Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
January 2000 APREL Project No.: HYPB-SMARTICE-CDPD-3365 Consulting * Research * Training * Certification Testing Since 1981 Exhibit 9 SmartICE/CDPD Point of Sale Device Hypercom FCC ID: NVA010164-005A User’s Manual SmartICE Hardware and Installation Manual Version 1.0 January 26, 2000 draft Corporate Telephone 602.504.5000 Corporate Fax 602.866.5380 Corporate Website www.hypercom.com Copyright 2000 by Hypercom Corporation. Produced in the United States of America. Hypercom Corporation 2851 West Kathleen Road Phoenix, Arizona 85053 USA Hypercom Corporation 2000. All rights reserved. Hypercom and the Hyprcom logo are registered trademarks of Hypercom Corporation. Hypercom has attempted throughout this publication to distinguish proprietary trademarks from descriptive terms by following the capitalization style used by the manufacturer. This document is proprietary to Hypercom Corporation and is intended solely for use by Hypercom customers. This publication may not be reproduced or distributed for any purpose without the written permission of Hypercom Corporation. NOTICE Hypercom Corporation reserves the right to make changes to the publication at any time and without notice. The information furnished in this publication by Hypercom Corporation is believed to be accurate and reliable; however, Hypercom Corporation assumes no responsibility for its use. Any error in identifying or reflecting any proprietary marks or notices is inadvertent and unintentional. This document applies to the SmartICE Series Terminals. FCC PART 15 REQUIREMENTS NOTICE ß · This device must not be installed on coin-operated telephone lines or party lines. · This device (equipment) complies with the requirements in Part 15 of FCC Rules for a Class B computing device. Operation of this device (equipment) is subject to the following two conditions: - This device (equipment) may not cause harmful interference, and - This device must accept any interference received, including interference that may cause undesired operation. · If this device (equipment) is used in a residential area, it may cause unacceptable interference to radio and TV reception requiring the operator to take whatever steps necessary to correct the interference. · Repair work on this device (equipment) must by done by Hypercom Corporation or an authorized repair station. 940264-001Hypercom Corporationv Table of Contents Introduction Document Organization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii Component Names. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii Procedures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xiv Warning and Caution Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiv Chapter 1 Equipment Information Terminal Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1 Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2 Terminal Connection Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 LAN Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 PIN Pad Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 Power Port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 Contrast Control Dial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 Terminal Modem. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 Terminal Radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 Terminal Power Adaptors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 Transactions and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4 Terminal Initialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4 Terminal Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4 Application Program Changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4 Financial Integrity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5 Fast Response Times . . . . . . . . . . . …
Text truncated - open the document above for the full version.
ICE 4000 Hardware and Installation Manual Version 1.0 May 8, 2000 Corporate Telephone: 602.504.5000 Corporate Fax: 602.866.5380 Corporate Web Site: www.hypercom.com Copyright 2000 by Hypercom Corporation. Produced in the United States of America. Hypercom Corporation 2851 West Kathleen Road Phoenix, Arizona 85053 USA Hypercom Corporation 2000. All rights reserved. Hypercom and the Hyprcom logo are registered trademarks of Hypercom Corporation. Hypercom has attempted throughout this publication to distinguish proprietary trademarks from descriptive terms by following the capitalization style used by the manufacturer. This document is proprietary to Hypercom Corporation and is intended solely for use by Hypercom customers. This publication may not be reproduced or distributed for any purpose without the written permission of Hypercom Corporation. NOTICE Hypercom Corporation reserves the right to make changes to the publication at any time and without notice. The information furnished in this publication by Hypercom Corporation is believed to be accurate and reliable; however, Hypercom Corporation assumes no responsibility for its use. Any error in identifying or reflecting any proprietary marks or notices is inadvertent and unintentional. This document applies to the Hypercom ICE 4000 terminal. n This device must not be installed on coin-operated telephone lines or party lines. n This device (equipment) complies with the requirements in Part 15 of FCC Rules for a Class A computing device. Operation of this device (equipment) is subject to the following two conditions: –This device (equipment) may not cause harmful interference, and –This device must accept any interference received, including interference that may cause undesired operation. n If this device (equipment) is used in a residential area, it may cause unacceptable interference to radio and TV reception requiring the operator to take whatever steps necessary to correct the interference. n Repair work on this device (equipment) must by done by Hypercom Corporation or an authorized repair station. This equipment has been tested and found to comply with the limits for a class B digital devise, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio and or television reception, which can be determined by turning the equipment off and on, the user is encouraged to attempt to correct the interference by one or more of the following measures: n Reorient or relocate the receiving antenna n Increase the separation between the equipment and the receiver n Connect the equipment into an electrical outlet on a circuit different from that to which the receiver is connected n Consult the dealer or an experience radio or television technician for assistance This equipment has been certified to comply within the limits for a Class B computing devise, pursuant to FCC Rules. In order to maintain compliance with FCC regulations, shielded cables must be used with this equipment. Operation with non-approved equipment or unsheilded cable is likely to result in radio and or television interference. The user is cautioned that changes and modifications made to this equipment without the expressed approval of the manufacturer, could void the user’s authority to operate this equipment. WARNING: To comply with FCC RF exposure requirements, the CDPD or Mobitex units must be operated with a minimum separation distance of 3 cm (1-1/8 inches) between its antenna and a person’s body. The user’s hand should not be placed next to the antenna or at locations on the unit where the antenna is connected. A minimum separation distance of 1.5 cm is needed to ensure compliance with FCC RF exposure limits for the hand. FCC PART 15 REQUIREMENTS NOTICE 940265-001Hypercom Corporationv Table of Contents List of Figures Introduction Document Organization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii Chapter 1 Equipment Information Terminal Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1 Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2 ICE 4000 Hardware Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 Transactions and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4 Terminal Initialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4 Terminal Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4 Application Program Changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4 Financial Integrity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5 Fast Response Times . . . . . . . . . . . . . …
Text truncated - open the document above for the full version.
January 2000 APREL Project No.: HYPB-SMARTICE-CDPD-3365 Consulting * Research * Training * Certification Testing Since 1981 Exhibit 1 SmartICE/CDPD Point of Sale Device Hypercom FCC ID: NVA010164-005A Authorization letter Letter requesting Confidentiality Letter from NOVATEL WIRELESS authorizing to use CDPD modem in Hypercom product
January 2000 APREL Project No.: HYPB-SMARTICE-CDPD-3365 Consulting * Research * Training * Certification Testing Since 1981 Exhibit 11 SmartICE/CDPD Point of Sale Device Hypercom FCC ID: NVA010164-005A FCC Part 15, Subpart B DoC letter
January 2000 APREL Project No.: HYPB-SMARTICE-CDPD-3365 Consulting * Research * Training * Certification Testing Since 1981 Table of Contents Point of Sale Device SmartICE with a Novatel NRM-6832 Transmitter CDPD FCC ID: NVA010164-005A Hypercom C C O O V V E E R R L L E E T T T T E E R R Exhibit 1: a. Authorization Letter and, b. Request for confidentiality c. Letter from NOVATEL WIRELESS authorizing to use CDPD modem in Hypercom product Exhibit 2:Engineering Report (Includes Test Set-up Photographs) Exhibit 3: Technical Descriptions and Tune-up Procedure Exhibit 4: FCC ID Label Exhibit 5:Photographs of the Equipment Internal and External Exhibit 6: Block Diagram (Confidential) Exhibit 7: Schematic Diagram (Confidential) Exhibit 8:Parts List (Confidential) Exhibit 9:User’s Manual Exhibit 10:SAR Report (Includes Test Set-up Photographs) Exhibit 11: FCC Part 15, Subpart B, DoC letter
January 2000 APREL Project No.: HYPB-SMARTICE-CDPD-3365 Consulting * Research * Training * Certification Testing Since 1981 Exhibit 5 SmartICE/CDPD Point of Sale Terminal Hypercom FCC ID: NVA010164-005A Photographs of the Equipment Internal External Hypercom Point of Sale Device SmartICE with a Novatel NRM-6832 transmitter CDPD: Front Hypercom Point of Sale Device SmartICE with a Novatel NRM-6832 transmitter CDPD: Front Open Hypercom Point of Sale Device SmartICE with a Novatel NRM-6832 transmitter CDPD: Front Open Hypercom Point of Sale Device SmartICE with a Novatel NRM-6832 transmitter CDPD: Front Open Hypercom Point of Sale Device SmartICE with a Novatel NRM-6832 transmitter CDPD: Front Open, detail, under screen Hypercom Point of Sale Device SmartICE with a Novatel NRM-6832 transmitter CDPD: Front Open, detail, back of screen Hypercom Point of Sale Device SmartICE with a Novatel NRM-6832 transmitter CDPD: Left Profile Hypercom Point of Sale Device SmartICE with a Novatel NRM-6832 transmitter CDPD: Back, battery compartment Hypercom Point of Sale Device SmartICE with a Novatel NRM-6832 transmitter CDPD: Back, battery. Hypercom Point of Sale Device SmartICE with a Novatel NRM-6832 transmitter CDPD: Back Open Hypercom Point of Sale Device SmartICE with a Novatel NRM-6832 transmitter CDPD: Back Open, Board connected to transmitter Hypercom Point of Sale Device SmartICE with a Novatel NRM-6832 transmitter CDPD: Back Open, detail, Board connected to transmitter Hypercom Point of Sale Device SmartICE with a Novatel NRM-6832 transmitter CDPD: Back Open, detail, transmitter
January 2000 APREL Project No.: HYPB-SMARTICE-CDPD-3365 Consulting * Research * Training * Certification Testing Since 1981 Exhibit 4 SmartICE/CDPD Point of Sale Device Hypercom FCC ID: NVA010164-005A FCC ID Label
January 2000 APREL Project No.: HYPB-SMARTICE-CDPD-3365 Consulting * Research * Training * Certification Testing Since 1981 Exhibit 3 SmartICE/CDPD Point of Sale Device Hypercom FCC ID: NVA010164-005A Technical Descriptions and Tune-up Procedure Ref: FCC Parts 2 paragraph 2.983(d) TECHNICAL DESCRIPTION OF THE EQUIPMENT Ref.: FCC Part 2 paragraph 2.983(d) Hypercom Point of Sale Device SmartICE with a Novatel NRM-6832 Transmitter CDPD Tune-up Procedure at Nominal Operating Power: Limiting Power: The unit integrates the Novatel CDPD module which complies with part 22 under FCCID NBZ NRM-6832 which will not allow us to exceed the max allowable limit. Circuitry and Devices for Determining and Stabilizing Frequency Frequency Stabilization: The unit integrates the Novatel CDPD module which complies with part 22 under FCCID NBZ NRM-6832 which has demonstrated a stability of 2.5 ppm. Circuits for Suppression of Spurious Radiation, Limiting of Modulation, and Limiting of Power Suppression of Spurious Radiation: Spurious and harmonic suppression is achieved by proper board layout, power distribution among ground planes and good filtering. We have demonstrated continuous compliance in our factory. Limiting Modulation: The unit integrates the Novatel CDPD module which complies with part 22 under FCCID NBZ NRM-6832 which will not allow us to alter modulation from the GMSK. Technical Description Hypercom Smart ICE Main Power Supply: The main power supply for the Smart ICE consists of an LTC1143 controller IC along with bipolar drivers, FET switches and a Schottky commutation diode. The chip is able to control two (2) buck mode regulators at different output voltages. Both regulators are similar except for the voltage setpoint, only one circuit will be described. An on chip linear regulator supplies chip power with an input voltage of 6 – 16VDC. The regulator senses voltage at the output of the regulator, and current being fed to the load. The voltage is controlled by pulse width modulation of the drive pulses in a constant off time configuration so the frequency of operation varies around 150 kHz. The drive pulses are current boosted by the driver transistors and applied to the gate of a p-channel FET switch. The drain of the FET is tied to the commutating diode and the energy storage inductor. The output of the inductor is tied to a current sense resistor, then to the filter capacitor and out to the powered circuitry. Battery Charger: The battery charger consists of a single chip charger IC (BQ2000) which runs as a current controlled buck mode regulator at a frequency of approximately 120 kHz. The width of the output pulses is controlled to give a constant charge current of 1/3 amp. Once the battery has reached approximately 90% charge the mode is changed to a burst mode holding a constant voltage and the battery is topped off to about 98-100% charge level. The charge can also be stopped by a timer built into the chip or by sensing the battery temperature via a thermistor built in to the battery pack. Magnetic Card Reader: The F/2F Read/Decode IC will recover clock and data signals from an F/2F data stream generated from a magnetic head. The IC will function for data rates from 150 to more than 12,000 bits per second. Display and Display Driver: The system display consists of a 160 x 160 pixel FSTN LCD module, driven by an Epson SED1335 graphic LCD controller IC The SED1335 is driven by the 9.83 MHz system clock. The LCD display is powered by an LT1303 DC/DC converter, which boosts the 5 volt system power up to 22 VDC. The DC/DC converter switches at approximately 150 kHz. The LCD display has an EL backlight. The backlight is driven by a Durel D355A driver IC It produces an AC voltage of approximately 75 Volts RMS at a frequency of approximately 220 Hz. Touchscreen Controller: Technical Description The display’s touchscreen is controlled by a Burr Brown ADS7843. The ADS7843 runs from a 1.2 MHz clock. The ADS7843 samples the touch screen at a rate of 1000 points per second (500 X-Y pairs per second). System FPGA: The system FPGA is a Xilinx Spartan 10XL. It acts as glue logic for the system. It is connected to the 9.8 MHz system clock, which it divides down in to the 1.22 MHz touchscreen controller clock, and also produces the 1.2 kHz, 1.6 kHz, and 2.4kHz clocks to drive the piezo buzzer. System ASIC: The system ASIC performs memory and I/O decoding functions for the Z80 microcontroller. It protects the SRAM from being written to during power up and power down, and contains a 16-bit timer for the Z80’s operating system. It also contains registers that identify the amount of system memory and system clock frequency. It also performs serial to parallel conversion for one track of magnetic card data. System Processor and Memory: The main system processor is a Zilog Z84C15. It is a member of the Z80 family, and runs with a system clock of 9.83 MHz. It can access up to 1.5 MB of static RAM memory plus 128 KB of FLASH memory. RS232 / 485 Communications: The TTL level serial communication ports on the Z80 are converted to RS232 / RS485 levels with an LTC1387 Multiprotocol Tranceiver I.C. with on board charge pump. CDPD Radio: This radio consists of a Radio Module Wireless IP Modem, Expidite 6832,manufactured by Novatel. The module supports asynchronous data rates up to 38.4K and an airlink data rate of 19.2K using Reed Solomon error correction. The transmitter is a class III (0.6Watt) transmitter using Modulation of GMSK. The transmit frequency band is 824 – 849 Mhz and the receive band is 869 to 894 Mhz. The main power supply requires 3.6 Vdc and the RF power amp is also a nominal 3.6 Vdc. The current usage of the module is apx 10 uA in sleep mode and up to 175 mA for the main supply and up to 725 mA for the Power Amp in transmit mode. The Antenna connection is 50 Ohm impedance. Printer: The system prints using a Panasonic EPLZ2050 thermal printer. The printer is controlled by a PIC16C74, which is driven by…
Text truncated - open the document above for the full version.
Certification Report on Specific Absorption Rate (SAR) Experimental Analysis Hypercom SmartIce, Point of Sale Device with Novatel NRM-6832 Expedite Wireless IP Modem 3348 Date: 21 December, 1999 51 Spectrum Way Nepean ON K2R 1E6 Tel: (613) 820-2730 Fax: (613) 820-4161 email: [email protected] This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories. This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories. Page 1 of 25© APREL Project #: HYPB-SmartICE CDPD-3348 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6Fax (613) 820 4161 e-mail: [email protected] This report shall not be reproduced, except in full,without the express written approval of APREL Laboratories. CERTIFICATION REPORT Subject:Specific Absorption Rate (SAR) Experimental Analysis Product:Point of Sale Device with a Novatel NRM 6832 Expedite Wireless IP Modem Model:SmartICE, CDPD Client:Hypercom Address:2851 W. Kathleen Rd. Phoenix, Arizona 85023 Project #:HYPB-SmartICE CDPD-3348 Prepared by:APREL Laboratories 51 Spectrum Way Nepean, Ontario K2R 1E6 Tested by___________________________Date: ________________ Heike Wünschmann, C.E.T. Submitted by____________________________Date: _________________ Dr. Paul G. Cardinal Director, Laboratories Approved by_____________________________Date: _________________ Dr. Jacek J. Wojcik, P. Eng. Page 2 of 25© APREL Project #: HYPB-SmartICE CDPD-3348 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6Fax (613) 820 4161 e-mail: [email protected] This report shall not be reproduced, except in full,without the express written approval of APREL Laboratories. FCC ID:NVA010164-005A Applicant:Hypercom Equipment:Point of Sale Device with a Novatel NRM 6832 Expedite Wireless IP Modem Model:SmartICE, CDPD Standard:FCC 96 –326, Guidelines for Evaluating the Environmental Effects of Radio- Frequency Radiation ENGINEERING SUMMARY This report contains the results of the engineering evaluation performed on a Hypercom SmartICE Point of Sale device with a Novatel NRM 6832 Expedite Wireless IP Modem. The measurements were carried out in accordance with FCC 96-326. The Point of Sale device was evaluated for its maximum nominal power level of 600 mW (27.8 dBm). The SmartICE was tested at high, middle, and low frequencies with the antenna extended and retracted as well as the top, the bottom, and the antenna side of the device. The maximum SAR coinciding with the peak performance RF output power of channel 383 (middle, 836 MHz) for the side position with the antenna retracted. Test data and graphs are presented in this report. Based on the test results and on how the device will be used, it is certified that the product meets the requirements as set forth in the above specifications, for an uncontrolled RF exposure environment for extremities (hand). The manual for this unit will require a warning to keep the side of the device near the base of the antenna (next to the integral printer) at least 6 mm away from any part of the body other than the extremities of either users or bystanders. The results presented in this report related only to the sample tested. Page 3 of 25© APREL Project #: HYPB-SmartICE CDPD-3348 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6Fax (613) 820 4161 e-mail: [email protected] This report shall not be reproduced, except in full,without the express written approval of APREL Laboratories. TABLE OF CONTENTS 1.Introduction........................................................................................................................4 2.Applicable Documents.......................................................................................................4 3.Equipment Under Test.......................................................................................................4 4.Test Equipment..................................................................................................................5 5.Test Methodology..............................................................................................................5 6.Test Results........................................................................................................................6 6.1.Transmitter Characteristics........................................................................................6 6.2.SAR Measurements....................................................................................................7 7.Bystander..........................................................................................................................10 8.Conclusions......................................................................................................................11 Appendix A..............................................................................................................................12 Appendix B..............................................................................................................................19 Appendix C..............................................................................................................................21 Appendix D..............................................................................................................................22 Appendix E...............................................................................................................................25 Page 4 of 25© APREL Project #: HYPB-SmartICE CDPD-3348 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6Fax (613) 820 4161 e-mail: [email protected] This report shall not be reproduced, except in full,without the express written approval of APREL Laboratories. 1. INTRODUCTION Tests were conducted to determine the Specific Absorption Rate (SAR) of a sample of a Hypercom SmartICE Point of Sale device. These tests were conducted at APREL Laboratories’ facility located at 51 Spectrum Way, Nepean, Ontar…
Text truncated - open the document above for the full version.
* Consulting * Research * Training * Certification Testing Since 1981 51 Spectrum Waytel: (613) 820-2730 Nepean, Ontariovisit our Web Pages: www.aprel.comfax: (613) 820-4161 Canada K2R 1E6email: [email protected] 08 May, 2000 Mr. Frank Coperich FCC Application Processing Branch Re:Questions from the FCC FCC ID:NVA010164-005A Correspondence Reference Number:13122 731 Confirmation NumberEA96661 Date of Original E-Mail:03/30/2000 Dear Mr. Coperich: Pursuant to your e-mail to our Jay Sarkar, I am forwarding to you our response to item 1. Item 2 has been addressed by an update to the warning in the product’s manual. The relevant portions of the FCC’s e-mail follow with our response inserted in the appropriate place: > -----Original Message----- > To:Jay Sarkar, [email protected] > From:Frank Coperich,[email protected] > FCC Application Processing Branch > > Re:FCC ID NVA010164-005A > Applicant:Hypercom Corporation > Correspondence Reference Number:13122 > 731 Confirmation Number:EA96661 > Date of Original E-Mail:03/30/2000 > > > 1. This is a Point of Sales handheld terminal. They did SAR > at extreme conditions and extrapolate back to determine a > minimum separation distance for satisfying SAR compliance. A > minimum separation distance of 0.5 cm for the hand and 1.1 cm > for the body were determined in the SAR report. The manual > indicated a 3 cm separation but the SAR report recommends 6 > mm, please confirm 3 cm is the final number used for the > separation distance. Testing was performed on two versions of this unit, the CDPD version referenced here, and the Mobitex version (FCC ID NVA010164-004, 731 Confirmation Number EA96756). The largest separation for compliance was determined for the Mobitex unit and to be conservative, rounded up to 3cm. Since the same manual is being used for both products the more severe * Consulting * Research * Training * Certification Testing Since 1981 51 Spectrum Waytel: (613) 820-2730 Nepean, Ontariovisit our Web Pages: www.aprel.comfax: (613) 820-4161 Canada K2R 1E6email: [email protected] restriction determined for the Mobitex version will be applied to both versions, and will be used in the Warning (see below). > 2. The proposed warning statement is unclear - "put the side > of the terminal near the antenna and above the credit card > slot less than 3 cm from .....". The 6-minute time averaging > factor is only applicable to controlled exposure environment, > it does not apply to this device. Please revise accordingly > and re-submit relevant pages of the manual; suggestion - > "WARNING: To comply with FCC RF exposure requirements, this > unit must be operated with a minimum separation distance of 3 > cm (1-1/8 inches) between its antenna and a p…
Text truncated - open the document above for the full version.
2851 West Kathleen Road · Phoenix, Arizona · United States
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 1 | 22.901(d) | 824.04 MHz - 849 MHz | 230.00 mW | 28K8FXW | 2.5000000000 ppm |
