O6R1823LOW POWER TRANSMITTER (2400-2483.5 MHz)

Garmin Canada Inc.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Sep 20, 2011
Application Purpose: Original Equipment
Date of Application: Sep 20, 2011
Equipment Note: LOW POWER TRANSMITTER (2400-2483.5 MHz)
Frequency Range: 2403.00000000 - 2480.00000000
Company: Garmin Canada Inc.
Country: Canada

Documents & Files

Select a file to view

Parts List/Tune Up Info

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

D00001445 Rev 0.7 C7 RF Transceiver Module FEATURES  78 selectable RF channels (2403 to 2480 MHz)  20mm x 20mm drop-in module with F antenna  Ultra low power operation  Simple sync/async serial interface  Programmable output power up to +4 dBm  Excellent receiver sensitivity -86 dBm  1 Mbps RF data rate, GFSK modulation  Up to 8 ANT channels  Broadcast, acknowledged, or burst data transmissions  Built-in ANT-FS (file share) with AES-128 encryption  ANT channel combined message rate up to 200Hz (8byte data payload)  Minimum message rate per ANT channel 0.5Hz  Burst transfer rate up to 20Kbps (true data throughput)  Up to 3 public, managed and/or private network keys  High resolution proximity pairing and RSSI reading  2 V to 3.6V supply voltage range  -40°C to +85°C operating temperature  Pin compatible with ANT AP2, AT3 and AP1 modules  Radio regulatory approval for major markets (pending)  RoHS compliant (Picture is to be updated) APPLICATIONS Network controllers and data hubs. Complex sensors in health and fitness FAMILY MEMBERS ANTC782M5IB – 8 ANT channels; Molex Connector ANTC782M4IB – 8 channels, surface mount ANT NETWORK CONFIGURATIONS 112 211 310 49 58 67 M PEER TO PEER STAR PRACTICAL MESH SHARED BI-DIRECTIONAL 87 6 9 10 11 12 13 1415 16 5 4 3 2 1 SCANNING MODE ANT-FS (Secure Authenticated) 112 211 310 49 ? 8 67 M AD-HOC AUTO SHARED 112 211 310 49 58 67 M SHARED UNI-DIRECTIONAL n Bidirectional Acknowledged BROADCAST SHARED CLUSTER Sensor Hub Relay Page 2 of 20 ANT C7 RF Transceiver Module thisisant.com Table of Contents 1. ANT C7 Module .......................................................................................................................................... 5 1.1 Module version ............................................................................................................................ 5 1.2 Interface ..................................................................................................................................... 6 1.3 Application MCU connection .......................................................................................................... 7 1.3.1 Async Mode ................................................................................................................... 7 1.3.2 Byte Sync Mode ............................................................................................................. 8 1.3.3 Bit Sync Mode ................................................................................................................ 9 1.3.4 External Memory Connection ........................................................................................ 10 1.4 Mounting Guideline .................................................................................................................... 10 1.5 Reflow Guideline ........................................................................................................................ 10 1.6 Pick-n-Place ............................................................................................................................... 10 2. Regulatory Approval (In process. Not completed) ................................................................................ 11 2.1 United States ............................................................................................................................. 11 2.2 Industry Canada Compliance ...................................................................................................... 11 2.3 CE Declaration of Conformity ...................................................................................................... 12 2.4 Australia & New Zealand ............................................................................................................ 12 3. Electrical Specifications .......................................................................................................................... 13 3.1 Absolute Maximum Ratings (1) ..................................................................................................... 13 3.2 Recommended Operating Conditions ........................................................................................... 13 3.3 ELECTRICAL CHARACTERISTICS ................................................................................................. 13 3.4 RF Characteristics ...................................................................................................................... 13 3.5 APPLICATION SPECIFIC POWER USAGE ...................................................................................... 15 3.6 Calculating the Average Current Consumption and Battery Life ...................................................... 16 4. Mechanical Drawings ............................................................................................................................. 18 5. Technical Support ................................................................................................................................... 20 5.1 Public Technical References ........................................................................................................ 20 5.2 ANT Forum ................................................................................................................................ 20 5.3 ANT Social Networks .................................................................................................................. 20 ANT C7 RF Transceiver Module Page 3 of 20 thisisant.com Notices and Restricted Use Information Information contained in this document is provided only for your ("Customer" or “you”) convenience and may be superseded by updates. It is your responsibility to ensure that your application meets with your specifications. Dynastream Innovations Inc. ("DYNASTREAM") makes no representations or warranties of any kind whether express or implied, written or oral, statutory or otherwise, re…
