Page 1 of 14 Report No.: AiTSZ-250917061FW3 Note: This device has been tested and found to comply with the standard(s) listed, this test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. This report shall not be reproduced except in full, without the written approval of Guangdong Asia Hongke Test Technology Limited. If there is a need to alter or revise this document, the right belongs to Guangdong Asia Hongke Test Technology Limited, and it should give a prior written notice of the revision document. This test report must not be used by the client to claim product endorsement. Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. RF Exposure evaluation Product Name:AX3000 WIFI6 Mesh Router Brand Name:N/A Model: WS-WN588HX3 Series Model: WS-WN589HX3, WS-WN573HP3, WS-WN553X1, WL- WN588HX3, WS-WN589HX3, WL-WN573HP3, WL-WN553X1, AERIAL HD9S FCC ID:NZ3-WN0009 Applicant:Winstars Technology Limited Address: 1-5F, NO.5, Taisong Industrial Zone, Dalang Community, Dalang Street, Longhua District, Shenzhen, China Manufacturer:Winstars Technology Limited Address: 1-5F, NO.5, Taisong Industrial Zone, Dalang Community, Dalang Street, Longhua District, Shenzhen, China Standard(s): 47CFR §1.1310, 47CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 Date of Receipt:Sep. 17, 2025 Date of Test:Sep. 18, 2025~ Oct. 24, 2025 Issued Date:Oct. 25, 2025 Issued By: Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Tel.: +86 0755-230967639 Fax.: +86 0755-230967639 Reviewed by: Approved by: Aalen.Ye Allen Wang Page 2 of 14 Report No.: AiTSZ-250917061FW3 Report Revise Record Report VersionIssued DateNotes M0Oct. 25, 2025Initial Release Page 3 of 14 Report No.: AiTSZ-250917061FW3 Contents 1GENERAL INFORMATION........................................................................................................................................4 1.1ENVIRONMENTAL CONDITIONS........................................................................................................................................4 1.2GENERAL DESCRIPTION OF EUT......................................................................................................................................4 1.3TEST FACILITY..............................................................................................................................................................6 1.4MEASUREMENT UNCERTAINTY........................................................................................................................................6 2METHOD OF MEASUREMENT..................................................................................................................................7 2.1APPLICABLE STANDARD.................................................................................................................................................7 2.2LIMIT.........................................................................................................................................................................7 2.3MPE CALCULATION METHOD........................................................................................................................................8 2.4ANTENNA INFORMATION...............................................................................................................................................8 2.5MANUFACTURING TOLERANCE.......................................................................................................................................8 2.6MPE RESULT............................................................................................................................................................12 2.7CONCLUSION.............................................................................................................................................................16 Page 4 of 14 Report No.: AiTSZ-250917061FW3 1GENERAL INFORMATION 1.1Environmental conditions During the measurement the environmental conditions were within the listed ranges: Normal Temperature:25°C Relative Humidity:55 % Air Pressure:101 kPa 1.2General Description of EUT Product Name:AX3000 WIFI6 Mesh Router Model/Type reference:WS-WN588HX3 Serial Model: WS-WN589HX3, WS-WN573HP3, WS-WN553X1, WL-WN588HX3, WS-WN589HX3, WL-WN573HP3, WL-WN553X1, AERIAL HD9S Model difference: PCB board, circuit, structure and internal of these model(s) are the same, only model name and appearance color is different for these model. Power Rating:DC 54.0V from adapter Adapter information: Model: TDX18-5400300E Input: 100-240V~ 50/60Hz 0.6A Output: 54.0V⎓0.3A 16.2 Hardware Version:WS-WN588HX3-B Software Version:M88HX3_V250625 Sample(s) Status: AiTSZ-250917061-1(Normal sample) AiTSZ-250917061-2(Engineer sample) 2.4G WIFI: Supported type: 802.11b/g/n(H20)/n(H40)/ax(HE20)/ax(HE40) Modulation: 802.11b: DSSS (CCK, DQPSK, DBPSK) 802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) 802.11ax: OFDMA (1024QAM, 256QAM, 64QAM, 16QAM, QPSK, BPSK) Operation frequency: 802.11b/g/n(H20)/ax(HE20): 2412MHz~2472MHz 802.11n(H40)/ax(HE40):2422MHz~2462MHz Channel number: 802.11b/g/n(H20)/ax(HE20): 11 802.11n(H40)/ax(HE40):7 Channel separation: 5MHz Antenna type: External Antenna MIMO 2*2 Antenna gain: Antenna 1:6.68dBi, Antenna 2: 6.68dBi Directional gain:9.69dBi 5G WIFI: 20MHz system 40MHz system 80MHz system 160MHz system Supported type: 802.11a 802.11n 802.11ac 802.11ax 802.11n 802.11ac 802.11ax 802.11ac 802.11ax N/A Page 5 of 14 Report No.: AiTSZ-250917061FW3 Operation frequency: 5180-5240MHz 5745-5825MHz 5190-5230MHz 5755-5795MHz 5210MHz 5775MHz N/A Modulation: OFDM/OFDMAOFDM/OFDMAOFD…

Text truncated - open the document above for the full version.

Page 1 of 1 FCC ID: NZ3-WN0009

Page 73 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT20)_LCH_5745MHz_MIMO_NTNV 802.11n(HT20)_MCH_5785MHz_Ant1_NTNV Page 74 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT20)_MCH_5785MHz_Ant2_NTNV 802.11n(HT20)_MCH_5785MHz_Ant3_NTNV Page 75 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT20)_MCH_5785MHz_MIMO_NTNV 802.11n(HT20)_HCH_5825MHz_Ant1_NTNV Page 76 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT20)_HCH_5825MHz_Ant2_NTNV 802.11n(HT20)_HCH_5825MHz_Ant3_NTNV Page 77 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT20)_HCH_5825MHz_MIMO_NTNV 802.11n(HT40)_LCH_5755MHz_Ant1_NTNV Page 78 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT40)_LCH_5755MHz_Ant2_NTNV 802.11n(HT40)_LCH_5755MHz_Ant3_NTNV Page 79 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT40)_LCH_5755MHz_MIMO_NTNV 802.11n(HT40)_HCH_5795MHz_Ant1_NTNV Page 80 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT40)_HCH_5795MHz_Ant2_NTNV 802.11n(HT40)_HCH_5795MHz_Ant3_NTNV Page 81 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT40)_HCH_5795MHz_MIMO_NTNV 802.11ac(VHT20)_LCH_5745MHz_Ant1_NTNV Page 82 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT20)_LCH_5745MHz_Ant2_NTNV 802.11ac(VHT20)_LCH_5745MHz_Ant3_NTNV Page 83 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT20)_LCH_5745MHz_MIMO_NTNV 802.11ac(VHT20)_MCH_5785MHz_Ant1_NTNV Page 84 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT20)_MCH_5785MHz_Ant2_NTNV 802.11ac(VHT20)_MCH_5785MHz_Ant3_NTNV Page 85 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT20)_MCH_5785MHz_MIMO_NTNV 802.11ac(VHT20)_HCH_5825MHz_Ant1_NTNV Page 86 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT20)_HCH_5825MHz_Ant2_NTNV 802.11ac(VHT20)_HCH_5825MHz_Ant3_NTNV Page 87 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT20)_HCH_5825MHz_MIMO_NTNV 802.11ac(VHT40)_LCH_5755MHz_Ant1_NTNV Page 88 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT40)_LCH_5755MHz_Ant2_NTNV 802.11ac(VHT40)_LCH_5755MHz_Ant3_NTNV Page 89 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT40)_LCH_5755MHz_MIMO_NTNV 802.11ac(VHT40)_HCH_5795MHz_Ant1_NTNV Page 90 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT40)_HCH_5795MHz_Ant2_NTNV 802.11ac(VHT40)_HCH_5795MHz_Ant3_NTNV Page 91 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT40)_HCH_5795MHz_MIMO_NTNV 802.11ac(VHT80)_MCH_5775MHz_Ant1_NTNV Page 92 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT80)_MCH_5775MHz_Ant2_NTNV 802.11ac(VHT80)_MCH_5775MHz_Ant3_NTNV Page 93 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT80)_MCH_5775MHz_MIMO_NTNV 802.11ax(HEW20)_LCH_5745MHz_SU_ / _Ant1_NTNV Page 94 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW20)_LCH_5745MHz_SU_ / _Ant2_NTNV 802.11ax(HEW20)_LCH_5745MHz_SU_ / _Ant3_NTNV Page 95 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW20)_LCH_5745MHz_SU_ / _MIMO_NTNV 802.11ax(HEW20)_MCH_5785MHz_SU_ / _Ant1_NTNV Page 96 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW20)_MCH_5785MHz_SU_ / _Ant2_NTNV 802.11ax(HEW20)_MCH_5785MHz_SU_ / _Ant3_NTNV Page 97 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW20)_MCH_5785MHz_SU_ / _MIMO_NTNV 802.11ax(HEW20)_HCH_5825MHz_SU_ / _Ant1_NTNV Page 98 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW20)_HCH_5825MHz_SU_ / _Ant2_NTNV 802.11ax(HEW20)_HCH_5825MHz_SU_ / _Ant3_NTNV Page 99 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW20)_HCH_5825MHz_SU_ / _MIMO_NTNV 802.11ax(HEW40)_LCH_5755MHz_SU_ / _Ant1_NTNV Page 100 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW40)_LCH_5755MHz_SU_ / _Ant2_NTNV 802.11ax(HEW40)_LCH_5755MHz_SU_ / _Ant3_NTNV Page 101 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW40)_LCH_5755MHz_SU_ / _MIMO_NTNV 802.11ax(HEW40)_HCH_5795MHz_SU_ / _Ant1_NTNV Page 102 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW40)_HCH_5795MHz_SU_ / _Ant2_NTNV 802.11ax(HEW40)_HCH_5795MHz_SU_ / _Ant3_NTNV Page 103 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW40)_HCH_5795MHz_SU_ / _MIMO_NTNV 802.11ax(HEW80)_MCH_5775MHz_SU_ / _Ant1_NTNV Page 104 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW80)_MCH_5775MHz_SU_ / _Ant2_NTNV 802.11ax(HEW80)_MCH_5775MHz_SU_ / _Ant3_NTNV Page 105 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW80)_MCH_5775MHz_SU_ / _MIMO_NTNV Page 106 of 107 Report No.: AiTSZ-250917061FW2 5. Frequency Stability 5.1 Test Result 5.1.1 Ant1 Ant1 Mode TX Type Frequency (MHz) Temperature (°C) Voltage (VAC) Measured Frequency (MHz) Limit (MHz) Verdict Carrier Wave SISO 5745 20 102 5745.017 5725 to 5850 Pass 120 5745.016 5725 to 5850 Pass 138 5745.015 5725 to 5850 Pass -30 120 5745.014 5725 to 5850 Pass -20 120 5745.014 5725 to 5850 Pass -10 120 5745.013 5725 to 5850 Pass 0 120 5745.013 5725 to 5850 Pass 10 120 5745.012 5725 to 5850 Pass 30 120 5745.012 5725 to 5850 Pass 40 120 5745.011 5725 to 5850 Pass 50 120 5745.011 5725 to 5850 Pass 5785 20 102 5785.008 5725 to 5850 Pass 120 5785.008 5725 to 5850 Pass 138 5785.007 5725 to 5850 Pass -30 120 5785.007 5725 to 5850 Pass -20 120 5785.007 5725 to 5850 Pass -10 120 5785.007 5725 to 5850 Pass 0 120 5785.006 5725 to 5850 Pass 10 120 5785.006 5725 to 5850 Pass 30 120 5785.006 5725 to 5850 Pass 40 120 5785.006 5725 to 5850 Pass 50 120 5785.006 5725 to 5850 Pass 5825 20 102 5825.006 5725 to 5850 Pass 120 5825.006 5725 to 5850 Pass 138 5825.005 5725 to 5850 Pass -30 120 5825.005 5725 to 5850 Pass -20 120 5825.005 5725 to 5850 Pass -10 120 5825.005 5725 to 5850 Pass 0 120 5825.005 5725 to 5850 Pass 10 120 5825.004 5725 to 5850 Pass 30 120 5825.004 5725 to 5850 Pass 40 120 5825.004 5725 to 5850 Pass 50 120 5825.004 5725 to 5850 Pass MIMO 5755 20 102 5755.006 5725 to 5850 Pass 120 5755.005 5725 to 5850 Pass 138 5755.005 5725 to 5850 Pass -30 120 5755.004 5725 to 5850 Pass -20 120 5755.004 5725 to 5850 Pass -10 120 5755.004 5725 to 5850 Pass 0 120 5755.004 5725 to 5850 Pass 10 120 5755.004 5725 to 5850 Pass 30 120 5755.004 5725 to 5850 Pass 40 120 5755.003 5725 to 5850 Pass 50 120 5755.003 5725 to 5850 Pass 5795 20 102 5795.019 5725 to 5850 Pass 120 5795.017 5725 to 5850 Pass Page 107 of 107 Report No.: AiTSZ-250917061FW2 138 5795.016 5725 to 5850…

Text truncated - open the document above for the full version.

Page 36 of 107 Report No.: AiTSZ-250917061FW2 3.2 Test Graph 3.2.1 Power 802.11a_LCH_5745MHz_Ant1_NTNV 802.11a_LCH_5745MHz_Ant2_NTNV Page 37 of 107 Report No.: AiTSZ-250917061FW2 802.11a_LCH_5745MHz_Ant3_NTNV 802.11a_MCH_5785MHz_Ant1_NTNV Page 38 of 107 Report No.: AiTSZ-250917061FW2 802.11a_MCH_5785MHz_Ant2_NTNV 802.11a_MCH_5785MHz_Ant3_NTNV Page 39 of 107 Report No.: AiTSZ-250917061FW2 802.11a_HCH_5825MHz_Ant1_NTNV 802.11a_HCH_5825MHz_Ant2_NTNV Page 40 of 107 Report No.: AiTSZ-250917061FW2 802.11a_HCH_5825MHz_Ant3_NTNV 802.11n(HT20)_LCH_5745MHz_Ant1_NTNV Page 41 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT20)_LCH_5745MHz_Ant2_NTNV 802.11n(HT20)_LCH_5745MHz_Ant3_NTNV Page 42 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT20)_MCH_5785MHz_Ant1_NTNV 802.11n(HT20)_MCH_5785MHz_Ant2_NTNV Page 43 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT20)_MCH_5785MHz_Ant3_NTNV 802.11n(HT20)_HCH_5825MHz_Ant1_NTNV Page 44 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT20)_HCH_5825MHz_Ant2_NTNV 802.11n(HT20)_HCH_5825MHz_Ant3_NTNV Page 45 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT40)_LCH_5755MHz_Ant1_NTNV 802.11n(HT40)_LCH_5755MHz_Ant2_NTNV Page 46 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT40)_LCH_5755MHz_Ant3_NTNV 802.11n(HT40)_HCH_5795MHz_Ant1_NTNV Page 47 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT40)_HCH_5795MHz_Ant2_NTNV 802.11n(HT40)_HCH_5795MHz_Ant3_NTNV Page 48 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT20)_LCH_5745MHz_Ant1_NTNV 802.11ac(VHT20)_LCH_5745MHz_Ant2_NTNV Page 49 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT20)_LCH_5745MHz_Ant3_NTNV 802.11ac(VHT20)_MCH_5785MHz_Ant1_NTNV Page 50 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT20)_MCH_5785MHz_Ant2_NTNV 802.11ac(VHT20)_MCH_5785MHz_Ant3_NTNV Page 51 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT20)_HCH_5825MHz_Ant1_NTNV 802.11ac(VHT20)_HCH_5825MHz_Ant2_NTNV Page 52 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT20)_HCH_5825MHz_Ant3_NTNV 802.11ac(VHT40)_LCH_5755MHz_Ant1_NTNV Page 53 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT40)_LCH_5755MHz_Ant2_NTNV 802.11ac(VHT40)_LCH_5755MHz_Ant3_NTNV Page 54 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT40)_HCH_5795MHz_Ant1_NTNV 802.11ac(VHT40)_HCH_5795MHz_Ant2_NTNV Page 55 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT40)_HCH_5795MHz_Ant3_NTNV 802.11ac(VHT80)_MCH_5775MHz_Ant1_NTNV Page 56 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT80)_MCH_5775MHz_Ant2_NTNV 802.11ac(VHT80)_MCH_5775MHz_Ant3_NTNV Page 57 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW20)_LCH_5745MHz_SU_ / _Ant1_NTNV 802.11ax(HEW20)_LCH_5745MHz_SU_ / _Ant2_NTNV Page 58 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW20)_LCH_5745MHz_SU_ / _Ant3_NTNV 802.11ax(HEW20)_MCH_5785MHz_SU_ / _Ant1_NTNV Page 59 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW20)_MCH_5785MHz_SU_ / _Ant2_NTNV 802.11ax(HEW20)_MCH_5785MHz_SU_ / _Ant3_NTNV Page 60 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW20)_HCH_5825MHz_SU_ / _Ant1_NTNV 802.11ax(HEW20)_HCH_5825MHz_SU_ / _Ant2_NTNV Page 61 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW20)_HCH_5825MHz_SU_ / _Ant3_NTNV 802.11ax(HEW40)_LCH_5755MHz_SU_ / _Ant1_NTNV Page 62 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW40)_LCH_5755MHz_SU_ / _Ant2_NTNV 802.11ax(HEW40)_LCH_5755MHz_SU_ / _Ant3_NTNV Page 63 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW40)_HCH_5795MHz_SU_ / _Ant1_NTNV 802.11ax(HEW40)_HCH_5795MHz_SU_ / _Ant2_NTNV Page 64 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW40)_HCH_5795MHz_SU_ / _Ant3_NTNV 802.11ax(HEW80)_MCH_5775MHz_SU_ / _Ant1_NTNV Page 65 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW80)_MCH_5775MHz_SU_ / _Ant2_NTNV 802.11ax(HEW80)_MCH_5775MHz_SU_ / _Ant3_NTNV Page 66 of 107 Report No.: AiTSZ-250917061FW2 4. Maximum Power Spectral Density 4.1 Test Result 4.1.1 PSD-Band3 Mode TX Type Frequency (MHz) RU RU Pos Maximum PSD (dBm/500kHz) Verdict ANT1 ANT2 ANT3 MIMO Limit 802.11a SISO 5745 / / -3.37 -2.27 -3.63 / <=29.17 Pass 5785 / / -3.68 -2.03 -3.92 / <=29.17 Pass 5825 / / -5.68 -3.52 -5.56 / <=29.17 Pass 802.11n (HT20) MIMO 5745 / / -5.82 -5.40 -6.04 -1.23 <=24.4 Pass 5785 / / -6.22 -4.28 -6.11 -0.89 <=24.4 Pass 5825 / / -7.77 -5.97 -7.90 -2.67 <=24.4 Pass 802.11n (HT40) MIMO 5755 / / -8.08 -7.71 -8.12 -3.42 <=24.4 Pass 5795 / / -8.58 -7.23 -8.66 -3.52 <=24.4 Pass 802.11ac (VHT20) MIMO 5745 / / -5.71 -5.21 -5.69 -1.07 <=24.4 Pass 5785 / / -5.92 -4.88 -5.34 -0.67 <=24.4 Pass 5825 / / -7.26 -6.33 -7.45 -2.46 <=24.4 Pass 802.11ac (VHT40) MIMO 5755 / / -7.32 -6.74 -7.83 -2.72 <=24.4 Pass 5795 / / -7.76 -7.42 -7.86 -3.10 <=24.4 Pass 802.11ac (VHT80) MIMO 5775 / / -9.02 -8.01 -9.37 -4.43 <=24.4 Pass 802.11ax (HEW20) MIMO 5745 SU / -3.64 -4.05 -3.86 0.61 <=24.4 Pass 5785 SU / -3.99 -3.44 -4.29 0.76 <=24.4 Pass 5825 SU / -5.45 -4.75 -5.70 -0.80 <=24.4 Pass 802.11ax (HEW40) MIMO 5755 SU / -6.74 -6.48 -7.45 -2.20 <=24.4 Pass 5795 SU / -5.84 -5.22 -5.51 -0.97 <=24.4 Pass 802.11ax (HEW80) MIMO 5775 SU / -8.36 -8.37 -8.49 -3.98 <=24.4 Pass Note1: Antenna Gain: Ant1: 6.83dBi; Ant2: 6.83dBi; Ant3: 6.83dBi; Note2: Directional Gain: Band3: 11.6dBi Page 67 of 107 Report No.: AiTSZ-250917061FW2 4.2 Test Graph 4.2.1 PSD-Band3 802.11a_LCH_5745MHz_Ant1_NTNV 802.11a_LCH_5745MHz_Ant2_NTNV Page 68 of 107 Report No.: AiTSZ-250917061FW2 802.11a_LCH_5745MHz_Ant3_NTNV 802.11a_MCH_5785MHz_Ant1_NTNV Page 69 of 107 Report No.: AiTSZ-250917061FW2 802.11a_MCH_5785MHz_Ant2_NTNV 802.11a_MCH_5785MHz_Ant3_NTNV Page 70 of 107 Report No.: AiTSZ-250917061FW2 802.11a_HCH_5825MHz_Ant1_NTNV 802.11a_HCH_5825MHz_Ant2_NTNV Page 71 of 107 Report No.: AiTSZ-250917061FW2 802.11a_HCH_5825MHz_Ant3_NTNV 802.11n(HT20)_LCH_5745MHz_Ant1_NTNV Page 72 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT20)_LCH_5745MHz_Ant2_NTNV 802.11n(HT20)_LCH_5745MHz_Ant3_NTNV

Page 1 of 107 Report No.: AiTSZ-250917061FW2 Appendix RF test data for 5G WIFI_UNII_Band 3 Page 2 of 107 Report No.: AiTSZ-250917061FW2 1. Duty Cycle 1.1 Test Result 1.1.1 Ant1 Ant1 Mode TX Type Frequency (MHz) RU RU Pos T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) Max. DC Variation (%) 802.11a SISO 5745 / / 1.397 1.605 87.04 0.60 0.03 5785 / / 1.398 1.606 87.05 0.60 0.03 5825 / / 1.398 1.606 87.05 0.60 0.06 802.11n (HT20) MIMO 5745 / / 1.309 1.517 86.29 0.64 0.07 5785 / / 1.309 1.517 86.29 0.64 0.03 5825 / / 1.309 1.517 86.29 0.64 0.03 802.11n (HT40) MIMO 5755 / / 0.649 0.856 75.82 1.20 0.04 5795 / / 0.650 0.857 75.85 1.20 0.03 802.11ac (VHT20) MIMO 5745 / / 0.481 0.689 69.81 1.56 0.03 5785 / / 0.481 0.689 69.81 1.56 0.03 5825 / / 0.481 0.689 69.81 1.56 0.00 802.11ac (VHT40) MIMO 5755 / / 0.260 0.469 55.44 2.56 0.07 5795 / / 0.267 0.469 56.93 2.45 0.09 802.11ac (VHT80) MIMO 5775 / / 0.149 0.357 41.74 3.79 0.04 802.11ax (HEW20) MIMO 5745 SU / 0.429 0.638 67.24 1.72 0.03 5785 SU / 0.430 0.638 67.40 1.71 0.03 5825 SU / 0.429 0.638 67.24 1.72 0.05 802.11ax (HEW40) MIMO 5755 SU / 0.270 0.479 56.37 2.49 0.08 5795 SU / 0.269 0.479 56.16 2.51 0.09 802.11ax (HEW80) MIMO 5775 SU / 0.184 0.394 46.70 3.31 0.03 Note:All antennas were test and recorded worst result of Ant 1. Page 3 of 107 Report No.: AiTSZ-250917061FW2 1.2 Test Graph 1.2.1 Ant1 802.11a_LCH_5745MHz_Ant1_NTNV 802.11a_MCH_5785MHz_Ant1_NTNV Page 4 of 107 Report No.: AiTSZ-250917061FW2 802.11a_HCH_5825MHz_Ant1_NTNV 802.11n(HT20)_LCH_5745MHz_Ant1_NTNV Page 5 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT20)_MCH_5785MHz_Ant1_NTNV 802.11n(HT20)_HCH_5825MHz_Ant1_NTNV Page 6 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT40)_LCH_5755MHz_Ant1_NTNV 802.11n(HT40)_HCH_5795MHz_Ant1_NTNV Page 7 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT20)_LCH_5745MHz_Ant1_NTNV 802.11ac(VHT20)_MCH_5785MHz_Ant1_NTNV Page 8 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT20)_HCH_5825MHz_Ant1_NTNV 802.11ac(VHT40)_LCH_5755MHz_Ant1_NTNV Page 9 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT40)_HCH_5795MHz_Ant1_NTNV 802.11ac(VHT80)_MCH_5775MHz_Ant1_NTNV Page 10 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW20)_LCH_5745MHz_SU_ / _Ant1_NTNV 802.11ax(HEW20)_MCH_5785MHz_SU_ / _Ant1_NTNV Page 11 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW20)_HCH_5825MHz_SU_ / _Ant1_NTNV 802.11ax(HEW40)_LCH_5755MHz_SU_ / _Ant1_NTNV Page 12 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW40)_HCH_5795MHz_SU_ / _Ant1_NTNV 802.11ax(HEW80)_MCH_5775MHz_SU_ / _Ant1_NTNV Page 13 of 107 Report No.: AiTSZ-250917061FW2 2. Bandwidth 2.1 Test Result 2.1.1 OBW Mode TX Type Frequency (MHz) RU RU Pos ANT 99% Occupied Bandwidth (MHz) Verdict Result Limit 802.11a SISO 5745 / / 1 16.970 / Pass 5785 / / 1 16.965 / Pass 5825 / / 1 17.097 / Pass 802.11n (HT20) MIMO 5745 / / 1 18.132 / Pass 5785 / / 1 18.009 / Pass 5825 / / 1 18.202 / Pass 802.11n (HT40) MIMO 5755 / / 1 36.068 / Pass 5795 / / 1 35.963 / Pass 802.11ac (VHT20) MIMO 5745 / / 1 18.121 / Pass 5785 / / 1 18.063 / Pass 5825 / / 1 18.090 / Pass 802.11ac (VHT40) MIMO 5755 / / 1 36.214 / Pass 5795 / / 1 36.023 / Pass 802.11ac (VHT80) MIMO 5775 / / 1 74.678 / Pass 802.11ax (HEW20) MIMO 5745 SU / 1 19.023 / Pass 5785 SU / 1 18.975 / Pass 5825 SU / 1 19.070 / Pass 802.11ax (HEW40) MIMO 5755 SU / 1 37.619 / Pass 5795 SU / 1 37.364 / Pass 802.11ax (HEW80) MIMO 5775 SU / 1 76.168 / Pass Note:All antennas were test and recorded worst result of Ant 1. 2.1.2 6dB BW Mode TX Type Frequency (MHz) RU RU Pos ANT 6dB Bandwidth (MHz) Verdict Result Limit 802.11a SISO 5745 / / 1 13.190 >=0.5 Pass 5785 / / 1 14.441 >=0.5 Pass 5825 / / 1 15.710 >=0.5 Pass 802.11n (HT20) MIMO 5745 / / 1 15.352 >=0.5 Pass 5785 / / 1 15.191 >=0.5 Pass 5825 / / 1 15.734 >=0.5 Pass 802.11n (HT40) MIMO 5755 / / 1 32.584 >=0.5 Pass 5795 / / 1 33.870 >=0.5 Pass 802.11ac (VHT20) MIMO 5745 / / 1 15.153 >=0.5 Pass 5785 / / 1 15.137 >=0.5 Pass 5825 / / 1 15.051 >=0.5 Pass 802.11ac (VHT40) MIMO 5755 / / 1 32.608 >=0.5 Pass 5795 / / 1 35.074 >=0.5 Pass 802.11ac (VHT80) MIMO 5775 / / 1 70.059 >=0.5 Pass 802.11ax (HEW20) MIMO 5745 SU / 1 15.374 >=0.5 Pass 5785 SU / 1 16.591 >=0.5 Pass Page 14 of 107 Report No.: AiTSZ-250917061FW2 5825 SU / 1 17.349 >=0.5 Pass 802.11ax (HEW40) MIMO 5755 SU / 1 35.066 >=0.5 Pass 5795 SU / 1 35.084 >=0.5 Pass 802.11ax (HEW80) MIMO 5775 SU / 1 70.062 >=0.5 Pass Note:All antennas were test and recorded worst result of Ant 1. Page 15 of 107 Report No.: AiTSZ-250917061FW2 2.2 Test Graph 2.2.1 OBW 802.11a_LCH_5745MHz_Ant1_NTNV 802.11a_MCH_5785MHz_Ant1_NTNV Page 16 of 107 Report No.: AiTSZ-250917061FW2 802.11a_HCH_5825MHz_Ant1_NTNV 802.11n(HT20)_LCH_5745MHz_Ant1_NTNV Page 17 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT20)_MCH_5785MHz_Ant1_NTNV 802.11n(HT20)_HCH_5825MHz_Ant1_NTNV Page 18 of 107 Report No.: AiTSZ-250917061FW2 802.11n(HT40)_LCH_5755MHz_Ant1_NTNV 802.11n(HT40)_HCH_5795MHz_Ant1_NTNV Page 19 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT20)_LCH_5745MHz_Ant1_NTNV 802.11ac(VHT20)_MCH_5785MHz_Ant1_NTNV Page 20 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT20)_HCH_5825MHz_Ant1_NTNV 802.11ac(VHT40)_LCH_5755MHz_Ant1_NTNV Page 21 of 107 Report No.: AiTSZ-250917061FW2 802.11ac(VHT40)_HCH_5795MHz_Ant1_NTNV 802.11ac(VHT80)_MCH_5775MHz_Ant1_NTNV Page 22 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW20)_LCH_5745MHz_SU_ / _Ant1_NTNV 802.11ax(HEW20)_MCH_5785MHz_SU_ / _Ant1_NTNV Page 23 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW20)_HCH_5825MHz_SU_ / _Ant1_NTNV 802.11ax(HEW40)_LCH_5755MHz_SU_ / _Ant1_NTNV Page 24 of 107 Report No.: AiTSZ-250917061FW2 802.11ax(HEW40)_HCH_5795MHz_SU_ / _Ant1_NTNV 802.11ax(HEW80)_MCH_5775MHz_SU_ / _Ant1_NTNV Page 25 of 107 Report No.: AiTSZ-250917061FW2 2.2.2 6dB BW 802.11a_LCH_5745MHz_Ant1_NTNV 802.11a_MCH_5785MHz_Ant1_NTNV Page 26 of 107 Report No.: AiTSZ-250917061FW2 802.11a_HCH_5825MHz_Ant1_NTNV 802.11n(HT20)_LCH_5745MHz_Ant1_NTNV Page 27 of 107 Report No.: AiTSZ-250917061FW2 802…
