NZ3WS-WN687NWireless N USB Adapter

Wireless-N USB Adapter Quick install guide Introduction Thank you for purchasing the Wireless-N USB Adapter,. Wireless-N USB 2.0 Adapter allows you to connect your laptop or desktop to any Wireless-N networks in your home or office. The Wireless-N (802.11n) USB 2.0 Adapter is great for those who want to upgrade older computers to be able to access the internet over a Wireless-N network. Package Contents • Wireless-N USB Adapter • Setup CD with user manual • Quick install guide System Requirements• Notebook or desktop PC with Pentium 1 GHz-compatible or higher processor • Windows 2000/XP/Vista/7, MAC OS, Linux • Available Hi-Speed USB 2.0 port Installation IMPORTANT: For proper operation, do not connect the Wireless-N USB Adapter to your computer before you install the software. If you do, wait for the Found New Hardware screen to display and click “Cancel”; otherwise, the installation process will likely be adversely affected. Insert the included setup CD in the CD-ROM Drive and start the Setup.exe program. To start the installation, please click on the “USB Wireless 802.11N Drivers” Wait for the installer to run Select Language and click “Next” to continue with the installation . The installer will automatically install the program. When done Select Yes, I want to restart my computer now and click Finish to reboot your computer. With the computer now turned on, insert the Wireless-N USB Adapter into an open USB 2.0 port. With the Welcome to the Found New Hardware Wizard screen displayed (which is automatic when the adapter is connected to the .computer), select the option “No, not this time” and click “Next.” When prompted with “What do you want the wizard to do?” select “Install the software automatically (Recommended)” and click “Next.” A status screen will display, indicating that the installation is in progress. No action is needed at this point. When the Completing the Found New Hardware Wizard screen displays, it indicates that the installation has been successfully completed and your Wireless-N USB Adapter is ready for configuration. Configuration Once the installation is complete, you can configure the Wireless-N USB Adapter to connect to a wireless access point (AP). The wireless configuration utility will start automatically, and you’ll also find a tray icon at the lower right in your Windows systems tray. 1. Right-click the Wireless tray icon and select “Open Config Utility.” 2. The configuration utility will scan for wireless networks within range. Click “Refresh” to refresh the list of available wireless networks. To join a particular network that displays, select it and click “Add to Profile.” 3. If the wireless network uses encryption, you need to input the correct encryption key. The configuration utility automatically suggests the correct authentication type (see the drop-down list), and you should not change the suggested value. NOTE: For WPA/WPA2 networks, you need to select the correct encryption type, as well (AES or TKIP). These settings depend on how the wireless network is set up. Only the owner of the wireless network can provide the required information. *** When you select the TKIP encryption mode, the speed would switch to 802.11g 54M following the TKIP protocol 4. If the wireless access point is successfully connected, you’ll see. NOTE: 1）For advanced settings and additional features of the Wireless-N USB Adapter, refer to the user manual on the enclosed CD. 2）This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC INFORMATION (Additional) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. RF Exposure: The highest measured body SAR value (1g) is: 1.166 W/Kg

Wugu Laboratory, TW1039

Report No.: C130702Z02-RP1 Page 1/1 External Photos of EUT

Label and Location on EUT

Report No.: C130702Z02-RP1 Page 1/2 Internal Photos of EUT Report No.: C130702Z02-RP1 Page 2/2

FCC ID APPLIC PRODU BRAND MODEL CLIENT DATE O STAND REPOR A CAUTIO This rep laborato CATION PUR UCT DESIGN D NAME L NAME T OF ISSUE DARD(S) RT VERSION Attestat ON: port shall n ory and sha SA Rep : RPOSE : NATION : : : : : : : tion of G not be repro all not be q R Te port No.: A NZ3 WS- W Original E Wireless‐ N/A WS‐WN68 Winstars Aug.03, 2 FCC Oet65 IEEE Std. 47CFR § 2 V1.0 Global C oduced exc uoted out o est AGC0086 WN687N Equipment N USB Adap 87N1, WS‐W Technology 013 5 Supplemen 1528‐2003 2.1093 Complia cept in full w of context. Rep 66130701 ter WN699N, WS Limited nt C June 200 ance(Sh without the Repor port 1FH01 ‐WN688N 01 henzhen e written p rt No.:AGC00 t n) Co., L ermission 0866130701 Page 1 Ltd. of the test FH01 of 96 Report No.:AGC00866130701FH01 Page 2 of 96 Report Revise Record Report Version Revise Time Issued Date Valid Version Notes V1.0 / Aug.03, 2013 Valid Original Report Applica Applica Manufa Manufa Product Brand N Model N Differen EUT Vo Applica Te s t Da Te s t Re Perform Report T nt Name nt Address cturer Name cturer Addre t Designatio Name Name nt Descriptio oltage ble Standard ate esults med Location Template Tes W B B a e W ess B B a n W N/ W on A m D d FC IE 47 A M Bo (T em n At 2 G A Docume Check e Authoriz st Rep Winstars Tech lock 4, TaiSo ao'an distric Winstars Tech lock 4, TaiSo ao'an distric Wireless-N U /A WS-WN687N ll the model model is WS- C3.7V by ba CC Oet65 S EEE Std. 152 7CFR 2. ug.02, 2013 MAX SAR ME ody: 0.962 W The EUT has mission befo ttestation of F, Building ushu, Xixian GCRT-US-2 nted By ed By zed By port C hnology Lim ong Industri ct,Shenzhen hnology Lim ong Industri ct,Shenzhen SB Adapter N1, WS-WN6 ls are the s -WN687N1. attery Supplement 28-2003 .1093 3 EASUREME W/Kg s been taken ore the test, fGlobal Com g 2, No.1-N ng Street, B 2G/SAR (20 Vivi Ze Angel a Solger Z Certific mited al Park, DaL , China mited al Park, DaL , China 699N, WS-W ame, only d C June 200 ENT(1g) n into projec the duty cyc mpliance(Sh No.4, Chaxi ao'an Distri c 13-03-01) eng a Li hang Repor cation Lang Street, Lang Street, WN688N different in m 1 ct mode to a cle is 100% enzhen) Co Sanwei Tec ct, Shenzhe Aug.03, 201 Aug.03, 201 Aug.03, 201 rt No.:AGC00 n , LongHua T , LongHua T model name achieve cont when testin o., Ltd. chnical Indu n, China 3 3 3 0866130701 Page 3 Town, Town, es. The test tinuous ng) ustrial Park, FH01 of 96 Report No.:AGC00866130701FH01 Page 4 of 96 TABLE OF CONTENTS 1. GENERAL INFORMATION ............................................................................................................................ 5 1.1. EUT DESCRIPTION ...................................................................................................................................... 5 1.2. TEST PROCEDURE ...................................................................................................................................... 6 1.3. TEST ENVIRONMENT .................................................................................................................................... 6 2. SAR MEASUREMENT SYSTEM ..................................................................................................................... 7 2.1. COMOSAR SYSTEM DESCRIPTION .............................................................................................................. 7 2.2. COMOSAR E-FIELD PROBE ....................................................................................................................... 9 2.3. ROBOT ....................................................................................................................................................... 9 2.4. VIDEO POSITIONING SYSTEM ..................................................................................................................... 10 2.5. DEVICE HOLDER ....................................................................................................................................... 10 2.6. SAM TWIN PHANTOM ................................................................................................................................. 11 3. TISSUE SIMULATING LIQUID ..................................................................................................................... 12 3.1. THE COMPOSITION OF THE TISSUE SIMULATING LIQUID ................................................................................... 12 3.2. TISSUE CALIBRATION RESULT ..................................................................................................................... 13 3.3. TISSUE DIELECTRIC PARAMETERS FOR HEAD AND BODY PHANTOMS .............................................................. 14 4. SAR MEASUREMENT PROCEDURE ......................................................................................................... 15 4.1. SAR SYSTEM VALIDATION .......................................................................................................................... 15 4.2. SAR MEASUREMENT PROCEDURE ............................................................................................................. 17 5. SAR EXPOSURE LIMITS ............................................................................................................................ 18 6. TEST EQUIPMENT LIST ............................................................................................................................. 19 7. MEASUREMENT UNCERTAINTY ................................................................................................................ 20 8. CONDUCTED POWER MEASUREMENT .................................................................................................... 21 9. TEST RESULTS .......................................................................................................................................... 22 9.1. SAR TEST RESULTS SUMMARY ....................................................................................…

Text truncated - open the document above for the full version.

Report No.: C130702Z02-RP1 FCC ID: NZ3WS-WN687N Page 1 / 81 FCC 47 CFR PART 15 SUBPART C for Wireless-N USB Adapter Model: WS-WN687N1,WS-WN699N,WS-WN688N Brand: N/A Test Report Number: C130702Z02-RP1 Issued Date: July 18, 2013 Issued for Winstars Technology Limited Block 4,TaiSong Industrial Park, DaLang Street, LongHua Town, Bao’an district, Shenzhen, China. Issued by: Compliance Certification Services (Shenzhen) Inc. No.10-1 Mingkeda Logistics park, No.18, Huanguan South Rd., Guan Lan Town, Baoan District, Shenzhen, China TEL: 86-755-28055000 FAX: 86-755-28055221 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NVLAP, NIST or any government agencies. The test results in the report only apply to the tested sample. Report No.: C130702Z02-RP1 FCC ID: NZ3WS-WN687N Page 2 / 81 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue No. Revisions Effect Page Revised By 00 C130702Z02-RP1 Initial Issue ALL Sinphy Xie Report No.: C130702Z02-RP1 FCC ID: NZ3WS-WN687N Page 3 / 81 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1 TEST CERTIFICATION.................................................................................................. 4 2 TEST RESULT SUMMARY............................................................................................ 5 3 EUT DESCRIPTION ....................................................................................................... 6 4 TEST METHODOLOGY ................................................................................................. 7 4.1. DESCRIPTION OF TEST MODES ...................................................................................... 7 5 SETUP OF EQUIPMENT UNDER TEST........................................................................ 8 5.1. DESCRIPTION OF SUPPORT UNITS................................................................................. 8 5.2. CONFIGURATION OF SYSTEM UNDER TEST ................................................................. 8 6 FACILITIES AND ACCREDITATIONS .......................................................................... 9 6.1. FACILITIES .......................................................................................................................... 9 6.2. ACCREDITATIONS ............................................................................................................. 9 6.3. MEASUREMENT UNCERTAINTY....................................................................................... 9 7 FCC PART 15.247 REQUIREMENTS.......................................................................... 10 7.1. POWER LINE CONDUCTED EMISSIONS MEASUREMENT........................................... 10 7.2. SPURIOUS EMISSIONS MEASUREMENT....................................................................... 14 7.3. 6dB BANDWIDTH MEASUREMENT ................................................................................. 46 7.4. PEAK OUTPUT POWER ................................................................................................... 54 7.5. BAND EDGES MEASUREMENT....................................................................................... 56 7.6. PEAK POWER SPECTRAL DENSITY MEASUREMENT.................................................. 74 Report No.: C130702Z02-RP1 FCC ID: NZ3WS-WN687N Page 4 / 81 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1 TEST CERTIFICATION Product Wireless-N USB Adapter Model WS-WN687N1,WS-WN699N,WS-WN688N Brand N/A Tested July 2~15, 2013 Applicant Winstars Technology Limited Block 4,TaiSong Industrial Park, DaLang Street, LongHua Town, Bao’an district, Shenzhen, China. Manufacturer Winstars Technology Limited Block 4,TaiSong Industrial Park, DaLang Street, LongHua Town, Bao’an district, Shenzhen, China. APPLICABLE STANDARDS Standard Test Type Standard Test Type 15.207(a) Power Line Conducted Emissions 15.247(d) 15.209(a) z Spurious Emissions z Conducted Measurement z Radiated Emissions 15.247(a)(2) 6dB Bandwidth Measurement 15.247(b)(3) 15.247(b)(4) Peak Power Measurement 15.247(d) Band Edges Measurement 15.247(e) Peak Power Spectral Density We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2009 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.247. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Tom Gan Supervisor of EMC Dept. Compliance Certification Service Inc. Ruby Zhang Supervisor of Report Dept. Compliance Certification Service Inc. Report No.: C130702Z02-RP1 FCC ID: NZ3WS-WN687N Page 5 / 81 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 2 TEST RESULT SUMMARY APPLICABLE STANDARDS Standard Test Type ResultRemark 15.247(a)(2) 6dB Bandwidth Measurement PassMeet the requirement of limit. 15.247(b)(3) 15.247(b)(4) Peak Power Measurement PassMeet the requirement of limit. 15.247(d) Band Edges Measurement PassMeet the requirement of limit. 15.247(e) Peak Power Spectral Density PassMeet the requirement of limit. 15.247(d) 15.209(a) z Spurious Emissions z Conducted Measurement z Radiated Emissions PassMeet the requirement of l…

Text truncated - open the document above for the full version.

Report No.: C130702Z02-RP1 FCC ID: NZ3WS-WN687N Page 1/2 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Report No.: C130702Z02-RP1 FCC ID: NZ3WS-WN687N Page 2/2 . RADIATED EMISSION TEST Below 1GHz Above 1GHz
