NZ3WS-WN518802.11bgn HIGH POWER WI-FI REPEATER

High Power Wi-Fi Repeater User Manual Quick Installation Guide(Q.I.G.) REV.1.2 Introduction： The Wi-Fi Repeater is a combined wired/wireless network connection device designed specifically for small business, office, and home office networking requirements. It allows a wireless network to be expanded using multiple access points without the need for a wired backbone to link them. It also works well with other 11b/g and 11n protocol wireless products. NOTE: If you need to reset the Wi-Fi Repeater, you need press and hold the reset button inside the tiny hole for 10 seconds. Package Contents Before you starting to use this router, please check if there’s anything missing in the package, and contact your dealer of purchase to claim for missing items: • 1 x Wireless-N Repeater • 1 x RJ-45 Networking Cable • 1 x Quick installation Guide reset WPS RJ45 Getting Started Setting up a Wireless Infrastructure Network For a typical wireless setup at home (as shown below), please do the following: Wireless Repeater Mode You will need WiFi AP/Router Internet access Wireless AP Mode You will need broadband Router Internet access Connect the WiFi-Repeater to your Router/Switch with RJ-45 Cable How to configure the Wi-Fi Repeater You can configure the Wi-Fi Repeater by connecting it with your computer/laptop with enclosed RJ45 cable or wirelessly. We recommend you to do it with wire. A. Configure the Wi-Fi Repeater with RJ45 Cable A1. Plug the Wi-Fi Repeater to a wall socket. Connect your computer / laptop with the Wi-Fi Repeater with enclosed RJ45 Cable. A2. Click the “ Start ” button (it should be located at the lower- left corner of your screen), then click “ Control Panel ”. Click “ View Network Status and Tasks ”, and then click “ Manage Network Connections ”. Right- click “ Local Area Network ”, then select “ Properties ”. When the “ Local Area Connection Properties ” window appears, select “I nternet Protocol Version 4 (TCP/IPv4) ” and then click “ Properties ”. A3. Setting IP address manually: Type IP address is 192.168.10.x ( x is from 2 to 254 ), and Subnet mask is 255.255.255.0 . Type the Router’s LAN IP address (the default IP is 192.168.10.1 ) into the Default gateway field. A4. Open web browser and type http://192.168.10.1 in the browser's address box. This number is the default IP address for this device. A5. The login screen below will appear. Enter the “User Name” and “Password” and click “OK” to login. The default User name is “admin” and the Password is “admin”. A6. After logging in and click “Setup Wizard”, you will see the web page below: Select “Wireless Repeater Mode (Station)” and click on ‘Next’ to continue. A7. Click on ‘Repeater – OneKey Setting’ button A8. Wait a few seconds and you will see the site below and please click on ‘Wireless Network Selection’ button. A9. Click on ‘Refresh List’ button. Select the Wireless SSID and click ‘Next’ to continue. A10. When you see the site below, please do not change any setting but only insert the password of your network. Click on ‘Apply and Reboot’ button. A11. Click ‘OK’ to confirm. The Repeater will restart. A12. Wait a few seconds and you will see the status site like below. It means your Wi-Fi Repeater is ready for use. * The Wi-Fi Repeater1 WLAN key is same with your router. If you do not see the site like above, you need to re-configure it again. NOTE: If you need to reset the Wi-Fi Repeater, you need press the reset button inside the tiny hole for 10 seconds. B. Configure the Wi-Fi Repeater wirelessly. 1. Plug the Wi-Fi Repeater to a wall socket. 2. Click on the network icon ( or ) on the right bottom of your desktop. You will find the signal from the Wi-Fi Repeater. Click on ‘Connect’ and wait for a few seconds. 3. Follow process A3 to A12 to configure your Wi-Fi Repeater wirelessly. C. Configure the Wireless AP Mode. 1. Plug the Wi-Fi Repeater to a wall socket. 2. Follow process A2 to A5. 3. Select “Standard Wireless AP Mode” and click on ‘Next’ to continue. 4. Click on ‘AP – OneKey Setting’ button 5. Wait a few seconds and you will see the status site like below. It means your Wi-Fi Repeater is ready for use. How to connect your computer/laptop with the Wi-Fi Repeater Adding a Wireless computers to the WiFi-Repeater 1. Log on to the computer. 2. Open Connect to a Network by right-clicking the network icon ( or ) in the notification area. 3. Choose the wireless network from the list that appears, and then click Connect . 4. Type the network security key or passphrase if you are asked to do so, and then click OK . You'll see a confirmation message when you are connected to the network. 5. To confirm that you added the computer, do the following: Open Network by clicking the Start button , and then clicking Control Panel . In the search box, type network , and then, under Network and Sharing Center, click View network computers and devices . You should see icons for the computer you added and for the other computers and devices that are part of the network. Note : If you don't see icons in the Network folder, then network discovery and file sharing might be turned off. Adding a wired (Ethernet) computer to the WiFi-Repeater 1. Plug the computer into WiFi-Repeater and then turn it on. 2. To confirm that you added the computer, do the following: Open Network by clicking the Start button , and then clicking Control Panel . In the search box, type network , and then, under Network and Sharing Center, click View network computers and devices . You should see icons for the computer you added and for the other computers and devices that are part of the network. For more information: http://windows.microsoft.com/en-US/windows7/Add-a-device-or-computer-to-a-network http://windows.microsoft.com/en-US/windows7/Setting-up-a-wireless-network http://windows.microsoft.com/en-US/windows-vista/Setting-up-a-wireless-network Configuring via Web Browser Wireless Base Configuration Please click “Wireless -> Basic Settings” located at the web managem…

Text truncated - open the document above for the full version.

RT8020(U915) ANT U21 SE2576L RTL8188RE(U1) SDRAM-U11 （ISSIIS42S16800B-6TL） 10/100M RJ45PORT RTL8196C(U17) L E D X140MHz DCPOWER MX25L1635DM2 1-12G(U19) Reset ACPOWER

WinstarsTechnologyLimited Block4,TaiSongIndustrialPark,DaLangStreet,LonghuaTown,Bao'andistrict,Shenzhen,China AttestationforFCCDoC FCCID:NZ3WS-WN518Date:Sept.10,2012 Pleasebenotifiedthatwe,theundersigned,WinstarsTechnologyLimited declarethattheproductwhichbearstheaboveFCCIDisalsocompliant withtheFCCrequirementsforDoC.Thetestreportnumbersupportingthe DoCis12B06221F.TestinginregardstothisreportwasdonebyInterocean EMCTechnologyCorp.,locatedatNo.5-2,Lin1,Tin-FuTsun,Lin-KouHsiang, TaipeiCounty244,Taiwan,R.O.C.,whichhasbeenaccreditedinaccordance toalloftherequirementsof47CFR2.948(d)and(e)oftheFCCrulesand KDB349827. Sincerely, JohnsonHuang/GeneralManager

WinstarsTechnologyLimited Block4,TaiSongIndustrialPark,DaLangStreet,LonghuaTown,Bao'andistrict,Shenzhen,China AGENCYAUTHORIZATIONLETTER FCCID:NZ3WS-WN518Date:Sept.10,2012 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Towhomitmayconcern: We,theundersigned,herebyauthorizeShenzhenCTLElectromagnetic TechnologyCo.,Ltd.(MR.TracyQi)onourbehalf,toapplytotheFederal CommunicationsCommissiononourequipment.Anyandallactscarriedout byShenzhenCTLElectromagneticTechnologyCo.,Ltd.(MR.TracyQi)on ourbehalfshallhavethesameeffectasactsofourown.Thisauthorization expiresonSept.09,2013. ThisistoadvisethatweareinfullcompliancewiththeAnti-DrugAbuse Act.We,WinstarsTechnologyLimitedarenotsubjecttoadenialoffederal benefitspursuanttoSection5301oftheAnti-DrugActof1988,21USC853a, andnopartytotheapplicationissubjecttoadenialoffederalbenefits pursuanttothatsection. Sincerely, JohnsonHuang/GeneralManager

V1.0Page78of84ReportNo.:CTL120822875-WF 6.Ex t e rn a lan dInt e rn alPhot osoftheEU T ExternalPhotosofEUT V1.0Page79of84ReportNo.:CTL120822875-WF

FCCIDLabelInformation 1.Labellocation: 2.FCCIDLabel: WinstarsTechnologyLimitedHighPowerWi-FiRepeater Model:WS-WN518HN1FCCID:NZ3WS-WN518 ThisdevicecomplieswithPart15oftheFCCRules.Operation issubjecttothefollowingtwoconditions:(1)thisdevicemay notcauseharmfulinterference,and(2)thisdevicemustaccept anyinterferencereceived,includinginterferencethatmaycause undesiredoperation.

The RTL8196C supports two simultaneous traffic streams using up to two integrated Together with single input/ output (SISO) radio chip RTL8188CE for cessing, supporting 10 Mbps too poor which could not support 100Mbps, th This device is a 10/100Mbps AP Router, which operates in the 2.4GHz ISM band. The onverters. Product Description Overview system is compliant with IEEE 802.11b/g and IEEE 802.11n draft 2.0. It uses OFDM technique that the maximum data rate could up to 300Mbps. If the signal to noise ratio is e 11Mbps data rate with DSSS technique will be applied. The RTL8196C integrates a media access control (MAC), a baseband processor, analog-to-digital and digital-to-analog c 2.4GHz to enable 802.11b/g/n solution. The RTL8196C implements single inputs, single output (SISO),half-duplex OFDM, CCK, and DSSS baseband pro and 40 MHz channel operations respectively, and all IEEE 802.11b/g data rates. transmit chains and receive chains for high throughput and range performance. Transmit chains combine baseband in-phase (I) and quadrature (Q) signals, convert them to the desired frequency, and drive the RF signal to multiple antennas. Receiver chains use integrated dual conversion architecture and require no off-chip intermediate frequency (IF) filters. The frequency synthesizer supports one-MHz steps to match frequencies defined by IEEE 802.11b/g/n specification.The 40MHz crystal oscillator feeds to the RTL8196C. The antennas are PCB antenna without any external connector. Power Supply For more detailed information, please refer to the user’s manual. The EUT is powered by AC100-240V from the host equipment.

ShenzhenCTLElectromagneticTechnologyCo.,Ltd. Tel:+86-755-89486194Fax:+86-755-89486194-805 MPETESTREPORT FCCPer47CFR2.1091(b) ReportReferenceNo.......................: FCCID................................................: CTL120822875-WM NZ3WS-WN518 Compiledby (position+printedname+signature)..:Fileadministrators JackyChen Nameoftheorganizationperforming thetests (position+printedname+signature)..: TestEngineerTracyQi Approvedby (position+printedname+signature)..: ManagerTracyQi Dateofissue.......................................:Sept.10,2012 RepresentativeLaboratoryName.:ShenzhenCTLElectromagneticTechnologyCo.,Ltd. Address...............................................:ZoneB,4/F,Block20,GuangqianIndustrialPark,LongzhuRoad, Nanshan,Shenzhen518055China. TestFirm ............................................ :BontekComplianceTestingLaboratoryLtd Address ............................................... :1/F,BlockEastH-3,OCTEasternInd.Zone,QiaochengEast Road,Nanshan,Shenzhen,China Applicant’sname.............................: WinstarsTechnologyLimited Address...............................................:Block4,TaisongIndustrialPark,DalangStreet,LonghuaTown, Bao'anDistrict,Shenzhen,China Testspecification: Standard.............................................: FCCPer47CFR2.1091(b) TRFOriginator .................................... :ShenzhenCTLElectromagneticTechnologyCo.,Ltd. MasterTRF ......................................... :Dated2011-01 ShenzhenCTLElectromagneticTechnologyCo.,Ltd.Allrightsreserved. Thispublicationmaybereproducedinwholeorinpartfornon-commercialpurposesaslongasthe ShenzhenCTLElectromagneticTechnologyCo.,Ltd.isacknowledgedascopyrightownerandsourceof thematerial.ShenzhenCTLElectromagneticTechnologyCo.,Ltd.takesnoresponsibilityforandwillnot assumeliabilityfordamagesresultingfromthereader'sinterpretationofthereproducedmaterialduetoits placementandcontext. Testitemdescription......................:HighPowerWi-FiRepeater TradeMark.........................................:/ OperationFrequency.........................:From2400MHzto2483.5MHz Model/Typereference........................:WS-WN518HN1 ListedModels .................................... : Result .................................................. :Positive V1.0Page2of8ReportNo.:CTL120822875-WM TESTREPORT TestReportNo.: CTL120822875-WM Sept.10,2012 ______________________________________________________________________________________________ Dateofissue EquipmentunderTest: HighPowerWi-FiRepeater Model/Type: WS-WN518HN1 ListedModels: / Applicant : WinstarsTechnologyLimited Address: Block4,TaisongIndustrialPark,DalangStreet,Longhua Town,Bao'anDistrict,Shenzhen,China Manufacturer:WinstarsTechnologyLimited Address: Block4,TaisongIndustrialPark,DalangStreet,Longhua Town,Bao'anDistrict,Shenzhen,China Thetestreportmerelycorrespondstothetestsample. Itisnotpermittedtocopyextractsofthesetestresultwithoutthewrittenpermissionofthetest laboratory. V1.0Page3of8ReportNo.:CTL120822875-WM Contents 1.SUMMARY............................................................................................................................................4 1.1.EUTconfiguration4 1.2.Powersupplysystemutilised4 1.3.Descriptionofthetestmode4 1.4.NOTE4 2.TESTENVIRONMENT .................................................................................................................. 6 2.1.Addressofthetestlaboratory6 2.2.Environmentalconditions6 2.3.Statementofthemeasurementuncertainty6 3.METHODOFMEASUREMENT................................................................................................7 3.1.ApplicableStandard7 3.2.Limit7 3.3.MPECalculationMethod7 4.CONCLUSION....................................................................................................................................8 V1.0Page4of8ReportNo.:CTL120822875-WM 1.SU M M AR Y 1.1.EUTconfiguration Thefollowingperipheraldevicesandinterfacecableswereconnectedduringthemeasurement: ●-suppliedbythemanufacturer ○-suppliedbythelab ○ PowerCableLength(m):/ Shield:/ Detachable:/ ○ MultimeterManufacturer:/ ModelNo.:/ 1.2.Powersupplysystemutilized Powersupplyvoltage: ● 120V/60Hz ○ 115V/60Hz ○ 12VDC ○ 24VDC ○ Other(specifiedinblankbelow) 1.3.Descriptionofthetestmode IEEE802.11b/g/n:ThirteenchannelsareprovidedtotheEUT,butonlyeleventhchannelsusedforUSA. ChannelFrequency(MHz)ChannelFrequency(MHz) 1241282447 2241792452 32422102457 42427112462 52432 62437 72442 1.4.NOTE TheEUTisan802.11b/g/nHighPowerWi-FiRepeater,ThefunctionsoftheEUTlistedasbelow: TestStandardsReferenceReport WLAN802.11b/g,802.11n FCCPart15SubpartC (Section15.247) CTL120822875-WF WLAN802.11b/g,802.11nFCCPer47CFR2.1091(b) CTL120822875-WM 2.ThefrequencybandsusedinthisEUTarelistedasfollows: FrequencyBand(MHz)2400-2483.55150-53505470-57255725-5850 802.11b √ －－－ 802.11g √ －－－ 802.11n(20MHz) √ －－－ 802.11n(40MHz) √ －－－ V1.0Page5of8ReportNo.:CTL120822875-WM 3.TheEUTincorporatesaSISOfunction,Physically,theEUTprovidesonecompletedtransmitterandone completedreceiver. ModulationModeTXFunction 802.11b1TX 802.11g1TX 802.11n(20MHz)1TX 802.11n(40MHz)1TX V1.0Page6of8ReportNo.:CTL120822875-WM 2.TESTEN VI RO N M EN T 2.1.Addressofthetestlaboratory BontekComplianceTestingLaboratoryLtd 1/F,BlockEastH-3,OCTEasternInd.Zone,QiaochengEastRoad,Nanshan,Shenzhen,China ThesitesareconstructedinconformancewiththerequirementsofANSIC63.7,ANSIC63.4(2003)and CISPRPublication22. 2.2.Environmentalconditions Duringthemeasurementtheenvironmentalconditionswerewithinthelistedranges: Temperature:15-35°C Humidity:30-60% Atmosphericpressure:950-1050mbar 2.3.Statementofthemeasurementuncertainty Thedataandresultsreferencedinthisdocumentaretrueandaccurate.Thereaderiscautionedthatthere maybeerrorswithinthecalibrationlimitsoftheequipmentandfacilities.Themeasurementuncertaintywas calculatedforallmeasurementslistedinthistestreportacc.toCISPR16-4„Specificationforradio disturbanceandimmunitymeasuringapparatusandmethods–Part4:UncertaintyinEMC Measurements“andisdocumentedintheBontekCom…

Text truncated - open the document above for the full version.

5 5 4 4 3 3 2 2 1 1 DD CC BB AA (DQM1) (DQM0) 16M 16bit SDARM x1 PCI-E Interface 10/100M PHY Interface LED Interface C224,C229 close to U17 UART Configure Interface Input 8 pins SPI Flash Single I/O Dual I/O Quad I/O R210=10K R212=10K SPI Flash 8 pins SPI R210=NC R212=NC Output Input A7 D8 D10 D1 A6 D5 A12 D15 RASB D14 D7 A5 D11 SD_CS0B A4 D13 A15 D6 D12 A8 A11 D9 D0 D4 A9 A16 D3 CASB D2 WEB RDIP4 TDON4 RDIN4 TDOP4 CLK-_HOST PERSTB HSOP HSIP HSON CLK+_HOST HSIN RESETB HSIP_E HSINHSIN_E HSIP SD_CLOCK JTGTDI WPS DEFAULT JTGTRST A0 A14 A10 A3 A13 A1 A2 SDRAM_CLK LED_PORT4 A11MA11 MSD_CS0BSD_CS0B A12MA12 MA3A3 MD14D14 MD1D1 MD3D3 WEBMWEB MD9D9 MA4A4 A14MA14 MA5A5 MD10D10 D5MD5 A6MA6 A13MA13 A2MA2 A8MA8 A10MA10 MA9A9 A0MA0 A1MA1 MD6D6 D15MD15 MD0D0 MD11D11 MD7D7 MA16A16 MD2D2 CASBMCASB MD4D4 D8MD8 A15MA15 MRASBRASB D13MD13 D12MD12 MA7A7 MD8 MA1 MA0 MRASB HSON MD12 MA5 JTGTDO MD4 RDIP4 AVDDX MD1 MA12 MA8 MD10 MD9 RDIN4 MD0 AVDDBG A17_SPIO3 MA4 MCASB MA14 MD13 MA16JTGTDI TDOP4 SF_CSB SF_SCK1 SD_CLOCK A20_SPIO0 MD7 TDON4 MA9 MSD_CS0B MD14 JTGCLK MA3 MD6MA15MA13 A19_SPIO1 MD2 MD15 JTGTMS MD5 MA11 HSOP MA6 MA7 MA2 PERSTB MWEB MD3 MD11 JTGTRST MA10 A18_SPIO2 CLK+_HOST CLK-_HOST AVDD10PCIE HSIP_E HSIN_E LED_PORT4 AVDD10PCIE VDD33_A VDD10_A U0RXD U0TXD CK_40M AVDD33USB CK_40M AVDD10USB WPSLEDJTGTMS U0TXD U0RXD 40M_SEL 40M_SEL ATEST WAKE# MA8 MA9 MA6 MA3 MA13 MA2 MA11 MA12 MA10 MA1 MA5 MA7 MA4 MA14 SYSLEDJTGTDO A20_SPIO0 A17_SPIO3 SF_SCK SF_CSB A19_SPIO1 A18_SPIO2 AVDDX CKE CKE SDRAM_CLK SF_SCK1SF_SCK WAKE# JTGCLK WAKEn PD# USBPOWER WAKEn AVDD10USB PD# USBPOWER USB0_DN USB0_DP USB0_DP USB0_DN JTGTMS JTGTDO JTGTRST JTGTDI JTGCLK TDOP0 TDON0 RDIP0 RDIN0 TDOP0TDON0RDIP0RDIN0 ATEST AVDD33USBAVDDBG GPIO55 GPIO33 GPIO22 GPIO22JTGCLK VDD33 VDD33 VDD33 VDD33 VDD10 VDD10 VDD10 VDD33VDD10 VDD33 VDD33 VDD33 VDD33 VDD33 VDD33 VDD33 VDD33 VDD10 VDD33 VDD10 VDD33 VDD10 VDD10 VDD33 VDD33 RDIN4{5} RDIP4{5} TDON4{5} TDOP4{5} CLK-_HOST{6} CLK+_HOST{6} HSON{6} PERSTB{6} HSIN{6} HSOP{6} HSIP{6} LED_PORT4{4} CK_40M{6} WAKE#{6} MA4{3} MA3{3} MA8{3} MA10{3} MA5{3} MA2{3} MA12{3} MA7{3} MA13{3} MA6{3} MA14{3} MA11{3} MA9{3} MA1{3} PD#{6} USBPOWER{4} USB0_DN{4} USB0_DP{4} GPIO55{4} GPIO33{4} GPIO22{4} Title SizeDocument NumberRev Date:Sheet of CPU/SDRAM/FLASH V311 Realtek 802.11n 10/100M Wireless Router Custom 27Thursday, April 07, 2011 Title SizeDocument NumberRev Date:Sheet of CPU/SDRAM/FLASH V311 Realtek 802.11n 10/100M Wireless Router Custom 27Thursday, April 07, 2011 Title SizeDocument NumberRev Date:Sheet of CPU/SDRAM/FLASH V311 Realtek 802.11n 10/100M Wireless Router Custom 27Thursday, April 07, 2011 C194 0.1uF C194 0.1uF R1590R1590 C192 0.1uF C192 0.1uF C234 0.1uF C234 0.1uF C225 0.1uF C225 0.1uF C200 0.1uF C200 0.1uF C252 0.1uF C252 0.1uF C236 0.1uF C236 0.1uF C197 0.1uF C197 0.1uF C201 0.1uF C201 0.1uF C233 10uF(0805) C233 10uF(0805) C246 1uF C246 1uF C195 0.1uF C195 0.1uF TP22TPTP22TP 1 1 C2060.1uFC2060.1uF C217 0.1uF C217 0.1uF R2162.5K(1%)R2162.5K(1%) R1610R1610 C101 0.1uF C101 0.1uF C220 10uF(0805) C220 10uF(0805) U11 ISSI IS42S16800B-6TL U11 ISSI IS42S16800B-6TL Vcc 1 DQ0 2 VccQ 3 DQ1 4 DQ2 5 VssQ 6 DQ3 7 DQ4 8 VccQ 9 DQ5 10 DQ6 11 VssQ 12 DQ7 13 Vcc 14 LDQM 15 WE 16 CAS 17 RAS 18 CS 19 BS0 20 BS1 21 A10/AP 22 A0 23 A1 24 A2 25 A3 26 Vcc 27 Vss 54 DQ15 53 VssQ 52 DQ14 51 DQ13 50 VccQ 49 DQ12 48 DQ11 47 VssQ 46 DQ10 45 DQ9 44 VccQ 43 DQ8 42 Vss 41 NC 40 UDQM 39 CLK 38 CKE 37 A12 36 A11 35 A9 34 A8 33 A7 32 A6 31 A5 30 A4 29 Vss 28 C253 1uF C253 1uF C2070.1uFC2070.1uF C216 10uF(0805) C216 10uF(0805) C248 0.1uF C248 0.1uF R1560R1560 C2290.1uFC2290.1uF J15 PIN1X4 J15 PIN1X4 C219 0.1uF C219 0.1uF C231 0.1uF C231 0.1uF R21310KR21310K R170 10K R170 10K C243 0.1uF C243 0.1uF C228 0.1uF C228 0.1uF C209 NC C209 NC TP21TPTP21TP 1 1 C202 0.1uF C202 0.1uF R8610R8610 L1110(0603)L1110(0603) R2180R2180 R169 10K R169 10K C198 0.1uF C198 0.1uF C204 10uF(0603) C204 10uF(0603) C191 0.1uF C191 0.1uF R20149.9R20149.9 J11 HEADER 6X2 (pitch=1.27mm) J11 HEADER 6X2 (pitch=1.27mm) 1 3 5 7 9 11 2 4 6 8 10 12 C193 0.1uF C193 0.1uF R210 10K R210 10K R2114.7KR2114.7K C199 0.1uF C199 0.1uF R173 10K R173 10K C242 0.1uF C242 0.1uF C241 0.1uF C241 0.1uF R1010R1010 R217 NC/10K R217 NC/10K R220NC/0R220NC/0 R187NC/10KR187NC/10K TP23TPTP23TP 1 1 R2080R2080 C224 0.1uF C224 0.1uF R212 10K R212 10K C211 0.1uF C211 0.1uF C235 0.1uF C235 0.1uF C227 0.1uF C227 0.1uF R172 10K R172 10K TP12 TP TP12 TP 1 1 R669 10K R669 10K U19 MX25L1635DM2I-12G/200mil(S08-wide) U19 MX25L1635DM2I-12G/200mil(S08-wide) CS 1 SO/SIO1 2 WP/SIO2 3 VSS 4 VCC 8 NC/SIO3 7 SCLK 6 SI/SIO0 5 R214 12K(1%) R214 12K(1%) TP24TPTP24TP 1 1 C205 1uF C205 1uF RTL8196C U17 RTL8196C RTL8196C U17 RTL8196C HSIP 122 PC I E _ RS T# 4 LED_PORT2 104 LED_PORT3 105 VDD10 103 VDD33 106 LED_PORT4 107 GPIOB7 108 HSOP 116 VDD10_USB 110 GND 111 HSON 115 AVDD33_USB_PCIE 114 USB_DP 113 USB_DN 112 AVDD10_PCIE 117 REFCLKN 118 REFCLKP 119 AGND_PCIE 120 HSIN 121 GPIOC0 109 AVDD33_25M 123 40M_SEL 124 40M_CLK 125 25M_XO 126 25M_XI 127 AVDD33_BG 128 R 12K 1 A GND _ SYSP LL 2 VDD 33 3 VDD 10 5 AVDD 10 6 T X O P0 7 TX ON0 8 R X I P0 9 RX I N0 10 AVDD 33 11 RX I N1 12 RX I P1 13 GND 14 T X ON1 15 T X O P1 16 AVDD 10 17 T X O P2 18 T X ON2 19 RX I P2 20 RX I N2 21 AVDD 33 22 RX I N3 23 RX I P3 24 T X ON3 25 T X O P3 26 AVDD 10 27 T X O P4 28 T X ON4 29 RX I P4 30 RX I N4 31 AVDD 33 32 I BREF 33 AVDD 10_ PHYP LL 34 ATEST 35 UAR T0_ RX 36 UAR T0_TX 37 TEST MO DE 38 VDD10 39 NF_CS1# 40 NF_CS0# 41 GND 42 MA17 43 VDD33 44 MA18 45 MA19 46 MA20 47 MA21 48 MA4 49 MA5 50 MA6 51 MA7 52 MA8 53 VDD33 54 MA9 55 MA11 56 MA12 57 MA3 58 MA2 59 MA1 60 MA0 61 MA10 62 MA14 63 VDD33 64 M A 13 65 M CS 0# 66 M CS 1# 67 GND 68 RAS# 69 CAS# 70 W E# 71 M A 15 72 VDD 10 73 M D7 74 M D5 77 M D4 78 M D3 79 M D2 80 M D1 81 M D0 82 GND 83 M C LK 84 M A 16 85 VDD 33 86 M D8 87 M D9 88 M D 10 89 M D 11 90 M D 12 91 M D 13 92 M D 14 93 M D 15 94 VDD 33 95 JT A G _T RS T# 96 J TA G _T MS 97 JT A G _T DO 98 JT A G _T DI 99 JT A G _ C LK 100 L ED _ P OR T0 …

Text truncated - open the document above for the full version.

ShenzhenCTLElectromagneticTechnologyCo.,Ltd. Tel:+86-755-89486194Fax:+86-755-89486194-805 MPETESTREPORT FCCPer47CFR2.1091(b) ReportReferenceNo.......................: FCCID................................................: CTL120822875-WM NZ3WS-WN518 Compiledby (position+printedname+signature)..:Fileadministrators JackyChen Nameoftheorganizationperforming thetests (position+printedname+signature)..: TestEngineerTracyQi Approvedby (position+printedname+signature)..: ManagerTracyQi Dateofissue.......................................:Sept.10,2012 RepresentativeLaboratoryName.:ShenzhenCTLElectromagneticTechnologyCo.,Ltd. Address...............................................:ZoneB,4/F,Block20,GuangqianIndustrialPark,LongzhuRoad, Nanshan,Shenzhen518055China. TestFirm ............................................ :BontekComplianceTestingLaboratoryLtd Address ............................................... :1/F,BlockEastH-3,OCTEasternInd.Zone,QiaochengEast Road,Nanshan,Shenzhen,China Applicant’sname.............................: WinstarsTechnologyLimited Address...............................................:Block4,TaisongIndustrialPark,DalangStreet,LonghuaTown, Bao'anDistrict,Shenzhen,China Testspecification: Standard.............................................: FCCPer47CFR2.1091(b) TRFOriginator .................................... :ShenzhenCTLElectromagneticTechnologyCo.,Ltd. MasterTRF ......................................... :Dated2011-01 ShenzhenCTLElectromagneticTechnologyCo.,Ltd.Allrightsreserved. Thispublicationmaybereproducedinwholeorinpartfornon-commercialpurposesaslongasthe ShenzhenCTLElectromagneticTechnologyCo.,Ltd.isacknowledgedascopyrightownerandsourceof thematerial.ShenzhenCTLElectromagneticTechnologyCo.,Ltd.takesnoresponsibilityforandwillnot assumeliabilityfordamagesresultingfromthereader'sinterpretationofthereproducedmaterialduetoits placementandcontext. Testitemdescription......................:HighPowerWi-FiRepeater TradeMark.........................................:/ OperationFrequency.........................:From2400MHzto2483.5MHz Model/Typereference........................:WS-WN518HN1 ListedModels .................................... : Result .................................................. :Positive V1.0Page2of8ReportNo.:CTL120822875-WM TESTREPORT TestReportNo.: CTL120822875-WM Sept.10,2012 ______________________________________________________________________________________________ Dateofissue EquipmentunderTest: HighPowerWi-FiRepeater Model/Type: WS-WN518HN1 ListedModels: / Applicant : WinstarsTechnologyLimited Address: Block4,TaisongIndustrialPark,DalangStreet,Longhua Town,Bao'anDistrict,Shenzhen,China Manufacturer:WinstarsTechnologyLimited Address: Block4,TaisongIndustrialPark,DalangStreet,Longhua Town,Bao'anDistrict,Shenzhen,China Thetestreportmerelycorrespondstothetestsample. Itisnotpermittedtocopyextractsofthesetestresultwithoutthewrittenpermissionofthetest laboratory. V1.0Page3of8ReportNo.:CTL120822875-WM Contents 1.SUMMARY............................................................................................................................................4 1.1.EUTconfiguration4 1.2.Powersupplysystemutilised4 1.3.Descriptionofthetestmode4 1.4.NOTE4 2.TESTENVIRONMENT .................................................................................................................. 6 2.1.Addressofthetestlaboratory6 2.2.Environmentalconditions6 2.3.Statementofthemeasurementuncertainty6 3.METHODOFMEASUREMENT................................................................................................7 3.1.ApplicableStandard7 3.2.Limit7 3.3.MPECalculationMethod7 4.CONCLUSION....................................................................................................................................8 V1.0Page4of8ReportNo.:CTL120822875-WM 1.SU M M AR Y 1.1.EUTconfiguration Thefollowingperipheraldevicesandinterfacecableswereconnectedduringthemeasurement: ●-suppliedbythemanufacturer ○-suppliedbythelab ○ PowerCableLength(m):/ Shield:/ Detachable:/ ○ MultimeterManufacturer:/ ModelNo.:/ 1.2.Powersupplysystemutilized Powersupplyvoltage: ● 120V/60Hz ○ 115V/60Hz ○ 12VDC ○ 24VDC ○ Other(specifiedinblankbelow) 1.3.Descriptionofthetestmode IEEE802.11b/g/n:ThirteenchannelsareprovidedtotheEUT,butonlyeleventhchannelsusedforUSA. ChannelFrequency(MHz)ChannelFrequency(MHz) 1241282447 2241792452 32422102457 42427112462 52432 62437 72442 1.4.NOTE TheEUTisan802.11b/g/nHighPowerWi-FiRepeater,ThefunctionsoftheEUTlistedasbelow: TestStandardsReferenceReport WLAN802.11b/g,802.11n FCCPart15SubpartC (Section15.247) CTL120822875-WF WLAN802.11b/g,802.11nFCCPer47CFR2.1091(b) CTL120822875-WM 2.ThefrequencybandsusedinthisEUTarelistedasfollows: FrequencyBand(MHz)2400-2483.55150-53505470-57255725-5850 802.11b √ －－－ 802.11g √ －－－ 802.11n(20MHz) √ －－－ 802.11n(40MHz) √ －－－ V1.0Page5of8ReportNo.:CTL120822875-WM 3.TheEUTincorporatesaSISOfunction,Physically,theEUTprovidesonecompletedtransmitterandone completedreceiver. ModulationModeTXFunction 802.11b1TX 802.11g1TX 802.11n(20MHz)1TX 802.11n(40MHz)1TX V1.0Page6of8ReportNo.:CTL120822875-WM 2.TESTEN VI RO N M EN T 2.1.Addressofthetestlaboratory BontekComplianceTestingLaboratoryLtd 1/F,BlockEastH-3,OCTEasternInd.Zone,QiaochengEastRoad,Nanshan,Shenzhen,China ThesitesareconstructedinconformancewiththerequirementsofANSIC63.7,ANSIC63.4(2003)and CISPRPublication22. 2.2.Environmentalconditions Duringthemeasurementtheenvironmentalconditionswerewithinthelistedranges: Temperature:15-35°C Humidity:30-60% Atmosphericpressure:950-1050mbar 2.3.Statementofthemeasurementuncertainty Thedataandresultsreferencedinthisdocumentaretrueandaccurate.Thereaderiscautionedthatthere maybeerrorswithinthecalibrationlimitsoftheequipmentandfacilities.Themeasurementuncertaintywas calculatedforallmeasurementslistedinthistestreportacc.toCISPR16-4„Specificationforradio disturbanceandimmunitymeasuringapparatusandmethods–Part4:UncertaintyinEMC Measurements“andisdocumentedintheBontekCom…

Text truncated - open the document above for the full version.

Shenzhen CTL Electromagnetic Technology Co., Ltd. Tel: +86-755-89486194 Fax: +86-755-89486194-805 FCC PART 15 SUBPART C TEST REPORT FCC Part 15.247 Report Reference No......................: CTL120822875-WF Compiled by ( position+printed name+signature) .: File administrators Jacky Chen Name of the organization performing the tests ( position+printed name+signature) .: Test Engineer Tracy Qi Approved by ( position+printed name+signature) .: Manager Tracy Qi Date of issue.....................................: Sept. 17, 2012 Representative Laboratory Name.: Shenzhen CTL Electromagnetic Technology Co., Ltd. Address ............................................: Zone B, 4/F, Block 20, Guangqian Industrial Park, Longzhu Road, Nanshan, Shenzhen 518055 China. Test Firm.........................................: Bontek Compliance Testing Laboratory Ltd Address ............................................: 1/F, Block East H-3, OCT Eastern Ind. Zone, Qiaocheng East Road, Nanshan, Shenzhen, China Applicant’s name............................: Winstars Technology Limited Address ............................................: Block 4, Taisong Industrial Park, Dalang Street, Longhua Town, Bao'an District, Shenzhen, China Test specification: Standard ...........................................: FCC Part 15.247: Operation within the bands 902–928 MHz, 2400– 2483.5 MHz, and 5725–5850 MHz. TRF Originator..................................: Shenzhen CTL Electromagnetic Technology Co., Ltd. Master TRF.......................................: Dated 2011-01 Shenzhen CTL Electromagnetic Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Electromagnetic Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Electromagnetic Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ....…

Text truncated - open the document above for the full version.
