O6ZS50-C3Satellite Redio Receiver (Dock Unit)

SIRIUS FM Direct Adapter S50 (091906c) FM ANTENNA CABLE MINI CONNECTOR FM ANTENNA SOCKET Plug the vehicle’s AM/FM antenna cable (which was disconnected from the vehicle’s AM/FM radio) into the FM antenna socket of the FM Direct Adapter. (An additional adapter may be required.) Plug the mini-connector of the FM Direct Adapter into the FM OUT connection at the rear of the S50 vehicle dock. Choose a channel on the FM band of the vehicle’s AM/FM radio that has little or no reception from a local FM station. You can consult the SIRIUS website at http://www.sirius.com/fm- channel for more information on finding a clear FM channel in your area. Choose the same channel from the FM Frequencies menu of your S50 radio. (Refer to the user guide of your S50 radio for detailed instructions.) If the installation is successful, you should hear the SIRIUS broadcasts through the vehicle’s AM/FM radio. 4. 5. 6. 7. Figure 3Figure 3 5 © 2006 Sirius Satellite Radio Inc. All Rights Reserved. ® “SIRIUS” and the SIRIUS dog logo are registered trademarks of Sirius Satellite Radio Inc. All Rights Reserved. ™ “S50” is a trademark of Sirius Satellite Radio Inc. All Rights Reserved. An “FM Out Plug” is installed in your S50 vehicle dock to ensure that your S50 radio operates prop- erly and does not interfere with other radios. Using the FM Direct Adapter is another way to ensure that your S50 does not interfere with other radios. Professional installation of the FM Direct Adapter is recommended. If you will not be using the FM Direct Adapter, the FM Out Plug is required to remain installed in the vehicle dock to ensure that your S50 radio operates properly and does not interfere with other radios. Instructions to Install the FM Direct Adapter to the S50 Vehicle Dock with an FM Out Plug FM OUTLINE OUTDC 5VANT FM Out Plug S50 Vehicle Dock (Rear) SIRIUS Customer Service: 1-888-539-7474 [email protected] SIRIUS Satellite Radio Inc. 1221 Avenue of the Americas New York, NY 10020 1-888-539-7474 http://www.sirius.com Considerations If you will be installing the FM Direct Adapter (also known as a FM Relay Switch or FM Switch Box), it will directly connect the FM signal from your SIRIUS radio to your vehicle’s AM/FM radio, reduc- ing any interference which might be present from FM radio station broadcasts. When the SIRIUS radio is turned off, the vehicle’s FM antenna is automatically connected back to the vehicle’s AM/FM radio. The adapter connects directly in-line with the vehicle’s existing AM/FM antenna input. If you will not be installing the FM Direct Adapter, the FM Out Plug must remain installed in the S50 vehicle dock to ensure that your S50 radio operates properly and does not interfere with other radios. SIRIUS suggests professional installation of the FM Direct Adapter in your vehicle. Ask your SIRIUS retailer if they provide professional installation services, or can recommend a professional installa- tion service. Certain vehicle models will require adapters to connect the vehicle’s AM/FM antenna to the FM Direct Adapter, and to connect the FM Direct Adapter to the vehicle’s AM/FM radio. Your SIRIUS retailer may sell these adapters, or a professional installer may be able to provide them. Installation Figure 1 shows an overall diagram of the FM Direct Adapter installation with your vehicle’s AM/FM radio and your SIRIUS S50 radio. FM DIRECT ADAPTER VEHICLE AM/FM ANTENNA VEHICLE AM/FM RADIO SIRIUS S50 RADIO & VEHICLE DOCK FROM VEHICLE AM/FM ANTENNA TO S50 VEHICLE DOCK TO VEHICLE AM/FM RADIO Figure 1Figure 1 To install the FM Direct Adapter in your vehicle follow these steps: Consult a professional installer to assist you in removing the FM Out Plug from the FM OUT connection at the rear of S50 vehicle dock. (Figure 2) Retain the FM Out Plug and reinstall it if the FM Direct Adapter is ever disconnected from the S50 vehicle dock. FM OUTLINE OUTDC 5VANT Remove the vehicle’s AM/FM radio from the dash and disconnect the vehicle’s AM/FM an- tenna cable from the rear of the radio. Refer to Figure 3 and plug the FM antenna cable from the FM Direct Adapter into the same connector on vehicle’s AM/FM radio. (An additional adapter may be required.) 1. 2. 3. Figure 2Figure 2 234

HUMAX CO., LTD. Humax Bldg., 212-1, Yubang-Dong, Yongin-Si, Gyeonggi-Do, 449-080, Korea Tel: +82-31-600-6362, Fax: +82-31-600-6396 Power of Attorney Date: August 01, 2005 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize ONETECH Corp., to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by ONETECH Corp on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing ONETECH Corp., as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, __________________________ Mr. Jung-Jae, Chio / Engineering Manager HUMAX Co., Ltd. Tel: +82-31-600-6362 Fax: +82-31-600-6396 E-Mail: [email protected]

#505 SK Apt. Factory, 223-28 Sangdaewon1-Dong, Jungwon-Gu, Seongnam-City, Kyunggi-Do 462-705 Korea [TEL]031-746-8500 [FAX]031-746-8700 CBTL -002 (Rev. 2) KOLAS www.onetech.co.k r Date : 2006. 10. 16 Ref. No : To : Application Examiner / Reviewing Engineer FCC Laboratory 7435 Oakland Mills Road Columbia, MD 21046 CC : Subject : Request for confidentiality per Section 0.459 of FCC Rules Applicant: Humax Co., Ltd., FCC ID: O6ZS50-C2 To whom it may concern, Request is hereby submitted, on behalf of my client, Humax Co., Ltd., to withhold from public review certain portions of the application for equipment certification for the referenced FCC identifier. In particular, the following sections of the application and report are requested to be kept confidential: Schematics Block Diagram Rationale for request for confidentiality: Humax Co., Ltd., has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the confidential portions of this application to competitors would give them competitive advantage in developing similar products. If you have questions or need further information, please contact the undersigned. Sincerely, Y.K. Kwon / Chief Engineer Onetech Corp. Email: [email protected]

Helen Zhao Subject: FW: HUMAX CO., LTD., FCC ID: O6ZS50-C2, Assessment NO.: AN06T6233 10/20/2006 From: Y.G. Gwon Sent: Friday, October 20, 2006 7:00 AM To: Helen Zhao Subject: RE: HUMAX CO., LTD., FCC ID: O6ZS50-C2, Assessment NO.: AN06T6233 Dear Helen, I think you are very busy now and I am sorry for hesitating you regarding this matter. I would like to clear your kind comments regarding this matter as following. Question # 1 : The exact FCC ID number is O6ZS50-C3. I am sorry for confusing you regarding this matter. I think you have to revise FCC 731 Form and other Form. I am really sorry about that. I would like to send some files for our revised setup photo, product photo and ID Location. Question # 2 : Attached please find revised our test report. Thanks a lot! Best Regards, Y. G. Gwon Question # 1 : The last page of external photos clearly show FCC ID: O6ZS50-C1, please confirm whether this is an correct sample for certification under FCC ID: O6ZS50-C2. Please modify the FCC ID on the photo to avoid confusion. Question # 2 : The test report shows field strength of fundamenal emission (vertical) is 35.78dBuV/m at 88.1MHz, but the spurious emission (vertical) is 39.59dBuV/m at 655.99 MHz. Based on FCC 15.215(b), "In no case shall the level of the unwanted emissions from an intentional radiator operating under these additional provisions exceed the field strength of the fundamental emission." Please address this non-incompliance issue. Best Regards, Helen Zhao The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender.

#505 SK Apt. Factory, 223-28 Sangdaewon1-Dong, Jungwon-Gu, Seongnam-City, Kyunggi-Do 462-705 Korea [TEL]+82-31-746-8500 [FAX]+82-31-746-8700 CBTL -002 (Rev. 2) KOLAS www.onetech.co.kr October 18, 2006 FCC Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Attention: Application Examiner / Reviewing Engineer Re: Confirmation Letter for FM Transmitter Applicant: Humax Co., Ltd. FCC ID: O6ZS50-C3 To whom it may concern, We, Onetech Corp., would like to answer following questions for requesting by the TCB, Compliance Certification Services Inc on behalf of our customer, Humax Co., Ltd. 1. How does this device operate? <Answer> It is used in a car. 2. Provide information on the device and its antenna <Answer> It is a personal satellite radio plus car kit with FM transmitter function. The TX antenna used is internal FM loop antenna. 3. How is it installed? <Answer> The device is installed with the radio mounted in a manner that avoids blocking the view of the road by the driver. External satellite magnetic antenna for RX only needs to be installed. 3. What test procedure was used? <Answer> ANSI C 63.4. 4. If tested in a car, how was it configured/tested? <Answer> It was not tested in a car, but it was tested in OATS and chamber, because the device does not have external antenna input port. 5. Was the tuning range properly verified? <Answer> Yes, the low channel is 88.1MHz, and the highest channel is 107.9 MHz. Please refer to the statement and test data on page 12 and 13 of the test report. 6. Was the bandwidth properly tested with maximum audio input? <Answer> The device does not have audio input port, so internal 1 kHz was used for the testing and the EUT was transmitted with maximum audio level. If you have questions or need further information, please contact the undersigned. Sincerely, Y.K. Kwon / Director Onetech Corp.

FCC ID. : Error! Unknown document property name.3 Page 1 of 3 Report No. : Error! Unknown document property name. It should not be reproduced except in full, without the written approval of ONETECH. FCC-002 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 Dong, Jungwon-Gu, Seongnam-City, Kyunggi-Do, 462-705, Korea (TEL: +82-31-746-8500, FAX: +82-31-746-8700) EMC Testing Dept : 426-1 Daessangryung-Ri, Chowol-Eup, Kwangju-City, Kyunggi-Do, 464-860, Korea. (TEL: +82-31-765-8289, FAX: +82-31-766-2904) FCC ID. : Error! Unknown document property name.3 Page 2 of 3 Report No. : Error! Unknown document property name. It should not be reproduced except in full, without the written approval of ONETECH. FCC-002 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 Dong, Jungwon-Gu, Seongnam-City, Kyunggi-Do, 462-705, Korea (TEL: +82-31-746-8500, FAX: +82-31-746-8700) EMC Testing Dept : 426-1 Daessangryung-Ri, Chowol-Eup, Kwangju-City, Kyunggi-Do, 464-860, Korea. (TEL: +82-31-765-8289, FAX: +82-31-766-2904) FCC ID. : Error! Unknown document property name.3 Page 3 of 3 Report No. : Error! Unknown document property name. It should not be reproduced except in full, without the written approval of ONETECH. FCC-002 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 Dong, Jungwon-Gu, Seongnam-City, Kyunggi-Do, 462-705, Korea (TEL: +82-31-746-8500, FAX: +82-31-746-8700) EMC Testing Dept : 426-1 Daessangryung-Ri, Chowol-Eup, Kwangju-City, Kyunggi-Do, 464-860, Korea. (TEL: +82-31-765-8289, FAX: +82-31-766-2904)

FCC ID. : O6ZS50-C3 Page 1 of 1 Report No. : E068R-025 It should not be reproduced except in full, without the written approval of ONETECH. EMC-002 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 Dong, Jungwon-Gu, Seongnam-City, Kyunggi-Do, 462-705, Korea (TEL: +82-31-746-8500, FAX: +82-31-746-8700) EMC Testing Dept : 307-51 Daessangryung-Ri, Chowol-Eup, Kwangju-City, Kyunggi-Do, 464-860, Korea. (TEL: +82-31-765-8289, FAX: +82-31-766-2904) IDENTIFICATION LABEL: PROPOSED FCC ID LABEL The FCC ID shall be permanently affixed to the rear side of the equipment This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operations. Made in Korea FCC ID : O6ZS50-C3 FCC ID AREA

FCC ID. : O6ZS50-C3 Page 1 of 5 Report No. : E068R-025 It should not be reproduced except in full, without the written approval of ONETECH. FCC-002 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 Dong, Jungwon-Gu, Seongnam-City, Kyunggi-Do, 462-705, Korea (TEL: +82-31-746-8500, FAX: +82-31-746-8700) EMC Testing Dept : 426-1 Daessangryung-Ri, Chowol-Eup, Kwangju-City, Kyunggi-Do, 464-860, Korea. (TEL: +82-31-765-8289, FAX: +82-31-766-2904) FCC ID. : O6ZS50-C3 Page 2 of 5 Report No. : E068R-025 It should not be reproduced except in full, without the written approval of ONETECH. FCC-002 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 Dong, Jungwon-Gu, Seongnam-City, Kyunggi-Do, 462-705, Korea (TEL: +82-31-746-8500, FAX: +82-31-746-8700) EMC Testing Dept : 426-1 Daessangryung-Ri, Chowol-Eup, Kwangju-City, Kyunggi-Do, 464-860, Korea. (TEL: +82-31-765-8289, FAX: +82-31-766-2904) FCC ID. : O6ZS50-C3 Page 3 of 5 Report No. : E068R-025 It should not be reproduced except in full, without the written approval of ONETECH. FCC-002 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 Dong, Jungwon-Gu, Seongnam-City, Kyunggi-Do, 462-705, Korea (TEL: +82-31-746-8500, FAX: +82-31-746-8700) EMC Testing Dept : 426-1 Daessangryung-Ri, Chowol-Eup, Kwangju-City, Kyunggi-Do, 464-860, Korea. (TEL: +82-31-765-8289, FAX: +82-31-766-2904) FCC ID. : O6ZS50-C3 Page 4 of 5 Report No. : E068R-025 It should not be reproduced except in full, without the written approval of ONETECH. FCC-002 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 Dong, Jungwon-Gu, Seongnam-City, Kyunggi-Do, 462-705, Korea (TEL: +82-31-746-8500, FAX: +82-31-746-8700) EMC Testing Dept : 426-1 Daessangryung-Ri, Chowol-Eup, Kwangju-City, Kyunggi-Do, 464-860, Korea. (TEL: +82-31-765-8289, FAX: +82-31-766-2904) FCC ID. : O6ZS50-C3 Page 5 of 5 Report No. : E068R-025 It should not be reproduced except in full, without the written approval of ONETECH. FCC-002 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 Dong, Jungwon-Gu, Seongnam-City, Kyunggi-Do, 462-705, Korea (TEL: +82-31-746-8500, FAX: +82-31-746-8700) EMC Testing Dept : 426-1 Daessangryung-Ri, Chowol-Eup, Kwangju-City, Kyunggi-Do, 464-860, Korea. (TEL: +82-31-765-8289, FAX: +82-31-766-2904)

9 Confidential Network Description Network Description STUDIO MOBILE RECEIVER “SIRIUS S50” SIRIUS SATELLITE RADIO SATELLITES Car Radio FM Antenna FM Transmitter (88.1 ~ 107.9MHz Magnetic Antenna CAR

FCC ID. : O6ZS50-C3 Page 1 of 15 Report No. : E068R-025 It should not be reproduced except in full, without the written approval of ONETECH. FCC-002 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 Dong, Jungwon-Gu, Seongnam-City, Kyunggi-Do, 462-705, Korea (TEL: +82-31-746-8500, FAX: +82-31-746-8700) EMC Testing Dept : 3 0 7 -51 Daessangryung-Ri, Chowol-Eup, Kwangju-City, Kyunggi-Do, 464-860, Korea. (TEL: +82-31-765-8289, FAX: +82-31-766-2904) ELECTROMAGNETIC EMISSION C OMPLIANCE REPORT FOR LOW POWER, NON-LICENSED TRANSMITTER Test Report No. : E068R-025 AGR No. : A068A-085 Applicant : Humax Co., Ltd. Address : Humax Building, 212-1, Yubang-Dong, Yongin-City, Gyunggi-Do, 449-080, Korea Manufacturer : Humax Co., Ltd. Address : Humax Building, 212-1, Yubang-Dong, Yongin-City, Gyunggi-Do, 449-080, Korea Type of Equipment : Satellite Radio Receiver (Dock Unit) (FM Transmitter) FCC ID. : O6ZS50-C3 Model Name : S50-C1 Serial number : N/A Total page of Report : 15 pages (including this page) Date of Incoming : August 09, 2006 Date of Issuing : October 16, 2006 SUMMARY The equipment complies with the regulation of FCC CRF 47 PART 15, SUBPART C, SECTION 15.239. This test report contains only the results of a single test of the sample supplied for the examination. It is not a general valid assessment of the features of the respective products of the mass-production. Prepared by: Reviewed by: Young-Min, Choi / Senior Engineer Y. K. Kwon / Director EMC Div. EMC Div. ONETECH Corp. ONETECH Corp. FCC ID. : O6ZS50-C3 Page 2 of 15 Report No. : E068R-025 It should not be reproduced except in full, without the written approval of ONETECH. FCC-002 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 Dong, Jungwon-Gu, Seongnam-City, Kyunggi-Do, 462-705, Korea (TEL: +82-31-746-8500, FAX: +82-31-746-8700) EMC Testing Dept : 3 0 7 -51 Daessangryung-Ri, Chowol-Eup, Kwangju-City, Kyunggi-Do, 464-860, Korea. (TEL: +82-31-765-8289, FAX: +82-31-766-2904) CONTENTS Page 1. VERIFICATION OF COMPLIANCE .............................................................................................................................3 2. GENERAL INFORMATION............................................................................................................................................4 2.1 PRODUCT DESCRIPTION.................................................................................................................................................4 2.2 MODEL DIFFERENCES....................................................................................................................................................4 2.3 RELATED SUBMITTAL(S) / GRANT(S)............................................................................................................................4 2.4 TEST SYSTEM DETAILS..................................................................................................................................................4 2.5 TEST METHODOLOGY....................................................................................................................................................4 2.6 TEST FACILITY...............................................................................................................................................................4 3. SYSTEM TEST CONFIGURATION...............................................................................................................................5 3.1 JUSTIFICATION...............................................................................................................................................................5 3.2 EUT EXERCISE SOFTWARE............................................................................................................................................5 3.3 CABLE DESCRIPTION.....................................................................................................................................................5 3.4 NOISE SUPPRESSION PARTS ON CABLE.........................................................................................................................5 3.5 EQUIPMENT MODIFICATIONS........................................................................................................................................5 3.6 CONFIGURATION OF TEST SYSTEM...............................................................................................................................6 3.7 ANTENNA REQUIREMENT..............................................................................................................................................6 4. PRELIMINARY TEST ......................................................................................................................................................6 4.1 AC POWER LINE CONDUCTED EMISSION TEST............................................................................................................6 4.2 RADIATED EMISSION TEST............................................................................................................................................6 5. FINAL RESULT OF MEASURMENT ............................................................................................................................7 5.1 RADIATED EMISSION TEST (WITHIN THE PERMITTED 200KHZ BAND)........................................................................7 5.2 RADIATED EMISSION TEST (OUTSIDE OF THE SPECIFIED 200KHZ BAND)...................................................................8 5.3 BANDWIDTH OF THE OPERATING FREQUENCY..............................................................................................................9 6. FIELD STRENGTH CALCULATION ..........................................................................................................................14 7. LIST OF TEST EQUIPMENT....................................................................................…

Text truncated - open the document above for the full version.

FCC ID. : O6ZS50-C3 Page 1 of 1 Report No. : E068R-025 It should not be reproduced except in full, without the written approval of ONETECH. FCC-003 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 Dong, Jungwon-Gu, Seongnam-City, Kyunggi-Do, 462-705, Korea (TEL: +82-31-746-8500, FAX: +82-31-746-8700) EMC Testing Dept : 426-1 Daessangryung-Ri, Chowol-Eup, Kwangju-City, Kyunggi-Do, 464-860, Korea. (TEL: +82-31-765-8289, FAX: +82-31-766-2904) Radiated Emission Test
