O7J-WLUD2454-13I802.11g Wireless USB Dongle

3 (1653x2338x256 jpeg)

2 (1653x2338x256 jpeg)

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 September 16, 2004 RE: Global Sun Technology Inc. FCC ID: O7J-WLUD2454-13I I have a few comments on this Application. Depending on your responses, kindly understand there may be additional comments. 1.) The RF power output reported on Form 731 and in the Test Report for 802.11b is very good – too good. I simply do not believe it is possible to measure RF power exactly to 1/100 th of a decibel. I also do not believe it is possible to measure to exactly 1/100 th of a decibel the exact same power on low, mid and high channels. Kindly provide true measured RF power within the Test Report and SAR Report. In addition, please submit a revised Form 731 showing the highest true measured power for this device. 2.) Please indicate how country settings are defined. In other words, how are channel settings determined for Europe, Japan or United States? William H. Graff President and Director of Engineering mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 September 23, 2004 RE: Global Sun Technology Inc. FCC ID: O7J-WLUD2454-13I I have a few comments on this Application. Depending on your responses, kindly understand there may be additional comments. 1.) Please indicate how country settings are defined. In other words, how are channel settings determined for Europe, Japan or United States? The manual on page 12 appears to suggest that any individual can select their country of choice via user software. This is, very simply, not permitted under any conditions. Please refer to Rule 15.15(b): “An intentional or unintentional radiator must be constructed such that the adjustments of any control that is readily accessible by or intended to be accessible to the user will not cause operation of the device in violation of the regulations.” William H. Graff President and Director of Engineering mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

FCC ID Label Location

S / N: MAC: FCC ID: O7J-WLUD2454-13I Made in TaiwanRating:5V Model: WL UD 2454 13I FOR HOME OR OFFICE USE Tested To Comply With FCC Standards High-Speed 802.11g Wireless USB Dongle of the FCC rules. two conditions: (1)This device may not cause harmful (2)This device must accept any received,including may cause undesired This device complies with part 15 Operation is subject to the following interference. interference interference that operation.

FCC ID Label Location

S / N: MAC: FCC ID: O7J-WLUD2454-13I Made in TaiwanRating:5V Model: WL UD 2454 13I FOR HOME OR OFFICE USE Tested To Comply With FCC Standards High-Speed 802.11g Wireless USB Dongle of the FCC rules. two conditions: (1)This device may not cause harmful (2)This device must accept any received,including may cause undesired This device complies with part 15 Operation is subject to the following interference. interference interference that operation.

Page 3 Page 4 Page 5

Page 3 Page 4 Page 5

FCC ID: O7J-WLUD2454-13I Report No.: RF930427L04 Operational Description This device is a 802.11g Wireless USB Dongle, which operates in the 2.4GHz frequency spectrum with throughput of up to 54Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 54Mbps, the 11Mbps data rate with CCK technique will be applied. The transmitter of the EUT is powered by host equipment via a USB interface. The antenna is Chip antenna without connector. The other instruction, please have a look at the users manual.

FCC ID: O7J-WLUD2454-13I Report No.: SA930427L041Issued: May 11, 2004 SAR TEST REPORT REPORT NO.: SA930427L04 MODEL NO.: WL UD 2454 13I (Refer to page 5 for other models) RECEIVED: April 27, 2004 TESTED: May 7, 2004 APPLICANT : GLOBAL SUN TECHNOLOGY INC. ADDRESS: NO.13 Tung Yuan Rd., Jung Li Industrial Park Jung Li City, Tao Yuan Hsien, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 34 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by any government agencies. The test results in the report only apply to the tested sample. FCC ID: O7J-WLUD2454-13I Report No.: SA930427L042Issued: May 11, 2004 Table of Contents 1.CERTIFICATION .........................................................................................................3 2.GENERAL INFORMATION..........................................................................................4 2.1 GENERAL DESCRIPTION OF EUT............................................................................4 2.2 GENERAL DESCRIPTION OF APPLIED STANDARDS .............................................6 2.3 GENERAL INOFRMATION OF THE SAR SYSTEM ...................................................6 2.4 GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION ...............10 3.DESCRIPTION OF TEST MODES AND CONFIGURATIONS ..................................14 4.DESCRIPTION OF SUPPORT UNITS ......................................................................15 5.TEST RESULTS ........................................................................................................16 5.1 TEST PROCEDURES ...............................................................................................16 5.2 MEASURED SAR RESULT .......................................................................................17 5.3 SAR LIMITS...............................................................................................................19 5.4 RECIPES FOR TISSUE SIMULATING LIQUIDS ......................................................19 5.5 TEST EQUIPMENT FOR TISSUE PROPERTY ........................................................22 6.SYSTEM VALIDATION ..............................................................................................23 6.1 TEST EQUIPMENT ...................................................................................................23 6.2 TEST PROCEDURE .................................................................................................23 6.3 VALIDATION RESULT...............................................................................................26 6.4 SYSTEM VALIDATION UNCERTAINTIES ................................................................27 7.MEASUREMENT SAR PROCEDURE UNCERTAINTIES.........................................28 7.1 PROBE CALIBRATION UNCERTAINTY ...................................................................28 7.2 ISOTROPY UNCERTAINTY......................................................................................28 7.3 BOUNDARY EFFECT UNCERTAINTY .....................................................................29 7.4 PROBE LINEARITY UNCERTAINTY ........................................................................29 7.5 READOUT ELECTRONICS UNCERTAINTY ............................................................29 7.6 RESPONSE TIME UNCERTAINTY...........................................................................30 7.7 INTEGRATION TIME UNCERTAINTY ......................................................................31 7.8 PROBE POSITIONER MECHANICAL TOLERANCE................................................31 7.9 PROBE POSITIONING .............................................................................................32 7.10 PHANTOM UNCERTAINTY ......................................................................................32 7.11 DASY4 UNCERTAINTY BUDGET.............................................................................33 8.INFORMATION ON THE TESTING LABORATORIES ..............................................34 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION FCC ID: O7J-WLUD2454-13I Report No.: SA930427L043Issued: May 11, 2004 1. CERTIFICATION PRODUCT : 802.11g Wireless USB Dongle MODEL NO. : WL UD 2454 13I (Refer to page 5 for other models) BRAND NAME : GLOBAL SUN (Refer to page 5 for other brands) TESTED : May 7, 2004 APPLICANT : GLOBAL SUN TECHNOLOGY INC. TEST ITEM : ENGINEERING SAMPLE STANDARDS : FCC Part 2 (Section 2.1093), FCC OET Bulletin 65, Supplement C (01-01), RSS-102 The above equipment has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY:, DATE:May 11, 2004 APPROVED BY: Stacy Hsueh , DATE:May 11, 2004 Cody Chang / Supervisor FCC ID: O7J-WLUD2454-13I Report No.: SA930427L044Issued: May 11, 2004 2. GENERAL INFORMATION GENERAL DESCRIPTION OF EUT PRODUCT 802.11g Wireless USB Dongle MODEL NO. WL UD 2454 13I POWER SUPPLY 5.0Vdc powered by host equipment CLASSIFICATION Portable device, production unit MODULATION TYPE BPSK, QPSK, CCK, 16QAM, 64QAM RADIO TECHNOLOGY DSSS/OFDM TRANSFER RATE 54/48/36/24/18/12/11/9/6/5.5/2/1Mbps FREQUENCY RANGE 2412MHz ~ 2462MHz NUMBER OF CHANNEL 11 MAXIMUN CONDUCTED OUTPUT POWER (FOR CCK) 16.03dBm MAXIMUN CONDUCTED OUTPUT POWER (F…

Text truncated - open the document above for the full version.

FCC ID: O7J-WLUD2454-13I Report No.: RF930427L041Issued: 07 May, 2004 FCC TEST REPORT REPORT NO.: RF930427L04 MODEL NO.: WL UD 2454 13I (Refer to page 6 for other models) RECEIVED: 27 April, 2004 TESTED: 01 May ~ 04 May, 2004 APPLICANT: GLOBAL SUN TECHNOLOGY INC. ADDRESS: No. 13, Tung Yuan Rd., Jung Li Industrial Park, Jung Li City, Tao Yuan Hsien, Taiwan ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 19, Hwa Ya 2nd rd., Kueishan, Taoyuan, Taiwan, R.O.C. This test report consists of 69 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by any government agencies. The test results in the report only apply to the tested sample. FCC ID: O7J-WLUD2454-13I Report No.: RF930427L042Issued: 07 May, 2004 Table of Contents 1CERTIFICATION ........................................................................................... 4 2SUMMARY OF TEST RESULTS................................................................... 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ............................................................. 6 3.2DESCRIPTION OF TEST MODES................................................................ 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS............................... 7 3.4DESCRIPTION OF SUPPORT UNITS .......................................................... 8 3.5CONFIGURATION OF SYSTEM UNDER TEST........................................... 8 4TEST TYPES AND RESULTS....................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT ................................................ 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT.............................. 9 4.1.2TEST INSTRUMENTS .................................................................................. 9 4.1.3TEST PROCEDURES................................................................................. 10 4.1.4DEVIATION FROM TEST STANDARD ....................................................... 10 4.1.5TEST SETUP ...............................................................................................11 4.1.6EUT OPERATING CONDITIONS................................................................ 12 4.1.7TEST RESULTS.......................................................................................... 13 4.2RADIATED EMISSION MEASUREMENT ................................................... 19 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT................................. 19 4.2.2TEST INSTRUMENTS ................................................................................ 20 4.2.3TEST PROCEDURES................................................................................. 21 4.2.4DEVIATION FROM TEST STANDARD ....................................................... 21 4.2.5TEST SETUP .............................................................................................. 22 4.2.6EUT OPERATING CONDITIONS................................................................ 22 4.2.7TEST RESULTS.......................................................................................... 23 4.2.8TEST RESULTS (A) .................................................................................... 25 4.2.9TEST RESULTS (B) .................................................................................... 28 4.36dB BANDWIDTH MEASUREMENT .......................................................... 31 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ........................................ 31 4.3.2TEST INSTRUMENTS ................................................................................ 31 4.3.3TEST PROCEDURE ................................................................................... 32 4.3.4DEVIATION FROM TEST STANDARD ....................................................... 32 4.3.5TEST SETUP .............................................................................................. 32 4.3.6EUT OPERATING CONDITIONS................................................................ 32 FCC ID: O7J-WLUD2454-13I Report No.: RF930427L043Issued: 07 May, 2004 4.3.7TEST RESULTS (A) .................................................................................... 33 4.3.8TEST RESULTS (B) .................................................................................... 37 4.4MAXIMUM PEAK OUTPUT POWER .......................................................... 41 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ........... 41 4.4.2TEST INSTRUMENTS ................................................................................ 41 4.4.3TEST PROCEDURES................................................................................. 41 4.4.4DEVIATION FROM TEST STANDARD ....................................................... 41 4.4.5TEST SETUP .............................................................................................. 42 4.4.6EUT OPERATING CONDITIONS................................................................ 42 4.4.7TEST RESULTS (A) .................................................................................... 43 4.4.8TEST RESULTS (B) .................................................................................... 44 4.5POWER SPECTRAL DENSITY MEASUREMENT...................................... 45 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ................... 45 4.5.2TEST INSTRUMENTS ................................................................................ 45 4.5.3TEST PROCEDURE ................................................................................... 46 4.5.4DEVIATION FROM TEST STANDARD ....................................................... 46 4.5.5TEST SETUP ..................................................................…

Text truncated - open the document above for the full version.

FCC ID: O7J-WLUD2454-13I Report No.: RF930427L0467Issued: 07 May, 2004 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: O7J-WLUD2454-13I Report No.: RF930427L0468Issued: 07 May, 2004 RADIATED EMISSION TEST
