NS920N920Tn920T 2020 900MHz OEM Frequency Hopping/DTS Module

Operating Manual n920T 2020 n920T 2020 900MHz OEM Frequency Hopping/DTS Module Revision 0.30, May 29, 2020 Microhard www.microhardcorp.com ii n920T 2020 Operating Manual Warranty Microhard Systems Inc. warrants that each product will be free of defects in material and workmanship for a period of one (1) year for its products. The warranty commences on the date the product is shipped by Microhard Systems Inc. Microhard Systems Inc.’s sole liability and responsibility under this warranty is to repair or replace any product which is returned to it by the Buyer and which Microhard Systems Inc. determines does not conform to the warranty. Product returned to Microhard Systems Inc. for warranty service will be shipped to Microhard Systems Inc. at Buyer’s expense and will be returned to Buyer at Microhard Systems Inc.’s expense. In no event shall Microhard Systems Inc. be responsible under this warranty for any defect which is caused by negligence, misuse or mistreatment of a product or for any unit which has been altered or modified in any way. The warranty of replacement shall terminate with the warranty of the product. Warranty Disclaims Microhard Systems Inc. makes no warranties of any nature of kind, expressed or implied, with respect to the hardware, software, and/or products and hereby disclaims any and all such warranties, including but not limited to warranty of non-infringement, implied warranties of merchantability for a particular purpose, any interruption or loss of the hardware, software, and/or product, any delay in providing the hardware, software, and/or product or correcting any defect in the hardware, software, and/or product, or any other warranty. The Purchaser represents and warrants that Microhard Systems Inc. has not made any such warranties to the Purchaser or its agents MICROHARD SYSTEMS INC. EXPRESS WARRANTY TO BUYER CONSTITUTES MICROHARD SYSTEMS INC. SOLE LIABILITY AND THE BUYER’S SOLE REMEDIES. EXCEPT AS THUS PROVIDED, MICROHARD SYSTEMS INC. DISCLAIMS ALL WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PROMISE. MICROHARD SYSTEMS INC. PRODUCTS ARE NOT DESIGNED OR INTENDED TO BE USED IN ANY LIFE SUPPORT RELATED DEVICE OR SYSTEM RELATED FUNCTIONS NOR AS PART OF ANY OTHER CRITICAL SYSTEM AND ARE GRANTED NO FUNCTIONAL WARRANTY. Indemnification The Purchaser shall indemnify Microhard Systems Inc. and its respective directors, officers, employees, successors and assigns including any subsidiaries, related corporations, or affiliates, shall be released and discharged from any and all manner of action, causes of action, liability, losses, damages, suits, dues, sums of money, expenses (including legal fees), general damages, special damages, including without limitation, claims for personal injuries, death or property damage related to the products sold hereunder, costs and demands of every and any kind and nature whatsoever at law. IN NO EVENT WILL MICROHARD SYSTEMS INC. BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, INCIDENTAL, BUSINESS INTERRUPTION, CATASTROPHIC, PUNITIVE OR OTHER DAMAGES WHICH MAY BE CLAIMED TO ARISE IN CONNECTION WITH THE HARDWARE, REGARDLESS OF THE LEGAL THEORY BEHIND SUCH CLAIMS, WHETHER IN TORT, CONTRACT OR UNDER ANY APPLICABLE STATUTORY OR REGULATORY LAWS, RULES, REGULATIONS, EXECUTIVE OR ADMINISTRATIVE ORDERS OR DECLARATIONS OR OTHERWISE, EVEN IF MICROHARD SYSTEMS INC. HAS BEEN ADVISED OR OTHERWISE HAS KNOWLEDGE OF THE POSSIBILITY OF SUCH DAMAGES AND TAKES NO ACTION TO PREVENT OR MINIMIZE SUCH DAMAGES. IN THE EVENT THAT REGARDLESS OF THE WARRANTY DISCLAIMERS AND HOLD HARMLESS PROVISIONS INCLUDED ABOVE MICROHARD SYSTEMS INC. IS SOMEHOW HELD LIABLE OR RESPONSIBLE FOR ANY DAMAGE OR INJURY, MICROHARD SYSTEMS INC.'S LIABILITY FOR ANYDAMAGES SHALL NOT EXCEED THE PROFIT REALIZED BY MICROHARD SYSTEMS INC. ON THE SALE OR PROVISION OF THE HARDWARE TO THE CUSTOMER. Proprietary Rights The Buyer hereby acknowledges that Microhard Systems Inc. has a proprietary interest and intellectual property rights in the Hardware, Software and/or Products. The Purchaser shall not (i) remove any copyright, trade secret, trademark or other evidence of Microhard Systems Inc.’s ownership or proprietary interest or confidentiality other proprietary notices contained on, or in, the Hardware, Software or Products, (ii) reproduce or modify any Hardware, Software or Products or make any copies thereof, (iii) reverse assemble, reverse engineer or decompile any Software or copy thereof in whole or in part, (iv) sell, transfer or otherwise make available to others the Hardware, Software, or Products or documentation thereof or any copy thereof, except in accordance with this Agreement. iii n920T 2020 Regulatory Requirements - PLEASE READ THIS SECTION CAREFULLY WARNING: To satisfy FCC RF exposure requirements for mobile transmitting devices, a separation distance of 35 cm or more should be maintained between the antenna of this device and persons during device operation. To ensure compliance, operations at closer than this distance is not recommended. The antenna used for this transmitter must not be co-located in conjunction with any other antenna or transmitter. WARNING: Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation. WARNING: Changes or modifications not expressly approved by Microhard Systems Inc. could void the user’s authority to operate the equipment. This device has been tested with UFL to Reverse Polarity SMA connectors with the antennas listed in Appendix A When integrated in OEM products, fixed antennas require installation preventing end-users from replacing them with non-approved antennas. Antennas not listed in the tables must be tested to comply with FCC Section 15.203 (unique antenna connectors) and Section 15.247 (emissions). WARNING: MAXIMU…

Text truncated - open the document above for the full version.

Tel: (403) 248-0028 Fax: (403) 248-2762 E-mail: [email protected] www.microhardcorp.com Leaders in Wireless Telecom Modular Approval Request Applicant: Microhard Systems Inc. FCC ID: NS920N920T May 1 2020 To Whom It May Concern: Pursuant to Section 15.212(a)(1) of the FCC rules, the Applicant, request for single modular approval, compliance with the requirements are addressed below. Single Modular Approval Requirements Justification (i) The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. The modular transmitter has its own RF shielding (ii) The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with part 15 requirements under conditions of excessive data rates or ove r-modulation. The modular transmitter has buffered modulation/data inputs (iii) The modular transmitter must have its own power supply regulation. The modular transmitter has its own analog and digital power supply regulation. (iv) The modular transmitter must comply with the antenna and transmission system requirements of §§ 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a ‘‘unique’’ antenna coupler (at all connections between the module and the antenna, including the cable). The ‘‘professional installation’’ provision of § 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. The radio and its associated antennas are provided with the special coupling antenna connectors (v) The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in § 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see § 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see § 15.31(i)). The modular transmitter was tested in a stand-alone configuration Tel: (403) 248-0028 Fax: (403) 248-2762 E-mail: [email protected] www.microhardcorp.com Leaders in Wireless Telecom (vi) The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: ‘‘Contains Transmitter Module FCC ID: XYZMODEL1’’ or ‘‘Contains FCC ID: XYZMODEL1.’’ Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: ‘‘Contains FCC certified transmitter module(s).’’ Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included in the application for equipment authorization. A Label is attached to the device showing the FCC ID of the device. The manual includes End Device labeling instructions. (vii) The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. End-users must comply with the following instruction sated in the users’ manual: Labeling requirement for equipment using this modular transmitter. RF Exposure Warning for compliance with FCC Rules 2.1091 and 1.1307 when the radio is used in a mobile or base system (viii) The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. The module complies with the requirements for a mobile device. Refer to the RF Exposure test report submitted with this application. The EUT is compliant with all applicable RF exposure requirements. Refer to RF Exposure exhibit. See manual for details and limits. Hany Shenouda Director of Engineering Microhard Systems Inc.

Tel: (403) 248-0028 Fax: (403) 248-2762 E-mail: [email protected] www.microhardcorp.com Leaders in Wireless Telecom May 1 2020 To Whom It May Concern Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: SUBJECT: FCC Application for FCC ID: NS920N920T To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Supplier's Declaration of Conformity (SDoC) procedure pursuant to Part 15, Subpart B - Unintentional Radiators, portion of this composite filing. Sincerely, Hany Shenouda Director of Engineering Microhard Systems Inc.

Tel: (403) 248-0028 Fax: (403) 248-2762 E-mail: [email protected] www.microhardcorp.com Leaders in Wireless Telecom May 27 2020 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. Subject: Attestation to use Original Test Reports in New Filing Applicant: Microhard Systems Inc. FCC ID: NS920N920T IC: 3143A‐20N920T Dear Sir/Madam, We, Microhard Systems Inc., hereby attest to the fact that the transmitter module(s) report(s) listed below, used in support of the co‐location RF exposure evaluation accurately represent test results under the new conditions. The integration of the module in co‐location configurations will adhere to conditions of the original filing. Associated FCC IDAssociated IC IDTest Report Identifiers EM12‐G XMR201901EM12G 10224A‐201901EM12G FA8N2911 L850 ZMOL850GL 21374‐L850GL SA170106C02 SARA‐R410M XPY2AGQN4NNN 8595A‐2AGQN4NNN XPY2AGQN4NNN EG25‐G XMR201903EG25G 10224A‐201903EG25G HR/2019/1001602 Yours truly, Hany Shenouda Director of Engineering Microhard Systems Inc.

Tel: (403) 248-0028 Fax: (403) 248-2762 E-mail: [email protected] www.microhardcorp.com Leaders in Wireless Telecom May 1 2020 To Whom It May Concern Subject: Authority to Act as an Agent Applicant: Microhard Systems Inc. FCC ID: NS920N920T Dear Sir/Madam: I hereby appoint UltraTech Engineering Labs Inc. (UltraTech) to act as my agent in preparation of this application for authorization of above equipment under F.C.C. Rules. The applicant hereby certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a “party” for these purposes. I also certify that the information provided, properly describe the device or system for which authorization is required. Sincerely, Hany Shenouda Director of Engineering Microhard Systems Inc.

Tel: (403) 248-0028 Fax: (403) 248-2762 E-mail: [email protected] www.microhardcorp.com Leaders in Wireless Telecom May 1 2020 To Whom It May Concern Subject: Confidentiality Request Letter Applicant: Microhard Systems Inc. FCC ID: NS920N920T Dear Sir/Madam: The applicant would like to request the following documents submitted with this application for certification be withheld from public disclosure as per Sections 0.457 & 0.459 of FCC Rules. 1. Operational Description 2. Block Diagram 3. Schematic(s) 4. Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Yours truly, Hany Shenouda Director of Engineering Microhard Systems Inc.

Top Bottom

LABEL FORMAT AND LOCATION TOP View 902 to 928 MHz OEM Module n920T IC: 3143A-20N920T FCC ID: NS920N920T Model: n920T 2020 Power: 1W

Top without Shield

Sporton International (Kunshan) Inc. Page Number : 1 of 11 TEL : 86-512-57900158 Report Issued Date : Jan. 30, 2019 FAX : 86-512-57900958 Report Version : Rev. 01 FCC ID : XMR201901EM12G RF Exposure Evaluation Report Report No. : FA8N2911 RF Exposure Evaluation Report APPLICANT : Quectel Wireless Solutions Co., Ltd. EQUIPMENT : LTE-A Cat 12 M.2 Module BRAND NAME : Quectel MODEL NAME : EM12-G FCC ID : XMR201901EM12G STANDARD : 47 CFR Part 2.1091 FCC KDB 447498 D01 v06 We, Sporton International (Kunshan) Inc., would like to declare that the device has been evaluated in accordance with 47 CFR Part 2.1091 and FCC KDB 447498 D01 v06, and pass the limit. Without written approval of Sporton International (Kunshan) Inc., the test report shall not be reproduced except in full. Approved by: Mark Qu / Manager Sporton International (Kunshan) Inc. No. 1098, Pengxi North Road, Kunshan Economic Development Zone, Jiangsu Province 215335, China Sporton International (Kunshan) Inc. Page Number : 2 of 11 TEL : 86-512-57900158 Report Issued Date : Jan. 30, 2019 FAX : 86-512-57900958 Report Version : Rev. 01 FCC ID : XMR201901EM12G RF Exposure Evaluation Report Report No. : FA8N2911 Table of Contents 1. ADMINISTRATION DATA ........................................................................................................................... 4 1.1. Testing Laboratory ............................................................................................................................. 4 2. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ............................................................................. 5 3. MAXIMUM RF AVERAGE OUTPUT POWER AMONG PRODUCTION UNITS ........................................ 6 4. RF EXPOSURE LIMIT INTRODUCTION .................................................................................................... 7 5. RADIO FREQUENCY RADIATION EXPOSURE EVALUATION ............................................................... 8 5.1. Standalone Power Density Calculation ............................................................................................. 8 5.2. Collocated Power Density Calculation ............................................................................................... 9 Sporton International (Kunshan) Inc. Page Number : 3 of 11 TEL : 86-512-57900158 Report Issued Date : Jan. 30, 2019 FAX : 86-512-57900958 Report Version : Rev. 01 FCC ID : XMR201901EM12G RF Exposure Evaluation Report Report No. : FA8N2911 Revision History REPORT NO. VERSION DESCRIPTION ISSUED DATE FA8N2911 Rev. 01 Initial issue of report Jan. 30, 2019 Sporton International (Kunshan) Inc. Page Number : 4 of 11 TEL : 86-512-57900158 Report Issued Date : Jan. 30, 2019 FAX : 86-512-57900958 Report Version : Rev. 01 FCC ID : XMR201901EM12G RF Exposure Evaluation Report Report No. : FA8N2911 1. Administration Data 1.1. Testing Laboratory Testing Laboratory Test Site Sporton International (Kunshan) Inc. Test Site Location No. 1098, Pengxi North Road, Kunshan Economic Development Zone, Jiangsu Province 215335, China TEL : 86-512-57900158 FAX : 86-512-57900958 Applicant Company Name Quectel Wireless Solutions Co., Ltd. Address 7th Floor, Hongye Building, No.1801 Hongmei Road, Xuhui District, Shanghai 200233, China Manufacturer Company Name Quectel Wireless Solutions Co., Ltd. Address 7th Floor, Hongye Building, No.1801 Hongmei Road, Xuhui District, Shanghai 200233, China Sporton International (Kunshan) Inc. Page Number : 5 of 11 TEL : 86-512-57900158 Report Issued Date : Jan. 30, 2019 FAX : 86-512-57900958 Report Version : Rev. 01 FCC ID : XMR201901EM12G RF Exposure Evaluation Report Report No. : FA8N2911 2. Description of Equipment Under Test (EUT) Product Feature & Specification EUT Type LTE-A Cat 12 M.2 Module Brand Name Quectel Model Name EM12-G FCC ID XMR201901EM12G IMEI Code 869710030005957 Wireless Technology and Frequency Range WCDMA Band II: 1852.4 MHz ~ 1907.6 MHz WCDMA Band IV: 1712.4 MHz ~ 1752.6 MHz WCDMA Band V: 826.4 MHz ~ 846.6 MHz LTE Band 2: 1850 MHz ~ 1910 MHz LTE Band 4: 1710 MHz ~ 1755 MHz LTE Band 5: 824 MHz ~ 849 MHz LTE Band 7: 2500 MHz ~ 2570 MHz LTE Band 12: 699 MHz ~ 716 MHz LTE Band 13: 777 MHz ~ 787 MHz LTE Band 14: 788 MHz ~ 798 MHz LTE Band 17: 704 MHz ~ 716 MHz LTE Band 25: 1850 MHz ~ 1915 MHz LTE Band 26: 814 MHz ~ 849 MHz LTE Band 30: 2305 MHz ~ 2315 MHz LTE Band 66: 1710 MHz ~ 1780 MHz LTE Band 38: 2570 MHz ~ 2620 MHz LTE Band 41: 2496 MHz ~ 2690 MHz Mode RMC/AMR 12.2Kbps HSDPA HSUPA DC-HSDPA HSPA+ (16QAM uplink) LTE: QPSK/16QAM/64QAM/256QAM(Downlink only) HW Version R1.0 SW Version EM12GPAR01A08M4G EUT Stage Identical Prototype Remark: The above EUT's information was declared by manufacturer. Please refer to the specifications or user's manual for more detailed description. Sporton International (Kunshan) Inc. Page Number : 6 of 11 TEL : 86-512-57900158 Report Issued Date : Jan. 30, 2019 FAX : 86-512-57900958 Report Version : Rev. 01 FCC ID : XMR201901EM12G RF Exposure Evaluation Report Report No. : FA8N2911 3. Maximum RF average output power among production units <WCDMA/LTE > Mode Maximum Average power(dBm) WCDMA Band II 24.00 Band IV 24.00 Band V 24.00 LTE Band 2 24.50 Band 4 24.50 Band 5 24.50 Band 7 24.50 Band 12 24.50 Band 13 24.50 Band 14 24.50 Band 17 24.50 Band 25 24.50 Band 26 24.50 Band 30 20.50 Band 38 24.50 Band 41 24.50 Band 66 24.50 Sporton International (Kunshan) Inc. Page Number : 7 of 11 TEL : 86-512-57900158 Report Issued Date : Jan. 30, 2019 FAX : 86-512-57900958 Report Version : Rev. 01 FCC ID : XMR201901EM12G RF Exposure Evaluation Report Report No. : FA8N2911 4. RF Exposure Limit Introduction According to ANSI/IEEE C95.1-1992, the criteria listed in Table 1 shall be used to evaluate the environmental impact of human exposure to radio frequency (RF) radiation as specified in §1.1310. The MPE was calculated at 20 cm to show compliance with the power density limit. The following formula was used to calculate the Power Density: 퐒=…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: HR/2019/1001602 Page: 1 of 7 Authorized Signature: Derek Yang Wireless Laboratory Manager Cover PRF Exposure Evaluation Report Application No.: HR/2019/10016 Applicant: Quectel Wireless Solutions Co., Ltd. Address of Applicant: 7th Floor, Hongye Building, No.1801 Hongmei Road, Xuhui District, Shanghai 200233, China Manufacturer: Quectel Wireless Solutions Co., Ltd. Address of Manufacturer: 7th Floor, Hongye Building, No.1801 Hongmei Road, Xuhui District, Shanghai 200233, China Factory: Quectel Wireless Solutions Co., Ltd. Address of Factory: 7th Floor, Hongye Building, No.1801 Hongmei Road, Xuhui District, Shanghai 200233, China EUT Description: LTE Module Model No.: EG25-G, EG25-G MINIPCIE Trade Mark: Quectel FCC ID: XMR201903EG25G Standards: 47 CFR Part 2 47 CFR Part 22 subpart H 47 CFR Part 24 subpart E 47 CFR Part 27 subpart C Date of Receipt: 2019/1/30 Date of Test: 2019/1/31 to 2019/2/28 Date of Issue: 2019/2/28 Test Result: PASS* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: HR/2019/1001602 Page: 2 of 7 1 Version Revision Record Version Chapter Date Modifier Remark 00 2019/2/28 Original Authorized for issue by: 2019/2/28 Mike Hu /Project Engineer 2019/2/28 David Chen /Reviewer Reamark: The difference between EG25-G and EG25-G MIMIPCIE: EG25-G and EG25-G MINIPCIE both are LTE modules(Category: Cat.4). They have the same frequency and use the same chipset and share the same software & hardware design. EG25-G MINIPCIE makes up of EG25-G module and PCIe carrier board.No any other internal changes in EG25-G module. We hereby state that two models are identical in interior structure and components, and just connector interface is different for the marketing requirement. According to the difference above, all the tests were performed on EG25-G, and the data of EG25-G MINIPCIE can refer to EG25-G. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: HR/2019/1001602 Page: 3 of 7 Contents 1 VERSION ................................................................................................................................................................. 2 2 GENERAL INFORMATION .................................................................................................................................. 4 2.1 CLIENT INFORMATION ..................................................................................................................................... 4 2.2 TEST LOCATION .............................................................................................................................................. 4 2.3 TEST FACILITY ................................................................................................................................................. 4 2.4 GENERAL DESCRIPTION OF EUT .................................................................................................................... 5 2.5 TEST MODE ..................................................................................................................................................... 5 3 RF EXPOSURE EVALUATION ........................................................................................................................... 6 3.1 RF EXPOSURE COMPLIANCE REQUIREMENT ................................................................................................. 6 3.1.1 Limits .......................................................................................................................................................... 6 3.1.2 Test Procedure ......................................................................................................................................... 6 3.1.3 EUT RF Exposure Evaluation ................................................................................................................ 7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: HR/2019/1001602 Page: 4 of 7 2 General Information 2.1 Client Information Applicant: Quectel Wireless Solutions Co., Ltd. Address of Applicant: 7th Floor, Hongye Building, No.1801 Hongmei Road, Xuhui District, Shanghai 200233, China Manufacturer: Quectel Wireless Solutions Co., Ltd. Address of Manufacturer: 7th Floor, Hongye Building, No.1801 Hongmei Road, Xuhui District, Shanghai 200233, China Factory: Quectel Wireless Solutions Co., Ltd. Address of Factory: 7th Floor, Hongye Building, No.1801 Hongmei Road, Xuhui District, Shanghai 200233, China 2.2 Test Location Company: SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Address: No. 1 Workshop, M-10, Middle section, Science & Technology Park, Shenzhen, Guangdong, China Post code: 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 E-mail: [email protected] 2.3 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • CNAS (No. CNAS L2929) CNAS has accredited SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch EMC Lab to ISO/IEC 17025:2005 General Requirements for the Competence of Testing and Calibration Laboratories (CNAS-CL01 Accreditation Criteria for the Competence of Testing and Calibration Laboratories) for the competence in the field of testing. • A2LA (Certificate No. 3816.01) SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 3816.01. • VCCI The 3m Fully-anechoic chamber for above 1GHz, 10m Semi-anechoic chamber for below 1GHz, Shielded Room for Mains Port Conducted Interference Measurement and Telecommunication Port Conducted Interference Measurement of SGS-CSTC Standards Technical Services Co., Ltd. have been registered in accordance with the Regulations for Voluntary Control Measures with Re…

Text truncated - open the document above for the full version.

TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 June 02, 2017 TUV SUD BABT Octagon House, Concorde Way Segensworth Rd N, Fareham PO15 5RL Attention: Director of Certification FCC ID: XPY2AGQN4NNN IC: 8595A-2AGQN4NNN RE: Antenna gain calculation per guidance from KDB 447498 D01 Mobile Portable RF Exposure v06 and RSS-102 Issue 5 March 2015. EUT u-blox San Diego, Inc. SARA-R410M LTE Cat-M1 Module Input Power of the Antenna 25.0 dBm / 0.316 mW (LTE Band 2, 4, 5 and 12) Frequency 699.7 MHz (LTE B12) to 1909.3 MHz (LTE B2) FCC Limit (§1.1310 (d)(4)) 4.66467 W/m 2 @ 699.7 MHz 10 W/m 2 @ 1909.3 MHz RSS-102 RF Limits (Table 4) 2.30329 W/m 2 @ 699.7 MHz 4.24313 W/m 2 @ 1710.7 MHz (worst case channel above 1GHz LTE Band 4) User separation distance 20 cm Equation for predicting RF field was used to determine the maximum antenna gain that can be used with the EUT and still comply with the requirements: 푆= 푃퐺 4휋푟 2 Where: S=the power flux P=input power of the antenna G=antenna gain relative to an isotropic antenna r=distance from the antenna to the point of investigation TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 From this formula, using 0.230329 mW/cm 2 as S (worst case than FCC limit), 20 cm as r then the antenna gain G is calculated. This is the maximum antenna gain in dBi that can be used with the EUT while still in compliance with the power density requirements. 퐺= 4휋푟 2 푆 푃 퐺= 4휋 ( 20 푐푚 ) 2 (0.230329 푚푊/푐푚 2 ) 316.0 푚푊 퐺= 1157.76 316.0 푚푊 Therefore G = 3.67 dBi for Band 12 and 4.1 dBi for Band 5 (using the same calculation approach) Using the same calculation for LTE Band 2: 퐺= 4휋 ( 20 푐푚 ) 2 (0.424313 푚푊/푐푚 2 ) 316.0 푚푊 퐺= 2132.83 316.0 푚푊 Therefore G = 6.74 dBi for Band 4 and 7.12 dBi for Band 2 (using the same calculation approach) Sincerely, Ferdie S. Custodio Name Authorized Signatory Title: Senior EMC/Wireless Test Engineer

FCC MPE Evaluation Report Report Format Version 5.0.0 Page No. : 1 of 8 Report No. : SA170106C02 Issued Date : Feb. 21, 2017 FCC MPE Evaluation Report Report No. : SA170106C02 Applicant : Fibocom Wireless Inc. Address : 5/F, Tower A, Technology Building II, 1057 Nanhai Blvd, Nanshan, Shenzhen, China Product : LTE module FCC ID : ZMOL850GL Brand : Fibocom Model No. : L850-GL Standards : FCC Part 2 (Section 2.1091) KDB 447498 D01 Sample Received Date : Jan. 06, 2017 Date of Evaluation : Feb. 20, 2017 CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch – Lin Kou Laboratories, and found …

Text truncated - open the document above for the full version.
