OG5MW-1361BLUETOOTH SPEAKER

B B R R A A N N D D P P o o r r t t a a b b l l e e B B l l u u e e t t o o o o t t h h S S p p e e a a k k e e r r PLEASE READ BEFORE OPERATING THIS EQUIPMENT. Model No. :MW-1361 1 IMPORTANT SAFETY INSTRUCTIONS When used in the directed manner, this unit has been designed and manufactured to ensure your personal safety. However, improper use can result in potential electrical shock or fire hazards. Please read all safety and operating instructions carefully before installation and use, and keep these instructions handy for future reference. Take special note of all warnings listed in these instructions and on the unit. Water and Moisture The unit should not be used near water or wet space. Such as bathtub, washbowl, kitchen sink, laundry tub, swimming pool or basement. Ventilation The unit should be situated in the location or position which places won’t interfere its proper ventilation. For example, it should not be situated on a bed, sofa, rug or similar surface that may block the ventilation openings. Also, it should not be placed in a built-in installation, such as a bookcase or cabinet, which may impede the flow of air through the ventilation openings. Heat The unit should be situated away from heat sources such as radiators, heat registers, stoves or other appliances (including amplifiers) that produce heat. 2 Power Source The unit should be connected to a power supply only of the type described in the operating instructions or as marked on the appliance. Power Cord Protection Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them. It is always best to have a clear area from where the cord exits the unit to where it is plugged into an AC wall outlet. Cleaning The unit should be cleaned only as recommended. See the section « Care and Maintenance » of this manual for cleaning instructions. Object and Liquid Entry Care should be taken so that objects do not fall and liquids are not spilled into any openings or vents located on the product, Lightning and Power Surge Protection Unplug the unit from the wall outlet. This will prevent damage to the product due to lightning and power-line surges. Overloading Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire of electric shock. Damage Requiring Service This unit should be serviced by qualified service personnel when: Objects have fallen into or liquid has been spilled into the enclosure. 3 The unit has been exposed to rain. The unit has been dropped or the enclosure damaged. The unit exhibits a marked change in performance or does not operate normally. Periods of Nonuse If the unit is to be left unused for an intended period of time, such as a week or longer, the power cord should be unplugged from the unit to prevent damage or corrosion. Servicing The user should not attempt to service the unit beyond those methods described in the user’s operating instructions. Service methods not covered in the operating instructions should be referred to qualified service personnel. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. WARNING: - Batteries shall not be exposed to excessive heat such as sunshine, fire or the like. - To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus shall not be exposed to dripping or splashing and that objects filled with liquids, such as vases, shall not be placed on apparatus. - The mains plug is used as disconnect device, the disconnect device shall remain readily operable. 4 LOCATION OF CONTROLS Top View Back View 5 1. M (MODE) Button .To select different play modes: Bluetooth/FM/USB/Aux 2.Button z In Bluetooth or USB mode : Tap this button once to return to the beginning of current track or previous track. z In FM mode: .Press and hold this button to auto search and automatically save up all the stations with strong signals in sequence. It will automatically play the No. 1 station saved once the auto searching is finished. .Tap this button continuously to manually tune to desired station. 3. Play/Pause(On/Off) button Š Press and hold this button to turn the unit On or Off. Š In Bluetooth or USB playback mode: to play/ pause current playback Š In Bluetooth mode: when receiving an incoming call on your cell phone, tap this button once to answer the phone, tap this button again to end the call or ignore the incoming call. Š In FM mode: to select the preset stations in sequence 4. Button z In Bluetooth or USB mode : Tap this button once to to advance to the next track. z In FM mode: .Press and hold this button to auto search and automatically save up all the stations with strong signals in sequence. It will automatically play the No. 1 station saved once the auto searching is finished. 6 .Tap this button continuously to manually tune to desired station. 5. -Button Press this button to adjust volume level down. 6. + Button z Press this button to adjust volume level up 7. Built-in Microphone 8. LED Display 9. Battery Status Indicator (Green color) z Rapid flashing =low battery ‹ While charging : z Flashing =charging z Steady Green= full charged 10. Telescopic Antenna 11. Aux-In Jack 12. USB port 13. AC Socket POWER SOURCES Power Supply This unit is designed to operate on AC 100-240V～50/60 Hz household mains supply or the built-in rechargeable Li-ion battery. Connect To AC Power Before using this new Wireless speaker the first time, you should connect it to AC (mains) power. 1.Plug the connector of AC cord into the AC socket on the back of the speaker unit. 7 2. Plug the AC cord plug into a convenient AC wall outlet. 3. The green color battery charging indicator will light up & charging begins. 3. Press and hold the Button to turn on the unit, the LED display will light up. 4. Press and hold the Button again to turn off the unit. 5.Remove the AC cord out of the wall …

Text truncated - open the document above for the full version.

775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SHENZHEN MANIWAY ELECTRONICS LIMITED SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 2014-02-25 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, SHENZHEN MANIWAY ELECTRONICS LIMITED hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product： BLUETOOTH SPEAKER Trade Name：MANIWAY、SONIQ Model Name： MW-1361 Serial Model： MB405 FCC ID： OG5MW-1361 We affirm that between SIEMIC and SHENZHEN MANIWAY ELECTRONICS LIMITED , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Signature Name: Ming Wan Title: SM Address: Bldg 8,Sanlian Hebei Industrial Estate,Longhua Street,Bao'an District,Shenzhen,China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 SHENZHEN MANIWAY ELECTRONICS LIMITED \ 2014-02-25 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: OG5MW-1361 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Signature Name: Ming Wan Title: SM Address: Bldg 8,Sanlian Hebei Industrial Estate,Longhua Street,Bao'an District,Shenzhen,China

SHENZHEN MANIWAY ELECTRONICS LIMITED Model Difference FCC ID: OG5MW-1361 Model : MW-1361, MB405 All the same,Only model name is different. Regards, Client’s signature Signature Name: Ming Wan Title: SM Address: Bldg 8,Sanlian Hebei Industrial Estate,Longhua Street,Bao'an District,Shenzhen,China

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Label

FCC ID LABELING AND LOCATION FCC ID Label BLUETOOTH SPEAKER Model NO.：MW-1361 MANIWAY Input Rating：AC 100-240V50/60Hz FCC ID: OG5MW-1361 Shenzhen Maniway Electronics Limited. Made in China This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 BT Antenna Photo 9 Photo 10 Photo 11 Photo 12 Photo 13 Photo 14 Photo 15 Photo 16

FCC ID: OG5MW-1361 FCC §15.247 (i), §2.1091 – RF Exposure Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density FCC ID: OG5MW-1361 MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna TEST RESULTS Mode Maximum peak output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result 1Mbps 1.875 1.540 1(0dBi) 0.3064 1 Pass 2Mbps 1.925 1.558 1(0dBi) 0.3099 1 Pass 3Mbps 2.282 1.691 1(0dBi) 0.3364 1 Pass

FCC RADIO TEST REPORT FCC ID: OG5MW-1361 Product： BLUETOOTH SPEAKER Trade Name： MANIWAY、SONIQ Model Name： MW-1361 Serial Model： MB405 Report No.： NTEK-2014NT0212382F1 Prepared for SHENZHEN MANIWAY ELECTRONICS LIMITED Bldg 8,Sanlian Hebei Industrial Estate,Longhua Street, Bao'an District,Shenzhen,China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 74 Report No.: NTEK-2013NT1216238F2 TEST RESULT CERTIFICATION Applicant’s name............. SHENZHEN MANIWAY ELECTRONICS LIMITED Address ............................. Bldg 8,Sanlian Hebei Industrial Estate,Longhua Street, Bao'an District,Shenzhen,China Manufacture's Name........ SHENZHEN MANIWAY ELECTRONICS LIMITED Address ............................. Bldg 8,Sanlian Hebei Industrial Estate,Longhua Street, Bao'an District,Shenzhen,China Product description Product name ......................BLUETOOTH SPEAKER Model and/or type reference .......................... MW-1361 Serial Model： MB405 Standards......................... FCC Part15.247 Test procedure ..................... ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test........................................ Date (s) of performance of tests ......... 12 Feb. 2014 ~28 Feb. 2014 Date of Issue....................................... 28 Feb. 2014 Test Result........................................... Pass Testing Engineer : (Saint Xu) Technical Manager : (Brown Lu) Authorized Signatory : (Bovey Yang) Page 3 of 74 Report No.: NTEK-2013NT1216238F2 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BELOW 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 23 4 . NUMBER OF HOPPING CHANNEL 33 4.1 APPLIED PROCEDURES / LIMIT 33 4.1.1 TEST PROCEDURE 33 4.1.2 DEVIATION FROM STANDARD 33 4.1.3 TEST SETUP 33 4.1.4 EUT OPERATION CONDITIONS 33 4.1.5 TEST RESULTS 34 5 . AVERAGE TIME OF OCCUPANCY 35 5.1 APPLIED PROCEDURES / LIMIT 35 Page 4 of 74 Report No.: NTEK-2013NT1216238F2 Table of Contents Page 5.1.1 TEST PROCEDURE 35 5.1.2 DEVIATION FROM STANDARD 35 5.1.3 TEST SETUP 36 5.1.4 EUT OPERATION CONDITIONS 36 5.1.5 TEST RESULTS 37 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 43 6.1 APPLIED PROCEDURES / LIMIT 43 6.1.1 TEST PROCEDURE 43 6.1.2 DEVIATION FROM STANDARD 43 6.1.3 TEST SETUP 43 6.1.4 EUT OPERATION CONDITIONS 43 6.1.5 TEST RESULTS 44 7 . BANDWIDTH TEST 50 7.1 APPLIED PROCEDURES / LIMIT 50 7.1.1 TEST PROCEDURE 50 7.1.2 DEVIATION FROM STANDARD 50 7.1.3 TEST SETUP 50 7.1.4 EUT OPERATION CONDITIONS 50 7.1.5 TEST RESULTS 51 8 . PEAK OUTPUT POWER TEST 57 8.1 APPLIED PROCEDURES / LIMIT 57 8.1.1 TEST PROCEDURE 57 8.1.2 DEVIATION FROM STANDARD 57 8.1.3 TEST SETUP 57 8.1.4 EUT OPERATION CONDITIONS 57 8.1.5 TEST RESULTS 58 9 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 64 9.1 DEVIATION FROM STANDARD 64 9.2 TEST SETUP 64 9.3 EUT OPERATION CONDITIONS 64 9.4 TEST RESULTS 65 10 . ANTENNA REQUIREMENT 72 10.1 STANDARD REQUIREMENT 72 10.2 EUT ANTENNA 72 11 . EUT TEST PHOTO 73 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 74 Report No.: NTEK-2013NT1216238F2 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 74 Report No.: NTEK-2013NT1216238F2 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 74 Report No.: NTEK-2013NT1216238F2 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment BLUETOOTH SPEAKER Trade Name MANIWAY、SONIQ Model Name MW-1361 Serial Model MB405 Model Difference All the names are the same circ…
