O7J-GL2411RT-0BAccess Point

GL2411RT-0B Wireless Access Point Router USER MANUAL Version 1.1 Jan. 28, 2002 2 Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy. If this equipment is not installed and used in accordance with the manufacturer's instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by during the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. FCC RF Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. Manufacturer's Disclaimer Statement The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. No warranty or representation, either expressed or implied, is made with respect to the quality, accuracy or fitness for any particular purpose of this document. The manufacturer reserves the right to make changes to the content of this document and/or the products associated with it at any time without obligation to notify any person or organization of such changes. In no event will the manufacturer be liable for direct, indirect, special, incidental or consequential damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of such damages. This document contains materials protected by copyright. All rights are reserved. No part of this manual may be reproduced or transmitted in any form, by any means or for any purpose without expressed written consent of its authors. Product names appearing in this document are mentioned for identification purchases only. All trademarks, product names or brand names appearing in this document are registered property of their respective owners. Printed in Taiwan 3 Contents Section 1 About GL2411RT-0B.........................................................5 1-1 Features...........................................................................................................5 1-2 Benefits.................................................................................6 1-3 Applications...........................................................................7 1-4 Product Kit.............................................................................8 Section 2 Hardware Installation.........................................................9 2-1 Equipment Requirement..............................................................9 2-2 Wireless Access Point Router Hardware Installation............................9 2-3 Software Limitation.................................................................10 2-4 The Front View......................................................................11 2-5 The Rear View.......................................................................11 Section 3 Connect Wireless Access Point Gateway To The Network..............14 Section 4 Configuring Your Wireless Access Point Router........................16 4-1 Device Information..................................................................16 4-2 Device Status........................................................................17 4-3 Setup Wizard........................................................................19 4-4 Advanced Settings..................................................................25 4-5 System Tools........................................................................31 Section 5 Configuring Your Wireless Access Point Router With Telnet........35 Section 6 How To Configure Your PC To Connect The Router..................37 Appendix A Specifications.............................................................51 Appendix C Glossary....................................................................52 4 Section 1 About GL2411RT-0B-4 Ideal for home/SOHO users whom like to share a broadband connection without the re- connecting cost of extra IP addresses and want the flexibility of a wire-free connection. The latest SOHO wireless AP gateway router from Global Sun tech. offers freedom to notebook, desktop PC and other internet device users: connect them to your home network with the same Wi-Fi certified wireless LAN PC Card. The GL2411RT-0B-4 wireless LAN AP router is an ideal solution for connecting to Cable Modem, DSL for always-on high speed Internet access to any desktop or notebook, plus the flexibility of a built-in 3 ports Ethernet swit…

Text truncated - open the document above for the full version.

28 Misc. Settings IP-Sec Pass Through: This feature lets you use IP Security Pass Through. Usually it requires a 3 rd party client software (VPN) on the workstations to be able to use the function. Check the box and click “submit” if you want to enable the feature. PPTP Pass Through: Point to Point Tunneling Protocol is the method used to enable VPN (Virtual Private Networking) sessions. This encryption method is supported by all Microsoft Operating System on the market. To enable this feature, please check the box and click “submit”. 4-5 System tools Detects the status of the Wireless Access Point Gateway. Intruder Detection Log 29 The event messages show the possible hacker attacks that have occurred on your internet Gateway router. Up to 32 hacker attacks may be logged in this manner. Display Routing Table System diagnosis 30 System diagnosis shows your internet gateway’s information. It will perform a check-up on your internet gateway to make sure that everything is functioning properly. Load Default settings Load Default settings will lout the factory default settings for the device. Upgrade Firmware 31 The upgrade firmware option allows you to upgrade the newest firmware to your Wireless Access Point Gateway. Reset device Resetting the device will restart it. Click on the START button to restart. 32 Section 5 Configuring your Gateway Router with Telnet session You can start the telnet session by click “start” “run” and type in “telnet 192.168.1.1” Type in “admin” as your login name and hit “enter” for default password. 33 The main menu. You can press “Ctrl-Q” to bring up the help screen and learn all the command in telnet session. Press “Ctrl-C” to cancel the selection. 34 Setup Hit “Enter” on setup and it will take you to the following menu. In this menu, you may setup: System – Setup generic system configuration. LAN – Setup LAN interface configuration. Wan – Setup first WAN interface profile. PPP – Setup point-to-point protocol configuration. ISP – Setup first ISP profile. Configuration – Configuration user profile. System Hit “Enter”, it will take you to the screen to setup host name. LAN Hit “Enter” on LAN, it will take you to setup Address – Setup LAN interface IP and network Attrib – Administrative status and NAT network type. Bridge – Setup interface bridging function state. 35 WAN Hit “Enter” on WAN and it will take you to setup: Address – Setup WAN interface IP address, Subnet Mask. Link_type – Setup interface link type. Attrib – Administrative status and NAT network type. Bridge – Setup interface bridging function state. Ether_interface – Setup PPP over Ethernet interface number. ISP – Setup ISP profile attrib. PPP 36 Hit “Enter” on PPP and you can setup: Peer_address – Setup peer IP address. User_Profile – Setup access account and password. ISP Hit “Enter” on ISP and you can setup: ISP_profile – Configure dial-out ISP name and destination string. Account_profile – Configure access account and password. Configuration Hit “Enter” on configuration and it will prompt you for login ID and password, also you may need to enter the client’s IP address. Upgrade 37 Hit “Enter” on Upgrade and you can configure the following: Image – Upgrade kernel image file. Web_image – Upgrade web config image file. Bootstrap2 – Upgrade boot strap. Conf – Configuration file upgrade. All these options require the server IP address and the file name to upgrade. Enable This function is to enable the configuration mode. Monitor 38 Hit “Enter” on Monitor you can setup the following: Route – List of routing table. Netbios_pool – List NetBIOS name database. Wan – List WAN interface status. Config_access – Monitor configure access control. Access-list – Monitor access control rules pool. Inspect-TCP – Monitor inspecting TCP sessions. Inspect-UDP – Monitor inspecting UDP sessions. Syslog – Monitor system log generated by CBAC. Password You may reset the password on this option. Hit “Enter” and it will prompt you for user name and to enter the new password. System 39 Hit “Enter” on system and you can setup the following: Op_mode – Kernel operation mode. Hostname – Config local hostname. Domain _name – Config local domain name. Default_gateway – Default gateway. Interface Hit “Enter” on interface and you can setup the following: Lan – Config LAN interface profile. Wan – Config WAN interface profile. Wireless – Config wireless interface profile. Access-List 40 Hit “Enter” on access-list and you can setup the following: Standard – Add/Modify standard access control rule. Extended – Add/Modify extended access control rule. URL_list – URL blocking list. Inspect Hit “Enter” on inspect and you can setup the following: Module – Enable or disable inspection module. Dos_Func – Enable or disable Dos pattern detect. Wan_ping – Deny ping request from WAN. Rip_defect – Deny RIP from WAN. DMZ – Enable or disable DMZ. Name – Modify inspection rules pool. Name_delete – Delete inspection rule. TCP – TCP session timeout. UDP – UDP session timeout. Max-incomplete – Existing half-open session threshold. One-minute – The rate of new half-open session. Port_scan_defect – “Port Scan” defect sensitive criteria. PPP

N0.13, Tung Yuan Rd., Jung Li City Industrial Park , Jung Li City, Tao Yuan Hsien, Taiwan, R.O.C. Tel: +886-2-8522-7155 Fax: +886-2-8500-7156 Inform Letter Dear Customer, According to FCC’s regulation, the following Declaration of Conformity has to be made by a company located in USA. They are: This device has been confirmed to be in compliance with the requirements of ANSI C63.4 & FCC part 15 regulations. The test result has been shown in the ADT test report with number RF910304R01. And this compliance is subject to the following two conditions: (1) This device may not cause harmful interference and, (2) This device must accept any interference received, including interference that may cause undesired operation. This declaration can be a separate sheet and be sure that the following message will be also included in this declaration: 1) Product name, model name and trade name. 2) Company name, and address of the one who is responsible for this declaration. 3) Name, title, telephone and fax number as well as the signature of the contact person. Thanks for your attention.

41 Hit “Enter” on PPP and you can setup the following: Users_edit – Edit users profile. Address_pool – Config dynamic assigned address pool. Authenticate – User authentication policy. Assign_address – Peer address assignment policy. Wan_pppoe – WAN port PPPoE function. ISP Hit “Enter” on ISP and you will prompt to input the ISP profile number. IP_share 42 Hit “Enter” on Ip_share and you can setup the following: Pat – Config port address translation. Nat – Config network address translation. DHCP Hit “Enter” on DHCP and you can setup the following: Generic – Configure generic DHCP parameter. Fixed – Configure Fixed host IP address list. Client – DHCP client functionality. Client_interface – DHCP client activate interface number. DNS Proxy Hit “Enter” on DNS Proxy and you can setup DNS_proxy server name and its IP address. 43 Tftp Hit “Enter” on Tftp and you can setup the IP address for Tftp server. Route Hit “Enter” on Route and you can setup Static – To configure the static route parameters. Rip – To configure RIP protocol module parameter. Bridge 44 Hit “Enter” on Bridge you can setup Generic – To configure bridging function, IP and subnet mask. Static – To configure static bridging parameter. WLAN Hit “Enter” you are able to configure, SSID Channel – Current operating frequency channel. Tx_rate – Transmission Rate Basic_rate – Basic rate. Station name – station name Rts Threshold – Rtx threshold. FragThreshold – Fragmentation threshold (even numbers only) Weprequired – Enable/Disable WEP function. DefaultKeyID – WEP default key ID. DefaultKeys – WEP key table. Show Hit “Enter” on Show you may be able to view Run – Show all configuration. Configuration – Show all configuration in command script Interface – Show interface configuration. 45 PPP – Show PPP configuration. IP_share – Show IP address sharing configuration. DHCP – Show DHCP configuration. Route – Show routing configuration Bridge – Show bridging configuration. ISP – Show ISP profiles. WLAN – Show wireless LAN configuration. Access-List – Show access control rules pool. Inspect – Show inspection setting or rules pool. Reset_Default Hit “Enter” on reset_default and type “y” for yes and “n” for no to reset to default setting. Write Hit “Enter” on Write and type “y” for yes and “n” for no to reset the system configuration to default status. Reboot 46 Hit “Enter” on reboot and type “y” for yes and “n” for no to restart system and activate new system configuration. Su Hit “Enter” on su to switch to supervisor mode, it will prompt you for supervisor password. Sys_info Hit “Enter” on sys_info and it will take you to a status screen. 47 Ping Hit “Enter” on ping and it will prompt you for a IP address to ping to. Exit Hit “Enter” on exit to disable privileged command or disconnect. 48 Section 6 How to Configure Your PC to Connect the Gateway Router If you do not wish to set a static IP address on your PC, you will need to configure your PC to accept the IP address that your gateway will provide. 1. Click Start button, select Settings, then Control Panel 2. Double-click the Network Icon 3. In the configuration windows, select the Internet Protocol that has been associated with your network card/adapter. If there is no TCP/IP line listed, you will need to install the TCP/IP now. 49 4. Click the Properties button, then choose the IP ADDRESS tab. Select Obtain an IP address automatically. 5. Then select DNS configuration tab to add DNS IP address. If you do not wish to add DNS you can disable DNS function. Press OK. You have completed the client settings. 6. After clicking OK, windows will ask you to restart the PC. Click Yes. Confirm Your PC’s IP Configuration There are two tools which are great for finding out a computer’s IP configuration: MAC address and default gateway. l WINIPCFG (for windows 95/98/ME) Inside the windows 95/98/ME Start button, select Run and type winipcfg. In the example below this computer has a IP address of 192.168.1.2 and the default 50 gateway is 192.168.1.1. The default gateway should be the network device IP address. The MAC address in windows 95/98 is called the Adapter Address. l IPCONFIG (for windows 2000/NT/XP) In the DOS command type IPCONFIG and press Enter. Your PC IP information will be displayed as shown below. This concludes the user manual. Should you require further assistance or have other inquires please contact your distributor. 51 Appendix A Specifications HardwareSpecification Architecture† SAMSUNG ARM7 embedded Operating System supports† Supertask M/B Form Factor† 7.5”x5.5” CPU Support† SAMSUNG ARM7 Memory† Flash: 1Mbyte † SDRAM: 8Mbyte Wireless network architecture † Compatibility: Devices supporting IEEE802.11b wireless standards † Frequency Band: 2400-2483.4 MHz † Wireless Medium: Direct Sequence Spread Spectrum † Radio data rate: 1, 2, 5.5 and 11Mbps † Modulation:DBPSK@1Mbps,DQPSK@2Mbps, [email protected] and 11Mbps † Chipset: Intersil PRISM II.5 † OperationChannel : 11Channel(America,Canada) 13Channel(Europe) 14 Channel (Japan) † Non-Overlapping channels: 3 † Receive Sensitivity: -88dBm@1Mbps,-86dBm@2Mbps,[email protected], - 80dBm@11Mbps † Output Power: 18-20 dBm max. † Range: 300 feet Wired Network architecture . 10/100 Base-T LAN support Back I/O † 4 x 10/100 Base-T LAN Port † 2 x Antenna † 1 x AC Power Port 52 Appendix B Glossary Access Point An internetworking device that seamlessly connects wired and wireless networks. Ad-Hoc An Ad-Hoc wireless LAN is a group of computers each with LAN adapters, connected as an independent wireless LAN. Authentication Type Indication of an authentication algorithm which can be supported by this node: Open System : Open System authentication is the simplest of the available authentication algorithms. Essentially it is a null authentication algorithm. Any station that requests authentication with this algorithm may become authenticated if dot11AuthenticationType at the recipient station is set to Open System authentication. Shared Key : Shared Key authentication s…

Text truncated - open the document above for the full version.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3

! Dxx-xxxxJP NYxxxxx Gzxxxxx 2.4D S42.4D S4

Page 4 Page 5

Page 6 Page 7

Page 8 Page 9 Page 10

FCC ID: O7J-GL2411RT-0B ADT No.910220R01 Operational Description The transmitter of the EUT (Wireless Router) is powered by power adapter. The antenna is Dipole antenna. The antenna connector is MCX connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

ADT No: 910220R01 1 FCC TEST REPORT REPORT NO.: RF910220R01 MODEL NO.: GL2411RT-0B ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:GLOBAL SUN TECHNOLOGY, INC. ADDRESS:No.13, Tung Yuan Rd., Jung Li Industrial Park, Jung Li City, Tao Yuan Hsien, Taiwan R.O.C ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 ILAC MRA Lab Code: 200102-0 ADT No: 910220R01 2 RF Exposure Measurement 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz ADT No: 910220R01 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5 Climate Condition The temperature and related humidity: 23 deg. C and 55 % RH 6. Classification This device is not fixed inside the host equipment, it is connected with host through wire. So it is easy to be re-located in the place where at least 20 cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. ADT No: 910220R01 4 7 Test Results 7.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 1dBi or 1.26 (numeric). 7.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241268.392.61 6243777.092.78 11246278.892.81 The minimum allowable distance is very close to the enclosure of the antenna. So, the user has no need to worry about the harmfulness of radiation. But it is recommended to always keep, at least, 20 cm separation distance with the antenna.

FCC ID: O7J-GL2411RT-0B Report No.: RF910220R01 1 Issued: Feb. 25, 2002 FCC TEST REPORT REPORT NO.: RF910220R01 MODEL NO.: GL2411RT-0B RECEIVED: Feb. 18, 2002 TESTED: Feb. 20 ~ Feb. 21, 2002 APPLICANT:GLOBAL SUN TECHNOLOGY INC. ADDRESS: No. 13, Tung Yuan Rd., Jung Li Industrial Park, Jung Li City, Tao Yuan Hsien, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14 th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 49 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: O7J-GL2411RT-0B Report No.: RF910220R01 2 Issued: Feb. 25, 2002 Table of Contents 1CERTIFICATION........................................................................................... 4 2SUMMARY OF TEST RESULTS .................................................................. 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ............................................................. 6 3.2DESCRIPTION OF TEST MODES ............................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS .............................. 7 3.4DESCRIPTION OF SUPPORT UNITS ......................................................... 8 4TEST TYPES AND RESULTS ...................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT................................................ 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................................... 9 4.1.2TEST INSTRUMENTS ...........................................................................................................9 4.1.3TEST PROCEDURES .......................................................................................................... 10 4.1.4TEST SETUP ....................................................................................................................... 10 4.1.5EUT OPERATING CONDITIONS......................................................................................... 11 4.1.6TEST RESULTS ................................................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT................................................... 18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ......................................................... 18 4.2.2TEST INSTRUMENTS ......................................................................................................... 19 4.2.3TEST PROCEDURES .......................................................................................................... 20 4.2.4TEST SETUP ....................................................................................................................... 21 4.2.5EUT OPERATING CONDITIONS......................................................................................... 21 4.2.6TEST RESULTS ................................................................................................................... 22 4.36dB BANDWIDTH MEASUREMENT .......................................................... 27 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ................................................................ 27 4.3.2TEST INSTRUMENTS ......................................................................................................... 27 4.3.3TEST PROCEDURE ............................................................................................................28 4.3.4TEST SETUP ....................................................................................................................... 28 4.3.5EUT OPERATING CONDITIONS......................................................................................... 28 4.3.6TEST RESULTS ................................................................................................................... 29 4.4MAXIMUM PEAK OUTPUT POWER.......................................................... 33 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ................................... 33 4.4.2INSTRUMENTS.................................................................................................................... 33 4.4.3TEST PROCEDURES .......................................................................................................... 34 4.4.4TEST SETUP ....................................................................................................................... 34 4.4.5EUT OPERATING CONDITIONS......................................................................................... 34 4.4.6TEST RESULTS ................................................................................................................... 35 4.5POWER SPECTRAL DENSITY MEASUREMENT ..................................... 36 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ........................................... 36 4.5.2TEST INSTRUMENTS ......................................................................................................... 36 4.5.3TEST PROCEDURE ............................................................................................................37 4.5.4TEST SETUP ....................................................................................................................... 37 4.5.5EUT OPERATING CONDITION ........................................................................................... 37 4.5.6TEST RESULTS ................................................................................................................... 38 4.6BAND EDGES MEASUREMENT ................…

Text truncated - open the document above for the full version.

FCC ID: O7J-GL2411RT-0B Report No.: RF910220R01 47 Issued: Feb. 25, 2002 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: O7J-GL2411RT-0B Report No.: RF910220R01 48 Issued: Feb. 25, 2002 RADIATED EMISSION TEST
