OB6-IGDT40916Data Tag

Hi-G-Tek Ltd. Microelectronics & Asset Tracking Technology Pg.1 DataTag – Application On Object User Instructions. The DataTag is delivered with a set of double-sided tapes that are used for placing the DataTag on the tagged object. The Sensor Plate (item #1) is supplied separately from the DataTag. To place the Sensor Plate peel the paper from the double-sided tape (item #2) and place the Sensor Plate in its place. 1 2 Press the sensor Tape to create the contact between the tape and the sensor Plate. Make sure the contacts at the bottom part of the plate are aligned with the pins. Peel the paper from the three pieces of double-sided tape: The two larger pieces (Items #3 & #4) are used for holding the DataTag to the tagged object while the smaller piece in the middle (Item #5) is used for pulling the Sensor Plate off the DataTag in order to create the TAMPER event when the DataTag is removed from the tagged object. 3 5 4 Hi-G-Tek Ltd. Microelectronics & Asset Tracking Technology Pg.2 Placing the DataTag on the vehicle Note: The Installation instructions refer to the case when the DataReader is installed VERTICALY. There are two preferred orientations for placing the DataTag on the vehicle: Horizontal Orientation: Place the tag on a flat surface that is completely horizontal and press firmly to create good contact between the DataTag and the tagged object. Vertical Orientation Place the DataTag on a flat surface that is completely vertical and press firmly to create good contact between the DataTag and the Tagged object. It is recommended that the height of the DataTag above ground will be above 3’ and the optimal height is 5’ above ground. Hi-G-Tek Ltd. Microelectronics & Asset Tracking Technology Pg.3 FCC ID: OB6-IGDT40916 This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to this equipment not expressly approved by Hi-G-Tek Ltd. could void the user’s authority to operate the equipment.

November 14, 2002 American TCB 6731 Whittier Ave Suite C110 McLean, VA 22101 USA Subject: Request for confidentiality for DataTag, model IG-DT-40-916, FCC ID: OB6-IGDT40916 Dear Gentlemen, We apply to you with request to withhold Hi-G-Tek Ltd. trade secrets in Application for Certification for FCC ID: OB6-IGDT40916. These trade secrets can be found in the transmitter schematic diagrams (4 pages of this Application: 47G10050 electrical diagram). Many thanks in advance. Sincerely yours Mr. Micha Auerbach, President and CEO Hi-G-Tek Ltd.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 December 29, 2002 RE: Hi-G-Tek Ltd. FCC ID: OB6-IGDT40916 After a review of the submitted information, I have a few comments on the above referenced Application. 1) The fundamental field strength at 125 kHz should be measured using a IF/RBW of 9 kHz. Please provide new test data. 2) FYI. The field strength of harmonics to 15.249 in section 4.2 of the test report shows compliance to the average limits of 54 dBuV/m only. Compliance with the peak limit of 74 dBuV/m is shown in the plots, but was not easily noted in the test report. Review of the test report is easier if peak measurements were also presented in section 4.2 of the test report. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

FCC ID: OB6-IGDT40916 In reply to e-mail dated December 29, 2002 Dear Mr. Johnson, Below is the answer to your question. Please find the result of 125 kHz carrier field strength measurement with resolution bandwidth 9 kHz in "Attachment to the test report HIGRAD_FCC.15297" submitted via "Add to existing application", Test Report folder on January 6, 2003. With great respect, Natasha. To: "'[email protected]'" <[email protected]> Subject: FCC ID: OB6-IGDT40916 Page 1 of 1In 1/6/2003Printed for "Timothy R. Johnson" <[email protected]>

FCC ID:OB6-IGDT40916 Date: December 2002 Page 1 of 4 EXTERNAL PHOTOGRAPHS This document contains 3 photographs FCC ID:OB6-IGDT40916 Date: December 2002 Page 2 of 4 Photograph No.1 DataTag general view The correct label will be placed here. FCC ID:OB6-IGDT40916 Date: December 2002 Page 3 of 4 Photograph No.2 DataTag close view The correct label will be placed here. FCC ID:OB6-IGDT40916 Date: December 2002 Page 4 of 4 Photograph No.3 DataTag rear view The correct label will be placed here.

FCC ID: OB6-IGDT40916 Date: December 2002 Page 1 of 1 LABEL The label shown below is affixed on the front lateral side of the DataTag. The label dimensions are 31.8 x 6.4 (mm), material - PVC with a permanent adhesive. The manufacturer and EUT names are silk screened on the front panel of the DataTag. The FCC part 15, §15.105 statement is placed in Installation Instructions, page 3. Label placement on the EUT front lateral side FCC ID: OB6-IGDT40916 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

FCC ID:OB6-IGDT40916 Date: December 2002 Page 1 of 10 INTERNAL PHOTOGRAPHS This document contains 9 photographs FCC ID:OB6-IGDT40916 Date: December 2002 Page 2 of 10 Photograph No.1 EUT view without cover FCC ID:OB6-IGDT40916 Date: December 2002 Page 3 of 10 Photograph No.2 Main PCB upper side FCC ID:OB6-IGDT40916 Date: December 2002 Page 4 of 10 Photograph No.3 Main PCB bottom side FCC ID:OB6-IGDT40916 Date: December 2002 Page 5 of 10 Photograph No.4 916.5 MHz transmitter 916.5 MHz transmitter FCC ID:OB6-IGDT40916 Date: December 2002 Page 6 of 10 Photograph No.5 125 kHz tag 125 kHz receiver 125 kHz transmitter FCC ID:OB6-IGDT40916 Date: December 2002 Page 7 of 10 Photograph No.6 916.5 MHz receiver 916.5 MHz receiver FCC ID:OB6-IGDT40916 Date: December 2002 Page 8 of 10 Photograph No.7 Tamper PCB FCC ID:OB6-IGDT40916 Date: December 2002 Page 9 of 10 Photograph No.8 Antenna board, component side FCC ID:OB6-IGDT40916 Date: December 2002 Page 10 of 10 Photograph No.9 Antenna board, printed side

Attachment to the test report HIGRAD_FCC.15297 Plot 1 125 kHz carrier field strength RESOLUTION BANDWIDTH: 9 kHz

FCC ID:OB6-IGDT40916 Date: December 2002 Page 1 of 6 TEST SETUP PHOTOGRAPHS This document contains 5 photographs FCC ID:OB6-IGDT40916 Date: December 2002 Page 2 of 6 Photograph No.1 Radiated emission measurements test setup with loop antenna, 9 kHz – 30 MHz frequency range, anechoic chamber method FCC ID:OB6-IGDT40916 Date: December 2002 Page 3 of 6 Photograph No.2 Radiated emission measurements test setup with biconilog antenna, 30 MHz – 1000 MHz frequency range, anechoic chamber method FCC ID:OB6-IGDT40916 Date: December 2002 Page 4 of 6 Photograph No.3 Radiated emission measurements test setup with double ridge guide antenna, 1 GHz – 10 GHz frequency range, anechoic chamber method FCC ID:OB6-IGDT40916 Date: December 2002 Page 5 of 6 Photograph No.4 Radiated emission measurements test setup, EUT bottom placed vertically, anechoic chamber method FCC ID:OB6-IGDT40916 Date: December 2002 Page 6 of 6 Photograph 5 Radiated emission measurements test setup, EUT bottom placed horizontally, anechoic chamber method
