54Mbps Wireless Network Mini PCI Adapter USER’S MANUAL Model Name: WL MP 2454 1A3 Version: 1.0 Date: Aug/20/04 Please make sure TURN OFF your computer and remove the power cord from your PC. Open the computer case and then please insert the 54Mbps Wireless mini PCI Adapter. Once the 54Mbps Wireless mini PCI Adapter is installed, place the computer case back. Turn ON your computer. Driver Installation 1. Please select the second option and click “Next”. 2. Please click “Continue Anyway” 3. Please click “Finish” 4. To make sure if the installation is successful, you could check it through the device management. 5. Once the installation is successful, a utility program icon will show on your desktop. To lunch the utility, just double click the icon. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and 2) The transmitter module may not be co-located with any other transmitter or antenna. As long as 2 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed (for example, digital device emissions, PC peripheral requirements, etc.). IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labeling This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users (for example :AP, Router, WLAN HDD etc.). The final end product must be labeled in a visible area with the following: “Contains TX FCC ID: O7J-WLMP2454-1A3”. Manual Information That Must be Included The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the users manual of the end product which integrate this module. The users manual for OEM integrators must include the following information in a prominent location “ IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.

FCC ID: O7J-WLMP2454-1A3 Report No.:930808L01 Modular Approval Request Letter Advance Data Technology Sept. 23, 2004 Dear Application Examiner, Global Sun Technology, 802.11g Wireless mini PCI module, with FCC ID: O7J- WLMP2454-1A3, would like to have your authorization as a full modular approval specific to Access Point and Router, and laptop. The requirements of Public Notice DA00-1407 have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.”: The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip AR5213. 3. “The modular transmitter must have its own power supply regulation.” The chips IF converter and RF/IF converter which will influence the frequency radiation, have to be 2.5Vdc powered. The mini-pci interface provides 3.3VDC, so there are regulators in front of these chips, the part number of this regulator is AME8805DEFT. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” Due to the mini-pci card with brand Intel, and the model name WM3B2200BG is specified to the Laptop PC, the EUT is tested in full system configuration. Please see section Photographs of Test Configuration in the test report. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions given to the OEM on how to label the end product. FCC ID: O7J-WLMP2454-1A3 Report No.:930808L01 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, Cody Chang / Deputy Manager Advance Data Technology

Page 1 CONSTRUCTION PHOTOS OF EUT

FCC ID Label Location

16mm Model Name: WL MP 2454 1A3 Tested To Comply With FCC Standards Made in Taiwan Rating: 3.3V FCC ID: O7J-WLMP2454-1A3 Prodect Name: 802.11g Wireless mini PCI module GLOBAL SUN TECHNOLOGY INC. FOR HOME OR OFFICE USE 47mm 5.0mm 12mm 11mm

Page 2 Page 3 Page 4

FCC ID: O7J-WLMP2454-1A3 Report No. RF930808L01 Operational Description This device is a 802.11g Wireless mini PCI module which operates in the 2.4GHz frequency spectrum with throughput of up to 54Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 54Mbps, the 11Mbps data rate with CCK technique will be applied. The transmitter of the EUT is powered by host equipment via a Mini PCI interface. The antenna is dipole antenna with Revise SMA connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual.

FCC ID: O7J-WLMP2454-1A3 Report No.: SA930808L01 1 RF EXPOSURE REPORT REPORT NO.: SA930808L01 MODEL NO.: WL MP 2454 1A3 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: GLOBAL SUN TECHNOLOGY INC. ADDRESS: NO.13 Tung Yuan Rd., Jung Li Industrial Park, Jung Li City, Tao Yuan Hsien, Taiwan, R. O. C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. FCC ID: O7J-WLMP2454-1A3 Report No.: SA930808L01 2 RF Exposure Measurement (Mobile Device) 1. Introduction 2.4GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 30-30061.40.1631.06 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 30-30027.50.0730.230 300-1500......F/150030 1500-100,000......1.030 F = Frequency in MHz FCC ID: O7J-WLMP2454-1A3 Report No.: SA930808L01 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 2.5cm. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification This modular is specified to be installed in access point which is connected with host through wire. So it is easy to be re-located in the place where at least 20cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: O7J-WLMP2454-1A3 Report No.: SA930808L01 4 6 Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 1.8dBi or 1.513 (numeric). 6.2 Output Power Into Antenna & RF Exposure value at distance 20cm: For 802.11b Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241231.8420.0101.0 6243731.6230.0101.0 11246231.7690.0101.0 For 802.11g Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241231.7690.0101.0 6243731.6960.0101.0 11246231.6230.0101.0

FCC ID: O7J-WLMP2454-1A3 Report No.: RF930808L011Issued: Aug. 11, 2004 FCC TEST REPORT REPORT NO.: RF930808L01 MODEL NO.: WL MP 2454 1A3 RECEIVED: Aug. 04, 2004 TESTED: Aug. 04~ Aug. 05, 2004 APPLICANT: GLOBAL SUN TECHNOLOGY INC. ADDRESS: NO.13 Tung Yuan Rd., Jung Li Industrial Park, Jung Li City, Tao Yuan Hsien, Taiwan, R. O. C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 19, Hwa Ya 2nd Rd., Kueishan, Taoyuan, Taiwan, R.O.C. This test report consists of 68 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA FCC ID: O7J-WLMP2454-1A3 Report No.: RF930808L012Issued: Aug. 11, 2004 Table of Contents 1CERTIFICATION .......................................................................................................4 2SUMMARY OF TEST RESULTS ...............................................................................5 2.1MEASUREMENT UNCERTAINTY.............................................................................5 3GENERAL INFORMATION........................................................................................6 3.1GENERAL DESCRIPTION OF EUT ..........................................................................6 3.2DESCRIPTION OF TEST MODES ............................................................................7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ...........................................7 3.4DESCRIPTION OF SUPPORT UNITS ......................................................................8 3.5 CONFIGURATION OF SYSTEM UNDER TEST .......................................................8 4TEST TYPES AND RESULTS ...................................................................................9 4.1CONDUCTED EMISSION MEASUREMENT ............................................................9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT..........................................9 4.1.2TEST INSTRUMENTS...............................................................................................9 4.1.3TEST PROCEDURES .............................................................................................10 4.1.4DEVIATION FROM TEST STANDARD ...................................................................10 4.1.5TEST SETUP........................................................................................................... 11 4.1.6EUT OPERATING CONDITIONS ............................................................................ 11 4.1.7TEST RESULTS ......................................................................................................12 4.2RADIATED EMISSION MEASUREMENT ...............................................................18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT.............................................18 4.2.2TEST INSTRUMENTS.............................................................................................19 4.2.3TEST PROCEDURES .............................................................................................20 4.2.4DEVIATION FROM TEST STANDARD ...................................................................20 4.2.5TEST SETUP...........................................................................................................21 4.2.6EUT OPERATING CONDITIONS ............................................................................21 4.2.7TEST RESULTS ......................................................................................................22 4.36dB BANDWIDTH MEASUREMENT.......................................................................30 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ....................................................30 4.3.2TEST INSTRUMENTS.............................................................................................30 4.3.3TEST PROCEDURE................................................................................................31 4.3.4DEVIATION FROM TEST STANDARD ...................................................................31 4.3.5TEST SETUP...........................................................................................................31 4.3.6EUT OPERATING CONDITIONS ............................................................................31 4.3.7TEST RESULTS ......................................................................................................32 4.4MAXIMUM PEAK OUTPUT POWER ......................................................................40 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT .......................40 FCC ID: O7J-WLMP2454-1A3 Report No.: RF930808L013Issued: Aug. 11, 2004 4.4.2TEST INSTRUMENTS.............................................................................................40 4.4.3TEST PROCEDURES .............................................................................................41 4.4.4DEVIATION FROM TEST STANDARD ...................................................................41 4.4.5TEST SETUP...........................................................................................................41 4.4.6EUT OPERATING CONDITIONS ............................................................................41 4.4.7TEST RESULTS ......................................................................................................42 4.5POWER SPECTRAL DENSITY MEASUREMENT..................................................43 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ...............................43 4.5.2TEST INSTRUMENTS.............................................................................................43 4.5.3TEST PROCEDURE.............................................................................................…

Text truncated - open the document above for the full version.

FCC ID: O7J-WLMP2454-1A3 Report No.: RF930808L0164Issued: Aug. 11, 2004 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: O7J-WLMP2454-1A3 Report No.: RF930808L0165Issued: Aug. 11, 2004 FCC ID: O7J-WLMP2454-1A3 Report No.: RF930808L0166Issued: Aug. 11, 2004 RADIATED EMISSION TEST FCC ID: O7J-WLMP2454-1A3 Report No.: RF930808L0167Issued: Aug. 11, 2004
