O33AR200

Advantra International Flanders Language Valley 90 Tel: +32 (0) 57 221711 8900 IEPER Fax: +32 (0) 57 221700 Belgium  Advantra International Page 1 of 11 ReFLEX is a trademark of Motorola Inc. Publication ref. PTP 232 Issue 2 User manual The AR200  Advantra International Page 2 of 11 ReFLEX is a trademark of Motorola Inc. Amendment List Amendment No. Date Initials CN Number(s) applicable and Remarks Rev 1 28 March 2002 E.O. Rev 1 for FCC documentation ERRORS AND OMISSIONS The usefulness of this publication depends upon its accuracy. Whilst every endeavour has been made to eliminate errors, some may exist, it is therefore requested that any errors or omissions noted be advised as follows. Please quote: Please send to: (a) Title of publication Advantra International (b) Ref No and issue No. Customer Services Manager (c) Last amendment No received Flanders Language Valley 90 (d) Page and/or Fig No In error 8900 Ieper BELGIUM  Advantra International Page 3 of 11 ReFLEX is a trademark of Motorola Inc. Table of Contents 1 PRODUCT DESCRIPTION ............................................................................................................... 4 2 DEVICE CONFIGURATOR ............................................................................................................... 5 2.1 Tabsheet ‘TitlePage’ .................................................................................................................. 5 2.2 Tabsheet ‘Customer’ inspection’ ............................................................................................ 6 2.2.1 Product ID .............................................................................................................................. 6 2.2.2 Build ID ................................................................................................................................... 7 2.2.3 Frequency (Hz) ...................................................................................................................... 7 2.2.4 Checksum0 & Checksum1.................................................................................................... 7 2.2.5 Electronic Serial number .......................................................................................................8 2.2.6 Personal Address .................................................................................................................. 8 2.2.7 Customer reference............................................................................................................... 8 2.2.8 Read button............................................................................................................................ 8 2.3 Menu item ‘File’ .......................................................................................................................... 9 2.4 Menu item ‘Device’..................................................................................................................... 9 2.5 Menu item ‘Test’ ......................................................................................................................... 9 2.5.1 Test / Device status ............................................................................................................... 9 2.5.2 Test / Power calibration .......................................................................................................11 2.6 Menu item ‘Debug’ ...................................................................................................................11 2.7 Menu item ‘Serial port’ ............................................................................................................11 2.8 Menu item ‘Help’.......................................................................................................................11  Advantra International Page 4 of 11 ReFLEX is a trademark of Motorola Inc. 1 PRODUCT DESCRIPTION The Advantra Model AR200 is a Telemetry module. This product is to be compatible with the so- called 2.6 requirements of the ReFLEX specifications. The module has two connections. One connection is the antenna port, the other connection is the data port / power supply. The host device will talk to the module over this data port and will instruct to execute some commands. To use the device on a ReFLEX  network, the device must be configured and this also happens over this data port. To be able to configure the device, a specific windows application exists. More explanations on that windows application ‘Configurator’ can be found in the sections below.  Advantra International Page 5 of 11 ReFLEX is a trademark of Motorola Inc. 2 DEVICE CONFIGURATOR When starting up the software ‘Configurator’ a screen will pop up with a menu bar and two tab sheets. The menu bar has 6 possibilities: File, Device, Test, Debug, Serial Port and Help. The two- tab sheets are Title Page and Customer inspection. In this section all possibilities with this menu’s and tab sheets will be explained. Before operation is possible, check item 2.4 Menu item ‘Device’. 2.1 Tab sheet ‘Title Page’ Depending on who is using the device, a specific configurator exists. There are configurators for development, network providers, service, repair and FCC. The functionality of the device doesn’t change but the number of options available is different. (Example, a customer is not allowed to change the ReFLEX address, no one out of development is allowed to change passwords, ...). On the tab sheet ‘Title Page’ info on the type of configurator is given.  Advantra International Page 6 of 11 ReFLEX is a trademark of Motorola Inc. 2.2 Tab sheet ‘Customer’ inspection’ In the tab sheet ‘customer inspection’ following items can be found. • Product ID • Build ID • Frequency (Hz) • Checksum0 & Checksum1 • Electronic Serial Number • Personal Address • Customer Reference • Read-button 2.2.1 Product ID The Product ID is a four-character ASCII string identifying the product: This …

Text truncated - open the document above for the full version.

Advantra International Flanders Language Valley 90 Tel: +32 (0) 57 221711 8900 IEPER Fax: +32 (0) 57 221700 Belgium  Advantra International Page 1 of 12 ReFLEX is a trademark of Motorola Inc. Publication ref. PTP 232 Issue 2 User manual The AR200  Advantra International Page 2 of 12 ReFLEX is a trademark of Motorola Inc. Amendment List Amendment No. Date Initials CN Number(s) applicable and Remarks Rev 2 02 August 2002 E.O. Rev 2 for FCC documentation ERRORS AND OMISSIONS The usefulness of this publication depends upon its accuracy. Whilst every endeavour has been made to eliminate errors, some may exist, it is therefore requested that any errors or omissions noted be advised as follows. Please quote: Please send to: (a) Title of publication Advantra International (b) Ref No and issue No. Customer Services Manager (c) Last amendment No received Flanders Language Valley 90 (d) Page and/or Fig No In error 8900 Ieper BELGIUM  Advantra International Page 3 of 12 ReFLEX is a trademark of Motorola Inc. Table of Contents 1 PRODUCT DESCRIPTION.............................................................................................................4 2 DEVICE CONFIGURATOR ............................................................................................................5 2.1 Tabsheet ‘TitlePage’ ............................................................................................................... 5 2.2 Tabsheet ‘Customer’ inspection’ .......................................................................................... 6 2.2.1 Product ID ........................................................................................................................... 6 2.2.2 Build ID................................................................................................................................ 7 2.2.3 Frequency (Hz) ................................................................................................................... 7 2.2.4 Checksum0 & Checksum1 ................................................................................................. 7 2.2.5 Electronic Serial number..................................................................................................... 8 2.2.6 Personal Address................................................................................................................8 2.2.7 Customer reference ............................................................................................................ 8 2.2.8 Read button......................................................................................................................... 8 2.3 Menu item ‘File’ ....................................................................................................................... 9 2.4 Menu item ‘Device’ .................................................................................................................. 9 2.5 Menu item ‘Test’ ...................................................................................................................... 9 2.5.1 Test / Device status ............................................................................................................9 2.5.2 Test / Power calibration .................................................................................................... 11 2.6 Menu item ‘Debug’ ................................................................................................................ 11 2.7 Menu item ‘Serial port’.......................................................................................................... 11 2.8 Menu item ‘Help’.................................................................................................................... 11 3,0 Antenna connection, suitable antennas .............................................................................12  Advantra International Page 4 of 12 ReFLEX is a trademark of Motorola Inc. 1 PRODUCT DESCRIPTION The Advantra Model AR200 is a Telemetry module. This product is to be compatible with the so- called 2.6 requirements of the ReFLEX specifications. The module has two connections. One connection is the antenna port, the other connection is the data port / power supply. The host device will talk to the module over this data port and will instruct to execute some commands. To use the device on a ReFLEX network, the device must be configured and this also happens over this data port. To be able to configure the device, a specific windows application exists. More explanations on that windows application ‘Configurator’ can be found in the sections below.  Advantra International Page 5 of 12 ReFLEX is a trademark of Motorola Inc. 2 DEVICE CONFIGURATOR When starting up the software ‘Configurator’ a screen will pop up with a menu bar and two tab sheets. The menu bar has 6 possibilities: File, Device, Test, Debug, Serial Port and Help. The two- tab sheets are Title Page and Customer inspection. In this section all possibilities with this menu’s and tab sheets will be explained. Before operation is possible, check item 2.4 Menu item ‘Device’. 2.1 Tab sheet ‘Title Page’ Depending on who is using the device, a specific configurator exists. There are configurators for development, network providers, service, repair and FCC. The functionality of the device doesn’t change but the number of options available is different. (Example, a customer is not allowed to change the ReFLEX address, no one out of development is allowed to change passwords, ...). On the tab sheet ‘Title Page’ info on the type of configurator is given.  Advantra International Page 6 of 12 ReFLEX is a trademark of Motorola Inc. 2.2 Tab sheet ‘Customer’ inspection’ In the tab sheet ‘customer inspection’ following items can be found. • Product ID • Build ID • Frequency (Hz) • Checksum0 & Checksum1 • Electronic Serial Number • Personal Address • Customer Reference • Read-button 2.2.1 Product ID The Product …

Text truncated - open the document above for the full version.

Advantra International Flanders Language Valley 90 Tel: +32 (0) 57 221711 8900 IEPER Fax: +32 (0) 57 221700 Belgium  Advantra International Page 1 of 13 ReFLEX is a trademark of Motorola Inc. Publication ref. PTP 232 Issue 2 User manual The AR200  Advantra International Page 2 of 13 ReFLEX is a trademark of Motorola Inc. Amendment List Amendment No. Date Initials CN Number(s) applicable and Remarks Rev 3 22 August 2002 E.O. Rev 3 for FCC documentation ERRORS AND OMISSIONS The usefulness of this publication depends upon its accuracy. Whilst every endeavour has been made to eliminate errors, some may exist, it is therefore requested that any errors or omissions noted be advised as follows. Please quote: Please send to: (a) Title of publication Advantra International (b) Ref No and issue No. Customer Services Manager (c) Last amendment No received Flanders Language Valley 90 (d) Page and/or Fig No In error 8900 Ieper BELGIUM  Advantra International Page 3 of 13 ReFLEX is a trademark of Motorola Inc. Table of Contents 1 PRODUCT DESCRIPTION.............................................................................................................4 2 DEVICE CONFIGURATOR ............................................................................................................5 2.1 Tabsheet ‘TitlePage’ ............................................................................................................... 5 2.2 Tabsheet ‘Customer’ inspection’ .......................................................................................... 6 2.2.1 Product ID ........................................................................................................................... 6 2.2.2 Build ID................................................................................................................................ 7 2.2.3 Frequency (Hz) ................................................................................................................... 7 2.2.4 Checksum0 & Checksum1 ................................................................................................. 7 2.2.5 Electronic Serial number..................................................................................................... 8 2.2.6 Personal Address................................................................................................................8 2.2.7 Customer reference ............................................................................................................ 8 2.2.8 Read button......................................................................................................................... 8 2.3 Menu item ‘File’ ....................................................................................................................... 9 2.4 Menu item ‘Device’ .................................................................................................................. 9 2.5 Menu item ‘Test’ ...................................................................................................................... 9 2.5.1 Test / Device status ............................................................................................................9 2.5.2 Test / Power calibration .................................................................................................... 11 2.6 Menu item ‘Debug’ ................................................................................................................ 11 2.7 Menu item ‘Serial port’.......................................................................................................... 11 2.8 Menu item ‘Help’.................................................................................................................... 11 3,0 Antenna connection, suitable antennas and RF safety ..................................................12  Advantra International Page 4 of 13 ReFLEX is a trademark of Motorola Inc. 1 PRODUCT DESCRIPTION The Advantra Model AR200 is a Telemetry module. This product is to be compatible with the so- called 2.6 requirements of the ReFLEX specifications. The module has two connections. One connection is the antenna port, the other connection is the data port / power supply. The host device will talk to the module over this data port and will instruct to execute some commands. To use the device on a ReFLEX network, the device must be configured and this also happens over this data port. To be able to configure the device, a specific windows application exists. More explanations on that windows application ‘Configurator’ can be found in the sections below.  Advantra International Page 5 of 13 ReFLEX is a trademark of Motorola Inc. 2 DEVICE CONFIGURATOR When starting up the software ‘Configurator’ a screen will pop up with a menu bar and two tab sheets. The menu bar has 6 possibilities: File, Device, Test, Debug, Serial Port and Help. The two- tab sheets are Title Page and Customer inspection. In this section all possibilities with this menu’s and tab sheets will be explained. Before operation is possible, check item 2.4 Menu item ‘Device’. 2.1 Tab sheet ‘Title Page’ Depending on who is using the device, a specific configurator exists. There are configurators for development, network providers, service, repair and FCC. The functionality of the device doesn’t change but the number of options available is different. (Example, a customer is not allowed to change the ReFLEX address, no one out of development is allowed to change passwords, ...). On the tab sheet ‘Title Page’ info on the type of configurator is given.  Advantra International Page 6 of 13 ReFLEX is a trademark of Motorola Inc. 2.2 Tab sheet ‘Customer’ inspection’ In the tab sheet ‘customer inspection’ following items can be found. • Product ID • Build ID • Frequency (Hz) • Checksum0 & Checksum1 • Electronic Serial Number • Personal Address • Customer Reference • Read-button 2.2.1 Product ID The Product ID is a four-…

Text truncated - open the document above for the full version.

FCC ELECTRONIC FILING FAO: Bette Tabue 23 May 2002 Our File Ref: 2H5618 Dear Sir, Please find enclosed the FCC 731 form and supporting documentation submitted on behalf of our client Advantra Internatio nal for the original type approval filing of the AR200 Telemetry Module in the USA. All product test data for the AR200 can be found on the CTMS Ltd test report CTMS 2002/2234 (also attached) In advance of the application I have already requested that the following monies are paid to the MELLON BANK on behalf of Advantra (I have attached a copy of the bank request transactio n Form 159) $940USD for a licensed Module device approval If any problems should arise with this documentation, please co ntact me in o ur Hull office on phone: +44 1482 801801, fax: +44 1482 801806 or email: [email protected] Should you have any queries regarding the above then please do not hesitate to contact me. Yo urs f aithf ully Gary Slater Approvals Specialist [email protected] Enclosure

LETTER EXHIBIT: TO CHANGE CONTACT DETAILS FOR THE APPROVAL OF THE AR200 IN THE USA Recipient of Certificate: Oliver Dykmans Tel Number: + 32 22 17 10 Fax Number: + 32 22 17 00 Advant ra I nter natio na l Flanders Language Valley 90, Ieper, 8900, Belgium Email: [email protected] Technical Contact: Luc Van Asch or Frédéric Boes Engineer Advant ra I nter natio na l Flanders Language Valley 90 B-8900 Ieper Belgium +32 57 22 17 82 Email: [email protected] Non Technical Contact: Gary Slater KTL Saxon Way Priory Park West Kingsto n upo n H ull HU13 9PB UK Tel: +44(0)1482 801801 Fax: +44(0)1482 801806 E-mail: [email protected] Mobile: +44 07802 280 914

COVER LETTER /REQUEST FOR CONFIDENTIALITY What’s allowed on the FCC website Advantra would like to have confidentiality on the FCC website for the following items: • Schematic • PCB layouts (component and copper layouts)

EQUIPMENT : AR200 TEST REPORT NUMBER: CTMS 2002/2234 FCC Identifier : O33AR200 CTMS FCC Registration Number : 93385 Page 1 of 45 CTMS Ltd. 3 Cardinal Park Godmanchester Huntingdon Cambridgeshire PE29 2XN TEST REPORT ON AR200 UHF Reflex Telemetry Module FCC Authorization Procedures Part 2 subpart J, Part 90, and Part 24 TEST REPORT NUMBER CTMS 2002/2234 April 2002 Prepared for: Advantra International Flanders Language Valley 90, 8900 - Ieper, Belgium This results in this report refer to the tested unit only EQUIPMENT : AR200 TEST REPORT NUMBER: CTMS 2002/2234 FCC Identifier : O33AR200 CTMS FCC Registration Number : 93385 Page 2 of 45 Certificate of Test Cambridge Test and Measurement Services Ltd., certifies that the product listed was fully tested to the relevant sections of Parts 2, 90, and 24 of the FCC Code of Regulations 47CFR, the results of which are contained in this test report No: CTMS 2002/2234 Advantra AR200 I certify that the application was prepared under my supervision and that to the best of my knowledge and belief, the facts set forth in this application and technical data, are true and correct. Signature : Date : 25/03/02 Name : David Fisher Title : Radio Technical Manager EQUIPMENT : AR200 TEST REPORT NUMBER: CTMS 2002/2234 FCC Identifier : O33AR200 CTMS FCC Registration Number : 93385 Page 3 of 45 General Test Information Date Test Sample Received : 19 th March 2002 Date Testing Started : 19 th March 2002 Date Testing Finished : 20 th March 2002 Equipment Serial Number : A900 000 06006 / 000YB CTMS Project Number : 2002/2234 Test Engineer : M. Billis Report Copy No. 1 EQUIPMENT : AR200 TEST REPORT NUMBER: CTMS 2002/2234 FCC Identifier : O33AR200 CTMS FCC Registration Number : 93385 Page 4 of 45 TABLE OF CONTENTS PAGE No Part 2.1033 Application for Certification 5 2.1046 RF Power Output at terminals 6 2.1049 (1) Occupied Bandwidth 10 2.1051 Spurious emissions at antenna terminals 18 2.1053 Field Strength of spurious radiation 29 2.1053 (a) (1) Frequency Stability with temperature variation 34 2.1053 (d) (1) Frequency Stability with primary voltage variation 36 2.1057 Frequency spectrum to be investigated 38 General Information and Attachments : Photographs of Equipment 34 Company Accreditations & Credentials 38 EQUIPMENT : AR200 TEST REPORT NUMBER: CTMS 2002/2234 FCC Identifier : O33AR200 CTMS FCC Registration Number : 93385 Page 5 of 45 2.1033 Application for Certification For use in accordance with FCC Rules and Regulations 47 CFR parts 2, 90, and part 24. 2.1033 (c) (1) Name of applicant : Advantra Address of applicant : Advantra International, Flanders Language Valley, 8900 - Ieper, Belgium Contact : Frédéric Boes / Luc Van Asch / Els Ollevier 2.1033 (c) (2) FCC Identifier : Model Type Number : AR200 2.1033 (c) (3) Installation and operating instructions : User Guide, see appropriate exhibit 2.1033 (c) (4) Type(s) of emission : Direct FSK, 12K5F1D -- 2.1033 (c) (5) Frequency range : 929.000 - 942.000 MHz (RX) 896.000 - 902.000 MHz (TX) 2.1033 (c) (6) Output power range : 0.06 W - 1.92 W 2.1033 (c) (7) Maximum power rating : 1.92 W 2.1033 (c) (8) dc voltage applied to power amplifier : 5.0 V dc current to power amplifier : 1.4 A 2.1033 (c) (9) Tune-up procedure for RF power : n/a EQUIPMENT : AR200 TEST REPORT NUMBER: CTMS 2002/2234 FCC Identifier : O33AR200 CTMS FCC Registration Number : 93385 Page 6 of 45 RF Power Output at Antenna terminals - 47 CFR 2.1046(a) The transmitter is operated under standard test conditions, using the standard test voltage, with the transmitter, tuned in accordance with the procedure described in the accompanying documentation. The transmitter was keyed in an unmodulated condition and the output was connected to a spectrum analyser, with resolution and video bandwidths set to 3 MHz and 30 Hz respectively, the RF power output was observed and recorded, accounting for the loss of the cable and the attenuator. The RF Power Output was measured in accordance with the following test configuration, using the test instruments listed. (Calibrated items are indicated in Blue) Test instruments used : RF Spectrum Analyser : Advantest type R3271 RF Attenuator : Bird type 25-A-MFN-10 Results in accordance with Part 2.1046(a) Power and emissions TRANSMITTER OUTPUT POWER 896.000 MHz 899.000 MHz 902.000 MHz Analyser reading 21.96 dBm 22.08 dBm 22.11 dBm Cable and attenuator loss 10.66 dB 10.75 dB 10.69 dB Result 32.62 dBm 32.83 dBm 32.80 dBm Result (Watts) 1.83 1.92 1.91 EUT 10 dB attenuator Spectrum Analyser EQUIPMENT : AR200 TEST REPORT NUMBER: CTMS 2002/2234 FCC Identifier : O33AR200 CTMS FCC Registration Number : 93385 Page 7 of 45 RF Power Output at Antenna terminals - 47 CFR 2.1046(a) dBm 32 22 12 2 -8 -18 -28 -38 -48 -58 -68 SoftPlot Measurement Presentation Trace A Start: 892.000000 MHzStop: 900.000000 MHz Res BW: 3 MHzVid BW: 30 HzSweep: 180 ms 20/03/02 10:17:110FILE_001.SPT 896.000 MHz with 10dB external attenuator in line. EQUIPMENT : AR200 TEST REPORT NUMBER: CTMS 2002/2234 FCC Identifier : O33AR200 CTMS FCC Registration Number : 93385 Page 8 of 45 RF Power Output at Antenna terminals - 47 CFR 2.1046(a) dBm 32 22 12 2 -8 -18 -28 -38 -48 -58 -68 SoftPlot Measurement Presentation Trace A Start: 895.000000 MHzStop: 903.000000 MHz Res BW: 3 MHzVid BW: 30 HzSweep: 180 ms 20/03/02 10:22:49FILE_002.SPT 899.000 MHz with 10dB external attenuator in line. EQUIPMENT : AR200 TEST REPORT NUMBER: CTMS 2002/2234 FCC Identifier : O33AR200 CTMS FCC Registration Number : 93385 Page 9 of 45 RF Power Output at Antenna terminals - 47 CFR 2.1046(a) dBm 32 22 12 2 -8 -18 -28 -38 -48 -58 -68 SoftPlot Measurement Presentation Trace A Start: 898.000000 MHzStop: 906.000000 MHz Res BW: 3 MHzVid BW: 30 HzSweep: 180 ms 20/03/02 10:21:30FILE_003.SPT 902.000 MHz with 10dB external attenuator in line. EQUIPMENT : AR200 TEST REPORT NUMBER: CTMS 2002/2234 FCC Identifier : O33AR200 CTMS…

Text truncated - open the document above for the full version.

LABEL INFO : AR200 FCC ID : O33AR200 TESTED TO COMPLY WITH FCC STANDARD FOR PART 2, PART 15, PART 24 AND PART 90 ||||||||||||||||| 12A57 FREQUENCY: 929.6625 Mhz REFLEX ADDRESS: 0018998472

LABEL INFO : AR200 FCC ID : O33AR200 TESTED TO COMPLY WITH FCC STANDARD FOR PART 2, PART 15, PART 24 AND PART 90 ||||||||||||||||| 12A57 FREQUENCY: 929.6625 Mhz Safety distance REFLEX ADDRESS: 0018998472 antenna : 20 cm

EQUIPMENT : AR200 TEST REPORT NUMBER: CTMS 2002/2234 FCC Identifier : O33AR200 CTMS FCC Registration Number : 93385 Page 1 of 45 CTMS Ltd. 3 Cardinal Park Godmanchester Huntingdon Cambridgeshire PE29 2XN TEST REPORT ON AR200 UHF Reflex Telemetry Module FCC Authorization Procedures Part 2 subpart J, Part 90, and Part 24 TEST REPORT NUMBER CTMS 2002/2234 April 2002 Prepared for: Advantra International Flanders Language Valley 90, 8900 - Ieper, Belgium This results in this report refer to the tested unit only EQUIPMENT : AR200 TEST REPORT NUMBER: CTMS 2002/2234 FCC Identifier : O33AR200 CTMS FCC Registration Number : 93385 Page 2 of 45 Certificate of Test Cambridge Test and Measurement Services Ltd., certifies that the product listed was fully tested to the relevant sections of Parts 2, 90, and 24 of the FCC Code of Regulations 47CFR, the results of which are contained in this test report No: CTMS 2002/2234 Advantra AR200 I certify that the application was prepared under my supervision and that to the best of my knowledge and belief, the facts set forth in this application and technical data, are true and correct. Signature : Date : 25/03/02 Name : David Fisher Title : Radio Technical Manager EQUIPMENT : AR200 TEST REPORT NUMBER: CTMS 2002/2234 FCC Identifier : O33AR200 CTMS FCC Registration Number : 93385 Page 3 of 45 General Test Information Date Test Sample Received : 19 th March 2002 Date Testing Started : 19 th March 2002 Date Testing Finished : 20 th March 2002 Equipment Serial Number : A900 000 06006 / 000YB CTMS Project Number : 2002/2234 Test Engineer : M. Billis Report Copy No. 1 EQUIPMENT : AR200 TEST REPORT NUMBER: CTMS 2002/2234 FCC Identifier : O33AR200 CTMS FCC Registration Number : 93385 Page 4 of 45 TABLE OF CONTENTS PAGE No Part 2.1033 Application for Certification 5 2.1046 RF Power Output at terminals 6 2.1049 (1) Occupied Bandwidth 10 2.1051 Spurious emissions at antenna terminals 18 2.1053 Field Strength of spurious radiation 29 2.1053 (a) (1) Frequency Stability with temperature variation 34 2.1053 (d) (1) Frequency Stability with primary voltage variation 36 2.1057 Frequency spectrum to be investigated 38 General Information and Attachments : Photographs of Equipment 34 Company Accreditations & Credentials 38 EQUIPMENT : AR200 TEST REPORT NUMBER: CTMS 2002/2234 FCC Identifier : O33AR200 CTMS FCC Registration Number : 93385 Page 5 of 45 2.1033 Application for Certification For use in accordance with FCC Rules and Regulations 47 CFR parts 2, 90, and part 24. 2.1033 (c) (1) Name of applicant : Advantra Address of applicant : Advantra International, Flanders Language Valley, 8900 - Ieper, Belgium Contact : Frédéric Boes / Luc Van Asch / Els Ollevier 2.1033 (c) (2) FCC Identifier : Model Type Number : AR200 2.1033 (c) (3) Installation and operating instructions : User Guide, see appropriate exhibit 2.1033 (c) (4) Type(s) of emission : Direct FSK, 12K5F1D -- 2.1033 (c) (5) Frequency range : 929.000 - 942.000 MHz (RX) 896.000 - 902.000 MHz (TX) 2.1033 (c) (6) Output power range : 0.06 W - 1.92 W 2.1033 (c) (7) Maximum power rating : 1.92 W 2.1033 (c) (8) dc voltage applied to power amplifier : 5.0 V dc current to power amplifier : 1.4 A 2.1033 (c) (9) Tune-up procedure for RF power : n/a EQUIPMENT : AR200 TEST REPORT NUMBER: CTMS 2002/2234 FCC Identifier : O33AR200 CTMS FCC Registration Number : 93385 Page 6 of 45 RF Power Output at Antenna terminals - 47 CFR 2.1046(a) The transmitter is operated under standard test conditions, using the standard test voltage, with the transmitter, tuned in accordance with the procedure described in the accompanying documentation. The transmitter was keyed in an unmodulated condition and the output was connected to a s…
