O6Y-CDM7075ATri-Mode Dual-Band Analog/ PCS Phone (AMPS/ CDMA)

SprintPCS ® ® Phone Guide www.sprint.com ©2006 Sprin tNextel. All righ ts reserved. No reproduction in whole or in part without prior written approval. Sprint, the "Going Forward"logo, the NEXTEL name and logo, and other trademarks are trademarks of SprintNe xtel. Printed in the U.S.A. CDM220SP by UTStarcom Table of Contents Welcome to Sprint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .i Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ii Your Phone’s Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii Section 1: Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . .1 1A. Setting Up Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Getting Started With Sprint PCS Service . . . . . . . . . . . . . . . . . . . . . .3 Setting Up Your Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 Sprint PCS Account Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 Section 2: Your Sprint PCS Phone . . . . . . . . . . . . . . . . . . . .9 2A. Your Sprint PCS Phone: The Basics . . . . . . . . . . . . . . . . . .10 Front View of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 Viewing the Display Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 Features of Your Sprint PCS Phone . . . . . . . . . . . . . . . . . . . . . . . . . . .15 Turning Your Phone On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 Using Your Phone’s Battery and Charger . . . . . . . . . . . . . . . . . . . . .18 Navigating Through Phone Menus . . . . . . . . . . . . . . . . . . . . . . . . . .21 Displaying Your Phone Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 Making and Answering Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34 2B. Controlling Your Phone’s Settings . . . . . . . . . . . . . . . . . .39 Sound Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40 Display Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44 Location Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47 Messaging Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48 Airplane Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51 TTY Use With Sprint PCS Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52 Phone Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53 Text Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54 Phone Setup Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56 My Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58 2C. Setting Your Phone’s Security . . . . . . . . . . . . . . . . . . . . . .59 Accessing the Security Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60 Using Your Phone’s Lock Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60 Using Special Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62 Restricting Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63 Picture Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63 Erasing the Contacts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64 Erasing the Message List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65 Erasing the Voice Mail List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65 Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66 Resetting Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66 Security Features for Sprint PCS Vision SM . . . . . . . . . . . . . . . . . . . . . .67 2D. Controlling Your Roaming Experience . . . . . . . . . . . . . . .68 Understanding Roaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69 Setting Your Phone’s Roam Mode . . . . . . . . . . . . . . . . . . . . . . . . . . .72 Using Call Guard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73 Using Data Guard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74 Roaming Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74 2E. Managing Call History . . . . . . . . . . . . . . . . . . . . . . . . . . . .75 Viewing History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76 Call History Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77 Making a Call From Call History . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77 Saving a Phone Number From Call History . . . . . . . . . . . . . . . . . . .78 Prepending a Phone Number From Call History . . . . . . . . . . . . . . .79 Erasing Call History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79 2F. Using Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80 Adding a New Contacts Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81 Finding Contacts Entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82 Contacts Entry Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

UTStarcom, Inc. 33 Wood Avenue South 3 rd , Floor Iselin, NEW JERSEY, 08830, U.S.A Date: March 02, 2006 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch, 7435 Oakland Mills Road Columbia, MD 21046, U.S.A. Subject: Authorization Letter FCC ID: O6Y-CDM7075A (Tri-Mode Dual-Band Phone (AMPS/CDMA/ PCS CDMA)) Part 24, 22, 2, 20 Certification To whom it may concern: We, the undersigned. hereby authorized HYUNDAI Calibration & Certification Technologies Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these manners. Any and all acts carried out by HYUNDAI Calibration & Certification Technologies Co., Ltd. on our behalf shall have the same effect as acts of our own. This authorization is valid until Dec. 31, 2006. Sincerely Yours, UTStarcom, Inc. 33 Wood Avenue South 3 rd , Floor Iselin, NEW JERSEY, 08830, U.S.A Date: March 02, 2006 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch, 7435 Oakland Mills Road Columbia, MD 21046, U.S.A. Subject: Authorization Letter FCC ID: O6Y-CDM7075A (Tri-Mode Dual-Band Phone (AMPS/CDMA/ PCS CDMA)) Part 24, 22, 2, 20 Certification Gentlemen: In accordance with 0.459 of CFR 47, UTStarcom, Inc. hereby requests confidentiality of the Block Diagrams attachment, Schematic Diagrams attachment, Operational Description attachment, and Part List/Tune-Up Procedure attachment for the above-referenced Certification application. These documents contain detailed system and equipment description and related information about the product which UTStarcom, Inc. considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, UTStarcom, Inc. feels this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Sincerely Yours, UTStarcom, Inc. 33 Wood Avenue South 3 rd , Floor Iselin, NEW JERSEY, 08830, U.S.A Date: March 02, 2006 AFFIDAVIT FOR ESN PROTECTION OF CELLULAR MOBILE TELEPHONES We hereby certify that the tri-mode phone (FCC ID: O6Y-CDM7075A) is so designed that it complies with all the requirements for ESN protection specified in Section 22.919 of the FCC Rules. a) The transmitter in service has a unique ESN. b) The ESN host component is permanently attached to a main circuit board of the mobile transmitter and the integrity of the unit operating software cannot be altered. The ESN is plated from fraudulent contact and tampering. The ESN is encoded using multiplication by a polynomial and the ESN data programmed in the memory with other information. c) The ESN is factory-set and cannot be altered, transferred, removed or otherwise able to be manipulated. Cellular mobile equipment is specifically designed such that any attempt to remove, tamper with, or change the ESN chip, its logic system, or firmware originally programmed by the manufacturer will render the mobile transmitter inoperative. Sincerely Yours, UTStarcom, Inc. 33 Wood Avenue South 3 rd , Floor Iselin, NEW JERSEY, 08830, U.S.A Date: March 02, 2006 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch, 7435 Oakland Mills Road Columbia, MD 21046, U.S.A. Subject: Authorization Letter FCC ID: O6Y-CDM7075A (Tri-Mode Dual-Band Phone (AMPS/CDMA/ PCS CDMA)) Part 24, 22, 2, 20 Certification Gentlemen: UTStarcom, Inc. hereby confirms that the attached RF exposure warning page will be readily visible to the user, and will be placed at a prominent location in the front section of the user's manual. Should you have any questions or comments concerning the above, please do not hesitate contact me. Sincerely Yours, UTStarcom, Inc. 33 Wood Avenue South 3 rd , Floor Iselin, NEW JERSEY, 08830, U.S.A Date: March 02, 2006 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046, U.S.A. Subject: FCC E911 Requirements Per §22.921 FCC ID: O6Y-CDM7075A (Tri-Mode Dual-Band Phone (AMPS/CDMA/ PCS CDMA)) Part 24, 22, 2, 20 Certification Gentlemen : UTStarcom, Inc. hereby certifies that the tri-mode phone(FCC ID : O6Y-CDM7075A ), using the Automatic A/B Roaming - Intelligent Retry Method, meets the E911 requirements specified in Section 22.921 of the FCC Rules. This procedure recognizes when a “9-1-1” call is made and, at such time, will override any programming in the mobile unit that determines the handling of a non-911 call and permits the call to be handled by other analog carriers. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely Yours,

UTStarcom Inc. 33 Wood Avenue South 3 rd , Floor Iselin, NEW JERSEY 08830, United Stated Date: March 2, 2006 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: O6Y-CDM7075A To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, UTStarcom Inc. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for April 14, 2006 days after the grant as outlined in Public Notice DA 04-1705. This provision will give UTStarcom Inc. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure CONFIDENTIAL 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM CONFIDENTIAL 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, UTStarcom Inc.

UTStarcom Inc. 33 Wood Avenue South 3 rd , Floor Iselin, NEW JERSEY 08830, United Stated Date: February 28, 2006 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: UTStarcom Inc. FCC ID: O6Y-CDM7075A Part 20.19 Certification To Whom It May Concern: We, UTStarcom Inc., hereby declare the samples evaluated in this application are equivalent to production samples. Should you have any questions or comments concerning the above, please contact the undersigned.

UTStarcom, Inc. 33 Wood Avenue South 3 rd , Floor Iselin, NEW JERSEY, 08830, U.S.A Date: March 02, 2006 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046, U.S.A. Subject: SPECIFICATION COMPLIANCE STATEMENT FCC ID: O6Y-CDM7075A (Tri-Mode Dual-Band Phone (AMPS/CDMA/ PCS CDMA)) Part 22/ 24 Certification Gentlemen : UTStarcom, Inc. hereby certifies that the Tri-mode phone(FCC ID : O6Y-CDM7075A ), for Tri-Mode Mobile Station cellular is capable of Compliance with the ANSI TIA/EIA –95-B Mobile Station – Base Station Compatibility Standards for Dual-Mode Spread Spectrum Systems, December 1998. Furthermore, we certify compliance to ANSI TIA/EIA-553-A-1999, Mobile Station-Land Station Compatibility Specification. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely Yours,

Courtenay Geraghty From: Gregory Czumak [[email protected]] Sent: Thursday, October 20, 2005 3:25 PM To: PCTEST - Courtenay Subject: FW: CDMA 2000 application Follow Up Flag: Follow up Flag Status: Red Attachments: CDMA-2000 SAR Config.doc Page 1 of 2 11/7/2005 From: Kwok Chan [mailto:[email protected]] Sent: Thursday, May 19, 2005 11:37 AM To: Gregory Czumak Cc: PCTEST - Al Cirwithian; PCTEST - Randy Ortanez Subject: RE: CDMA 2000 application Greg: According to information available to us, the attached describes the basic criteria for reviewing typical CDMA- 2000 client devices. This should be considered as a draft while we are continuing to review & identify other test and product specific issues. Please let us know if this is insufficient or if more coordination is necessary, and continue to inform us on subsequent CDMA-2000 filings. Kwok Chan -----Original Message----- From: Gregory Czumak [mailto:[email protected]] Sent: Thursday, May 19, 2005 9:10 AM To: Kwok Chan Cc: PCTEST - Al Cirwithian; PCTEST - Randy Ortanez; PCTest - Andrea Zaworski; PCTEST - Keats Ortiz; PCTEST - Steve Liu; PCTEST - Yukio Tanuma Subject: CDMA 2000 application Hi Kwok, I hope all is well with you and your family (your kids must be getting big... I know mine are!). Based on the info provided last week at the Workshop, I am contacting you to let you know that I am currently reviewing an application for a WLL PCS CDMA phone that has CDMA 2000 capabilities. As with most WLL phones that we see, it is designed to replace the phone on your desk (i.e., it sits on the desk, and looks like a regular corded phone- no RF in the handset, just a whip antenna sticking out of the back of the base portion). The lab performed body SAR measurements with a separation distance of 2.5 cm. Is there anything specific for which I should look, given its CDMA 2000 capabilities? Please let me know at your earliest convenience (of course, we are under pressure to finish the review ASAP). I appreciate your time and effort- thank you. Take care. Greg Sincerely, Gregory Czumak Quality Manager Senior Certification Engineer PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road Columbia, MD 21045 410-290-6652 410-290-6654 (Fax) [email protected] This communication and its attachments contain information from PCTEST Engineering Laboratory, Inc., and is intended for the exclusive use of the recipient (s) named above. It may contain information that is confidential and/or legally privileged. Any unauthorized use that may compromise that confidentiality via distribution or disclosure is prohibited. Please notify the sender immediately if you receive this communication in error, and delete it from your computer system. Usage of PCTEST email addresses for non-business related activities is strictly prohibited. No warranty is made that the e-mail or attachment(s) are free from computer virus or other defect. Thank you. Page 2 of 2 11/7/2005

SAN 136-1,AMI-RI,BUBAL-EUP, ICHEON-SI, KYOUNKI-DO, 467-701,KOREA SUBJECT: UTStarcom, Inc. FCC ID: O6Y-CDM7075A MODEL: CDM7075A, CDM220SP Part 22 / 24 / 2 / 20 Certification Gentlemen: Submitted herewith, on behalf of UTStarcom, Inc., is an application for Part 22 / 24 / 2 / 20 Certification of the following Tri-Mode Dual-Band Phone (AMPS/ CDMA/ PCS CDMA): Trade Name/Model(s): UTStarcom / CDM7075A, CDM220SP EUT Type: Tri-Mode Dual-Band Phone (AMPS/CDMA/ PCS CDMA) Tx Frequency: 824.04 — 848.97 MHz (AMPS) / 824.70 — 848.31 MHz (CDMA) 1851.25 — 1908.75 MHz (PCS CDMA) Rx Frequency: 869.04 — 893.97 MHz (AMPS) / 869.70 — 893.31 MHz (CDMA) 1931.25 — 1988.75 MHz (PCS CDMA) Max. RF Output Power: 0.375W ERP AMPS (25.7dBm) / 0.301W ERP CDMA (24.8dBm) / 0.315W EIRP PCS CDMA (25.0dBm) Maximum SAR: 1.42 W/kg AMPS Brain SAR / 1.17W/kg AMPS Body SAR 1.19 W/kg CDMA Brain SAR / 0.832 W/kg CDMA Body SAR 1.32 W/kg PCS CDMA Brain SAR / 0.723 W/kg PCS CDMA Body SAR Attached is the applicant’s Letter of Authorization, Confidentiality Request, ESN Affidavit, E911 compliance statement, measurement report test data and plots, RF Exposure measurement report and data, FCC ID label and location, test setup photographs, block diagram (confidential), circuit diagrams & description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. Report prepared by : Ki-Soo Kim Manager of Product Compliance Team cc: Mr. Rick Phung – UTStarcom, Inc. Project Manager March 14, 2006 Test Site: HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. FRN: 0005866421 TEL: +82 31 639 8518 FAX: +82 31 639 8525 http://www.hct.co.kr

Report No.: HCT-SAR06-0303 FCC ID: 06Y-CDM7075A DATE: March 09, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ATTACHMENT E – FCC ID LABEL/ LOCATION Report No.: HCT-SAR06-0303 FCC ID: 06Y-CDM7075A DATE: March 09, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. ( SEE NEXT PAGE ) Report No.: HCT-SAR06-0303 FCC ID: 06Y-CDM7075A DATE: March 09, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr

Report No.: HCT-SAR05-1210 FCC ID: 06Y-CDM7025SP DATE: December 22, 2005 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ATTACHMENT H – INTERNAL PHOTOGRAPHS Report No.: HCT-SAR05-1210 FCC ID: 06Y-CDM7025SP DATE: December 22, 2005 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR05-1210 FCC ID: 06Y-CDM7025SP DATE: December 22, 2005 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR05-1210 FCC ID: 06Y-CDM7025SP DATE: December 22, 2005 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR05-1210 FCC ID: 06Y-CDM7025SP DATE: December 22, 2005 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR05-1210 FCC ID: 06Y-CDM7025SP DATE: December 22, 2005 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR05-1210 FCC ID: 06Y-CDM7025SP DATE: December 22, 2005 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR05-1210 FCC ID: 06Y-CDM7025SP DATE: December 22, 2005 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR05-1210 FCC ID: 06Y-CDM7025SP DATE: December 22, 2005 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR05-1210 FCC ID: 06Y-CDM7025SP DATE: December 22, 2005 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR05-1210 FCC ID: 06Y-CDM7025SP DATE: December 22, 2005 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO Report No.: HCT-SAR05-1210 FCC ID: 06Y-CDM7025SP DATE: December 22, 2005 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ■ INTERNAL PHOTO

HYUNDAI CALIBRATION & CERTIFICATION TECH. CO., LTD. PRODUCT COMPLIANCE DIVISION SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr CERTIFICATE OF COMPLIANCE SAR EVALUATION EUT Type: Tri-Mode Dual-Band Phone (AMPS/CDMA/ PCS CDMA) Tx Frequency: 824.04 — 848.97 MHz (AMPS) / 824.70 — 848.31 MHz (CDMA) 1851.25 — 1908.75 MHz (PCS CDMA) Rx Frequency: 869.04 — 893.97 MHz (AMPS) / 869.70 — 893.31 MHz (CDMA) 1931.25 — 1988.75 MHz (PCS CDMA) Max. RF Output Power: 0.375W ERP AMPS (25.7dBm) / 0.301W ERP CDMA (24.8dBm) / 0.315W EIRP PCS CDMA (25.0dBm) Max. RF Output Power: 0.355W AMPS (25.5dBm) / 0.282W CDMA (24.5dBm) (Conducted) 0.282W PCS CDMA (24.5dBm) Trade Name/Model(s): UTStarcom /CDM7075A, CDM220SP FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) Application Type: Certification FCC Rule Part(s): §2.1093; FCC/ OET Bulletin Supplement C [July 2001] Maximum SAR: 1.42 W/kg AMPS Brain SAR / 1.17W/kg AMPS Body SAR 1.19 W/kg CDMA Brain SAR / 0.832 W/kg CDMA Body SAR 1.32 W/kg PCS CDMA Brain SAR / 0.723 W/kg PCS CDMA Body SAR This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/ IEEE Std. C95.1- 1992 and had been tested in accordance with the measurement procedures specified in ANSI/ IEEE Std. C95.3- 1992. (See Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Hyundai C-Tech Co., Ltd. Certifies that no party to this application has been denied FCC benefits pursuant to section 5301 of the Anti- Drug Abuse Act of 1998, 21 U.S. C. 853(a) Report prepared by : Ki-Soo Kim Manager of Product Compliance Team This report only responds to the tested sample and may not be reproduced, except in full, without written approval of the HCT Co., Ltd. FCC ID : APPLICANT : O6Y-CDM7075A UTStarcom Inc. Date of Issue: March 9, 2006 Test Report No.: HCT-SAR06-0303 Test Site: HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. FRN: 0005866421 UTStarcom, Inc. 1275 Harbor Bay Parkway Alameda, CA 94502 USA FRN: 0005823877 Report No.: HCT-SAR06-0303 FCC ID: 06Y-CDM7075A DATE: March 09, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ２ of 24 Table of Contents 1.1 SCOPE ---------------------------------------------------------------------------------------------------------- 2.1 INTRODUCTION / SAR DEFINITION --------------------------------------------------------------------- 3.1 SAR MEASUREMENT SET-UP --------------------------------------------------------------------------- 4.1 E-FIELD PROBE SYSTEM --------------------------------------------------------------------------------- 5.1 EUT ARRANGEMENT ------------------------------------------------------------------------------------- 6.1 E-FIELD PROBE CALIBRATION PROCESS -------------------------------------------------------- 7.1 PHANTOM, HOLDER, & EQUIVALENT TISSUE --------------------------------------------------- 8.1 SYSTEM SPECIFICATIONS ------------------------------------------------------------------------------ 9.1 MEASUREMENT PROCESS ------------------------------------------------------------------------------ 10.1 ANSI/ IEEE C95.1 - 1992 RF EXPOSURE LIMITS -------------------------------------------------------- 11.1 MEASUREMENT UNCERTAINTIES ------------------------------------------------------------------- 12.1 TEST DATA SUMMARY ---------------------------------------------------------------------------------- 13.1 SAR TEST EQUIPMENT LIST --------------------------------------------------------------------------- 14.1 CONCLUSION ------------------------------------------------------------------------------------------------ 15.1 REFERENCES -------------------------------------------------------------------------------------------- 3 4 5 6 7-8 9-10 11 12 13 14 15 16-21 22 23 24 Report No.: HCT-SAR06-0303 FCC ID: 06Y-CDM7075A DATE: March 09, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ３ of 24 SAR MEASUREMENT REPORT 1.1 SCOPE Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 1. 2 Applicant • EUT Type: Tri-Mode Dual-Band Phone (AMPS/CDMA/PCS CDMA) • Trade Name: UTStarcom • Model(s): CDM7075A, CDM220SP • FCC ID: O6Y-CDM7075A • Serial Number(s): O6Y7075A20060300001 • Tx Frequency: 824.04 — 848.97 MHz (AMPS) / 824.70 — 848.31 MHz (CDMA) 1851.25 — 1908.75 MHz (PCS CDMA) • Rx Frequency: 869.04 — 893.97 MHz (AMPS) / 869.70 — 893.31 MHz (CDMA) 1931.25 — 1988.75 MHz (PCS CDMA • Application Type: Certification • FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) • FCC Rule Part(s): §2.1093; FCC/ OET Bulletin Supplement C [July 2001] • Modulation(s): AMPS/ CDMA/ PCS CDMA • Αntenna Type: Retractable (Retracted/Extended) • Max. RF Output Power: 0.375W ERP AMPS (25.7dBm) 0.301W ERP CDMA (24.8dBm) 0.315W EIRP PCS CDMA (25.0dBm) • Date(s) of Tests: March 06, 2006 – March 08, 2006 • Place of Tests: Hyundai C-Tech. EMC Lab. Icheon, Kyounki-Do, KOREA • Report Serial No.: HCT-SAR06-0303 Figure 1. SAR System 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting sour…
