LINKSYS WAP11 V2.2 Version:1.0 Date:2001/12/21 1 Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy. If this equipment is not installed and used in accordance with the manufacturer's instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by during the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Manufacturer's Disclaimer Statement The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. No warranty or representation, either expressed or implied, is made with respect to the quality, accuracy or fitness for any particular purpose of this document. The manufacturer reserves the right to make changes to the content of this document and/or the products associated with it at any time without obligation to notify any person or organization of such changes. In no event will the manufacturer be liable for direct, indirect, special, incidental or consequential damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of such damages. This document contains materials protected by copyright. All rights are reserved. No part of this manual may be reproduced or transmitted in any form, by any means or for any purpose without expressed written consent of its authors. Product names appearing in this document are mentioned for identification purchases only. All trademarks, product names or brand names appearing in this document are registered property of their respective owners. Printed in Taiwan 2 Contents SECTION 1 ABOUT WAP11 V2.2.........................................................................................3 INTRODUCTION........................................................................................................................................................3 1-1 FEATURES...........................................................................................................................................................3 1-2 FIRMWARE FUNCTIONALITY...................................................................................................................3 1-3 APPLICATIONS.................................................................................................................................................3 1-4 PRODUCT KIT..................................................................................................................................................4 SECTION 2 HARDWARE INSTALLATION...........................................................5 2-1 EQUIPMENT REQUIREMENT....................................................................................................................5 2-2 HARDWARE INSTALLATION.................................................................................................................5 SECTION 3 INSTALLING & CONFIGURING WAP11 V2.2..............6 3-1 INSTALLING AND CONFIGURING WAP11 V2.2.........................................................................6 3-1-1 Setup..................................................................................................................................................................6 3-1-2 Advanced Setup...............................................................................................................................................11 APPENDIX A SPECIFICATIONS......................................................................................13 APPENDIX B GLOSSARY..........................................................................................................14 3 Section 1 About WAP11 V2.2 Introduction The 22 Mbps WAP11 V2.2 is a long-range, high performance and high powered LAN product, which provides WAP11 V2.2 services to a 2,4 GHz RF network and bridges to an Ethernet backbone. The design of this product is based on Taxes Instrument’s ACX100 chip, a highly integrated ASIC designed to combine legacy LANs with wireless LANs. ACX100 performs all the necessary inter-networking and bridging functions. It receives data from both networks, stores them locally for further processing, installs and maintains connections and transmits the packets to the appropriate destination. Furthermore, AC…

Text truncated - open the document above for the full version.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

Page 3 Page 4 Page 5

! Dxx-xxxxJP NYxxxxx Gzxxxxx 2.4D S42.4D S4 0T0 O Xxxxxxxxxxx

! 3 9 . 0 m m 59.0 mm Dxx-xxxxJP NYxxxxx Gzxxxxx 2.4D S42.4D S4 0T0 O Xxxxxxxxxxx 6 . 7 m m

Page 6 Page 7

Page 8 Page 9

Page 10 Page 11

Page 12 Page 13

FCC ID: O7J-GL2422AP ADT No.910124R06 Operational Description The transmitter of the EUT is powered by power adapter and connected with notebook through RJ45 port. The antenna used in this product is Dipole Antenna. There are two combinations on the antenna connector that MCX and Reversed TNC. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11,22Mbps.

FCC ID: O7J-GL2422AP ADT No.: 910124R06 FCC TEST REPORT REPORT NO.: RF910124R06 MODEL NO.: WAP22 WAP11 ver. 2.2 GL2422AP-0T0 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:GLOBAL SUN TECHNOLOGY INC. ADDRESS: No. 13, Tung Yuan Rd., Jung Li Industrial Park, Jung Li City, Tao Yuan Hsien, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: O7J-GL2422AP ADT No.: 910124R06 RF Exposure Measurement (Mobile Device) 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. Classification The antenna of the product, under normal use condition, is at least 20 cm away from the body of the user. Warning statement for keeping 20 cm separation distance and the prohibition of operating next to a person has been printed on the users manual. So, this product is classified as the Mobile Device. 3. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). FCC ID: O7J-GL2422AP ADT No.: 910124R06 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 30-30061.40.1631.06 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 30-30027.50.0730.230 300-1500......F/150030 1500-100,000......1.030 F = Frequency in MHz 4. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 5. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: O7J-GL2422AP ADT No.: 910124R06 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 5dBi or 3.16 (numeric). 6.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241235.082.97 6243738.643.12 11246237.503.07 The minimum allowable distance is very close to the enclosure of the antenna. So, the user has no need to worry about the harmfulness of radiation. But it is recommended to always keep, at least, 20 cm separation distance with the antenna.

FCC ID: O7J-GL2422AP Report No.: RF910124R06 1 Issued: Jan. 29, 2002 FCC TEST REPORT REPORT NO.: RF910124R06 MODEL NO.: WAP22 (the others please refer P.6) RECEIVED: Jan. 24, 2002 TESTED: Jan. 24, 2002 ~ Jan. 28, 2002 APPLICANT:GLOBAL SUN TECHNOLOGY INC. ADDRESS: No. 13, Tung Yuan Rd., Jung Li Industrial Park, Jung Li City, Tao Yuan Hsien, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14 th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 54 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: O7J-GL2422AP Report No.: RF910124R06 2 Issued: Jan. 29, 2002 Table of Contents 1CERTIFICATION........................................................................................... 4 2SUMMARY OF TEST RESULTS .................................................................. 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ............................................................. 6 3.2DESCRIPTION OF TEST MODES ............................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS .............................. 7 3.4DESCRIPTION OF SUPPORT UNITS ......................................................... 8 4TEST TYPES AND RESULTS ...................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT................................................ 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................................... 9 4.1.2TEST INSTRUMENTS ...........................................................................................................9 4.1.3TEST PROCEDURES .......................................................................................................... 10 4.1.4TEST SETUP ....................................................................................................................... 10 4.1.5EUT OPERATING CONDITIONS......................................................................................... 11 4.1.6TEST RESULTS ................................................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT................................................... 18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ......................................................... 18 4.2.2TEST INSTRUMENTS ......................................................................................................... 19 4.2.3TEST PROCEDURES .......................................................................................................... 20 4.2.4TEST SETUP ....................................................................................................................... 21 4.2.5EUT OPERATING CONDITIONS......................................................................................... 21 4.2.6TEST RESULTS (A) ............................................................................................................. 22 4.2.7TEST RESULTS (B) ............................................................................................................. 27 4.36dB BANDWIDTH MEASUREMENT .......................................................... 32 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ................................................................ 32 4.3.2TEST INSTRUMENTS ......................................................................................................... 32 4.3.3TEST PROCEDURE ............................................................................................................33 4.3.4TEST SETUP ....................................................................................................................... 33 4.3.5EUT OPERATING CONDITIONS......................................................................................... 33 4.3.6TEST RESULTS ................................................................................................................... 34 4.4MAXIMUM PEAK OUTPUT POWER.......................................................... 38 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ................................... 38 4.4.2INSTRUMENTS.................................................................................................................... 38 4.4.3TEST PROCEDURES .......................................................................................................... 39 4.4.4TEST SETUP ....................................................................................................................... 39 4.4.5EUT OPERATING CONDITIONS......................................................................................... 39 4.4.6TEST RESULTS ................................................................................................................... 40 4.5POWER SPECTRAL DENSITY MEASUREMENT ..................................... 41 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ........................................... 41 4.5.2TEST INSTRUMENTS ......................................................................................................... 41 4.5.3TEST PROCEDURE ............................................................................................................42 4.5.4TEST SETUP ....................................................................................................................... 42 4.5.5EUT OPERATING CONDITION ........................................................................................... 42 4.5.6TEST RESULTS ....…

Text truncated - open the document above for the full version.

FCC ID: O7J-GL2422AP Report No.: RF910124R06 41 Issued: Jan. 29, 2002 4.5 POWER SPECTRAL DENSITY MEASUREMENT 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT The Maximum of Power Spectral Density Measurement is 8dBm. 4.5.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until SPECTRUM ANALYZERFSEK30100049July 17, 2002 NOTE: 1. The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2. The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. FCC ID: O7J-GL2422AP Report No.: RF910124R06 42 Issued: Jan. 29, 2002 4.5.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer through an attenuator, the bandwidth of the fundamental frequency was measured with the spectrum analyzer using 3 kHz RBW and 30 kHz VBW, set sweep time = span/3 kHz. The power spectral density was measured and recorded. The sweep time is allowed to be longer than span/3 kHz for a full response of the mixer in the spectrum analyzer. 4.5.4 TEST SETUP 4.5.5 EUT OPERATING CONDITION Same as Item 3.4.5 EUT SPECTRUM ANALYZER FCC ID: O7J-GL2422AP Report No.: RF910124R06 43 Issued: Jan. 29, 2002 4.5.6 TEST RESULTS EUT Wireless Network Access Point MODEL WAP22 INPUT POWER (SYSTEM) 120Vac, 60Hz ENVIRONMENTAL CONDITIONS 25 deg. C, 60%RH, 1005 hPa TESTED BY: Bruce Shiau CHANNEL NUMBER CHANNEL FREQUENCY (MHz ) RF POWER LEVEL IN 3 kHz BW (dBm) MAXIMUM LIMIT (dBm) PASS/FAIL 12412-3.198PASS 62437-2.528PASS 112462-3.388PASS FCC ID: O7J-GL2422AP Report No.: RF910124R06 44 Issued: Jan. 29, 2002 CH1 FCC ID: O7J-GL2422AP Report No.: RF910124R06 45 Issued: Jan. 29, 2002 CH6 FCC ID: O7J-GL2422AP Report No.: RF910124R06 46 Issued: Jan. 29, 2002 CH11 FCC ID: O7J-GL2422AP Report No.: RF910124R06 47 Issued: Jan. 29, 2002 4.6 BAND EDGES MEASUREMENT 4.6.1 LIMITS OF BAND EDGES MEASUREMENT Below –20dB of the highest emission level of operating band (in 100KHz Resolution Bandwidth). 4.6.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until SPECTRUM ANALYZERFSEK30100049July 17, 2002 NOTE: 1.The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2.The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. 4.6.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer via a low lose cable. Set both RBW and VBW of spectrum analyzer to 100 kHz with suitable frequency span including 100 kHz bandwidth from band edge. The band edges was measured and recorded. FCC ID: O7J-GL2422AP Report No.: RF910124R06 48 Issued: Jan. 29, 2002 4.6.4 EUT OPERATING CONDITION Same as Item 3.4.5 4.6.5 TEST RESULTS The spectrum plots are attached on the following 2 pages. D2 line indicates the highest level, D1 line indicates the 20dB offset below D2. It shows compliance with the requirement in part 15.247(C). NOTE: The band edge emission plot on the following 2 pages shows 53.65dB delta between carrier maximum power and local maximum emission in restrict band (2.4839GHz). The emission of carrier strength list in the test result of channel 11 at the item 4.2.6 (Page 31) is 98.2dBuV/m, so the maximum field strength in restrict band is 98.2-53.65=44.55dBuV/m which is under 54 dBuV/m limit. FCC ID: O7J-GL2422AP Report No.: RF910124R06 49 Issued: Jan. 29, 2002 FCC ID: O7J-GL2422AP Report No.: RF910124R06 50 Issued: Jan. 29, 2002 FCC ID: O7J-GL2422AP Report No.: RF910124R06 51 Issued: Jan. 29, 2002 4.7 ANTENNA REQUIREMENT 4.7.1 STANDARD APPLICABLE For intentional device, according to FCC 47 CFR Section 15.203, an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. And according to FCC 47 CFR Section 15.247 (b), if transmitting antennas of directional gain greater than 6dBi are used, the power shall be reduced by the amount in dB that the directional gain of the antenna exceeds 6dBi. 4.7.2 ANTENNA CONNECTED CONSTRUCTION The antenna used in this product is Dipole Antenna. There are two combinations on the antenna connector as following, Antenna Connector Set 1Set 2 InternalMCXMCX ExternalReversed TNCNA FCC ID: O7J-GL2422AP Report No.: RF910124R06 52 Issued: Jan. 29, 2002 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: O7J-GL2422AP Report No.: RF910124R06 53 Issued: Jan. 29, 2002 RADIATED EMISSION TEST FCC ID: O7J-GL2422AP Report No.: RF910124R06 54 Issued: Jan. 29, 2002 6 INFORMATION ON THE TESTING LABORATORIES We, ADT Corp., were founded in 1988 to provide our best service in EMC and Safety consultation. Our laboratories are accredited and approved by the following approval agencies according to ISO/IEC 17025, Guide 25 or EN 45001: USAFCC, NVLAP, UL GermanyTUV Rheinland JapanVCCI New ZealandMoC NorwayNEMKO R.O.C.BSMI, DGT, CNLA Copies of accreditation certificates of our laboratories obtained from approval agencies can be downloaded from our web site: www.adt.com.tw/index.5/phtml. If you have any comments, please feel free to contact us at the following: Lin Kou EMC Lab: Tel: 886-2-26052180 Fax: 886-2-26052943 Hsin Chu EMC Lab: Tel: 886-35-935343 Fax: 886-35-935342 Lin Kou Safety Lab: Tel: 886-2-26093195 Fax: 886-2-26093184 Lin Kou RF&Telecom Lab Tel: 886-3-3270910 Fax: 886-3-3270892 Email: [email protected] Web Site: www.adt.com.tw The address and road map of all our labs can be found in our web site also.

FCC ID: O7J-GL2422AP Report No.: RF910124R06 52 Issued: Jan. 29, 2002 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: O7J-GL2422AP Report No.: RF910124R06 53 Issued: Jan. 29, 2002 RADIATED EMISSION TEST
