O6ZR16DIREC TV SATELLITE RECEIVER

This reminder is provided to call your attention to articles 810 and 820 of the 2005 National Electrical Code. Refer to article 810, in particular 810-1 and 810-15, for required grounding of the metal structure of the dish antenna. Refer also to the 810-2 which, by reference to article 820, requires that the satellite dish coaxial cable shield be connected to the grounding system of the building as close to the point of cable entry as practical. Note to Satellite Dish Installer • Ensure proper ventilation — the vent slots on the DIRECTV Receiver must be left uncovered to allow proper airfl ow to the unit. Blocking the airfl ow to the unit could impair performance or damage your receiver and other components. • Do not stack electronic components or other objects on top of the DIRECTV Receiver. Also, do not stack the receiver on top of a “hot component” such as an audio power amplifi er. • Protect your components from power surges by connecting all the components before plugging any power cords into the wall outl et. Use of a surge protector is also recommended. • Don’t overload power outlets or extension cords, which can result in the risk of fi re or shock. It’s also important to use on ly the type of power source indicated on the marking label or in this manual. • Avoid audio hum or interference by inserting all cable plugs fi rmly into their jacks. Also, place Audio/Video (A/V) cables to the sides of the TV back panel rather than down the middle once connected. Try not to coil any twin-lead cables and keep them away from A/V cables as much as possible. • Never insert objects of any kind into any openings in the DIRECTV Receiver (other than the DIRECTV® Access Card as detailed in this manual). • Place it on a fl at, hard surface — do not operate the DIRECTV Receiver on a carpet or other padded surface.• Th e mains power connector at the back of the unit or at the outlet should be accessible to allow quick shutdown in case of emerg ency. • Always unplug your DIRECTV Receiver before moving it.• Always unplug the DIRECTV Receiver, TV and other equipment before you connect or disconnect any cables.• Th e only way to disconnect the the DIRECTV Receiver from the power supply is to remove the power cord. Th e DIRECTV Receiver unit must therefore be installed next to the power point which must be easily accessible. • CAUTION: Electric Shock — never attempt to disassemble the DIRECTV Receiver yourself; always take it to a qualifi ed service person when repair is required. Opening or removing covers may expose dangerous voltage or other risks, and incorrect reassembly can cause shock when receiver is subseque ntly used. Attempted self-repair may also void your warranty. Changes or modifi cations not expressly approved by the party responsible for compliance (by the warranty or by the manufacturer) could void th e user’s authority to operate the equipment. • Do not drop your DIRECTV Receiver and always move it with care.• Have your DIRECTV Receiver professionally serviced (do not attempt to service it yourself ).• Any changes or modifi cations in construction of this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. • If you move your DIRECTV Receiver between locations at diff erent temperatures, allow it to reach room temperature before you apply power to it. • Do not pick up or otherwise move your DIRECTV Receiver while it is connected to the AC power supply. If you want to move your set-top box, fi rst disconnect it, then wait at least 30 seconds before continuing For your information:Th e identifi cation sticker can be located underneath or on the back of your receiver. Th e telecommunication network voltage used is the category number 3. TIP We highly recommend plugging the DIRECTV Plus DVR into a surge protector to prevent damage from fluctuations in your power supply. R16 UG Book.indb iiiR16 UG Book.indb iii 7/31/07 1:58:44 PM7/31/07 1:58:44 PM iv Contents Getting Started Welcome ....................................................................................................................... .............................2 About Your DIRECTV Plus DVR ................................................................................................... ..........2 Making the Right Connections .................................................................................................. ................3 Getting Familiar .............................................................................................................. ..........................4 What’s On Watching TV .................................................................................................................. ........................11 Th e Guide ...................................................................................................................... .........................17 Th e Mini Guide ................................................................................................................. ......................19 Recording Programs ............................................................................................................ .....................20 Pay Per View .................................................................................................................. ..........................23 Th e Playlist ................................................................................................................... ...........................24 The Menu Using the Menu ................................................................................................................ .......................28 Settings ...................................................................................................................... ..............................28 Audio Options .....................................................................................…

Text truncated - open the document above for the full version.

FCC ID: O6ZR16 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 1 FCC ID: O6ZR16 Copyright Ⓒ 2007, DIGITAL EMC Co., Ltd. View 2

FCC ID: O6ZR16 FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase Per 15.19 FCC ID: O6ZR16

FCC ID: O6ZR16 Copyright ○ Ⓒ 2007, DIGITAL EMC Co., Ltd. View 1 FCC ID: O6ZR16 Copyright ○ Ⓒ 2007, DIGITAL EMC Co., Ltd. View 2 FCC ID: O6ZR16 Copyright ○ Ⓒ 2007, DIGITAL EMC Co., Ltd. View 3 FCC ID: O6ZR16 Copyright ○ Ⓒ 2007, DIGITAL EMC Co., Ltd. View 4 FCC ID: O6ZR16 Copyright ○ Ⓒ 2007, DIGITAL EMC Co., Ltd. View 5 FCC ID: O6ZR16 Copyright ○ Ⓒ 2007, DIGITAL EMC Co., Ltd. View 6

DEMC#DR50110711J FCC ID: O6ZR16 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 1 of 31 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 Tel: +82-31-321-2664 Fax: +82-31-321-1664 http://www.digitalemc.com CERTIFICATE OF COMPLIANCE FCC Part 15B Certification Dates of Tests : November 24 ~ 26, 2007 Test Report No. : DR50110711J Test Site : DIGITAL EMC CO., LTD. FCC ID. APPLICANT FCC Classification : Part 15 TV interface device Device name : DIRECTV Plus DVR Manufacturer 1 : Humax Co., Ltd. Manufacturer 2 : DongGuan LiaoBu Anam Electronics Co., Ltd. Model name : R16-500 Brand name DIRECTV Test Device Serial number : Identical prototype FCC Rule Part(s) : FCC Part 15 Subpart B Date of issue : November 26, 2007 I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. O6ZR16 Humax Co., Ltd. DEMC#DR50110711J FCC ID: O6ZR16 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 2 of 31 TABLE OF CONTENTS 1. GENERAL INFORMATION ----------------------------------------------------------------------------- 2. INFORMATION ABOUT TEST ITEM ----------------------------------------------------------------- 3. TEST REPORT --------------------------------------------------------------------------------------------- 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 MEASUREMENT REQUIREMENTS ------------------------------------------------------------- 3.2.1 RADIATED EMISSION MEASUREMENT ------------------------------------------------- 3.2.2 CONDUCTED EMISSION MEASUREMENT --------------------------------------------- 3.2.3 OUTPUT SIGNAL LEVEL MEASUREMENT --------------------------------------------- 3.2.4 OUTPUT TERMINAL CONDUCTED SPURIOUS EMISSION ------------------------- 3.2.5 TRANSFER SWITCH ISOLATION MEASUREMENT ----------------------------------- APPENDIX TEST EQUIPMENT USED FOR TESTS ----------------------------------------------- 3 4 5 5 6 6 9 18 24 29 30 DEMC#DR50110711J FCC ID: O6ZR16 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 3 of 31 1. General Information This report contains the result of tests performed by: DIGITAL EMC CO., LTD. Address : 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 http://www.digitalemc.com E-mail : [email protected] Tel: +82-31-321-2664 Fax: +82-31-321-1664 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. This laboratory is accredited by NVLAP for NVLAP Lab. Code : 200559-0. Test operator: Engineer November 26, 2007 Seung-Bum Cho Data Name Signature Report Reviewed By: Manager November 26, 2007 Young-Kyu Shin Data Name Signature Ordering party: Company name : Humax Co., Ltd. Address : Humax Building 212-1, Yubang-Dong, Yongin-City City/town : Gyunggi-Do Country : Korea. Zip code : 449-080 Date of order : November 09, 2007 DEMC#DR50110711J FCC ID: O6ZR16 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 4 of 31 2. Information about test item R16-500 2.1 Equipment information Kind of Equipment DIRECTV Plus DVR Model No.(Brand Name) R16-500 (DIRECTV) Add Model No. R16 Model difference Only model name Serial No. None Type of Sample Tested Pre-Production Rating Power Supply 100 – 240V, 50/60Hz, 55Watts Frequencies 4MHz, 27MHz, 24MHz, 28.224MHz, 13.225625MHz, 166MHz Internal Board and Layers SMPS B/D : 1 layer, MAIN B/D : 4 layers, FRONT B/D : 2 layers Signal Ports SAT(1,2), RF IN/OUT, USB, Digital Audio Out, S-Video Out, Video out(1,2), Audio out(1,2), Phone jack RF Output Channel CH3, CH4 Impedance of RF In/Out Port 75ohm Tested Power Supply 1 Phase 120Vac, 60Hz 2.2 Ancillary Equipment Equipment Model No. FCC ID Serial No. Manufacturer Video monitor SAM-14MV DOC F509M0962 KTV GROBAL USB Memory Stick(4GB) Mandriva DOC N/A AXXEN 2.3 Used Cables Port Name Shield Length(m) Back shell Connected to Satellite In 1 Y 10 Metal Satellite ANT Satellite In 2 Y 10 Metal Satellite ANT Off-AIR In Y 1.5 Metal Termination Out To TV Y 1.5 Metal Termination USB - - Metal USB Memory Stick S-Video Out Y 1.5 Metal Video monitor Audio/Video Out 1 Y 1.5 Metal Video monitor Audio/Video Out 2 Y 1.5 Metal Termination Phone jack N 10 Plastic Tel Line DEMC#DR50110711J FCC ID: O6ZR16 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 5 of 31 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Status (Note 1) 15.109 Radiated Emission Measurement C 15.107 Conducted Emissions Measurement C 15.115(b) Output Signal Level Measurement C 15.115(b) Output Terminal Conducted Spurious Emissions Measurement C 15.115(c) Transfer Switch Isolation Measurement C Note 1: C= Complies NC=Not Complies NT=Not Tested NA=Not Applicable Note 2: The EUT was tested according to FCC Part 15B and ANSI C63.4-2003. 3.2 Operation Modes for test The measurement were made at each I/O ports of EUT being connected with appropriate cables, signal generator and peripherals for termination. This EUT has RCA type video/audio output terminals, two satellite antenna inputs, a TV antenna input, a RF output terminal, a Optical audio output and a S-video output terminal. All ports were exercised appropriately for the tests. Note : USB port is for future use. DEMC#DR50110711J FCC ID: O6ZR16 Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 6 of 31 3.2 Measurement requirements 3.2.1 Radiated Emission Measurement Procedure: In the frequency range of 30MHz to 1GHz, the electric field strength was measured on a 10m Semi Anechoic Chamber with a reference ground plane and at a distance of 3m. And above 1GHz frequency range, the electric field strength was measured with double-ridged horn antenna at a distance of 3m. The height of the measuring antenna was varied between 1 to 4 m and the table (height: 0.8m) was r…
