O63GH9762DLD02Spread Spectrum Cordless Phone

Multi-HANDSET, Multi-BASE UNIT 2.4GHz Digital Spread Spectrum Technology CORDLESS ALL DIGITAL ANSWERING SYSTEM WITH CALLER ID/CALL WAITING 77 CHANNEL AUTOHOP Model GH9762 OWNER’S MANUAL INSTALLATION AND OPERATING INSTRUCTIONS PLEASE READ THIS MANUAL CAREFULLY BEFORE USE. KEEP FOR YOUR REFERENCE. For installation information, please see “Getting Started” instructions on page 6 or your separate Quick Start guide. Visit Us on the Web: www.uselectronics.info © 2002 BellSouth Corporation S PE AK ER P A G E M EM O TIM E C OD E O G M E RA SE O N /OF F AN SW ER RP T SK IP S TO P VO L+ VO L- P L AY SP EA KE R IN USE / AN S. ON /O FF C HA RG E d s s DSST~MAN4~9762.qxd 11/12/2002 2:46 PM Page 1 Special Features ongratulations on your selection of a quality BellSouth Product. With proper care and adherence to the set-up and user instructions in this Owner's Manual, this unit will provide you with years of trouble-free service. BellSouthis committed to providing quality products that fit your needs. We would like to have any comments or suggestions you might have on this product. You may mail your comments to: U.S. Electronics 105 Madison Avenue New York, NY 10016 When examining your new BellSouth cordless telephone, you will find an array of special features including: Digital Spread Spectrum Technology - Utilizes a “wider frequency band” for a more secure conversation with a clarity of digital sound, extended range, and minimal interference from other cordless telephone. 77 Channel Auto-hop- When interference is received, the telephone automatically hops to the clearest channel. Desk or Wall Mount- Use this equipment as a desk phone or as a wall phone. Tone or Pulse Dialing- Use this phone for either TONE (push-button) or PULSE (rotary) dialing. Automated Functions - Redial the last number called and automatic STANDBY mode. Security- Ensures greater privacy because of a built-in security code with 4,000,000 possible combinations that prevents use of your telephone line by another nearby cordless phone. Special Services- Use the button to access special services such as Call Waiting supplied by your telephone company or company switchboard. STANDBY Mode- When in STANDBY mode (ON-HOOK), the phone is capable of receiving a call. When the HANDSETis on the BASE UNIT, it is automatically in the STANDBY mode (ON- HOOK). When the HANDSETis taken off the BASE UNIT, it remains in the STANDBY mode until you activate the button. Battery Power Saver- Recharge your BATTERYPACK many times with the built-in CHARGER. Once fully charged, in STANDBY mode, the HANDSET can receive/send calls for a maximum of five days without the need for recharging. Length of charge depends on frequency of use. Luminous LCD Screen- The LCD Screen emits light for 5 seconds everytime you press any of the TELEPHONE KEYPAD button. HANDSET Ringer Level- Select the ringer sound level (HI, LOW, OFF). HANDSET Ringer Melody- Select the desired ringer melody from the 10 available melodies. HANDSET Volume Control- Press the /MENU buttonand thenselect the desired receiver volume setting from Low, Medium, High, or Maximum. Alarm Clock- The telephone emits a distinctive sound when the ALARM CLOCK function is activated (See page 27). HEADSET JACK- Your telephone can utilize a headset for hands-free communication. BELT CLIP- Use the BELTCLIP to hang your HANDSET on your belt. EDIT/FLASH TALK C VOL DSST~MAN4~9762.qxd 11/12/2002 2:46 PM Page 2 Special Features Special Features CALLER ID SYSTEM Multi-Function Large LCD Screen- Shows the number you are dialing and, with Caller ID service available through subscription from your local telephone company, displays information about the caller before you answer the call. Name and Number DIRECTORY (PHONE BOOK) - Stores up to 40 names and numbers so that you can call them with a single key stroke. Caller List- Available with Caller ID service. Stores up to 50 calls to keep track of everyone who called. The name, phone number, time and date of the call are recorded. Allows you to return their calls with a few key strokes. Outgoing Call Memory- The telephone stores the last 8 OUTGOING CALLS to keep track of the one you called. The name, phone number, time, date, and the duration of the call are recorded. Allows you to call them again with a single key stroke. Preferred Calls - You can mark the name and number of a welcome caller in the DIRECTORY (PHONE BOOK). When that number calls in, the caller’s name will appear on the LCD Screen and a special ring sound or the selected PREFERRED RINGERMELODY will be heard. Blocked Calls - You can mark the name and number of an unwelcome caller in the DIRECTORY (PHONE BOOK). When that number calls in, the caller’s name will appear on the LCD Screen and the ringer will be disabled. Repeat Call Indicator- Shows if a new incoming call has called more than once. Out of Area Call Indicator- Advises you that the incoming call is not in a Caller ID service area. Unavailable Call Indicator- Advises you that the origin of the incoming call does not support the Caller ID system. Call Waiting Service- Displays the name and number of the second caller, if you have subscribed for Call Waiting service from your local telephone company (see page 14.) MULTI-HANDSET, MULTI-BASE UNIT SYSTEM Multi-HANDSET- Registers a total of 9 HANDSETSinto the operating system. Multi-BASEUNIT -The user can have the option to add another BASEUNIT. The system supports 2 BASEUNITSconnected to a separate telephone line. Once registered, the HANDSETScan open link to any of the BASE UNITSto make and/or receive a call. Automatic Linking - All 9 HANDSETS can register to the twoBASE UNITS (B1, B2). When the FIRST BASEUNIT (B1)is already engaged, the other HANDSETScan automatically open link to the SECOND BASEUNIT (B2)by pressing the button. Intercom Call- A HANDSETcan make an INTERCOM call to the other HANDSETS in the system. Call Transfer- During a telephone conversation, the call can be transferrred from one HANDSET…

Text truncated - open the document above for the full version.

MessageFrom: Jennifer Song [[email protected]] Sent: Friday, December 20, 2002 10:40 AM To: William Graff Subject: Re: Lionda FCC ID: O63GH9762DLD02 Hi, Bill, Sorry to hear that. Please take care. Per your request, I uploaded the block diagram with info. of spread spectrum system. And Lionda just emailed us the information below: Here is the information for spread spectrum system: 1. Spread Rate: 32-chip per symbol. 2. Data rate per symbol: 3-bit / symbol 3. Average chip per data bit: 32 (chip / symbol) / 3 (bit / symbol) = 10.667 4. Symbol rate at 19.2MHz master clock: 23.4 us (microsecond) per symbol. 5. Spread Spectrum method: FSK modulation 6. Chip rate: 1.366Mbps 7. Voice Coding: ADPCM Please let me know if there is anything else you need. Thank you! Best Regards, Jennifer Song BACL, Documentation Personnel Email: [email protected] Tel: 408-732-9162 * 39 Fax: 408-732-9164 ----- Original Message ----- From: William Graff To: 'Jennifer Song' Sent: Wednesday, December 18, 2002 11:00 AM Subject: RE: Lionda FCC ID: O63GH9762DLD02 Jennifer, My apologies for the delay in answering you. My mother in law passed yesterday and it was most important to take care of my wife first. Please look at the definition of a spread spectrum system under Section 2.1 of the Rules. In it's simplest form, your device takes a voice signal, converts it to relatively slow data rate signal, and then logically sums it with a much faster data rate. The chip rate is the ratio between the slow speed data and the high speed spreading data. Please provide information on your slow speed data rate, and the chip rate. If a block diagram can be provided illustrating the spreading function, this would also be welcomed. Bill -----Original Message----- From: Jennifer Song [mailto:[email protected]] Sent: Monday, December 16, 2002 3:54 PM To: William Graff Subject: Lionda FCC ID: O63GH9762DLD02 Hi, Bill, I just got your message about the application mentioned above in the subject. Sorry, I dont really get your problems. Would you email me about those issues, so that I can let our engineer solve the problems? Thank you very much for your help! Best Regards, Jennifer Song BACL, Documentation Personnel Email: [email protected] Tel: 408-732-9162 * 39 Fax: 408-732-9164

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 December 4, 2002 RE: Lionda Technology FCC ID: O63GH9762DLD02 I have a few comments on this Application. 1.) Please provide a description of how this device meets the definition of a Spread Spectrum system as defined in Part 2.1 of the Rules. It is unclear if I am examining a Direct Sequence or Frequency Hopping system. If this is a hopper, a listing of the hop sequence is required. If this is a direct sequence system a description of the chip rate would be helpful. 2.) Please provide a required circuit description. None has been provided as of this writing. 3.) Does this equipment have “constant envelope” emissions? In other words, does the modulation envelope change over variations of input audio tones and/or input audio amplitude? 4.) The RF Exposure comment as listed on pp. 17 of the Test Report is inappropriate for a low power device such as this. Please revise. 5.) There is no RF Exposure warning contained in the Manual. Please correct. 6.) Please provide RF Exposure estimation. 7.) Please provide a conducted as well as a radiated RF Pout measurement. Please describe the power as peak or average as appropriate. If any time averaging is utilized, please report the duty cycle. Thanks, William H. Graff President and Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

EUT EXTERNAL PHOTOGRAPHS EUT - Adapter View Base - Top View Base - Bottom View Handset - Top View Handset - Back View

APPENDIX A - FCC PRODUCT LABELING AND WARNING STATEMENT FCC ID Label Specifications: Text is black or white in color and is left justified. Labels are silk-screened and shall be “permanently affixed” at a conspicuous location on the EUT. Proposed Label Location on EUT Bottom Side of Base/Proposed FCC ID Back Side of Handset/Proposed FCC ID FCC ID: O63GH9762DLD02 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communications may not be ensured when using this phone.

EUT INTERNAL PHOTOGRAPHS Base - Main Board Component View Base - Main Board Solder View Base - Transceiver Component View Base - Transceiver Solder View Handset - Main Board Component View Handset - Main Board Solder View Handset - Transceiver Component View Handset - Transceiver Component View

LINE DRAWING LIONDA TECHNOLOGY COMPANY LIMITED ENGINEERING DEPARTMENT TITLE DRAWN BY DATE : : : CHECKED BY DATE APPROVED BY DATE REVISION : : : : : AM PM TOTAL L-D-C C-FCALLS BATT MSG DIR NEW RPT # HEADSET d s s VOL DIR/ ESC M E N U R E /P A D E L /I N T F L A S H / E D I T SAVE GH9762/GH9763 Handset front Nov. 8, 2002 LINE DRAWING LIONDA TECHNOLOGY COMPANY LIMITED ENGINEERING DEPARTMENT TITLE DRAWN BY DATE : : : CHECKED BY DATE APPROVED BY DATE REVISION : : : : : USE ONLY WITH CLASS 2 POWER SOURCE 9V DC 500mA TEL LINE ONOFF RINGER TS 5R 3R RING SELECT ON OFF MSSG ALERT ICM ANNC SELECT TONE PULSE RESET SPEAKER PAGE MEMO TIME CODE OGM ERASE ON/OFF ANSWER RPT SKIP STOP VOL+ VOL- PLAY SPEAKER IN USE/ ANS. ON/OFF CHARGE d s s GH9762/GH9763 Base top Nov. 8, 2002 LINE DRAWING LIONDA TECHNOLOGY COMPANY LIMITED ENGINEERING DEPARTMENT TITLE DRAWN BY DATE : : : CHECKED BY DATE APPROVED BY DATE REVISION : : : : : GH9762/GH9763 Base bottom LD FOR SERVICE PLEASE CALL 1-800-210-8950 US L I S T E D R 2001632 ANSI/UL STD. 1950 CONFORMS TO HAC Nov. 8, 2002 US L I S T E D R 2001632 ANSI/UL STD. 1950 CONFORMS TO 1.80mm 2.16mm 1.77mm 1.52mm 13.08mm 1:1 Model No.:GH9762 FCC ID: O63GH9762DLD02 COMPLIES WITH 47 CFR PART 68 REQUIREMENTS USOC: RJ11C REN: (Insert) FCC REGISTRATION NO.:(Insert) THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE. AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. PRIVACY OF COMMUNICATIONS MAY NOT BE ENSURED WHEN USING THIS PHONE. LIONDA TECHNOLOGY CO. LTD.MADE IN CHINA Model No.:GH9762 FCC ID: O63GH9762DLD02 Model No.:GH9763 FCC ID: O63GH9762DLD02 COMPLIES WITH 47 CFR PART 68 REQUIREMENTS USOC: RJ11C REN: (Insert) FCC REGISTRATION NO.:(Insert) THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE. AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. PRIVACY OF COMMUNICATIONS MAY NOT BE ENSURED WHEN USING THIS PHONE. LIONDA TECHNOLOGY CO. LTD.MADE IN CHINA Model No.:GH9763 FCC ID: O63GH9762DLD02 COMPLIES WITH 47 CFR PART 68 REQUIREMENTS USOC: RJ11C REN: (Insert) FCC REGISTRATION NO.:(Insert) THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE. AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. PRIVACY OF COMMUNICATIONS MAY NOT BE ENSURED WHEN USING THIS PHONE. LIONDA TECHNOLOGY CO. LTD.MADE IN CHINA Model No.:GH9763 FCC ID: O63GH9762DLD02

APPENDIX B - TEST SETUP PHOTOGRAPHS Base Conducted Emission Base Radiated Emission Handset Radiated Emission

Note: This test report is specially limited to the above client company and the product model only. It may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. FCC PART 15 Subpart C EMI MEASUREMENT AND TEST REPORT For Lionda Technology Company Limited Block 2 Laodong 2 nd Industrial Area, Xixian, Baoan, Shenzhen, Guangdong, China 518102 FCC ID: O63GH9762DLD02 November 21, 2002 This Report Concerns: Original Report Equipment Type: 2.4GHz Digital Cordless Telephone System - Household Appliances Test Engineer:Benjamin Jin Report Number:R0211061 Test Date:November 12, 2002 Reviewed By:Jeff Lee Prepared By:Bay Area Compliance Laboratory Corporation 230 Commercial Street Sunnyvale, CA 94085 Tel: (408) 732-9162 Fax: (408) 732 9164 Lionda Technology Company Limited FCC ID: O63GH9762DLD02 Report # R0211061 Page 2 of 28 FCC Part 15.247 Test Report TABLE OF CONTENTS 1 - GENERAL INFORMATION.................................................................................................................................................4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT).........................................................................................4 1.2 OBJECTIVE................................................................................................................................................................................4 1.3 RELATED SUBMITTAL(S)/GRANT(S)......................................................................................................................................4 1.4 TEST METHODOLOGY.............................................................................................................................................................4 1.5 TEST FACILITY.........................................................................................................................................................................4 1.6 TEST EQUIPMENT LIST............................................................................................................................................................5 1.7 LOCAL SUPPORT EQUIPMENT................................................................................................................................................5 1.8 POWER SUPPLY AND LINE FILTERS OF EUT........................................................................................................................5 1.9 EXTERNAL I/O CABLING LIST AND DETAILS......................................................................................................................6 2 - SYSTEM TEST CONFIGURATION..................................................................................................................................7 2.1 DESCRIPTION OF TEST CONFIGURATION..............................................................................................................................7 2.2 EQUIPMENT MODIFICATIONS.................................................................................................................................................7 2.3 CONFIGURATION OF TEST SYSTEM.......................................................................................................................................8 2.4 TEST SETUP BLOCK DIAGRAM..............................................................................................................................................8 3 - SUMMARY OF TEST RESULTS........................................................................................................................................9 4 - CONDUCTED OUTPUT POWER MEASUREMENT................................................................................................10 4.1 STANDARD APPLICABLE.......................................................................................................................................................10 4.2 MEASUREMENT PROCEDURE...............................................................................................................................................10 4.3 MEASUREMENT RESULT.......................................................................................................................................................10 5 - 6 DB BANDWIDTH................................................................................................................................................................11 5.1 STANDARD APPLICABLE.......................................................................................................................................................11 5.2 MEASUREMENT PROCEDURE...............................................................................................................................................11 5.3 MEASUREMENT DATA..........................................................................................................................................................11 6 - SPURIOUS EMISSION.........................................................................................................................................................12 6.1 STANDARD APPLICABLE.......................................................................................................................................................12 6.2 MEASUREMENT PROCEDURE...............................................................................................................................................12 6.3 MEASUREMENT DATA..........................................................................................................................................................12 7 - 100 KHZ BANDWIDTH OF BAND EDGES MEASUREMENT..............................................................................13 7.1 STANDARD APPLICABLE..........................…

Text truncated - open the document above for the full version.

APPENDIX B - TEST SETUP PHOTOGRAPHS Base Conducted Emission Base Radiated Emission Handset Radiated Emission
