 1 2015 To Whom It May Concern Subject: Authority to Act as an Agent Applicant: Microhard Systems Inc. FCC ID: NS915PX2 Dear Sir/Madam: I hereby appoint UltraTech Engineering Labs Inc. (UltraTech) to act as my agent in preparation of this application for authorization of above equipment under F.C.C. Rules. The applicant hereby certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a “party” for these purposes. I also certify that the information provided, properly describe the device or system for which authorization is required. Sincerely, Hany Shenouda Director of Engineering Microhard Systems Inc.

Tel: (403) 248-0028 Fax: (403) 248-2762 E-mail: [email protected] www.microhardcorp.com Leaders in Wireless Telecom June 10, 2015 To Whom It May Concern Subject: Confidentiality Request Letter Applicant: Microhard Systems Inc. FCC ID: NS915PX2 Dear Sir/Madam: The applicant would like to request the following documents submitted with this application for certification be withheld from public disclosure as per Sections 0.457 & 0.459 of FCC Rules. 1. Operational Description 2. Block Diagram 3. Schematic(s) 4. Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Yours truly, Hany Shenouda Director of Engineering Microhard Systems Inc.

UltraTech Group of Labs FCC TCB & IC CB Ultratech’s Accreditations: 0685 91038 1309 46390-2049 NVLAP LAB CODE 200093-0 SL2-IN-E-1119R Korea KCC-RRA CA2049 TL363_B TPTDP DA1300 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] June 16, 2015 Ultratech Engineering Labs, Inc. 3000 Bristol Circle Oakville, Ontario L6H 6G4 Subject: Application for Equipment Certification under FCC Part 15, Subpart C, Section 15.247 - Digital Modulation Systems (DTS) Operating in 2400 - 2483.5 MHz Band. Applicant: Microhard Systems Inc. Product: Pico 2.4GHz High Speed 1W Module Model: pX2 FCC ID: NS915PX2 Dear Sir/Madam: As appointed agent for Digi International Inc, we submit the application for certification of the above product. Kindly review all files uploaded to your electronic filing site. This application is subject to FCC certification for modular approval, kindly refer to Applicant’s letter requesting for modular approval according to the modular approval requirements in Section 15.212 rules. If you have any queries, please do not hesitate to contact us. Yours truly, Dan Huynh Dan Huynh Authorized Agent

Top No Shield Bottom

FCC Part 15, Subpart C, Section 15.247 – DTS Page 155 of 159 Pico 2.4GHz High Speed 1W Module, Model pX2 FCC ID: NS915PX2 ULTRATECH GROUP OF LABS File #: 15MCRS083_FCC15C247DTS 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 June 16, 2015 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 5.7. RF EXPOSURE REQUIRMENTS [§§ 15.247(i), 1.1310 & 2.1091] 5.7.1. Limits § 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3-3.0 6141.63*(100) 6 3.0-30 1842/f4.89/f*(900/f 2 ) 6 30-300 61.40.1631.0 6 300-1500 f/300 6 1500-100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 6141.63*(100) 30 1.34-30 824/f2.19/f*(180/f 2 ) 30 30-300 27.50.0730.2 30 300-1500 f/1500 30 1500-100,000 1.0 30 f = frequency in MHz * = Plane-wave equivalent power density Note 1: Occupational/controlled limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when an individual is transient through a location where occupational/controlled limits apply provided he or she is made aware of the potential for exposure. Note 2: General population/uncontrolled exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or can not exercise control over their exposure. FCC Part 15, Subpart C, Section 15.247 – DTS Page 156 of 159 Pico 2.4GHz High Speed 1W Module, Model pX2 FCC ID: NS915PX2 ULTRATECH GROUP OF LABS File #: 15MCRS083_FCC15C247DTS 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 June 16, 2015 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 5.7.2. Method of Measurements Calculation Method of Power Density/RF Safety Distance : 22 44r EIRP r PG S      Where, P: power input to the antenna in mW EIRP: Equivalent (effective) isotropic radiated power. S: power density mW/cm 2 G: numeric gain of antenna relative to isotropic radiator r: distance to centre of radiation in cm S EIRP S PG r     44 5.7.3. RF Evaluation 5.7.3.1. Standalone Maximum EIRP, P EIRP [dBm]: 36.00 MPE Limit for General Population/Uncontrolled Exposure, S uncontrolled [mW/cm 2 ] 1.0 Calculated RF Safety Distance for General Population/Uncontrolled Exposure, r safety_uncontrolled [cm] 17.8 FCC Part 15, Subpart C, Section 15.247 – DTS Page 157 of 159 Pico 2.4GHz High Speed 1W Module, Model pX2 FCC ID: NS915PX2 ULTRATECH GROUP OF LABS File #: 15MCRS083_FCC15C247DTS 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 June 16, 2015 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 5.7.3.2. Co-location Pursuant to KDB 447498 D01 General RF Exposure Guidance v05r02, Section 7.2: Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modeled or measured field strengths or power density, is ≤ 1.0. Co-location will only applies to EUT with 2 dBi dipole antenna, worst case EIRP of 32 dBm will be used in co- location at the minimum 23 cm evaluation separation distance required by the operating configurations and exposure conditions of the host device. The maximum calculated MPE ratio of the EUT with 2 dBi dipole antenna Frequency (MHz) EUT EIRP (dBm) EUT EIRP (mW) Evaluation Distance (cm) Power Density (mW/cm 2 ) FCC/IC MPE Limit (mW/cm 2 ) MPE Ratio 2412 32 1584.893 23 0.238 1.0 0.238 The maximum calculated MPE ratio for the EUT with 2 dBi dipole antenna is 0.238, this configuration can be co- located with other antennas provided the sum of the MPE ratios for all the other simultaneous transmitting antennas incorporated in a host device is < 1.0 - 0.238 < 0.762. The following table addresses the co-location of the EUT with 2 dBi antenna with the specified radio modules. EUT with 2 dBi dipole antenna co-location with radio module indentified in this table *Radio Module Frequency (MHz) EIRP (mW) Evaluation Distance (cm) Power Density (mW/cm 2 ) FCC/IC MPE Limit (mW/cm 2 ) MPE Ratio MPE Ratio of EUT with 2 dBi antenna Sum of MPE Ratio Verdict Data Card Module (FCC ID: RI7LN930, IC: 5131A-LN930) 824.2 2511.89 23 0.378 0.549 0.689 0.238 0.927 Compliant LTE Data Transmitter Module (FCC ID: R5Q-TOBYL100, IC: 8595B-TOBYL100) 782 2564.48423 0.386 0.521 0.741 0.238 0.979 Compliant GSM/UMTS/LTE Data Module (FCC ID: XPYTOBYL200, IC: 8595A-TOBYL200) 1909.8 2944.21923 0.443 1.0 0.443 0.238 0.681 Compliant * The test data of the radio modules represented in this table is the worst-case configuration (maximum MPE ratio) derived from the original radio modules MPE reports. Refer to these reports for details.

TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 August 30, 2013 TUV SUD BABT Octagon House, Concorde Way Segensworth Rd N, Fareham PO15 5RL Attention: Director of Certification RE: Prediction of MPE limit at a given distance as per KDB 447498 D01 Mobile Portable RF Exposure v05r01 FCC ID R5Q-TOBYL100 IC: 8595B-TOBYL100 Equation for Power Density: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to isotropic R = distance to the center of radiation of the antenna LTE Band 4 LTE Band 13 Maximum peak output power at antenna input terminal: 23.13 23.39 dBm Maximum peak output power at antenna input terminal: 205.59 218.27 mW Antenna gain (max): 6.57 10.7 dBi Maximum antenna gain: 4.539 11.749 numeric Prediction distance: 20 20 cm Source Based Time Average Duty Cycle: 100 100 % Prediction frequency: 1732.5 782 MHz MPE limit for uncontrolled exposure at prediction frequency: 1.000 0.521 mW/cm 2 Power density at prediction frequency: 0.1857 0.5102 mW/cm 2 Power density at prediction frequency: 1.857 5.102 W/m 2 Margin of Compliance: -7.31 -0.09 dB Sincerely, Ferdie S. Custodio Name Authorized Signatory Title: EMC/Wireless Test Engineer

SPORTON INTERNATIONAL INC. Page Number : 1 of 27 TEL : 886-3-327-3456 Report Issued Date : Nov. 21, 2013 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : RI7LN930 RF Exposure Evaluation Report Report No. : FA391111 RF Exposure Evaluation Report APPLICANT : Telit Communications S.p.A. EQUIPMENT : Data Card BRAND NAME : Telit MODEL NAME : LN930 MARKETING NAME : LN930 FCC ID : RI7LN930 STANDARD : 47 CFR Part 2.1091 We, SPORTON INTERNATIONAL INC., would like to declare that the device has been evaluated in accordance with 47 CFR Part 2.1091, and pass the limit. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. Approved by: Jones Tsai / Manager Reviewed by: Eric Huang / Deputy Manager SPORTON INTERNATIONAL INC. Page Number : 2 of 27 TEL : 886-3-327-3456 Report Issued Date : Nov. 21, 2013 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : RI7LN930 RF Exposure Evaluation Report Report No. : FA391111 Table of Contents 1. ADMINISTRATION DATA ........................................................................................................................... 4 1.1. Testing Laboratory ............................................................................................................................. 4 1.2. Applicant ............................................................................................................................................ 4 1.3. Manufacturer ...................................................................................................................................... 4 2. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ............................................................................. 5 3. RF EXPOSURE LIMIT INTRODUCTION .................................................................................................... 6 4. MAXIMUM RF AVERAGE OUTPUT POWER AMONG PRODUCTION UNITS ........................................ 7 5. CONDUCTED RF OUTPUT POWER (UNIT: DBM) .................................................................................. 14 6. RADIO FREQUENCY RADIATION EXPOSURE EVALUATION ............................................................. 26 SPORTON INTERNATIONAL INC. Page Number : 3 of 27 TEL : 886-3-327-3456 Report Issued Date : Nov. 21, 2013 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : RI7LN930 RF Exposure Evaluation Report Report No. : FA391111 Revision History REPORT NO. VERSION DESCRIPTION ISSUED DATE FA391111 Rev. 01 Initial issue of report Nov. 21, 2013 SPORTON INTERNATIONAL INC. Page Number : 4 of 27 TEL : 886-3-327-3456 Report Issued Date : Nov. 21, 2013 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : RI7LN930 RF Exposure Evaluation Report Report No. : FA391111 1. Administration Data 1.1. Testing Laboratory Test Site SPORTON INTERNATIONAL INC. Test Site Location No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. TEL: +886-3-327-3456 FAX: +886-3-328-4978 1.2. Applicant Company Name Telit Communications S.p.A. Address Viale Stazione di Prosecco 5/b, Trieste Italy 34010 1.3. Manufacturer Company Name Foxconn International Holdings Ltd. Address No. 4, Mingsheng St.,Tu-Cheng Dist., New Taipei City 23679, Taiwan SPORTON INTERNATIONAL INC. Page Number : 5 of 27 TEL : 886-3-327-3456 Report Issued Date : Nov. 21, 2013 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : RI7LN930 RF Exposure Evaluation Report Report No. : FA391111 2. Description of Equipment Under Test (EUT) Product Feature & Specification EUT Type Data Card Brand Name Telit Model Name LN930 Marketing Name LN930 FCC ID RI7LN930 Wireless Technology and Frequency Range GSM850: 824.2 MHz ~ 848.8 MHz GSM1900: 1850.2 MHz ~ 1909.8 MHz WCDMA Band V: 826.4 MHz ~ 846.6 MHz WCDMA Band IV: 1712.4 MHz ~ 1752.6 MHz WCDMA Band II: 1852.4 MHz ~ 1907.6 MHz LTE Band 17: 706.5 MHz ~ 713.5 MHz LTE Band 13: 779.5 MHz ~ 784.5 MHz LTE Band 5: 824.7 MHz ~ 848.3 MHz LTE Band 4: 1710.7 MHz ~ 1754.3 MHz LTE Band 2: 1850.7 MHz ~ 1909.3 MHz LTE Band 7: 2506.5 MHz ~ 2535 MHz and 2553.5 MHz ~ 2570MHz Mode •GPRS/EGPRS •UMTS Rel 99 •HSDPA Rel 7, Cat14 •DC-HSDPA Rel 8, Cat24 •HSUPA Rel 6, Cat6 •LTE: QPSK, 16QAM EUT Stage Production Unit Remark: 1. The above EUT's information was declared by manufacturer. Please refer to the specifications or user's manual for more detailed description. 2. The differences between Sample 1 and Sample 2 are as below : (1) Sample 1：EUT with HW version: PR3.2; SW version: FIH7160_MODEM_01.1326.00 Sample 2：EUT with HW version: PR4.5; SW version: FIH7160_MODEM_01.1338.03 (2) Swap auxiliary and main antenna connectors' location. SPORTON INTERNATIONAL INC. Page Number : 6 of 27 TEL : 886-3-327-3456 Report Issued Date : Nov. 21, 2013 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : RI7LN930 RF Exposure Evaluation Report Report No. : FA391111 3. RF Exposure Limit Introduction The FCC categorizes the RF exposure limit based on the intended usage of the device and the user’s awareness and ability to exercise control over his or her exposure. This is a consumer product to be used in the home, hence this device was evaluated by mobile device with general population/uncontrolled exposure condition. The definition of these category are shown as follows:  Mobile Devices: A mobile device is defined as a transmitting device designed to be used in other than fixed locations and to be generally used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitters' radiating structures and the body of the user or nearby persons. Transmitters designed to be used by consumers or workers that can be easily re-located are considered mobile devices if they meet the 20 centimeter separation requirement. The FCC rules for evaluating mobile devices for RF compliance are fo…

Text truncated - open the document above for the full version.

Test Laboratory: Borsigstrasse 11 Germany 7Layers AG 40880 Ratingen Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7 layers AG Aufsichtsratsvorsitzender  Registergericht registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Peter Mertel USt-IdNr  VAT No.: Phone: +49 (0) 2102 749 0 Vorstand Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H.-J. Meckelburg TAX No. 147/5869/0385 www.7Layers.com Dr. H. Ansorge RF Exposure and Maximum ERP/EIRP Assessment For TOBY‐L200 GSM/UMTS Module FCC ID: XPYTOBYL200 IC: 8595A‐TOBYL200 Assessment Reference: MDE_UBLOX_1408_MPEa Rev 3 Assessment Reference: MDE_UBLOX_1408_MPEa Rev 3 Page 2 of 12 Table of Contents 0 Summary 3 0.1 Technical Report Summary 3 1 Administrative Data 4 1.1 Testing Laboratory 4 1.2 Project Data 4 1.3 Applicant Data 4 1.4 Manufacturer Data 4 2 Test object Data 5 2.1 General EUT Description 5 2.2 EUT Main components 5 2.3 Ancillary Equipment 5 2.4 Auxiliary Equipment 5 2.5 Operating Modes 6 3 Evaluation Results 7 3.1 Maximum ERP / EIRP 7 3.2 RF Exposure Evaluation for Module 8 3.3 RF Exposure Evaluation for multiple transmitters in co-location 10 Assessment Reference: MDE_UBLOX_1408_MPEa Rev 3 Page 4 of 12 1 Administrative Data 1.1 Testing Laboratory Company Name: 7Layers AG Address Borsigstr. 11 40880 Ratingen Germany This facility has been fully described in a report submitted to the FCC and accepted under the registration number 96716. The test facility is also accredited by the following accreditation organisation: Laboratory accreditation no.: DAkkS D‐PL‐12140‐01‐01 Responsible for Accreditation Scope:Dipl.‐Ing. Bernhard Retka Dipl.‐Ing. Robert Machulec Dipl.‐Ing. Andreas Petz Dipl.‐Ing. Marco Kullik Report Template Version: 2014‐05‐15 1.2 Project Data Responsible for assessment and report:Mr. Patrick Lomax Date of Report: 2014‐09‐23 1.3 Applicant Data Company Name: u‐blox AG Address: Zürcherstrasse 68, CH-8800 Thalwil Switzerland Contact Person: Giulio Comar 1.4 Manufacturer Data Company Name: please see applicant data Address: Contact Person: Assessment Reference: MDE_UBLOX_1408_MPEa Rev 3 Page 5 of 12 2 Test object Data 2.1 General EUT Description Equipment under Test TOBY‐L200 Module Type Designation: TOBY‐L200 Kind of Device: GPRS/EDGE MSC GSM/UMTS/LTE DataModule GPRS Multi‐slot class 12 FCC ID: XPYTOBYL200 IC Number: 8595A‐TOBYL200 General product description: The EUT is Cellular radio module supporting GSM/GPRS/WCDMA/HSDPA/HSUPA/LTE 2.2 EUT Main components Type, S/N, Short Descriptions etc. used in this Test Report Short DescriptionEquipment under TestType DesignationSerial No.HW Status SW Status EUT A Code: DE1015003AU12 TOBY‐L200L200352255060018284192BA0 09.41 NOTE: The short description is used to simplify the identification of the EUT in this test report. 2.3 Ancillary Equipment For the purposes of this test report, ancillary equipment is defined as equipment which is used in conjunction with the EUT to provide operational and control features to the EUT. It is necessary to configure the system in a typical fashion, as a customer would normally use it. But nevertheless Ancillary Equipment can influence the test results. Short Description Equipment under Test Type Designation HW StatusSW StatusSerial no. FCC ID N/A ‐ 2.4 Auxiliary Equipment For the purposes of this test report, auxiliary equipment is defined as equipment which is used temporarily to enable operational and control features especially used for the tests of the EUT which is not used during normal operation or equipment that is used during the tests in combination with the EUT but is not subject of this test report. It is necessary to configure the system in a typical fashion, as a customer would normally use it. But nevertheless Auxiliary Equipment can influence the test results. Short Description Equipment under Test Type Designation Serial no.HW StatusSW Status FCC ID N/A – Assessment Reference: MDE_UBLOX_1408_MPEa Rev 3 Page 6 of 12 2.5 Operating Modes This chapter describes the operating modes of the EUTs used for testing. Op. Mode Description of Operating ModesRemarks Op‐mode 1 EUT transmitting in standalone configurationAntenna‐to‐person distance > 20cm Op‐mode 2 EUT transmitting in the 850 MHz Band simultaneously with a generic Bluetooth radio. Antenna‐to‐person distance > 20cm Op‐mode 3 EUT transmitting in the 1900 MHz Band simultaneously with a generic Bluetooth radio. Antenna‐to‐person distance > 20cm Op‐mode 4 EUT transmitting in the 850 MHz Band simultaneously with a generic WLAN radio. Antenna‐to‐person distance > 20cm Op‐mode 5 EUT transmitting in the 1900 MHz Band simultaneously with a generic WLAN radio. Antenna‐to‐person distance > 20cm Op‐mode 6 EUT transmitting in the 850 MHz Band simultaneously with a generic Bluetooth radio and WLAN radio. Antenna‐to‐person distance > 20cm Op‐mode 7 EUT transmitting in the 1900 MHz Band simultaneously with a generic Bluetooth radio and WLAN radio. Antenna‐to‐person distance > 20cm Op‐mode 8 EUT transmitting in the 700 MHz Band simultaneously with a generic Bluetooth radio. Antenna‐to‐person distance > 20cm Op‐mode 9 EUT transmitting in the 700 MHz Band simultaneously with a generic WLAN radio. Antenna‐to‐person distance > 20cm Op‐mode 10 EUT transmitting in the 700 MHz Band simultaneously with a generic Bluetooth radio and WLAN radio. Antenna‐to‐person distance > 20cm Op‐mode 11 EUT transmitting in the 1700 MHz Band simultaneously with a generic Bluetooth radio. Antenna‐to‐person distance > 20cm Op‐mode 12 EUT transmitting in the 1700 MHz Band simultaneously with a generic WLAN radio. Antenna‐to‐person distance > 20cm Op‐mode 13 EUT transmitting in the 1700 MHz Band simultaneously with a generic Bluetooth radio and WLAN radio. Antenna‐to‐person distance > 20cm Op‐mode 14 EUT transmitting in the 2500 MHz …

Text truncated - open the document above for the full version.

Pico 2.4GHz High Speed 1W Module Model: pX2 FCC ID: NS915PX2 Applicant: Microhard Systems Inc. 150 Country Hills Landing NW Calgary, Alberta Canada T3K 5P3 In Accordance With Federal Communications Commission (FCC…

Text truncated - open the document above for the full version.
