360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 39 of 85 © Rhein Tech Laboratories, Inc. APPENDIX I: MANUAL Instruction Manual CONTENTS WARNING! FCC RF EXPOSURE COMPLIANCE.......................................................................... 1 1. BEFORE USING THIS PRODUCTS ...................................................................... 2 1.1 EXPLANATION OF ALERT SYMBOLS USED IN THIS MANUAL .............................. 2 1.2 FOR SAFE OPERATION - IT IS IMPORTANT YOU READ THIS ........................... 3 „ Telephone handling instructions .......................................................................................................... 3 FOR SAFE OPERATION - IT IS IMPORTANT YOU READ THIS (continue) ...... 4 1.3 FOR SAFE OPERATION - IT IS IMPORTANT YOU READ THIS ........................... 5 „ AC Adapter handling instructions ...................................................................................................... 5 FOR SAFE OPERATION - IT IS IMPORTANT YOU READ THIS (continue) ...... 6 1.4 CAUTION OF USING .............................................................................................................................. 7 1.5 FEATURES OF DESKTOP TELEPHONE UTS600 ................................................... 8 „ Benefits ................................................................................................................................................................... 8 1.6 CHECK PACKEAGE CONTENTS .................................................................................................. 9 1.7 NAMES AND FUNCTIONS ......................................................................................................... 10 2. OPERATION ........................................................................................................................... 12 2.1 PREPARATION .......................................................................................................................................... 12 2.2 Antenna Orientation ............................................................................................................................................... 13 Antenna Type Determination Guidelines ............................................................................................. 13 Main Unit Site Selection ................................................................................................................................14 Installation Accessories, Standard and Special Tools ................................................................... 14 Coaxial Cable Installation ................................................................................................................................. 16 Antenna Installation .............................................................................................................................................. 17 2.3 OPERATION ................................................................................................................................................. 21 „ Placing a Call ............................................................................................................................................................. 21 „ Receive a Call ............................................................................................................................................................ 22 3. MAINTENANCE .................................................................................................................. 22 4. SPECIFICATIONS........................................................................................................................ 22 1 WARNING! FCC RF EXPOSURE COMPLIANCE This PCS base station complies with the Federal Communications Commission (FCC) RF exposure limits for General Population/Uncontrolled exposure environment. In addition, it complies with the following Standards and Guidelines: • FCC 96-326, Guidelines for Evaluating the Environmental Effects of Radio-Frequency Radiation. • FCC OET Bulletin 65 Edition 01-01 (2001) Supplement C, Evaluating Compliance with FCC Guidelines for Human Exposure to Radio Frequency Electromagnetic Fields. • ANSI/IEEE C95.1-1992, IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. • ANSI/IEEE C95.3-1992, IEEE Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave. Antenna Installation Requirement: The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. 2 1. BEFORE USING THIS PRODUCTS 1.1 EXPLANATION OF ALERT SYMBOLS USED IN THIS MANUAL So that user can use this product in the correct safe manner, this instruction manual uses various alert symbols. These symbols are for the prevention of injury to the user or others and for the prevention of property damage. The following shows the symbols and explains their meaning. Please learn these symbols before reading this manual. Example of alert symbols This symbol indicates that ignorance of the symbol and the instruction given together wit h it or erroneous on the product may cause an imminent hazard which directly results in personal serious injury or death. This symbol implies a factor that may cause personal serious injury or death due to ignorance of the symbol and of the instructions given together with it or erroneous operations of the product. This symbol implies a factor that may cause personal injury or property damage due to ignorance of the symbol and of the instructions given together with it or erroneous operations on the product. This…

Text truncated - open the document above for the full version.

Instruction Manual CONTENTS WARNING! FCC RF EXPOSURE COMPLIANCE ....................................................................... 1 1. BEFORE USING THIS PRODUCTS .................................................................... 2 1.1 EXPLANATION OF ALERT SYMBOLS USED IN THIS MANUAL .............................. 2 1.2 FOR SAFE OPERATION - IT IS IMPORTANT YOU READ THIS ........................... 3 ! Telephone handling instructions .......................................................................................................... 3 FOR SAFE OPERATION - IT IS IMPORTANT YOU READ THIS (continue) ...... 4 1.3 FOR SAFE OPERATION - IT IS IMPORTANT YOU READ THIS ........................... 5 ! AC Adapter handling instructions ...................................................................................................... 5 FOR SAFE OPERATION - IT IS IMPORTANT YOU READ THIS (continue) ...... 6 1.4 CAUTION OF USING .............................................................................................................................. 7 1.5 FEATURES OF DESKTOP TELEPHONE UTS600 ................................................... 8 ! Benefits ................................................................................................................................................................... 8 1.6 CHECK PACKEAGE CONTENTS .................................................................................................. 9 1.7 NAMES AND FUNCTIONS ......................................................................................................... 10 2. OPERATION ...................................................................................................................... 12 2.1 PREPARATION .......................................................................................................................................... 12 2.2 Antenna Orientation ............................................................................................................................................... 13 Antenna Type Determination Guidelines ............................................................................................. 13 Main Unit Site Selection ................................................................................................................................14 Installation Accessories, Standard and Special Tools ................................................................... 14 Coaxial Cable Installation ................................................................................................................................. 16 Antenna Installation .............................................................................................................................................. 17 2.3 OPERATION ................................................................................................................................................. 21 ! Placing a Call ............................................................................................................................................................. 21 ! Receive a Call ............................................................................................................................................................ 22 3. MAINTENANCE ............................................................................................................. 22 4. SPECIFICATIONS .................................................................................................................... 22 1 WARNING! FCC RF EXPOSURE COMPLIANCE This PCS base station complies with the Federal Communications Commission (FCC) RF exposure limits for General Population/Uncontrolled exposure environment. In addition, it complies with the following Standards and Guidelines: • FCC 96-326, Guidelines for Evaluating the Environmental Effects of Radio-Frequency Radiation. • FCC OET Bulletin 65 Edition 01-01 (2001) Supplement C, Evaluating Compliance with FCC Guidelines for Human Exposure to Radio Frequency Electromagnetic Fields. • ANSI/IEEE C95.1-1992, IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. • ANSI/IEEE C95.3-1992, IEEE Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave. Antenna Installation Requirement: The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. 2 1. BEFORE USING THIS PRODUCTS 1.1 EXPLANATION OF ALERT SYMBOLS USED IN THIS MANUAL So that user can use this product in the correct safe manner, this instruction manual uses various alert symbols. These symbols are for the prevention of injury to the user or others and for the prevention of property damage. The following shows the symbols and explains their meaning. Please learn these symbols before reading this manual. Example of alert symbols This symbol indicates that ignorance of the symbol and the instruction given together wit h it or erroneous on the product may cause an imminent hazard which directly results in personal serious injury or death. This symbol implies a factor that may cause personal serious injury or death due to ignorance of the symbol and of the instructions given together with it or erroneous operations of the product. This symbol implies a factor that may cause personal injury or property damage due to ignorance of the symbol and of the instructions given together with it or erroneous operations on the product. This symbol indicates CAUTION (includes DANDER and WARNING), the pictures in the triangle show caution details.(The left picture shows a general warning.) These symbol indicate actions that must not be performed. Carefully read the given instructions and DO NOT carr y out these actions. …

Text truncated - open the document above for the full version.

03/21/02 Mr. Dan Baltzell Rheintech In reference to FCC ID: 06YUTS-600FSU Mr.Baltzell Upon completion of preliminary review of the application for FCC ID: LX8766E, there are several issues that must be addressed before the application can be granted by ATCB. Please address each issue below. 1) Please provide a corrected 731form with the correct operating frequency listed. Corrected 2) Page one of the test report states the operation frequency is 1896.65 – 1909.95, however the test data indicates the system operate between 1893.65 – 1909.95 MHz, please explain difference. Incorrect report filed, corrections made. 3) The manual states that there are three antennas available, including a patch antenna with a maximum gain of 14dBi. The MPE calculations however were only done with the 10dBi gain antenna. Please provide RF Exposure data for all the available antennas RF exposure added for a 2 dBi antenna, 14 dBi antenna not used. 4) The RF Exposure calculations were done based on duty cycle of 12.8%, this will be reflected in the grant notes that the maximum duty cycle allowed will be 12.8%. Noted. 5) Please provide information on how the manufacturer will limit the duty cycle of this system to 12.8% maximum if the system can operate at greater then 12.8% duty cycle or provide MPE study with the transmitter operating at the maximum duty cycle allowed or 100% if such operation is possible. Firmware control, additional data submitted with 100% operation. 6) There is no data in the test report that supports the 14dBi patch antenna listed in the manual, please provide a set of data with this antenna. Deleted from users manual as well as correction to 10nW to 10mW power on last page. Noye: Dan, Missy – there are a couple of things I need to verify with Bill so there may be an additional question or two on Monday morning. Regards David A. Case NCE Examining Engineer mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 46 of 85 © Rhein Tech Laboratories, Inc. APPENDIX K: EXTERNAL PHOTOGRAPHS PHOTOGRAPH 7: TOP VIEW 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 47 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 8: BACK VIEW 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 48 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 9: BOTTOM VIEW 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 49 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 10: BATTERY COMPARTMENT 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 50 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 11: REAR ANTENNA CONNECTOR 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 51 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 12: 4VDC POWER SUPPLY 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 52 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 13: BOTTOM OF HANDSET 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 53 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 14: TOP OF HANDSET

360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 36 of 85 © Rhein Tech Laboratories, Inc. APPENDIX F: LABEL AND LABEL LOCATION Please see the following page.

360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 54 of 85 © Rhein Tech Laboratories, Inc. APPENDIX L: INTERNAL PHOTOGRAPHS PHOTOGRAPH 15: INSIDE TOP CASE WITH KEYPAD PCB ATTACHED 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 55 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 16: INSIDE TOP CASE WITH BOTTOM OF KEYPAD 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 56 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 17: INSIDE TOP CASE 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 57 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 18: INSIDE BOTTOM OF CASE WITH RF, POWER PCB’S, AND CONNECTOR 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 58 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 19: RF PCB IN BOTTOM CASE 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 59 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 20: CONNECTOR PCB IN CASE 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 60 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 21: TOP OF KEYPAD PCB 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 61 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 22: TOP OF DC POWER PCB 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 62 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 23: BOTTOM OF DC POWER PCB 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 63 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 24: INSIDE BOTTOM OF CASE 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 64 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 25: CONNECTIONS ON MID RF PCB 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 65 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 26: TAPED CONNECTIONS ON BOTTOM OF RF PCB 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 66 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 27: KEYPAD SIDE OF RF PCB 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 67 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 28: CONNECTIONS AT LOWER SIDE OF RF PCB 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 68 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 29: CONNECTIONS AT LOWER END OF RF PCB 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 69 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 30: RF PCB SHOWING CONNECTIONS TO KEYPAD PCB PHOTOGRAPH 31: INSIDE BOTTOM OF HANDSET WITH COMPONENTS 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 70 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 32: INSIDE TOP CASE OF HANDSET 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 71 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 33: INSIDE HANDSET SHOWING BRACE HOLDING COMPONENTS 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 72 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 34: EARPIECE SPEAKER OF HANDSET 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 73 of 85 © Rhein Tech Laboratories, Inc. PHOTOGRAPH 35: MICROPHONE AND CONNECTOR TO HANDSET 360 Herndon Parkway Work Order: 20…

Text truncated - open the document above for the full version.

APPENDIX A: RF EXPOSURE COMPLIANCE FCC Rules and Regulations Part 1.1307, 1.1310, 2.1091, 2.1093: 1. General Information: FCCID: O6YUTS-600FSU Environment: General Population/Uncontrolled Exposure Device category: Mobile per Part 2.1091 Modulation Type/Mode: PHS (TDMA-TDD) 2. Operating Configurations and Test Conditions: 2.1 Antenna Type(s): Antenna Type Gain (dBi) Numeric Gain QXX0318900 Patch 10.0 10.0 Whip Omni 2.0 1.59 Frequency Range Freq. Tolerance (ppm) Emission Designator 1893.65-1909.85 1.4 289KDXW 10 dBi Antenna Output Power (Worst Case) Time averaging as an inherent property (100 % Duty Cycle) (W) Time averaging as an inherent property (12.8 % Duty Cycle, -8.9 dB) (W) ERP 0.01862 (12.7 dBm) 0.0024 (3.8 dBm) EIRP 0.1862 (22.7 dBm) 0.024 (13.8 dBm) Conducted 0.055 (17.4 dBm) 0.0071 (8.5 dBm) Rated 0.010 (10.0 dBm) 0.0013 (1.1 dBm) 2 dBi Antenna Output Power (Worst Case) Time averaging as an inherent property (100 % Duty Cycle) (W) Time averaging as an inherent property (12.8 % Duty Cycle, -8.9 dB) (W) ERP 0.1096 (18.38 dBm) .0089 (9.48 dBm) EIRP 0.0689 (20.4 dBm) .0141 (11.5 dBm) Conducted 0.055 (17.4 dBm) 0.0071 (8.5 dBm) Rated 0.010 (10.0 dBm) 0.0013 (1.1 dBm) 3. MPE Calculation: The maximum distance, from the antenna at which MPE is met or exceeded, is calculated from the equation relating field strength E in V/m, transmit power P in Watts, transmit antenna numeric gain G, and separation distance in meters: The Electric field generated for a 1mW/cm 2 exposure (S) is calculated as follows: Z E S 2 = where: S = Power density E = Electric field Z = Impedance. ZSmVE×=)/( 1 mW/cm 2 = 10 W/m 2 The impedance of free space is 337 ohms, where E and H fields are perpendicular. Thus: 37710)/( ×= mVE = 64.1 V/m MPE Calculation: The maximum distance, from the antenna at which MPE is met or exceeded, is calculated from the equation relating field strength E in V/m, transmit power P in Watts, transmit antenna numeric gain G, and separation distance in meters above and solving for d below: d GP mVE ×× = 30 )/( and )/( 30 mVE GP d ×× = Power density: 3770 )/( 2 2 E cmmWP d = The limit for general population/uncontrolled exposure environment above 1500MHz is 1 2 /cmmW . SEPARATION DISTANCE: Antenna Gain (dBi) Separation Distance A 10.0 Power B (Watt) (in) (cm) Duty Cycle (%) 0.0024 0.5 1.4 12.8 0.01862 1.5 3.8 100.0 Calculations: 12.8% duty cycle = 4.61 100024.030 014.0 ×× =m 100% duty cycle = 4.61 1001862.030 038.0 ×× =m Antenna Gain (dBi) Separation Distance A 2.0 Power B (Watt) (in) (cm) Duty Cycle (%) .0089 0.4 1.1 12.8 .0689 1.2 3.0 100.0 Calculations: 12.8% duty cycle = 4.61 58.10089.030 011.0 ×× =m 100% duty cycle = 4.61 58.10689.030 03.0 ×× =m Notes: A = Distances are calculated for the largest (worst-case) separation distance as applicable B = Measured radiated output power ERP C ONCLUSION : The device complies with the MPE requirements by providing a safe separation distance between the antenna, including any radiating structure, and any persons. Proposed RF exposure safety information to include in User’s Manual: CAUTION: Antenna Installation Requirement The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.

360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 1 of 85 © Rhein Tech Laboratories, Inc. CERTIFICATE OF COMPLIANCE FCC PART 24 CERTIFICATION & INDUSTRY CANADA CERTIFICATION Test Lab: Rhein Tech Laboratories, Inc. Phone: 703-689-0368 360 Herndon Parkway Fax: 703-689-2056 Suite 1400 Web Site: www.rheintech.com Herndon, VA 20170 Applicant Information UTStarcom, Inc. 33 Wood Avenue South 3 rd Floor Iselin, NJ 08830 732-767-5263 (Scott Black) USA FCC ID: O6YUTS-600FSU GRANTEE FRN NUMBER: 0005823877 PLAT FORM: N/A RTL WORK ORDER NUMBER: 2002018 MODEL(S): UTS-600FSU RTL QUOTE NUMBER: QRTL02-241 DATE OF TEST REPORT: March 15, 2002 American National Standard Institute: ANSI/TIA/EIA603 and ANSI/TIA/EIA 603-1 FCC Classification: PCB - Licensed Base Station for Part 24 FCC Rule Part(s): PART 24: PERSONAL COMMUNICATIONS SERVICES Subpart E - Broadband PCS Industry Canada Standard: RSS-133: 2 GHz Personal Communications Services Digital Interface Information Digital Interface was found to be compliant Receiver Information Receiver was found to be compliant Frequency Range (MHz) EIRP (W) Freq. Tolerance Emission Designator 1896.65-1909.95 0.380 2.5 ppm 289KDXW 360 Herndon Parkway Work Order: 2002018 Revision: 2 Suite 1400 Quote Number: QRTL02-241 Revision: Herndon, VA 20170 FCC CFR 47 Rules and Regulations http://www.rheintech.com Industry Canada Standard(s) Page 2 of 85 © Rhein Tech Laboratories, Inc. TABLE OF CONTENTS 1 GENERAL INFORMATION ............................................................................................................................................... 5 1.1 SCOPE .......................................................................................................................................................................... 5 1.2 TEST FACILITY .......................................................................................................................................................... 5 1.3 RELATED SUBMITAL(S)/GRANT(S) ....................................................................................................................... 5 2 EQUIPMENT INFORMATION .......................................................................................................................................... 6 2.1 APPLICANT AND EQUIPMENT INFORMATION ................................................................................................... 6 2.2 JUSTIFICATION .......................................................................................................................................................... 6 2.3 EXERCISING THE EUT .............................................................................................................................................. 6 2.4 TEST SYSTEM DETAILS ........................................................................................................................................... 7 2.5 CONFIGURATION OF TESTED SYSTEM ................................................................................................................ 7 3 DC VOLTAGES AND CURRENTS - PART §2.1033(C)(8) .............................................................................................. 8 4 RF POWER OUTPUT - §2.1046 ................................…
