Cat. No. 22-1699 Owner’s Manual Please read before using this equipment. 360 Laser/Radar Detector FEATURES Your RadioShack 360° Laser/Radar detector can alert you to all known police traffic radar and laser systems with its distinct visual and audio alerts. It receives X-, K-, and Ka- band radar signals, and detects both the instant-on and laser systems many police departments use to measure vehicle speed. Plus, your detector can give you advance warning of potential road hazards by detecting signals from transmitters that broadcast Safety Warning System™ alerts. Note: Before reading this Owner’s Manual, read the su- pplied booklet Questions and Answers About Vehicle Speed Detection to familiarize yourself with the terms and uses associated with your detector. Your detector’s features include: Electric Compass – provides accurate heading information with alphanumeric display and LED panel. Real Voice Alert – greets you as you turn on the detector and alerts you with different vocal indicators including radar and laser detection. 2000 Tandy Corporation All Rights Reserved RadioShack is a registered trademark used by Tandy Corporation. SWS is a trademark of Safety Warning System, Inc. Compass technology is licensed under US patent numbers 4,851,775 and 5,239,264 from Precision Navigation, Inc. FAST is a registered trademark used by Tandy Corporation. Instaclear is a registered trademark used by Ford Motor Company. ElectriClear is a registered trademark by Libbey, Owens, Ford and Delco-Remy. 2 Alphanumeric Display - appears you turn on the detector and alerts you with various text messages including radar and laser detection 360°Detection – detects laser signals from all around your vehicle. VG-2 Protection - makes your detector invisible to the VG-2 radar-detector when it senses VG-2 operation X-, K-, Ka-Band( Newly Included Ka-POP ), and Laser Signal Detection - warns you when it detects signals from traffic radar or laser devices. Different tone and display indicators let you know the type of signal received. Safety Warning System Detection - alerts you to the presence of potential road hazards, and emergency veh- icles signaled by Safety Warning System transmission. City/Highway Modes - let you minimize alerts when you are in areas that have false radar sources. City/Highway Selector and City/Highway Indicator - displays which mode is currently selected. FAST® (False Alert Suppression Technology) - helps prevent false alarms caused by non-traffic radar sources. Tutorial Mode – lets you experience how the detector alerts you with its detection display, tones, and real voice alert to all of the different signals the detector recognizes. 3 Auto Mute Mode – automatically reduce the audio volume of all alerts after 4 seconds for as long as the signal is detected. 3 Memory Retention - retains operational settings in memory without power, so when you turn on your detector, the setting will be the same as when you turned it off. Instant On Radar Protection - alerts you to sudden high level and radar signals. Your radar/laser detector includes the following items: i coiled power cord i windshield bracket with suction cups i hook and loop tape i Spare fuse i Question and Answer About Vehicle Speed Detection We recommend you record your detector’s serial number here. The number is on the detector’s bottom panel. Serial Number: Important: Some areas have laws regulating the use of radar detectors. Check with your local law enforcement agency about the laws in your area. 4 CONTENTS A Quick Look ....................................................... 6 Installation ...........................................................8 Selecting a Mounting Location ............................. 8 Mounting Guidelines ...............................,...... 8 Windshield Mounting .......................................... 9 Hook and Loop Mounting ................................... 11 Connecting Power .............................................. 12 Operation ...........................................................13 Turning On the detector .................................... 13 Adjusting the Volume ........................................ 13 Tutorial mode...................................................14 ELECTRIC COMPASS.......................................15 Operating Setting .............................................17 Selecting the City and Highway Modes ............ 17 Selecting Display Brightness .......................... 18 Muting the Audio Alert .................................. 18 Auto Mute mode...........................................19 Selecting VG-2 Modes .................................. 20 Receiving and Identifying Radar, Laser, and Safety Alert Signals.................................... 20 SWS Categories and Messages........................22 Troubleshooting ..................................................25 Care and Maintenance ......................................... 27 Replacing the fuse ........................................... 28 5 A QUICK LOOK 1. 360 ̊Laser Eye – receives incoming laser signals directed at your vehicle from all directions. 2. DC 12V Jack – the power cord plugs in here. 3. DIM Button – controls the brightness of alphanumeric display. 4. Mute Button – silences the alert tone for about 20 seconds after the current signal is lost. 5. City (City/Highway) Button – switches between the city and highway modes. 6 6. Speaker – sounds a digital voice alert and tones let you know the types of radar and laser signals detected 7. LED Compass – indicates your headinginformation. 8. High Visibility Alphanumeric Display - provides di- stinct visual of signal detected, signal strength, and he- ading information, and indicates the selected operating mode. 9. VOLUME/OFF Control – turns the detector on and off and lets you adjust the volume. SAFETY WARNING ® SYSTEM ™ The revolutionary Safety Warning System (SWS) has won formal approval from the Federal Communications Comm…
Text truncated - open the document above for the full version.
APPLICANT: SK GLOBAL FCC ID: O8B2201699 REPORT #: S\SK_GLOBAL\632KT3\632KT3TestReport.doc TABLE OF CONTENTS LIST TABLE OF CONTENTS LIST APPLICANT: SK GLOBAL FCC ID : O8B2201699 TEST REPORT CONTAINING: PAGE 1-4....TEST EQUIPMENT LIST PAGE 5-6....TEST PROCEDURES PAGE 7......RADIATION INTERFERENCE TEST DATA PAGE 8......VERTICAL MEASUREMENT PLOT PAGE 9......HORIZONTAL MEASURMENT PLOT EXHIBITS CONTAINING: EXHIBIT 1............FCC ID LABEL SAMPLE EXHIBIT 2............SKETCH OF LABEL LOCATION EXHIBIT 3............BLOCK DIAGRAM EXHIBIT 4............SCHEMATIC EXHIBIT 5............USERS MANUAL EXHIBIT 6............EXTERNAL PHOTOGRAPHS EXHIBIT 7............INTERNAL PHOTOGRAPHS EXHIBIT 8............THEORY OF OPERATION 1 EXHIBIT 9............THEORY OF OPERATION 2 EXHIBIT 10...........TEST SET UP PHOTO APPLICANT: SK GLOBAL FCC ID: O8B2201699 REPORT #: S\SK_GLOBAL\632KT3\632KT3TestReport.doc Page 1 of 9 EMC Equipment List DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS X 3-Meter OATS TEI N/A N/A Listed 1/13/03 1/13/06 3/10-Meter OATS TEI N/A N/A Listed 3/26/01 3/26/04 Receiver, Beige Tower Spectrum Analyzer HP 8566B Opt 462 3138A07786 3144A20661 CAL 8/31/01 8/31/03 RF Preselector HP 85685A 3221A01400 CAL 8/31/01 8/31/03 Quasi-Peak Adapter HP 85650A 3303A01690 CAL 8/31/01 8/31/03 X Receiver, Blue Tower X Spectrum Analyzer HP 8568B 2928A04729 2848A18049 CAL 4/15/03 4/15/05 X RF Preselector HP 85685A 2926A00983 CAL 4/15/03 4/15/05 X Quasi-Peak Adapter HP 85650A 2811A01279 CAL 4/15/03 4/15/05 Receiver, Silver/Grey Tower Spectrum Analyzer HP 8566B Opt 462 3552A22064 3638A08608 CAL 10/14/02 10/14/04 RF Preselector HP 85685A 2620A00294 CAL 10/14/02 10/14/04 Quasi-Peak Adapter HP 85650A 3303A01844 CAL 10/14/02 10/14/04 Preamplifier HP 8449B 3008A01075 CHAR 1/28/02 1/28/04 X Biconnical Antenna Electro-Metrics BIA-25 1171 CAL 4/26/01 4/26/03 Biconnical Antenna Eaton 94455-1 1096 CAL 10/1/01 10/1/03 Biconnical Antenna Eaton 94455-1 1057 CAL 3/18/03 3/18/05 BiconiLog Antenna EMCO 3143 9409-1043 X Log-Periodic Antenna Electro-Metrics LPA-25 1122 CAL 10/2/01 10/2/03 Log-Periodic Antenna Electro-Metrics EM-6950 632 CHAR 10/15/01 10/15/03 Log-Periodic Antenna Electro-Metrics LPA-30 409 CAL 3/4/03 3/4/05 Dipole Antenna Kit Electro-Metrics TDA-30/1-4 152 CAL 3/21/01 3/21/04 Dipole Antenna Kit Electro-Metrics TDA-30/1-4 153 CAL 9/26/02 9/26/05 APPLICANT: SK GLOBAL FCC ID: O8B2201699 REPORT #: S\SK_GLOBAL\632KT3\632KT3TestReport.doc Page 2 of 9 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS Double-Ridged Horn Antenna Electro-Metrics RGA-180 2319 CAL 2/17/03 2/17/05 Horn Antenna Electro-Metrics EM-6961 6246 CAL 3/31/03 3/31/05 Horn Antenna ATM 19-443-6R None No Cal Required Passive Loop Antenna EMC Test Systems EMCO 6512 9706-1211 CHAR 7/10/01 7/10/03 Line Impedance Stabilization . . . Electro-Metrics ANS-25/2 2604 CAL 10/9/01 10/9/03 Line Impedance Stabilization . . . Electro-Metrics EM-7820 2682 CAL 3/12/03 3/12/05 Termaline Wattmeter Bird Electronic Corporation 611 16405 CAL 5/25/99 5/25/01 Termaline Wattmeter Bird Electronic Corporation 6104 1926 CHAR 12/12/01 12/12/03 Oscilloscope Tektronix 2230 300572 CHAR 2/1/01 2/1/03 System One Audio Precision System One SYS1-45868 CHAR 4/25/02 4/25/04 Temperature Chamber Tenney Engineering TTRC 11717-7 CHAR 1/22/02 1/22/04 AC Voltmeter HP 400FL 2213A14499 CAL 10/9/01 10/9/03 AC Voltmeter HP 400FL 2213A14261 CHAR 10/15/01 10/15/03 AC Voltmeter HP 400FL 2213A14728 CHAR 10/15/01 10/15/03 X Digital Multimeter Fluke 77 35053830 CHAR 1/8/02 1/8/04 Digital Multimeter Fluke 77 43850817 CHAR 1/8/02 1/8/04 Digital Multimeter HP E2377A 2927J05849 CHAR 1/8/02 1/8/04 Multimeter Fluke FLUKE-77-3 79510405 CHAR 9/26/01 9/26/03 Peak Power Meter HP 8900C 2131A00545 CHAR 1/26/01 1/26/03 Power Meter HP 432A 1141A07655 CAL 4/15/03 4/15/05 Power Meter And Sensor Bird 4421-107 4022 0166 0218 CAL 4/16/03 4/16/05 Power Sensor HP 478A 72129 CAL 4/15/03 4/15/05 Digital Thermometer Fluke 2166A 42032 CAL 1/16/02 1/16/04 APPLICANT: SK GLOBAL FCC ID: O8B2201699 REPORT #: S\SK_GLOBAL\632KT3\632KT3TestReport.doc Page 3 of 9 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS Thermometer Traulsen SK-128 CHAR 1/22/02 1/22/04 Thermometer Extech 4028 14871-2 CAL 3/7/03 3/7/05 X Hygro-Thermometer Extech 445703 0602 CAL 10/4/02 10/4/04 Frequency Counter HP 5352B 2632A00165 CAL 11/28/01 11/28/03 Frequency Counter HP 5385A 2730A03025 CAL 3/7/03 3/7/05 Power Sensor Agilent Technologies 84811A 2551A02705 CHAR 1/26/01 1/26/03 Service Monitor IFR FM/AM 500A 5182 CAL 11/22/00 11/22/02 Comm. Serv. Monitor IFR FM/AM 1200S 6593 CAL 5/12/02 5/12/04 Signal Generator HP 8640B 2308A21464 CAL 2/15/02 2/15/04 Sweep Generator Wiltron 6648 101009 CAL 4/15/03 4/15/05 Sweep Generator Wiltron 6669M 007005 CAL 3/3/03 3/3/05 Modulation Analyzer HP 8901A 3435A06868 CAL 9/5/01 9/5/03 Modulation Meter Boonton 8220 10901AB CAL 4/15/03 4/15/05 Near Field Probe HP HP11940A 2650A02748 CHAR 2/1/01 2/1/03 BandReject Filter Lorch Microwave 5BR4-2400/ 60-N Z1 CHAR 3/2/01 3/2/03 BandReject Filter Lorch Microwave 6BR6-2442/ 300-N Z1 CHAR 3/2/01 3/2/03 BandReject Filter Lorch Microwave 5BR4-10525/ 900-S Z1 CHAR 3/2/01 3/2/03 High Pass Filter Microlab HA-10N CHAR 10/4/01 10/4/03 High Pass Filter Microlab HA-20N CHAR 2/7/03 2/7/05 Audio Oscillator HP 653A 832-00260 CHAR 3/1/01 3/1/03 Frequency Counter HP 5382A 1620A03535 CHAR 3/2/01 3/2/03 Frequency Counter HP 5385A 3242A07460 CAL 3/7/03 3/7/05 Preamplifier HP 8449B-H02 3008A00372 CHAR 3/4/01 3/4/03 APPLICANT: SK GLOBAL FCC ID: O8B2201699 REPORT #: S\SK_GLOBAL\632KT3\632KT3TestReport.doc Page 4 of 9 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS Amplifier HP 11975A 2738A01969 CHAR 3/1/01 3/1/03 Egg Timer Unk CHAR 8/31/01 8/31/03 Measuring Tape, 20M Kraftixx 0631-20 CHAR 2/1/02 2/1/04 Measuring Tape, 7.5M Kraftixx 7.5M PROFI 2/1/02 2/1/04 Coaxial Cable #51 Insulated Wire Inc. NPS 2251-2880 Timco #51 CHAR 1/23/02 1/23/04 Coaxial Cable #64 Semflex Inc. 60637 Timco #64 CHAR 1/…
Text truncated - open the document above for the full version.
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 3 | 15B | 33.40 GHz - 36.00 GHz | - |

Radar Detector
Equipment Class
CRD - Part 15 Radar Detector
Radar Detector
Equipment Class
CRD - Part 15 Radar Detector
Radar Detector
Equipment Class
CRD - Part 15 Radar Detector
Radar Detector with Compass
Equipment Class
CRD - Part 15 Radar Detector
Radar Detector
Equipment Class
CRD - Part 15 Radar Detector
