OG5MW1239Bluetooth Speaker

D e l u x e M u s i c S t a t i o n 2.1CH BLUETOOTH SPEAKER MODEL:MW-1239 PLEASE READ BEFORE OPERA TING EQUIPMENT Maniway - This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of non-insulated ’dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. - The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the appliance. This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does not require a safety connection to electrical earth. ’ Warning: To reduce the risk of electric shock, do not remove cover (or back) as there are no user- serviceable parts inside. Refer servicing to qualified personnel. CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions - All the safety and operating instructions should be read before this product is operated. 2. Keep these instructions -The safety and operating instructions should be retained for future reference. 3. Heed all warnings - All warnings on the appliance and in the operating instructions should be adhered to. 4. Follow all instructions - All operating and use instructions should be followed. 5. Do not use this apparatus near water - The appliance should not be used near water or moisture - for example, in a wet basement or near a swimming pool, and the like. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacture s instructions. ’ -1- 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding plug. A polarized plug has two blades with one wider than the other. A grounding plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at the plugs, convenience receptacles, and at the point where they exit from the apparatus. 11. Only use attachments/accessories specified by the manufacturer. 12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart or rack is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13. Unplug the apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 15. CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the perating instructions unless you are qualified to do so. 16. Do not install this equipment in a confined or building-in space such as a book case or similar unit, and remain a well ventilation conditions at open site. The ventilation should not be impeded by covering the ventilation openings with items such as newspaper, table-cloths, curtains etc. 17. WARNING˖Please refer the information on exterior bottom enclosure for electrical and safety information before installing or operating the apparatus. WARNING:SHOCK HAZARD. DO NOT OPEN AVIS:RISQUE DE CHOC ELECTRIOUE, NE PAS OUVRIR COMPLIANCE WITH FCC REGULATIONS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. -2- 18. WARNING˖To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus shall not be exposed to dripping or splashing and that objects filled with liquids, such as vases, shall not be placed on apparatus. 19. WARNING: The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such as sunshine, fire or the like. 20. WARNING: The mains plug is used as disconnect device, the d…

Text truncated - open the document above for the full version.

PAGE 3 OF 8 SHENZHEN MANIWAY ELECTRONICS LIMITED BLDG. 8, SANLIAN HEBEI INDUSTRIAL ESTATE, LONGHUA STREET, BAO'AN DIST., SHENZHEN,CHINA TEL：86-755-2813 1616 FAX：86-755-2815 2770 Date :2012-7-3 FCC ID: OG5MW1239 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Specifically, SHENZHEN MANIWAY ELECTRONICS LIMITED requests that the following materials be withheld from public inspection under 47CFR 0.459 because they are confidential trade secrets and technical data which would be guarded from competitors. (1) detailed circuit schematic of unit under test (2) parts list (3) block diagram (4) Circuit Description Therefore, in accordance with 47CFR Sections 0.457 and 0.459 we request that the above listed materials, copies of which are attached here, be withheld from public inspection. Sincerely, Signed & dated by the Company Representative.

SHENZHEN MANIWAY ELECTRONICS LIMITED BLDG. 8, SANLIAN HEBEI INDUSTRIAL ESTATE, LONGHUA STREET, BAO'AN DIST., SHENZHEN,CHINA TEL ：86-755-2813 1616 FAX：86-755-2815 2770 To: The Hong Kong Standards and Testing Centre Ltd. DECLARATION SHENZHEN MANIWAY ELECTRONICS LIMITED (Name of Manufacturer) Product Name: 2.1CH BLUETOOTH SPEAKER Model Number: MW-1238BT,MW-1239, BSS4803, SPK 1200, DOCK 3000Bi Brand Name: MANIWAY, AEG, NEOXEO We declare the equipment wireless (Bluetooth) modulation type is GFSK only. Signature with Company Chop : Printed Name : WAN MING DATE: Jul. 30, 2012

Updated on 2005/02/07 by Kally Chan SHENZHEN MANIWAY ELECTRONICS LIMITED To : The Hong Kong Standards and Testing Centre Ltd DECLARATION OF IDENTITY Hereby we: SHENZHEN MANIWAY ELECTRONICS LIMITED (Name of Applicant) Basic Model Number: MW-1239 Basic Brand Name: MANIWAY Basic Product Name: 2.1CH BLUETOOTH SPEAKER Basic Test Report Application Number: MH186654 Declare the Circuit, PCB Layout, Electrical Parts and Outlook of the following product(s) are identical to the basic model: New / Additional Model Number(s): 10890, BLUET7 New / Additional Brand Name(s): ALPHALINE, TECHNICAL PRO Except the following(s) : AESTHETIC/MODEL NO. & TRADE NAME Remarks: Signature with Company Chop : Printed Name : WAN MING DATE:2012-7-10

PAGE 4 OF 7 SHENZHEN MANIWAY ELECTRONICS LIMITED BLDG. 8, SANLIAN HEBEI INDUSTRIAL ESTATE, LONGHUA STREET, BAO'AN DIST., SHENZHEN,CHINA TEL：86-755-2813 1616 FAX：86-755-2815 2770 Date : 2012-6-12 PHOENIX TESTLAB GmbH Königswinkel 10 D-32825 Blomberg Dear Sirs, Re. : Letter of Appointment This is the letter of authorization to accept our appointment of The Hong Kong Standards and Testing Centre Ltd. Mr. KC Lee as agent for SHENZHEN MANIWAY ELECTRONICS LIMITED，BLDG. 8, SANLIAN HEBEI INDUSTRIAL ESTATE, LONGHUA STREET, BAO'AN DIST., SHENZHEN,CHINA to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with Certification of the following product of SHENZHEN MANIWAY ELECTRONICS LIMITED. Product name : 2.1CH BLUETOOTH SPEAKER Model : MW-1239 / 10890 / BLUET7 This authorization will expire one year from the date of this letter. _________________________ Signature with title By: Wan Ming Sales Manager

PHOTOGRAPH OF THE PRODUCT FRONT VIEW OF THE PRODUCT REAR VIEW OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT LEFT VIEW OF THE PRODUCT RIGHT VIEW OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT TOP VIEW OF THE PRODUCT BTTOM VIEW OF THE PRODUCT

PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT TOP VIEW PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT BOTTOM VIEW PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT

STC Test Report Date : 2012-07-23 Page 1 of 56 No. : MH186654 T h e H o n g K o n g S t a n d a r d s a n d T e s t i n g C e n t r e L t d . 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from the Hong Kong Standards and Testing Centre Ltd. For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of Homepage. Applicant (SHM004): SHENZHEN MANIWAY ELECTRONICS LIMITED BLDG.8, SANLIAN HEBEI INDUSTRIAL ESTATE, LONGHUA STREET, BAO’AN DIST., SHENZHEN, CHINA Manufacturer: SHENZHEN MANIWAY ELECTRONICS LIMITED BLDG.8, SANLIAN HEBEI INDUSTRIAL ESTATE, LONGHUA STREET, BAO’AN DIST., SHENZHEN, CHINA Description of Sample(s): Product: 2.1CH BLUETOOTH SPEAKER Brand Name: MANIWAY Model Number: MW-1239 FCC ID: OG5MW1239 Date Sample(s) Received: 2012-04-26 Date Tested: 2012-04-28 to 2012-05-22 Investigation Requested: Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2011 and ANSI C63.4:2009 for FCC Certification. Conclusion(s): The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remark(s): For additional models details, see page 3. For FM, Aux in function data refer to the test report with application number MH187119. Dr. LEE Kam Chuen Authorized Signatory ElectroMagnetic Compatibility Department For and on behalf of The Hong Kong Standards and Testing Centre Ltd. STC Test Report Date : 2012-07-23 Page 2 of 56 No. : MH186654 T h e H o n g K o n g S t a n d a r d s a n d T e s t i n g C e n t r e L t d . 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage CONTENT: Cover Page 1 of 56 Content Page 2 of 56 1.0 General Details 1.1 Test Laboratory Page 3 of 56 1.2 Equipment Under Test [EUT] Page 3 of 56 Description of EUT operation 1.3 Date of Order Page 3 of 56 1.4 Submitted Sample Page 3 of 56 1.5 Test Duration Page 3 of 56 1.6 Country of Origin Page 3 of 56 1.7 RF Module Details Page 4 of 56 1.8 Antenna Details Page 4 of 56 2.0 Technical Details 2.1 Investigations Requested Page 5 of 56 2.2 Test Standards and Results Summary Page 5 of 56 2.3 Table for Test Modes Page 6 of 56 3.0 Test Results 3.1 Emission Page 7-52 of 56 Appendix A List of Measurement Equipment Page 53 of 56 Appendix B Ancillary Equipment Page 53 of 56 Appendix C Photographs Page 54 - 56 of 56 STC Test Report Date : 2012-07-23 Page 3 of 56 No. : MH186654 T h e H o n g K o n g S t a n d a r d s a n d T e s t i n g C e n t r e L t d . 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 1.0 General Details 1.1 Test Laboratory The Hong Kong Standards and Testing Centre Ltd. EMC Laboratory 10 Dai Wang Street, Taipo Industrial Estate New Territories, Hong Kong 1.2 Equipment Under Test [EUT] Description of Sample(s) Product: 2.1CH BLUETOOTH SPEAKER Manufacturer: SHENZHEN MANIWAY ELECTRONICS LIMITED BLDG.8, SANLIAN HEBEI INDUSTRIAL ESTATE, LONGHUA STREET, BAO’AN DIST., SHENZHEN, CHINA Brand Name: MANIWAY Model Number: MW-1239 Additional Brand Name(s): ALPHALINE, TECHNICAL PRO Additional Model Number(s): 10890, BLUET7 Input Voltage: 120Va.c. 60Hz 1.2.1 Description of EUT Operation The Equipment Under Test (EUT) is a SHENZHEN MANIWAY ELECTRONICS LIMITED, 2.1CH BLUETOOTH SPEAKER. modulation by IC; the type is GFSK and the USB port only for communication with USB flash drive and charging. 1.3 Date of Order 2012-04-26 1.4 Submitted Sample(s): 1 Sample 1.5 Test Duration 2012-04-28 to 2012-05-22 1.6 Country of Origin China STC Test Report Date : 2012-07-23 Page 4 of 56 No. : MH186654 T h e H o n g K o n g S t a n d a r d s a n d T e s t i n g C e n t r e L t d . 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 1.7 RF Module Details Module Model Number: OVC3860 Module FCC ID: Module Transmission Type: Bluetooth V2.0 Modulation: FHSS (GFSK only) Data Rates: 1MBps: GFSK Frequency Range: 2400-2483.5MHz Carrier Frequencies: 2402MHz – 2480MHz Module information (provided by manufacturer) 1.8 Antenna Details Antenna Type: PCB Layout Inverted F Antenna Length: N/A Antenna Gain: 0dBi STC Test Report Date : 2012-07-23 Page 5 of 56 No. : MH186654 T h e H o n g K o n g S t a n d a r d s a n d T e s t i n g C e n t r e L t d . 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 2.0 Technical Details 2.1 Investigations Requested Perform Electromagnetic Interference measurements in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2011 Regulations and ANSI…

Text truncated - open the document above for the full version.

Test Set Up Measurement of Radiated Emission Test Set Up Measurement of Radiated Emission Test Set Up
