O63GH9702DLD022.4GHz Digital Cordless Phone System

3 Confidential 1. Introduction This document presents the functional specification of a Multi-Handset, Digital 2.4 GHz Frequency Code Division Spread Spectrum Basic Cordless phone system with Type II Caller ID. 2. System Features • Basic 2.4 GHz Code Division Spread Spectrum cordless telephone • 1 telephone line • Multi-Handset system (support up to 9 handsets) • Multi-Base system (handset can register up to 2 base) • 77 channels Autohop • 2 line, 14 character Caller ID display, 7-segment time and date, including icons max. of 18 characters on the Letter Icon and a max. of 22 digits on the Number Icon • 40 Caller Log Memory • 40 numbers telephone book (Name and Number) with priority setting • Caller ID Callback Function • Caller ID and Caller ID on Call Waiting (CIDCW) • Intercom Call between Handsets • One-touch Caller ID Call Record review • One-touch Outgoing Call Record review • Menu system with sub-levels • 2 Ringer Levels on Handset (high, low) • 3 Volume Levels on Handset (high, mid, low) • 6 Ringer Melody Settings • Username • Flash, Redial, Pause • Headset jack • Displaying Name, Number, Date and Time • Out of Range Indication • Call Waiting Indication • Battery Low Indication • Preferred Calls • Blocked Calls • Backlit LCD Display • Standby time – 80 hours • Talk time – 4 hours • 3 Language Selectable • New Call Indication • Call Counter 4 Confidential 3.0 Mechanical Layout The product comprises a cordless handset and a base unit. The handset contains the following keys: 1 7: PRS 2: ABC 8: TUV 3: DEF 9: WXY 4: GHI 0: OPER 5: JKL * 6: MNO #/OPTION button TALK button SAVE/RE/PA button (Save/Redial/Pause) UP, DOWN, and RIGHT, LEFT buttons DEL/INT button (Delete/Intercom) FLASH/EDIT button MENU/VOLUME button DIR/EXIT button The base unit has a PAGE button. The above-mentioned buttons create the ability for the user to operate the telephone.

Block 2 Laodong 2nd Industria Area, Xixian, Baoan, Shenzhen, China Tel.: 86-755-7917824/ 86-755-7902415, Fax: 86-755-7917944 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: O63GH9702DLD02 . Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: • Schematics • Block Diagram The above documents contain information for new 2.4 GHz DSS (Cordless Telephone) technology and ideas, so we would like to prevent the use of this information by other companies. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Dan Coronia

Lionda Technology Company Limited FCC ID: O63GH9702DLD02 Report # R0206054 FCC Part 15.247 Test Report EUT EXTERNAL PHOTOGRAPHS EUT - Adpater View Base - Top View Lionda Technology Company Limited FCC ID: O63GH9702DLD02 Report # R0206054 FCC Part 15.247 Test Report Base - Bottom View Handset - Top View Lionda Technology Company Limited FCC ID: O63GH9702DLD02 Report # R0206054 FCC Part 15.247 Test Report Handset - Back View

Lionda Technology Company Limited FCC ID: O63GH9702DLD02 Report # R0206054 FCC Part 15.247 Test Report FCC ID Label Specifications: Text is black or white in color and is left justified. Labels are silk-screened and shall be “permanently affixed” at a conspicuous location on the EUT. FCC ID: O63GH9702DLD02

Lionda Technology Company Limited FCC ID: O63GH9702DLD02 Report # R0206054 FCC Part 15.247 Test Report Proposed Label Location on EUT Bottom Side of Base/Proposed FCC ID Back Side of Handset/Proposed FCC ID

Lionda Technology Company Limited FCC ID: O63GH9702DLD02 Report # R0206054 FCC Part 15.247 Test Report EUT INTERNAL PHOTOGRAPHS Base - Main Board Component View Base - Main Board Solder View Lionda Technology Company Limited FCC ID: O63GH9702DLD02 Report # R0206054 FCC Part 15.247 Test Report Base - Transceiver Component View Base - Transceiver Solder View Lionda Technology Company Limited FCC ID: O63GH9702DLD02 Report # R0206054 FCC Part 15.247 Test Report Handset - Main Board Component View Handset - Main Board Solder View Lionda Technology Company Limited FCC ID: O63GH9702DLD02 Report # R0206054 FCC Part 15.247 Test Report Handset - Transceiver Component View Handset - Transceiver Component View

5 Confidential 4.1 Ringer on Handset The user has the ability to select two types of ringer levels for the handset by using the Phone Menu Setup. • Ringer Level Low • Ringer Level High 4.1.1 Ringer Tones The handset is equipped with six kinds of ringer tones. Select the desired ringer tone using the Phone Menu Setup. The handset will play a sample sound when toggling from one tone to another. 4.2 Charging Charging is initiated when the handset is placed in the base unit cradle. The “charge” LED on the base unit turns on while the handset is charging. It will turn off when the handset is removed from the cradle. 4.3 Line Detection from the base unit The system will detect if a parallel phone is off-hook or if no line is connected. The following situation applies for the base unit LED: 1. Idle-line: The LED is off. 2. Handset linking to Base: The LED is blinking 1/2 sec. on and 1/2 sec. off. 3. Line in use: The LED is on. In situations 2 and 3, it is not possible to hook off the line. 4.4 The LCD Icons The LCD Screen has four displays that show the following: • 1 st line: Left arrow, Phone Off/On hook, Private Call, Battery, Long Distance Call (LDC), Call Forward (CF), Phonebook, Host Base (B1), Extension Base (B2), and Right arrow icons • 2 nd line: a 5x7, 14 characters display for the Name icon. • 3 rd line: a 5x7, 14 digits display for the Number icon. • 4 th line: a 7-segment line containing the Time, Date, Number and Total Call Indicator, New, and Repeat Call icons. 4.4.1 Left Arrow Icon ( ) This icon pops up to indicate that a left part of the record is not displayed. Press the SHIFT LEFT button to view the leftmost data. 4.4.2 Off-Hook/On-Hook Icon ( ) The Phone On-hook icon pops up when all handsets enrolled in the base unit is in Standby mode. The Phone Off-hook icon pops up when one handset opens a link to the base unit and seize the telephone line. AM PM TOTAL RPT NEW # 6 Confidential 4.4.3 Battery Icon ( ) This symbol will show the status of the battery in three status: • Low Battery level (2 bars blinking) • During Charging (4 bars growing) • Battery full (4 bars shown) 4.4.4 Long Distance Call Indicator Icon (L-D-C) This icon pops up when the Incoming call is a Long Distance Call and the service is provided by your local telephone company. 4.4.5 Call Forward Indicator Icon (C-F) This icon pops up when the Incoming call has been assigned to your telephone number. 4.4.6 Phonebook Icon ( ) This icon pops up when reviewing the directory records or when a directory record is being displayed. 4.4.7 Host/Extension Base Icon ( B1 B2 ) This symbol will show to which base unit does the handset is currently using. All handsets enrolled to the Host base can alter the Phone Menu setup, Caller ID records, and the Directory records but they cannot make any alteration from the Extension Base setting except to open link and make/receive a call. 4.4.8 Right Arrow Icon ( ) This icon pops up to indicate that the record name or number currently displayed has more than 14 characters or digits. Press the SHIFT RIGHT button to view the other data. 4.4.9 Time Icon Shows the current time during Standby, Intercom and Talk mode. When browsing the Caller list, it shows the time tag of the Caller ID record. 4.4.10 Date Icon When browsing the Caller list, it shows the date tag of the Caller ID record. 4.4.11 New Icon (NEW) The new icon will appear if the currently displayed incoming Caller ID record is unread when any of the enrolled handset is browsing the Call Log. 4.4.12 Repeat Icon (RPT) The repeat icon will appear if the currently displayed incoming Caller ID record has called twice or more. 4.4.13 Counter Icon Shows the handset ID number during standby. Shows the call duration during Talk and Intercom mode. It shows the number of the Record when browsing the Call Log or the Directory. 7 Confidential 4.5 Handset Status Display When the handset is not in operation, the handset will show the standby display. If present, the user name is shown together with the number of new calls received. Handset ID Number AM # USER NAME NEW CALL:_ _ When the handset is placed in the base unit charge cradle, the handset is automatically in the standby mode and is capable of receiving a call. When the handset is taken off the base unit, it remains in the standby mode until the TALK button is activated. If a private page is received, a page tone will be heard and the LCD display will show: Handset ID Number AM # SOURCE NAME IS PAGING YOU If the telephone line is engaged by any other handset of the system, the display will show: AM # USER NAME PHONE IN USE The OFF-HOOK icon is blinkin g at 1 sec. on/ 1 sec. off 4.6 Outgoing Call to External Line The call can be initiated by pressing the TALK button before the number is dialed. After pressing the TALK button, the handset will open a link to the Host base unit, the phone OFF-HOOK icon will be blinking and the LCD screen will display: AM # CONNECTING... Once the connection is established, the Off-hook, Call Timer icons will pop up and the handset LCD display will show: AM # TAL K IN G .. . Call Timer Dial the telephone number using the keys 0-9, *, and # then the call will be send out. When one handset has already gain access to the Host base, all the other handsets cannot link anymore. They can have the option to make a call by linking to the Extension base. 4.7 Receiving an Incoming Call When a call arrives, all the handsets enrolled to the Host base will ring with the ring pattern and level selected by the user. The first handset to open link to the Host base will get the call. If Caller ID information is available, the handset will display the CID information on the screen. The date/time stamp from the Caller ID data will automatically update the handset clock. If the caller’s name and/or telephone number is blocked, “PRIVATE” and/or “P--- --- ---“ will appear in the 1 st line. 8 Confidential AM # PRIVATE If the origin of the incoming call does not support the Caller ID …

Text truncated - open the document above for the full version.

Note: This test report is specially limited to the above client company and the product model only. It may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. FCC PART 15 Subpart C EMI MEASUREMENT AND TEST REPORT For Lionda Technology Company Limited Block 2 Laodong 2 nd Industrial Area, Xixian, Baoan, Shenzhen, Guangdong, China 518102 FCC ID: O63GH9702DLD02 July 29, 2002 This Report Concerns: Original Report Equipment Type: 2.4GHz Digital Cordless Telephone System - Household Appliances Test Engineer: Benjamin Jin Report Number: R0206054 Test Date: June 20, 2002 Reviewed By: Jeff Lee Prepared By: Bay Area Compliance Laboratory Corporation 230 Commercial Street Sunnyvale, CA 94085 Tel: (408) 732-9162 Fax: (408) 732 9164 Lionda Technology Company Limited FCC ID: O63GH9702DLD02 Report # R0206054Rpt Page 2 of 34 FCC Part 15.247 Test Report TABLE OF CONTENTS 1 - GENERAL INFORMATION..................................................................................................................................4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..............................................................................4 1.2 OBJECTIVE.............................................................................................................................................................4 1.3 RELATED SUBMITTAL(S)/GRANT(S).......................................................................................................................4 1.4 TEST METHODOLOGY............................................................................................................................................4 1.5 TEST FACILITY.......................................................................................................................................................4 1.6 TEST EQUIPMENT LIST...........................................................................................................................................5 1.7 LOCAL SUPPORT EQUIPMENT.................................................................................................................................5 1.8 POWER SUPPLY AND LINE FILTERS OF EUT...........................................................................................................5 1.9 EXTERNAL I/O CABLING LIST AND DETAILS.........................................................................................................6 2 - SYSTEM TEST CONFIGURATION.....................................................................................................................7 2.1 DESCRIPTION OF TEST CONFIGURATION................................................................................................................7 2.2 EQUIPMENT MODIFICATIONS.................................................................................................................................7 2.3 CONFIGURATION OF TEST SYSTEM.........................................................................................................................8 2.4 TEST SETUP BLOCK DIAGRAM...............................................................................................................................8 3 - SUMMARY OF TEST RESULTS..........................................................................................................................9 4 - CONDUCTED OUTPUT POWER MEASUREMENT......................................................................................10 4.1 STANDARD APPLICABLE......................................................................................................................................10 4.2 MEASUREMENT PROCEDURE................................................................................................................................10 4.3 MEASUREMENT RESULT......................................................................................................................................10 5 - 6 DB BANDWIDTH...............................................................................................................................................13 5.1 STANDARD APPLICABLE......................................................................................................................................13 5.2 MEASUREMENT PROCEDURE................................................................................................................................13 5.3 MEASUREMENT DATA..........................................................................................................................................13 6 - SPURIOUS EMISSION.........................................................................................................................................16 6.1 STANDARD APPLICABLE......................................................................................................................................16 6.2 MEASUREMENT PROCEDURE................................................................................................................................16 6.3 MEASUREMENT DATA..........................................................................................................................................16 7 - 100 KHZ BANDWIDTH OF BAND EDGES MEASUREMENT......................................................................19 7.1 STANDARD APPLICABLE......................................................................................................................................19 7.2 MEASUREMENT PROCEDURE................................................................................................................................19 7.3 TEST RESULTS.....................................................................................................................................................19…

Text truncated - open the document above for the full version.

Note: This test report is specially limited to the above client company and the product model only. It may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. FCC PART 15 Subpart C EMI MEASUREMENT AND TEST REPORT For Lionda Technology Company Limited Block 2 Laodong 2 nd Industrial Area, Xixian, Baoan, Shenzhen, Guangdong, China 518102 FCC ID: O63GH9702DLD02 July 29, 2002 This Report Concerns: Original Report Equipment Type: 2.4GHz Digital Cordless Telephone System - Household Appliances Test Engineer:Benjamin Jin Report Number:R0206054 Test Date:June 20, 2002 Reviewed By:Jeff Lee Prepared By:Bay Area Compliance Laboratory Corporation 230 Commercial Street Sunnyvale, CA 94085 Tel: (408) 732-9162 Fax: (408) 732 9164 Lionda Technology Company Limited FCC ID: O63GH9702DLD02 Report # R0206054 Page 2 of 48 FCC Part 15.247 Test Report TABLE OF CONTENTS 1 - GENERAL INFORMATION.................................................................................................................................................4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT).........................................................................................4 1.2 OBJECTIVE................................................................................................................................................................................4 1.3 RELATED SUBMITTAL(S)/GRANT(S)......................................................................................................................................4 1.4 TEST METHODOLOGY.............................................................................................................................................................4 1.5 TEST FACILITY.........................................................................................................................................................................4 1.6 TEST EQUIPMENT LIST............................................................................................................................................................5 1.7 LOCAL SUPPORT EQUIPMENT................................................................................................................................................5 1.8 POWER SUPPLY AND LINE FILTERS OF EUT........................................................................................................................5 1.9 EXTERNAL I/O CABLING LIST AND DETAILS......................................................................................................................6 2 - SYSTEM TEST CONFIGURATION..................................................................................................................................7 2.1 DESCRIPTION OF TEST CONFIGURATION..............................................................................................................................7 2.2 EQUIPMENT MODIFICATIONS.................................................................................................................................................7 2.3 CONFIGURATION OF TEST SYSTEM.......................................................................................................................................8 2.4 TEST SETUP BLOCK DIAGRAM..............................................................................................................................................8 3 - SUMMARY OF TEST RESULTS........................................................................................................................................9 4 - CONDUCTED OUTPUT POWER MEASUREMENT................................................................................................10 4.1 STANDARD APPLICABLE.......................................................................................................................................................10 4.2 MEASUREMENT PROCEDURE...............................................................................................................................................10 4.3 MEASUREMENT RESULT.......................................................................................................................................................10 5 - 6 DB BANDWIDTH................................................................................................................................................................13 5.1 STANDARD APPLICABLE.......................................................................................................................................................13 5.2 MEASUREMENT PROCEDURE...............................................................................................................................................13 5.3 MEASUREMENT DATA..........................................................................................................................................................13 6 - SPURIOUS EMISSION.........................................................................................................................................................16 6.1 STANDARD APPLICABLE.......................................................................................................................................................16 6.2 MEASUREMENT PROCEDURE...............................................................................................................................................16 6.3 MEASUREMENT DATA..........................................................................................................................................................16 7 - 100 KHZ BANDWIDTH OF BAND EDGES MEASUREMENT..............................................................................19 7.1 STANDARD APPLICABLE..................................…

Text truncated - open the document above for the full version.
