OG5MW-15852.1CH Sound Base

ManiWay Owner's Manual 2 2 . . 1 1 C C H H S S o o u u n n d d b b a a s s e e w w i i t t h h B B u u i i l l t t - - i i n n S S u u b b w w o o o o f f e e r r PLEASE READ BEFORE OPERATING THIS EQUIPMENT. Model No.: MW-1585 IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacture’s instructions. 8. Do not install near any heat source such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus . 11. Only use attachments/accessories specified by the manufacturer. 12. Unplug the apparatus during lightning storms or when unused for long periods of time. 13. Refer all serving to qualified personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 14. Battery 1).CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. 2). Warning: DO NOT INGEST BATTERY, CHEMICAL BURN HAZARD. - This This product contains a coin/button cell battery. If the coin/button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death. - Keep new and used batteries away from children. If the battery compartment does not close securely, stop using the product and keep it away from children. - If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention. 15. This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does not require a safety connection to electrical earth. Warning This appliance is not intended for use by persons (including children) with reduced physical sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. 1. To prevent possible hearing damage, do not listen at high volume levels for long time periods respectively a sudden high volume level. 2. Never use the device unsupervised! Switch off the device whenever you are not using it, even if this only for a short while. 3. The appliance is not intended to be operated by means of an external timer or separate remote control system. 4. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. 5. Before operating this system, check the voltage of this system to see if it is identical to the voltage of your local power supply. 6. The unit should not be impeded by covering the ventilation opening with items such as newspaper, table-cloths, curtains etc. Make sure that there are at least 20 cm of space above and at least 5 cm of space on each side of the unit. 7. The apparatus must not be exposed to dripping or splashing and that objects filled with liquids, such as vases, must not be placed on the apparatus. 8. To prevent fire or shock hazard, do not expose this equipment to hot places, rain, moisture or dust. 9. Do not locate this unit near any water sources e.g. taps, bathtubs, washing machines or swimming pools. Ensure that you place the unit on a dry, stable surface. 10. Do not place this unit close to a strong magnetic field. 11. Do not place the unit on a amplifier or receiver. 12. Do not place this unit in a damp area as the moisture will affect the life of electric components. 13. If the system is brought directly from a cold to a warm location, or is placed in a very damp room, moisture may condense on the lens inside the player. If this occurs, the system will not operate properly. Please leave the system turned on for about an hour until the moisture evaporates. 14. Do not attempt to clean the unit with chemical solvents as this might damage the finish. Wipe with a clean, dry or slightly damp cloth. 15. When removing the power plug from the wall outlet, always pull directly on the plug, never pull on the cord. 16. The mains plug is used as the disconnect device, the disconnect device must remain readily operable. CAUTION To reduce the risk of electric shock, do not dismantle the product and do not expose the apparatus to rain or moisture. No user-serviceable parts inside. Refer servicing to qualified personnel only. Explanation of Graphical Symbols: The lightning flash within an equilateral triangle is intended to alert you to the presence of un-insulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute an electric shock to a person or persons. The exclamation point within an equilateral triangle is intended to alert you to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. To achieve the utmost in enjoyment and performance, and in order to become familiar with its features, please read this manual carefully before attempting to operate this product. This will assure you years of tro…

Text truncated - open the document above for the full version.

Page 4 Shenzhen Maniway Electronics Limited Date : 2015-08-05 Shenzhen Maniway Electronics Limited Bldg 8, Sanlian Hebei Industrial Estate, Longhua Street, Bao’an District, Shenzhen, China Dear Sirs, Re. : Letter of Appointment This is the letter of authorization to accept our appointment of The Hong Kong Standards and Testing Centre Ltd. Mr. KC Lee as agent for Shenzhen Maniway Electronics Limited , Bldg 8, Sanlian Hebei Industrial Estate, Longhua Street, Bao’an District, Shenzhen, China to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with Certification of the following product of Shenzhen Maniway Electronics Limited . Product name : 2.1CH Sound Base Model : MW-1585, PSBV630HDBT, PSBV620BT This authorization will expire one year from the date of this letter. Print name Wan Ming Title: Marketing Manager Signature:

Page 3 Shenzhen Maniway Electronics Limited Company Name : Shenzhen Maniway Electronics Limited Address : Bldg 8, Sanlian Hebei Industrial Estate, Longhua Street, Bao’an District, Shenzhen, China Date :2015-8-5 FCC ID: OG5MW-1585 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Specifically, “Shenzhen Maniway Electronics Limited” requests that the following materials be withheld from public inspection under 47CFR 0.459 because they are confidential trade secrets and technical data which would be guarded from competitors. (1) detailed circuit schematic of unit under test (2) parts list (3) block diagram (4) Circuit Description Therefore, in accordance with 47CFR Sections 0.457 and 0.459 we request that the above listed materials, copies of which are attached here, be withheld from public inspection. Sincerely, Print name Wan Ming Title: Marketing Manager Signature:

Updated on 2005/02/07 by Kally Chan To : STC (DongGuan) COMPANY LIMITED DECLARATION OF IDENTITY Hereby we: SHENZHEN MANIWAY ELECTRONICS LIMITED (Name of Applicant) Basic Model Number: MW-1585 Basic Brand Name: MANIWAY Basic Product Name: 2.1CH Sound Base Basic Test Report Application Number: Declare the Circuit, PCB Layout, Electrical Parts and Outlook of the following product(s) are identical to the basic model: New / Additional Model Number(s): PSBV630HDBT. PSBV620BT New / Additional Brand Name(s): PYLE Except the following(s) : MODEL NUMBER ,BRAND NAME THE OTHER IS THE SAME Remarks: Signature with Company Chop : Printed Name : Wan Ming DATE: 2015-8-3

OG5MW-1585 PHOTOGRAPH OF THE PRODUCT FRONT VIEW OF THE PRODUCT REAR VIEW OF THE PRODUCT OG5MW-1585 PHOTOGRAPH OF THE PRODUCT LEFT VIEW OF THE PRODUCT RIGHT VIEW OF THE PRODUCT OG5MW-1585 PHOTOGRAPH OF THE PRODUCT TOP VIEW OF THE PRODUCT BTTOM VIEW OF THE PRODUCT

Label Location

OG5MW-1585 PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT TOP VIEW OG5MW-1585 PHOTOGRAPH OF THE PRODUCT OG5MW-1585 PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT BOTTOM VIEW OG5MW-1585 PHOTOGRAPH OF THE PRODUCT OG5MW-1585 PHOTOGRAPH OF THE PRODUCT OG5MW-1585 PHOTOGRAPH OF THE PRODUCT

STC Test Report Date: 2015-08-01 Page 1 of 83 No.: DM120157 Applicant: Shenzhen Maniway Electronics Limited Bldg. 8, Sanlian Hebei Industrial Estate, Longhua Street, Bao’an Dist., Shenzhen, China Manufacturer: Shenzhen Maniway Electronics Limited Bldg. 8, Sanlian Hebei Industrial Estate, Longhua Street, Bao’an Dist., Shenzhen, China Description of Sample(s): Product: 2.1CH Sound Base Brand Name: MANIWAY Model Number: MW-1585 FCC ID: OG5MW-1585 Date Sample(s) Received: 2015-07-07 Date Tested: 2015-07-13 to 2015-07-17 Investigation Requested: Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2014 and ANSI C63.4: 2009 for FCC Certification. Conclusion(s): The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remark(s): For additional model(s) details, please page 3. LONG Yun Jian, Along Authorized Signatory ElectroMagnetic Compatibility Department For and on behalf of STC (Dongguan) Company Limited STC Test Report Date: 2015-08-01 Page 2 of 83 No.: DM120157 CONTENT: Cover Page 1 of 83 Content Page 2 of 83 1.0 General Details 1.1 Test Laboratory Page 3 of 83 1.2 Equipment Under Test [EUT] Page 3 of 83 Description of EUT operation 1.3 Date of Order Page 3 of 83 1.4 Submitted Sample Page 3 of 83 1.5 Test Duration Page 3 of 83 1.6 Country of Origin Page 3 of 83 1.7 RF Module Details Page 4 of 83 1.8 Antenna Details Page 4 of 83 2.0 Technical Details 2.1 Investigations Requested Page 5 of 83 2.2 Test Standards and Results Summary Page 5 of 83 2.3 Table for Test Modes Page 6 of 83 3.0 Test Results 3.1 Emission Page 7 – 78 of 83 Appendix A List of Measurement Equipment Page 79 of 83 Appendix B Photographs Page 80-83 of 83 STC Test Report Date: 2015-08-01 Page 3 of 83 No.: DM120157 1.0 General Details 1.1 Test Laboratory STC (Dongguan) Company Limited EMC Laboratory 68 Fumin Nan Road, Dalang, Dongguan, Guangdong, China Telephone: (86 769) 81119888 Fax: (86 769) 81116222 1.2 Equipment Under Test [EUT] Description of Sample(s) Product: 2.1CH Sound Base Manufacturer: Shenzhen Maniway Electronics Limited Bldg. 8, Sanlian Hebei Industrial Estate, Longhua Street, Bao’an Dist., Shenzhen, China Brand Name: MANIWAY Additional Brand Name: PYLE Model Number: MW-1585 Additional Model Number: PSBV630HDBT, PSBV620BT Rating: 100-240Va.c. 50/60Hz 1.2.1 Description of EUT Operation The Equipment Under Test (EUT) is a 2.1CH Sound Base. The r.f. signal was modulated by IC and type of modulation was frequency hopping spread spectrum Modulation. 1.3 Date of Order 2015-07-07 1.4 Submitted Sample(s): 1 Sample 1.5 Test Duration 2015-07-13 to 2015-07-17 1.6 Country of Origin China STC Test Report Date: 2015-08-01 Page 4 of 83 No.: DM120157 1.7 RF Module Details Module Model Number: F-6188 Module FCC ID: N/A Module Transmission Type: Bluetooth V2.1 Modulation: FHSS (GFSK / π/4-DQPSK / 8DPSK) Data Rates: 1MBps: GFSK 2 MBps: π/4-DQPSK 3 MBps: 8DPSK Frequency Range: 2400-2483.5MHz Carrier Frequencies: 2402MHz – 2480MHz Module Specification (specification provided by manufacturer) 1.8 Antenna Details Antenna Type: Meader line antenna Antenna Gain: 0dBi STC Test Report Date: 2015-08-01 Page 5 of 83 No.: DM120157 2.0 Technical Details 2.1 Investigations Requested Perform Electromagnetic Interference measurements in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2014 Regulations. FCC Pubic Notice DA 00-705 and ANSI C63.4: 2009 for FCC Certification. 2.2 Test Standards and Results Summary Tables EMISSION Results Summary Test Condition Test Requirement Test Method Class / Test Result Severity Pass Fail N/A Maximum Peak Conducted Output Power FCC 47CFR 15.247(b)(1) FCC Pubic Notice DA 00-705 N/A Radiated Spurious Emissions FCC 47CFR 15.209 ANSI C63.4:2009 N/A AC Mains Conducted Emissions FCC 47CFR 15.207 ANSI C63.4:2009 N/A Number of Hopping Frequency FCC 47CFR 15.247 (b)(1) FCC Pubic Notice DA 00-705 N/A 20dB Bandwidth FCC 47CFR 15.247(a)(2) FCC Pubic Notice DA 00-705 N/A Hopping Channel Separation FCC 47CFR 15.247(a)(1) FCC Pubic Notice DA 00-705 N/A Band-edge measurement (Radiated) FCC 47CFR 15.247(d) FCC Pubic Notice DA 00-705 N/A Pseudorandom Hopping Algorithm FCC 47CFR 15.247(a)(1) N/A N/A Time of Occupancy (Dwell Time) FCC 47CFR 15.247(a)(1)(iii) FCC Pubic Notice DA 00-705 N/A Antenna requirement FCC 47CFR 15.203 N/A N/A RF Exposure FCC 47CFR 15.247(i) N/A N/A Note: N/A – Not Applicable STC Test Report Date: 2015-08-01 Page 6 of 83 No.: DM120157 2.3 Table for Test Modes Preliminary tests were performed in different data rate to find the worst radiated emission. The data rate in the table below is the worst case rate with respect to the specific test item. Investigation has been done on all the possible configurations for searching the worst cases. The device was realized by test software. The following table is a list of the test modes shown in this test report. Test Items Mode Data Rate Maximum Peak Conducted Output Power GFSK / π/4-DQPSK / 8DPSK 1MBps / 2MBps / 3MBps Hopping Channel Separation GFSK / π/4-DQPSK / 8DPSK 1MBps / 2MBps / 3MBps Number of Hopping Frequency GFSK / π/4-DQPSK / 8DPSK 2MBps Time of Occupancy(Dwell Time) 8DPSK (DH1 / DH3 / DH5) 2MBps Radiated Spurious Emissions GFSK / π/4-DQPSK / 8DPSK 1MBps / 2MBps / 3MBps Band-edge compliance of Conducted Emission GFSK / π/4-DQPSK / 8DPSK 2MBps STC Test Report Date: 2015-08-01 Page 7 of 83 No.: DM120157 3.0 Test Results 3.1 Emission 3.1.1 Maximum Peak Conducted Output Power Test Requirement: FCC 47CFR 15.247(b)(1) Test Method: FCC Pubic Notice DA 00-705 Test Date: 2015-07-17 Mode of Operation: Tx mode Test Method: A temporary antenna connector was soldered to the RF output.The RF output of the EUT was connected to the spectrum analyzer. All the attenuation or cable loss will be added to the measure…

Text truncated - open the document above for the full version.

OG5MW-1585 PHOTOGRAPH OF THE PRODUCT MEASUREMENT OF RADIATED EMISSION TEST SET UP OG5MW-1585 PHOTOGRAPH OF THE PRODUCT MEASUREMENT OF CONDUCTED EMISSION TEST SET UP
