Wireless Local Loop RPC/RP Installation & Configuration Manual WLL-RPC/RP-IN/UM-1.0 June 19, 2000 RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 ii Compiled by (Joseph) Guangping Zhang  Copyright 2000 UTStarcom Inc. All Rights Reserved. This manual has been prepared for UTStarcom customers, UTStarcom personnel, and licensees. The information contained herein is the property of UTStarcom Inc. and shall be neither reproduced nor utilized in any form or by any means, electronically or mechanically, in whole or in part, without prior written approval from UTStarcom Inc. RPC/RP Manual 19June2000 WLL-RPC/RP-IN/UM-1.0 iii Important Safety Instructions ! Safety Information: Installer and User WARNING The device is to be installed and operated at a “fixed location”. The term "fixed location" means that the device is physically secured at one location and is not able to be easily moved to another location. It must be located - (for indoor RPs) up on or near the ceiling away from users or bystanders – (for outdoor RPs) on the roof top site, pole, building, or traffic light away from users or bystanders. It must be mounted in a manner to ensure that a minimum separation distance of 20cm is normally maintained between all users, bystanders and the antenna (including any radiating structure). The installer may be required to perform an MPE evaluation and an Environmental Assessment (EA) of the location at the time of licensing per CFR 47 Part 1.1307. Fixed mounted antennae that are co-located with other antennae must satisfy the co-location requirements of Part 1.1307. Limits: The limit for general population/uncontrolled environment exposures is 1 2 /cmmW for the band 1500-100,000 MHz. MPE evaluation: The following calculations are provided for the more restrictive limit: uncontrolled environment/general population. The calculated minimum safe distance, Radii(cm), is approximately 10 times lower than the minimum required installation distance of 20 cm per Part 2.1091. RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 iv Therefore, the transmitter model numbers EA7H74B and EA7H75B complies with the MPE requirements by providing a safe separation distance between the antenna (including any radiating structure) and any persons. The calculations were performed using formulas found in OET Bulletin 65 Edition 97-01(1997). Transmitter Specifications: Antenna Type Gain (dBi) Output power EIRP (dBm) Output Power (dBm) Base stations M/N Minimum Installation Distance (cm) 2.4 21.4 19 dBm (Peak) EA7H74B 20 Built-in 2.4 12.4 10 dBm (avg) EA7H74B 20 7 26 19 dBm(Peak) EA1H75B 20 Omni- Directional 7 17 10 dBm (avg) EA1H75B 20 MPE Radii (m) For general population/uncontrolled environment Power P(W) Max. Peak Antenna G numeric Radii(cm) Base stations M/N 0.08 1.7 1.5 EA7H74B 0.08 5.0 2.5 EA1H75B General Safety Instructions: • The sign on the top right corner is intended to alert the user the presence of important operation and maintenance (service) instructions in the literature accompanying the product. Also notice warnings such as “WARNING!” or “CAUTION.” • When installing, operating, or maintaining the system, please follow the basic safety procedures in order to reduce the risk of fire, electric shock, and injury to persons, as listed below: • Read and understand all instructions. • Follow all warnings and instructions marked on this product. • For information on proper mounting instructions, consult the Installation Manual provided with this product. • Install only equipment identified in the Installation Manual provided with this product. Use of other equipment may result in improper connection of circuitry leading to fire or injury to persons. RPC/RP Manual 19June2000 WLL-RPC/RP-IN/UM-1.0 v • The telecommunication interfaces should not leave the building unless connected to telecommunication devices providing primary and secondary protection, as applicable. • This product should only be operated from the type of power source indicated on the marking label. • This equipment must be provided with a readily accessible disconnect device as part of the building installation. • Installation must include an independent frame ground drop to building ground. Refer to installation instructions. • Do not use this product near water, for example in a wet basement. • Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious damage to the product. • Use caution when installing or modifying telecommunications lines. • Never install telecommunications wiring during a lightning storm. • Never install telecommunications in wet locations. • Never touch uninsulated telecommunications wires or terminals unless the telecommunications line has been disconnected at the network interface. • Never touch uninsulated telecommunications wires or terminals carrying direct current or ringing current or leave this wiring exposed. Protect and tape such wiring and terminals to avoid risk of fire, electric shock, and injury to service personnel. • Never push objects of any kind into this product through slots as they may touch dangerous voltage points or short-out parts that could result in a risk of fire or electrical shock. Never spill liquids of any kind on this product. • Slots and openings in the unit are provided for ventilation, to protect it from overheating. These openings must not be blocked or covered. This product should not be placed in a built-in installation unless proper ventilation is provided. • To reduce the risk of an electrical shock, do not disassemble this product. Service should be performed by trained personnel only. Opening or removing covers and/or circuit boards may expose you to dangerous voltages or other risks. Incorrect re-assembly can cause electrical shock when the unit is subsequently used. RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 vi • This equipment is intended for installation in restricted access locations where access is controlled or where access can only be gai…

Text truncated - open the document above for the full version.

RPC/RP Manual RPC Installation 19June2000 WLL-RPC/RP-IN/UM-1.0 2-23 Figure 2-20: Card Installation 14. Connect the RMT or PC to the connector on the ECNT module. See Figure 2-21. RPC Installation RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 2-24 Figure 2-21: Maintenance Terminal or PC Connection F NOTE: RPC maintenance and configuration can also be made throught the network management system via the COT which is connected to the RPC. 15. Load operation data. 16. Replace the power source cover on the front of the RPC and secure it with screws as shown in Figure 2-22. RPC/RP Manual RPC Installation 19June2000 WLL-RPC/RP-IN/UM-1.0 2-25 Figure 2-22: Replacement of Power Source Cover 17. Replace the card cover. Make certain the hinge pins are properly aligned with the hinge. Tighten the thumbscrews. RPC Installation RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 2-26 Figure 2-23: Replacement of the Card Cover 18. This concludes the RPC installation. 19. When the RPs have been installed and connected to the RP Interface cards, measure the loop resistance of the cable. Then set the Distance Switch on the RP Interface card based on the loop resistance value. Refer to the table and figure below. The factory setting is Short. Setting Loop Resistance Long 150Ω or more Short Less than 150Ω Table 2-3: Distance Switch Settings RPC/RP Manual RPC Installation 19June2000 WLL-RPC/RP-IN/UM-1.0 2-27 Figure 2-24: Distance Switch RPC Installation RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 2-28 19June2000 WLL-RPC/RP-IN/UM-1.0 3 RP Installation 3 RP Installation 3.1 General Description The Radio Port (RP) is the radio equipment base station that relays the communication from the user side to the operator/network side or vice versa. A standard installation for RP applications places several RPs in a common service area. However, the number of RPs and their distribution deployment depend on the following factors: • Topography of the service area • Subscriber distribution in the service area • Desired Grade of Service and traffic load. There are two types of RPs: • Outdoor - is small in size and is encased in a weather-proof cabinet. This gives it the potential for various mounting scenarios - installed on the dedicated poles, buildings, or street lamp poles. • Indoor - is also small in size and can be installed in public and semi-public locations like an office building, a shopping mall, or an underground parking lot. The power for the RP is fed from the RPC and a synchronous clock is delivered from the RPC. The radio link between the RP and the FSU, or the RP and the PS is based on RCR-STD 28 Ver.2 PHS technology, which defines frequency bands, protocol, and so on. Both the indoor and the outdoor RPs have a 2 branch built-in antenna. The architecture of the WLL system is illustrated in Figure 3-1, which is followed by a block diagram of the RP. RP Installation RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 3-2 Figure 3-1: RP in the WLL System RPC/RP Manual RP Installation 19June2000 WLL-RPC/RP-IN/UM-1.0 3-3 Figure 3-2: Radio Port Block Diagram 3.1.1 Traffic Handling PHS applies Time Division Multiplex Access (TDMA) and Time Division Duplex (TDD) techniques. Each individual radio link between the RP and the FSU/PS is assigned 1 time slot for a control channel (C-ch) and 3 slots for traffic channels (T-chs). In the case of a single RP, there are 4 time slots installed for radio links. One slot is the control channel for signaling and the other three are the traffic channels. The number of accommodated subscribers in that RP covering the zone calculated according to the erlang theory is as follows: • Erlang per zone (3 T-chs, GOS=5%) = 0.899 erlang • Subscribers (FSUs or PSs) (0.899÷.08) = 11 subscribers Group Control maximizes the number of channels available for traffic by allowing one control channel to control up to 8 RPs (up to 31 traffic channels), which is an efficient application for high traffic areas. One master RP can control a maximum of 7 RPs in the same area. The master RP has one control channel, and all the other channels are assigned for traffic, leaving 31 channels open for traffic. Figure 3-3 represents the group control configuration with 4 RPs in the group. RP Installation RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 3-4 Figure 3-3: Group Control RPs In the group control mode, the number of accommodated subscribers in the group control coverage zone is calculated in accordance with the erlang theory as follows (with 4 RPs in the group): • Erlang per zone (15 T-chs, GOS=5%) = 10.663 erlang • Subscribers (FSUs or PSs) (10.663÷.08) = 132 subscribers The comparison for the number of accommodated subscribers between the group controlled RPs and the single RP is shown in Figure 3-4. F NOTE: Figure 3-4 represents the group control with 4 RPs. Each group can have a maximum of 8 RPs. RPC/RP Manual RP Installation 19June2000 WLL-RPC/RP-IN/UM-1.0 3-5 Figure 3-4: Accommodated Subscribers per RP in Group and Non-group Control The recommended installation design for RPs is as follows: • A zone of sparse subscribers should be covered by non-group controlled RPs. • A zone of dense subscribes should be covered by group-controlled RPs. The number of accommodated subscribers is the greatest when all of the RPs connected to an RPC are configured in the group control mode. In this case (with 4 RPs in each group), the number of service zones is eight (32÷4), and the maximum number of subscribers is 1,056 (132x8). Each Group Control zone supplies 15 traffic channels. Eight zones require 120 channels (15x8) provided by 4 E1 lines with 30 channels each. 3.1.2 Cell Overlap Maximum service results are achieved when the RP coverage area is strategically installed in a Cell Overlap Capacity. RP Installation RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 3-6 Figure 3-5: Coverage Service Area with Cell Overlap The combination of Cell Overlap and Dynamic Channel Allocation increases the flexibility and the capacity of the s…

Text truncated - open the document above for the full version.

RP Installation RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 3-14 Figure 3-12: Outdoor RP Instruction Flow Chart 3.4.1 Before Beginning To ensure that the outdoor RP installation goes smoothly, it is necessary to make adequate planning prior to the installation, including: • Tools required • Number of people needed to complete the installation • Location of the RP Main Unit 3.4.2 Outdoor RP Installation Follow the steps below to install an outdoor RP: 1. Unpack the outdoor RP and accessories and make sure they are in good condition. Refer to Figure 3-13. The package includes: • Outdoor RP (1) RPC/RP Manual RP Installation 19June2000 WLL-RPC/RP-IN/UM-1.0 3-15 • Mounting plate (2) • One M4 screw (3) • Four M6 screws (4) Figure 3-13: Overview of the RP, Packing, and Accessories 2. Make sure that the outdoor RP is installed in one of the positions shown in Figure 3-14. RP Installation RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 3-16 Figure 3-14: Outdoor RP Recommended Positions F WARNING: Installation of the RP in any other position may permit moisture to enter the device possibly causing damage or injury. 3. Pre-drill holes for bolts according to the dimensions shown in Figure 3-15. Attach the mounting plate to a wall with 4 bolts. Notice that the lower right edge of the mounting plate has a bend in it. The purpose of this bend is to hold the antenna connectors in place. Refer to Figure 3-15. RPC/RP Manual RP Installation 19June2000 WLL-RPC/RP-IN/UM-1.0 3-17 Figure 3-15: Mounting Plate 4. To remove the top cover, lower the screw caps and loosen the screws with the special screwdriver. Pull the top cover backward and upward from the main unit as shown in Figure 3-16. RP Installation RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 3-18 Figure 3-16: Top Cover Removal RPC/RP Manual RP Installation 19June2000 WLL-RPC/RP-IN/UM-1.0 3-19 5. Mount main unit on the mounting plate. Position both the hinge pins in the u- notches on the mounting plate. Refer to Figure 3-17. Do not fasten with the screws right now. The antenna cables must be connected first. Figure 3-17: Mount Main Unit 6. Connect each antenna cable and push the antenna connectors and surplus antenna cable in between the mounting plate and the RP main unit. Make sure that the antenna connectors are above the holding bend of the mounting plate and that the antenna cables are not caught by it. RP Installation RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 3-20 Figure 3-18: Antenna Cable Connections 7. Affix main unit to the mounting plate with the M4 screw as shown in Figure 3-19. RPC/RP Manual RP Installation 19June2000 WLL-RPC/RP-IN/UM-1.0 3-21 Figure 3-19: RP Attachment to the Mounting Plate 8. Replace the top cover. Make sure it is properly positioned over the fin on the main unit as shown in Figure 3-20. Tighten the screws in the top cover and replace the screw caps. RP Installation RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 3-22 Figure 3-20: Top Cover Attachment 9. This completes the installation of the outdoor RP. RPC/RP Manual RP Installation 19June2000 WLL-RPC/RP-IN/UM-1.0 3-23 19June2000 WLL-RPC/RP-IN/UM-1.0 4 RPC/RP Configuration 4 RPC/RP Configuration After the installation of the RPC and RP, configuration must be made to provision the RPC and RP. This is done through the Netman network management system. Netman is the network management tool for the system. It centralizes the management of all the DMs in the network, including the RPCs. This chapter describes the RPC/RP configuration process through Netman 2000. 4.1 Initialize an RPC Node RPCs are represented as independent DMs on the Netman Main View window although they are actually controlled by the COT node to which they are attached. Figure 4-1 and Figure 4-2 represent the toolbar and pull-down menu of the RPC DM window. Figure 4-1: Toolbar and Description (RPC R2.4) RPC/RP Configuration RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 4-2 Figure 4-2: Netman Pull-down Menus (RPC R2.4) This section describes the procedures to initialize an RPC node. Follow the steps below to get connected to an RPC: 1. On the Main View window of the Netman network management system, double click the target RPC icon. This opens the Connect RPCs window, as shown below. Figure 4-3: Connect RPCs Window RPC/RP Manual RPC/RP Configuration 19June2000 WLL-RPC/RP-IN/UM-1.0 4-3 2. There are 15 RPCs to select from. Click the check boxes of the RPCs to be connected and then click OK. 3. A connection status box appears, displaying the connection process. When the process is complete, the RPC window opens with four frames, as displayed in Figure 4-4. Figure 4-4: RPC Window The top left frame is called the Unit View window. It lists the current units, such as, RPCs, RPs, interfaces, etc. The NODE displays its IP address. The connection status of the RPC nodes on the tree structure is represented in three different colors. The green and red color indicate connected and unconnected RPCs respectively, whereas the RPC nodes in black color indicate that they are not selected for connection. The top right frame is called the Status View window. It displays the relevant status information corresponding to the selection on the left, on the menu bar, or on the toolbar. The small frame under the Unit View window is the Connection View window. It displays the connection status and the connected RPC. RPC/RP Configuration RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 4-4 Finally, the frame at the bottom is the Self Messages window. It displays messages about the command execution results, trap messages, or warnings, if there is any. 4. To get connected to a certain RPC, reselect the RPC by clicking the RPC on the Unit View window. A connection status box appears, displaying the connection process. If the connection is successful, a message will appear on the Connection View window, stating “Connected to RPC#...” If the connection fails, the message will be: “Not Connected!” 5. When the connection is complete, the Sta…

Text truncated - open the document above for the full version.

RPC/RP Configuration RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 4-12 Figure 4-13: RPC Window 4.2.1 Set Time To set the system time, follow the procedures below: 1. Click the Set Time option on the Configuration pull-down menu. The Set Time window appears, as shown in the figure below. Figure 4-14: Set Time Window 2. By default the RPC time is set to the current time of the PC. Set new date and time to RPC if necessary. Make necessary adjustment using the Arrow RPC/RP Manual RPC/RP Configuration 19June2000 WLL-RPC/RP-IN/UM-1.0 4-13 buttons in the fields. Click OK to accept the setting or Cancel to stop the transaction. 4.2.2 RPC Change Sometimes the operation data for an RPC may not be compatible to the hosting RPC. Use this function to make changes to the SDM (System Data Memory) so that it can accommodate the hosting RPC. Before making any change, the RPC device manager will disconnect from the RPC. 1. From the Configuration main menu, select RPC Change. This opens the RPC Assignment window, as illustrated in the figure below. Figure 4-15: RPC Assignment Window 2. Select the target RPC and click OK. This will change the SDM to fit the target RPC. 3. If this command doesn’t work, exit the current Netman session and restart. 4.2.3 Unit Control The Unit Control option can be accessed through the Maintenance pull-down menu. It has the following functions: • Blockade: block or unblock RPIF, E1IF, RPCs, RPs • TimeSlot Layout: configure the RP control channel time slot • Maintenance: set or cancel system maintenance • Master RP: change Master RP • RPC Sync: RPC Synchronization • Online Trace: retrieve the information of the active RP RPC/RP Configuration RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 4-14 4.2.3.1 Blockade/Unblockade The Blockade option is used to block or unblock RP interface, E1 interface, RPs, or the entire RPC. Use this function to block traffic from a malfunctioning device. It is also used when units are replaced. Netman 2000 must be connected to the WLL/V5WLL in order to perform this function. Another important usage of this option is to regain the synchronization of the slave RPCs upon the recovery of the master RPC. 1. From the Maintenance main menu, select Unit Control and then Blockade. This opens the Blockade/Unblockade window, as displayed in the figure below. Figure 4-16: Blockade/Unblockade Window Field Name Description RPC The entire RPC, including all the units under its control E1-I/F #... E1 interface. Each RPC uses 4 E1 interfaces to communicate with WLL/V5WLL. RP-I/F #... RP interface. RPC uss 8 RP interfaces to control RPs. Each RP interface is connected to 4 RPs. All RP All the 32 RPs RP #... Individual RP. There are altogether 32 RPs under each RPC. Blockade If this radio button is selected, the selected unit is blocked. UnBlockade If this radio button is selected, the selected unit is unblocked. Table 4-1: Blockade/Unblockade Window Field Description 2. Select the target E1 interface, RP interface, RP, or RPC, and then select Blockade or Unblockade. Click OK. Selecting RPC will block or unblock all RPC/RP Manual RPC/RP Configuration 19June2000 WLL-RPC/RP-IN/UM-1.0 4-15 the units controlled by the RPC. No new calls will be accepted and all the calls in progress are allowed to complete and then dropped. 3. When the action is implemented, the system displays a message in the Self Message window, and the Status View window will also show the Blockade result, as illustrated in the figure below. Use the window to verify the result. Figure 4-17: Self Message and Status View window for Blockade F NOTE: If an RPC or all RPs are blocked, calls cannot be made. 4. Zero “o” in the Blockade Maint column means the unit is blocked, and dash “- ” means the unit is unblocked. The Status and the Self Messages windows both indicate that RP#1 and RP#2 are blocked. 5. There are two ways to access the Status View window. One is to click Status and then the relevant options: RPC, RPs, RP-I/F Board, E1 Signal, Node-I/F Board, Air Channel, or TimeSlot Status. The other is to click the target item on the left frame of the RPC window. In either case the Status View window opens on the right frame. Of course, one can always access the window by clicking the relevant toolbar. RPC/RP Configuration RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 4-16 4.2.3.2 TimeSlot Layout F WARNING: Users are NOT recommended to make changes to the settings of the Time Slot. Use with caution! When connected to an RPC, use this function to reconfigure the RP control channel time slot. This function is used to complete the RP configuration and make it usable. This function applies to both RPCs and RPs. 1. Before configuring the time slot, use the Blockade function to block the target RPC or PC. 2. From the Maintenance main menu, select Unit Control and then TimeSlot Layout. This opens the Time Slot Layout window, as shown in the figure below. Figure 4-18: Time Slot Layout Window 3. Select the target RPC or RP. 4. Select Measure Level1. If separation is not completed, try another one from Measure Level2 through Measure Level4. Selecting No Selection may accelerate separation. 5. Select No Selection. If selection must be made, select one from Slot #1 through Slot #80. 6. Click OK to close the window. RPC/RP Manual RPC/RP Configuration 19June2000 WLL-RPC/RP-IN/UM-1.0 4-17 7. Unblock the RPC or RP. F NOTE: The Time Slot Layout window is for configuration purpose only. Actual separation is done when the target RPC or RP is unblocked. 4.2.3.3 Maintenance Use this function to set RPC maintenance status, test RPs, and do other configuration. Eligible units are fully installed RPCs and installed RPs. F NOTE: General PSs can not use RP when maintenance is under way. 1. From the Maintenance main menu, click Unit Control, and then Maintenance. The Set/Cancel Maintenance window opens, as displayed in the figure below. Figure 4-19: Set / Cancel Maintenance Window 2. Select the target RPC or RP, and click Set to set t…

Text truncated - open the document above for the full version.

RPC/RP Configuration RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 4-46 4.3.7 Copy Data This function is used to copy the operating data from the ACT SDM to the SBY SDM. The automatic SDM switching is not supported for this function. 1. From the Configure main menu, click Service Data, and then Write Data. This opens the Write System Service Data window, as shown in the figure below. Figure 4-52: Write System Service Data Window 2. Click the Copy radio button and then click OK. A confirmation dialog box appears, as illustrated in the figure below. Click OK to confirm the copying command. Figure 4-53: Confirmation Dialog Box 4.3.8 Edit Data RPC operation data contain three categories: 1. Service data 1: RP installation 2. Service data 2: Group control configuration 3. Service data 3: System parameters RPC/RP Manual RPC/RP Configuration 19June2000 WLL-RPC/RP-IN/UM-1.0 4-47 Use this function to edit an existing operation data file while the RPC is operating. F NOTE: Operation data must be edited locally in a file, and then downloaded to the system. 4.3.8.1 Service Data 1: RP Installation 1. From the Configuration main menu, click the Service Data option, and then the Edit Data option. This brings up the Specify File for Edit window, as shown in the figure below. Figure 4-54: Specify file for Edit Window 2. Select the target .dat or .eep file and click Open. The system edits all the files with any one of the two suffixes. The Edit of Service Data 1 window opens, as shown in the figure below. RPC/RP Configuration RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 4-48 Figure 4-55: Edit of Service Data 1 Window Field Name Description RP# RP ID number Inst. Set “installed” or “not installed” for RPs according to RP installation plan. Phantom The power is supplied by the RPC. Local The power is supplied by the RP power unit. Save Save the setting to a local file. Next Switch to the next Service Data window. Cancel Cancel the editing. Switch 1,2,3 Switch to one of the three Service Data windows. Table 4-12: Edit of Service Data 1 Window Field Description 3. For each installed RP, enter a √ in the Inst. row. For each installed RP, specify the power source by clicking on either the Phantom button or the Local button. For WLL, the power source is Phantom. Local is for future use when the power is 20 milliwatts or higher. 4.3.8.2 Service Data 2: Group Control Configuration 1. To get to the Edit of Service Data 2 window, click Next or Switch 2. The Edit of Service Data 2 window opens, as shown in the figure below. RPC/RP Manual RPC/RP Configuration 19June2000 WLL-RPC/RP-IN/UM-1.0 4-49 Figure 4-56: Edit of Service Data 2 Window Field Name Description RP-I/F RP interface ID number Group # Group ID number RP# RP ID number Master Master/Slave status of the RPs Save Save the Service Data toa a file. Next Switch to the next window Table 4-13: Edit of Service Data 2 Window Field Description F NOTE: RP ID numbers are defined according to the connected physical port numbers on the RP interface boards, as listed below: RP-IF#1 port 1 ----- RP#1 RP-IF#1 port 2 ----- RP#2 RP-IF#1 port 3 ----- RP#3 RP-IF#1 port 4 ----- RP#4 RP-IF#2 port 1 ----- RP#5 ..... RP-IF#3 port 1 ----- RP#9 ..... RP-IF#8 port 1 ----- RP#29 RP-IF#8 port 2 ----- RP#30 RP-IF#8 port 3 ----- RP#31 RP-IF#8 port 4 ----- RP#32 RPC/RP Configuration RPC/RP Manual WLL-RPC/RP-IN/UM-1.0 19June2000 4-50 2. This window is for the configuration of Group Control. Group Control maximizes the number of channels available for traffic by allowing one control channel to control up to 8 RPs (up to 31 traffic channels). A group can be set up only within two adjacent RP interface boards. Group members must be within the two RP Interface boards. For each RP, enter the group number and designate the master. In the above window, 7 RPs on RP Interface card 5 and 6 are in group 17 with the master RP designated as RP number 17. The master RP must be the RP with the lowest RP number in the group. The RPs that are not in group control must be designated as their own masters and have their own group numbers, as is the case for RP# 21 in the above figure. 4.3.8.3 Service Data 3: System Parameters The third Edit of Service Data window contains system parameters. It is not necessary to administer the parameters, as they are set at the factory. Users can only change the relevant values for the parameters. Click on Next or Switch 3 to open the Edit of Service Data 3 window, as shown in the figure below. Figure 4-57: Edit of Service Data 3 Window RPC/RP Manual RPC/RP Configuration 19June2000 WLL-RPC/RP-IN/UM-1.0 4-51 Field Name Definition No. Item sequence numbers, starting from 1 Value Specified value for the item. The value can be selected from the arrow drop-down list. Item Item name and value description Basic Basic value Unit Item value unit Min The minimum value which can be specified for the item Max The maximum value which can be specified for the item HEX val. Switch between the hexadecimal and the decimal value Button Name Description Target Select the target PRC ID number to display its system parameters. Item Only item names are displayed on the right column. Basic Basic value, unit value, and item names are displayed on the right column. Range Maximum value, minimum value, unit value, and item names are displayed on the right column. < Scroll the window downward one line at a time. > Scroll the window upward one line at a time. << Scroll the window downward one page at a time. >> Scroll the window upward one page at a time. Save Save the value setting. Top Go to Service Data 1 window. Table 4-14: Edit of Service Data 3 Window Field Definition There are three different windows for this function: Item, Basic, and Range. Use the View Block to switch to different windows. Edit the data as necessary and click Save. A confirmation box appears, prompting: “Current file will be replaced by this contents. OK?” Click Yes to confirm or No to stop the transaction. The operation data …

Text truncated - open the document above for the full version.
