OGM2328TX-27Shelby RC
Enertec Enterprises Ltd.
Click to zoom
Application Details
- Equipment Class
- DXX - Part 15 Low Power Communication Device Transmitter
- Date of Grant
- Aug 14, 2012
- Application Purpose
- Original Equipment
- Date of Application
- Aug 14, 2012
- Equipment Note
- Shelby RC
- Frequency Range
- 27.14500000 - 27.14500000
- Company
- Enertec Enterprises Ltd.
- Country
- Hong Kong
