OG5MW1306PORTABLE BLUETOOTH SPEAKER

B B R R A A N N D D P P o o r r t t a a b b l l e e B B l l u u e e t t o o o o t t h h S S p p e e a a k k e e r r PLEASE READ BEFORE OPERATING THIS EQUIPMENT. Model No. :MW-1306 1 IMPORTANT SAFETY INSTRUCTIONS When used in the directed manner, this unit has been designed and manufactured to ensure your personal safety. However, improper use can result in potential electrical shock or fire hazards. Please read all safety and operating instructions carefully before installation and use, and keep these instructions handy for future reference. Take special note of all warnings listed in these instructions and on the unit. Water and Moisture The unit should not be used near water or wet space . Such as bathtub, washbowl, kitchen sink, laundry tub, swimming pool or basement. Ventilation The unit should be situated in the location or position which places won’t interfere its proper ventilation. For example, it should not be situated on a bed, sofa, rug or similar surface that may block the ventilation openings. Also, it should not be placed in a built-in installation, such as a bookcase or cabinet, which may impede the flow of air through the ventilation openings. Heat The unit should be situated away from heat sources such as radiators, heat registers, stoves or other appliances (including amplifiers) that produce heat. Power Charger The unit should be connected to a power charger(not included) only of the type described in the operating instructions or as marked on the appliance. 2 Cleaning The unit should be cleaned only as recommended. See the section « Care and Maintenance » of this manual for cleaning instructions. Object and Liquid Entry Care should be taken so that objects do not fall and liquids are not spilled into any openings or vents located on the product. Damage Requiring Service This unit should be serviced by qualified service personnel when: Objects have fallen into or liquid has been spilled into the enclosure. The unit has been exposed to rain. The unit has been dropped or the enclosure damaged. The unit exhibits a marked change in performance or does not operate normally. Periods of Nonuse If the unit is to be left unused for an intended period of time, such as a week or longer, the power cord should be unplugged from the unit to prevent damage or corrosion. Servicing The user should not attempt to service the unit beyond those methods described in the user’s operating instructions. Service methods not covered in the operating instructions should be referred to qualified service personnel. 3 CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. WARNING: ‹ Batteries shall not be exposed to excessive heat such as sunshine, fire or the like. ‹ To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus shall not be exposed to dripping or splashing and that objects filled with liquids, such as vases, shall not be placed on apparatus. CARE AND MAINTENANCE ‹ Do not subject the unit to excessive force, shock, dust or extreme temperature. ‹ Do not tamper the internal components of the unit. ‹ Clean the unit with a damp (never wet) cloth except metal contact or speaker grille, Solvent or detergent should never be used. ‹ Avoid leaving your unit in hot, humid or dusty places. ‹ Keep your unit away from heating appliances and sources of electrical noise such as fluorescent lamps or motors. ‹ Always keep your finger dry and clear before touching all the buttons. ‹ Do not dispose of batteries in fire, batteries may explode or leak. 4 LOCATION OF CONTROLS Top View 1. -Button Press this button to adjust volume level down. 2. + Button z Press this button to adjust volume level up 3. Button(for USB only) z Press this button once to return to the beginning of current track or previous track. 4. Button(for USB only) 5 z ·Press this button once to to advance to the next track . 5. Power On/Standby Button 6. Battery charging Indicator (Red color) z Rapid flashing =low battery ‹ While charging : z Flashing =charging z Steady Red= full charged Operating mode indicator (Blue/Green/Cyan) Blue color =Bluetooth mode Green=Aux-in mode Green=USB mode 7. Built-in Microphone 8. Button z While unit is in Bluetooth or TF card Playback mode, press once to play or pause the current track. z In Bluetooth mode, when receiving an incoming call on your cell phone, tap this button once to answer the phone, press this button again or press and hold this button to end the call or ignore the incoming call. 9. Mini USB Charging jack 10. Aux-In Jack 11. USB port BATTERY CHARGING INSTRUCTION This unit operates on a built-in Li-ion battery that can be recharged either using the USB port on your computer or from a 6 USB power adaptor (not included) with a rated output of DC 5V 500mA and up. Note: The mini USB CHARGING JACK located on this unit is only designed for charging the built-in Li-ion battery. CHARGING THE BATTERY FOR FIRST TIME 1.) Charge the built-in Li-ion battery a minimum of 4 hours prior to first use. Plug the unit into the USB port on your computer or into a USB power adaptor (not included) using the included USB cable. 2.) The battery charging indicator flashes while charging and it stops flashing when the unit is fully charged. Unplug the USB cable from the power source once the battery is fully charged. RECHARGING THE INTERNAL BATTERY After prolonged use, the internal battery will become weak and the operation may become intermittent. When the internal battery capacity is very low, the battery Indicator will rapidly flash in red to alert you to recharge the internal battery as soon as possible. Plug the speaker into a USB port on your computer by using the included USB cable or into a DC 5V, 500mA and up USB power adaptor (not included). Disconnect the USB cable from the speaker as soon as it is fully charged. Notes: 7 1. Charging time will vary if you are listening to music while charging the i…

Text truncated - open the document above for the full version.

775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SHENZHEN MANIWAY ELECTRONICS LIMITED SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 2013/8/8 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, SHENZHEN MANIWAY ELECTRONICS LIMITED hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product： PORTABLE BLUETOOTH SPEAKER Trade Name： N/A Model Name： MW-1306 Serial Model： N/A FCC ID： OG5MW1306 We affirm that between SIEMIC and SHENZHEN MANIWAY ELECTRONICS LIMITED _, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Signature Name: Ming Wan Title: Sales Manager Tel: +86-755-2813 1616

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 SHENZHEN MANIWAY ELECTRONICS LIMITED 2013-08-08 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: OG5MW1306 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Signature Client’s name / title : Ming Wan / Sales Manager Contact information / address : Bldg 8, Sanlian Hebei Industrial Estate, Longhua Street, Bao' an Dist. Shenzhen, China

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC ID LABELING AND LOCATION FCC ID Label PORTABLE BLUETOOTH SPEAKER Model NO.：MW-1306 Input Rating：DC 5V Battery: 3.7V/ 1600mAh FCC ID: OG5MW1306 SHENZHEN MANIWAY ELECTRONICS LIMITED Made in China This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Ant Photo 7 Photo 8 Photo 9 Photo 10 Photo 11 Photo 12

FCC ID : OG5MW1306 RF EXPOSURE EVALUATION METHOD SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID : OG5MW1306 Maximum measured transmitter power. frequency Maximum Peak Conducted Output Power Max Antenna Gain GHz dBm dBi 2.480 3.541 0 Remark: The best case gain of the antenna is 0dBi. 1.0dBi logarithmic terms convert to numeric result is nearly 1 3.541dbm=2.26mW [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 2.26/5*√2.480=0.71≤3.0 Threshold at which no SAR required is 10mw and ≤ 3.0 for 1-g SAR, Separation distance is 5mm. Conclusion: No SAR is required.

FCC RADIO TEST REPORT FCC ID: OG5MW1306 Product： PORTABLE BLUETOOTH SPEAKER Trade Name： N/A Model Name： MW-1306 Serial Model： N/A Report No.： NTEK-2013NT0627641F Prepared for SHENZHEN MANIWAY ELECTRONICS LIMITED BLDG. 8, SANLIAN HEBEI INDUSTRIAL ESTATE, LONGHUA STREET, BAO'AN DISTRICT., SHENZHEN,CHINA Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 76 Report No.:NTEK-2013NT0627641F TEST RESULT CERTIFICATION Applicant’s name................. : SHENZHEN MANIWAY ELECTRONICS LIMITED Address ................................. : BLDG. 8, SANLIAN HEBEI INDUSTRIAL ESTATE, LONGHUA STREET, BAO'AN DISTRICT., SHENZHEN,CHINA Manufacture's Name............ : SHENZHEN MANIWAY ELECTRONICS LIMITED Address ................................. : BLDG. 8, SANLIAN HEBEI INDUSTRIAL ESTATE, LONGHUA STREET, BAO'AN DISTRICT., SHENZHEN,CHINA Product description Product name ........................... : PORTABLE BLUETOOTH SPEAKER Model and/or type reference : MW-1306 Serial Model： N/A Standards............................. : FCC Part15.247 Test procedure .............................. ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test............................................: Date (s) of performance of tests .............: 27 Jun. 2013 ~30 Jul. 2013 Date of Issue...........................................: 30 Jul. 2013 Test Result...............................................: Pass Testing Engineer : (Apple Huang) Technical Manager : (Brown Lu) Authorized Signatory : (Bovey Yang) Page 3 of 76 Report No.:NTEK-2013NT0627641F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BELOW 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 23 4 . NUMBER OF HOPPING CHANNEL 35 4.1 APPLIED PROCEDURES / LIMIT 35 4.1.1 TEST PROCEDURE 35 4.1.2 DEVIATION FROM STANDARD 35 4.1.3 TEST SETUP 35 4.1.4 EUT OPERATION CONDITIONS 35 4.1.5 TEST RESULTS 36 5 . AVERAGE TIME OF OCCUPANCY 37 5.1 APPLIED PROCEDURES / LIMIT 37 Page 4 of 76 Report No.:NTEK-2013NT0627641F Table of Contents Page 5.1.1 TEST PROCEDURE 37 5.1.2 DEVIATION FROM STANDARD 37 5.1.3 TEST SETUP 38 5.1.4 EUT OPERATION CONDITIONS 38 5.1.5 TEST RESULTS 39 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 45 6.1 APPLIED PROCEDURES / LIMIT 45 6.1.1 TEST PROCEDURE 45 6.1.2 DEVIATION FROM STANDARD 45 6.1.3 TEST SETUP 45 6.1.4 EUT OPERATION CONDITIONS 45 6.1.5 TEST RESULTS 46 7 . BANDWIDTH TEST 52 7.1 APPLIED PROCEDURES / LIMIT 52 7.1.1 TEST PROCEDURE 52 7.1.2 DEVIATION FROM STANDARD 52 7.1.3 TEST SETUP 52 7.1.4 EUT OPERATION CONDITIONS 52 7.1.5 TEST RESULTS 53 8 . PEAK OUTPUT POWER TEST 59 8.1 APPLIED PROCEDURES / LIMIT 59 8.1.1 TEST PROCEDURE 59 8.1.2 DEVIATION FROM STANDARD 59 8.1.3 TEST SETUP 59 8.1.4 EUT OPERATION CONDITIONS 59 8.1.5 TEST RESULTS 60 9 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 66 9.1 DEVIATION FROM STANDARD 66 9.2 TEST SETUP 66 9.3 EUT OPERATION CONDITIONS 66 9.4 TEST RESULTS 67 10 . ANTENNA REQUIREMENT 74 10.1 STANDARD REQUIREMENT 74 10.2 EUT ANTENNA 74 11 . EUT TEST PHOTO 75 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 76 Report No.:NTEK-2013NT0627641F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 76 Report No.:NTEK-2013NT0627641F 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 76 Report No.:NTEK-2013NT0627641F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment PORTABLE BLUETOOTH SPEAKER Trade Name N/A Model Name MW-1306 Serial Model N/A M…

Text truncated - open the document above for the full version.

Page 75 of 76 Report No.:NTEK-2013NT0627641F 11. EUT TEST PHOTO Radiated Measurement Photos Page 76 of 76 Report No.:NTEK-2013NT0627641F CONDUCTED EMISSION Photos
