G G L L O O B B A A L L S S U U N N C C O O M M M M U U N N I I C C A A T T I I O O N N S S I I N N C C . . G G L L - - 2 2 4 4 1 1 1 1 0 0 1 1 Wireless LAN PCMCIA Card USER MANUAL Version 0.2, July 07, 2000 2 Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy. If this equipment is not installed and used in accordance with the manufacturer's instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by during the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ƒ Reorient or relocate the receiving antenna. ƒ Increase the separation between the equipment and receiver. ƒ Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. ƒ Consult the dealer or an experienced radio/TV technician for help. The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. Manufacturer's Disclaimer Statement The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. No warranty or representation, either expressed or implied, is made with respect to the quality, accuracy or fitness for any particular purpose of this document. The manufacturer reserves the right to make changes to the content of this document and/or the products associated with it at any time without obligation to notify any person or organization of such changes. In no event will the manufacturer be liable for direct, indirect, special, incidental or consequential damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of such damages. This document contains materials protected by copyright. All rights are reserved. No part of this manual may be reproduced or transmitted in any form, by any means or for any purpose without expressed written consent of its authors. Product names appearing in this document are mentioned for identification purchases only. All trademarks, product names or brand names appearing in this document are registered property of their respective owners. Printed in Taiwan 3 Contents Chapter 1 About the GL-241101 PCMCIA Card ........................................................ 4 1-1 Features .............................................................................................................................................. 4 1-2 Applications ......................................................................................................................................... 4 1-3 Product Kit ........................................................................................................................................... 5 Chapter 2 Network Configuration and Planning ...................................................... 6 2-1 Network Topology................................................................................................................................ 6 2-2 Roaming .............................................................................................................................................. 8 Chapter 3 Adapter Installation and Configuration – Windows ® 98 ......................... 9 3-1 System Requirements ......................................................................................................................... 9 3-2 Inserting the Adapter ........................................................................................................................... 9 3-3 GL-241101 Driver Installation -Windows ® 98..................................................................................... 10 3-4 Adapter Configuration – Windows ® 98............................................................................................... 13 3-5 Protocol Installation – Windows ® 98 .................................................................................................. 17 3-6 GL-241101 Setup for Windows ® 2000 .............................................................................................. 20 3-7 W 11000 Setup for Windows ® NT 4.0 ............................................................................................... 22 3-8 GL-241101 Setup for Linux ............................................................................................................... 25 Chapter 4 Installing and Navigating the PRISM Configuration Utility .................. 30 4-1 PRISM Configuration Utility - Installation........................................................................................... 30 4-2 PRISM Configuration Utility- Navigation ............................................................................................ 32 Appendix A Troubleshooting................................................................................... 37 Appendix B Glossary................................................................................................ 39 4 Chapter 1 About the GL-24…

Text truncated - open the document above for the full version.

HFA3841 MAC HFA3861A BBP HFA3783 QUAD IF HFA3683A RF/IF CONV HFA3983 RFPA PLL RF LO REF IN PLL I/Q LO Q ADC ADC TX DAC Q DAC I DAC IF LO REF IN TX ADC REF_OUT IX ALC MOD DEMOD I/O ANT_SEL 6 1 1 1 6 6 6 6 6 REF IN 44 MHz Clock PHY I/O CONTROL PROCESSOR MEMORY ARBITER RADIO I/O HOST I/O WEP ENGINE REF IN CAL_EN T/R_SW FLASH & VOLATILE RAM HOST I ADC IF DAC RF ADC RF DAC AGC CTL Wireless LAN Card GL241101 Block Diagram RF Switch GLOBAL SUN COMMUNICATIONS INC.

FCC ID: O7J-GL2411010700 Rating: 5V MAC ID: FOR HOME OR OFFICE USE Tested To Comply With FCC Standards Product Name: DSSS 11M Wireless LAN Card Model Name: GL241101 Serial Number: Manufacture: GLOBAL SUN COMMUNICATIONS, INC 0499 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 4.2 cm 6.6 cm

Label Location FCC ID : O7J-GL2411010700 Size : 4.2 cm x 6.6 cm

RF Exposure Measurement 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the total power input to the antenna is measured by power meter. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r) 2 where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition A software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5 Climate Condition The temperature and related humidity: 20 and 78% RH 6 Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is –0.4dBi or 0.91 (numeric) (numeric) 6.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241225.591.36 6243737.841.66 11246231.411.51 The distance r (4 th column) calculated from the Friis transmission formula is far more shorter than 20 cm separation requirement. So, RF exposure limit warning or SAR test are not required.

RF Exposure Measurement 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the total power input to the antenna is measured by power meter. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Please be informed, Friis Formula estimate will over-predict the power density in the near field. Here we would like to use this estimate as the worst case condition. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r) 2 where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5 Climate Condition The temperature and related humidity: 20 and 78% RH 6 Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is –0.4dBi or 0.91 (numeric) (numeric) 6.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241264.262.16 6243795.062.61 11246278.882.37 The calculated exposure distance is very close to the enclosure of the product. The separation distance between user and antenna under normal use is longer than 2.61 cm. So, SAR testing is not required.

G G L L O O B B A A L L S S U U N N T T E E C C H H N N O O L L O O G G Y Y I I N N C C . . G G L L - - 2 2 4 4 1 1 1 1 0 0 1 1




Version 0.2, July 07, 2000 2 Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy. If this equipment is not installed and used in accordance with the manufacturer's instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by during the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: !" Reorient or relocate the receiving antenna. !" Increase the separation between the equipment and receiver. !" Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. !" Consult the dealer or an experienced radio/TV technician for help. The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. Manufacturer's Disclaimer Statement The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. No warranty or representation, either expressed or implied, is made with respect to the quality, accuracy or fitness for any particular purpose of this document. The manufacturer reserves the right to make changes to the content of this document and/or the products associated with it at any time without obligation to notify any person or organization of such changes. In no event will the manufacturer be liable for direct, indirect, special, incidental or consequential damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of such damages. This document contains materials protected by copyright. All rights are reserved. No part of this manual may be reproduced or transmitted in any form, by any means or for any purpose without expressed written consent of its authors. Product names appearing in this document are mentioned for identification purchases only. All trademarks, product names or brand names appearing in this document are registered property of their respective owners. Printed in Taiwan 3 Contents Chapter 1 About the GL-241101 PCMCIA Card ........................................................ 4
1-1 Features............................................................................................................................................... 4
1-2 Applications ......................................................................................................................................... 4
1-3 Product Kit ........................................................................................................................................... 5 Chapter 2 Network Configuration and Planning ...................................................... 6
2-1 Network Topology................................................................................................................................ 6
2-2 Roaming .............................................................................................................................................. 8 Chapter 3 Adapter Installation and Configuration – Windows ® 98 ......................... 9
3-1 System Requirements ......................................................................................................................... 9
3-2 Inserting the Adapter ........................................................................................................................... 9
3-3 GL-241101 Driver Installation -Windows ® 98 .................................................................................... 10
3-4 Adapter Configuration – Windows ® 98 .............................................................................................. 13
3-5 Protocol Installation – Windows ® 98 .................................................................................................. 17
3-6 GL-241101 Setup for Windows ® 2000 .............................................................................................. 20 3-7 W 11000 Setup for Windows ® NT 4.0 ............................................................................................... 22 3-8 GL-241101 Setup for Linux ............................................................................................................... 25 Chapter 4 Installing and Navigating the PRISM Configuration Utility .................. 30
4-1 PRISM Configuration Utility - Installation........................................................................................... 30
4-2 PRISM Configuration Utility- Navigation ............................................................................................ 32 Appendix A Troubleshooting................................................................................... 37 Appendix B Glossary................................................................................................ 39 4 Chapter 1 About …

Text truncated - open the document above for the full version.





                                                           !   "                     #$ %  &$ '#%&(   )** ++,+-              )  . * ').*("  $               )        $     "        "    "  #%&             "        "
-     /
-            $           0"            .  )**++,+-1                      $  2 '3)(     ++,-4'(
 5!#!0)63#.7!#8#%&3#!00!95&&7%6083&'#%&( )  3  '#( &  )  0 ':;( # )  0 '.;( % <  '/;
( .   '  ( !"  #  $  ,--2+=-->>);,--? +=--2+--"--->>=? %"  &'  $(    ,--2+=-->>);+=--? +=--2+--"--->>+-,- )@)  # )   )      1%@'% A(;'AA
(  %@   /;
% @      / @       %@,++? 3@               % #%&"+/;
!   $             "     "        #%&   3 1<B* "Field and Wave Electromagnetics"0  & " % ?-"& '++2+,,( *(+# ,        #     &8        "
 -+
    $     ) . *
C-9 -D+'  (







































































































































































                                        !
















































































  !




            "  "
  "!

# $

































 %
%%


























 %
%%
































       %















   " "  "%
 &
&
 &  &  &  &
              &

    %
 %
 %  %  %  %
 %

























 !
 !

 !
 !
 !

 !


!

 !

 !

!

!

!
 !

!

!
 !

 !

 !
 !
 "
!"!  !"
 '
 '   '  '  ' '  '  '

 '(   '
 '   '   '   ' '  '  '
 &  $"%
%  '
 "$
"$
$
 $  $"%  % "   !


' )' ''"
%'%' % ' ''%'"$' $' "'" ' ' ' '% "$'% $'"" #"$'" '!*'  $'%















             " "  #  "$ " $"$  " $" $"$"
" %  "  &" &"  "## ' "   ((( ( )(  ( *   (  +  ((  (  ((  *  ((((((((( %(( ( $






 %
%

 %%




 +  ' $( *  ( *   (  ( (
 *(
 * )

       )  "

 ,

 % %

 % %




 ,

 ,
   ",-.



























   !   !    "## $ "## $  "## $

%

&





















































 !"#  !"#  $" "      !$" "  $" "  %&


…

Text truncated - open the document above for the full version.

RF89072702Page 1/77 FCC ID: O7J-GL2411010700 Issued Date: August 10, 2000 REPORT NO:RF89072702 PRODUCT:Wireless LAN MODEL NO:GL241101-1, GL241101-2 SERIAL NO:N/A CLIENT:GLOBAL SUN COMMUNICATIONS, INC. ADDRESS:2F. No.6, Bau Chaing Road, Hsin-Tien, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation (ADT Corp.) OFFICE ADDRESS:11F, No. 1, Sec. 4, Nan-King East Rd., Taipei, Taiwan, R.O.C. LABORATORY ADDRESS:No. 47, 14 Ling, Chia Pau Tsuen, Lin Kou Hsian, Taipei Hsien, Taiwan, R.O.C. TEST STANDARD:47CFR Part 15, Subpart C (15.247) and Subpart B TEST DATE:August 7, 2000 TEST RESULT:Pass This test report consists of 77 pages in total. This test report is the property of ADT Corp. and shall not be reproduced, except in full, without the written consent of ADT. ADT hereby returns all rights in data to the client for legal use by the client. The test results contained in this report apply only to the samples tested. Accredited Laboratory RF89072702Page 2/77 FCC ID: O7J-GL2411010700 Issued Date: August 10, 2000 TABLE OF CONTENTS 1CERTIFICATION...........................................................................................................4 2SUMMARY OF TEST RESULTS...............................................................................5 3DECLARATION OF COMPLIANCE WITH SUBPART B........................................6 4GENERAL INFORMATION.........................................................................................7 4.1GENERAL DESCRIPTION OF EUT...............................................................................................................7 4.2DESCRIPTION OF TEST MODE.....................................................................................................................8 4.3TEST METHODOLOGY.................................................................................................................................8 4.4SUPPORT UNITS LIST...................................................................................................................................9 4.5CONFIGURATION OF SYSTEM UNDER TEST..............................................................................................9 5GENERAL INFORMATION OF TEST FACILITY...................................................10 5.1TEST LAB.....................................................................................…
