OGYFT5566-27Toy RC Savage

User Manual Trade name: Toy RC Savage Model number: FT2013C Use instruction 1) Turn the power switch of car-body to “ON” position; 2) When the user control the control stick, the LED light will be turn on; When the light is turning dimmer, the batteries are to be replaced; 3) Operate the handle of the controller, the car can move Forward and Backward clockwise. After play, turn the power switches of car-body to “OFF” position. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment such modifications could void the user authority to operate the equipment. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. MerchSource LLC Address: 15 Cushing Ave Irvine CA 92618。 。。 。 Phone, Fax: 949-900-0924, 949-707-2780

Block Diagram Filter RF power amplifier and Modulator Oscillator 27.145MHz Encoder Control key 27.145MHz Ant IC1, 128KHz

External Photos

Label Artwork and Location

Internal Photos

Technical description Description Function Component Antenna Transmit modulated RF signal ANT Filter Suppression of spurious emissions L1, C3, C9 RF power amplifier and modulation Modulate the carrier and amplify the modulated RF signal Q1 Oscillator Generate 27.145 MHz carrier TX1, Q2 Encoder IC Generate code signal to modulator IC1 Type of antenna: Integral antenna Type of modulation: Pulse modulation Antenna Gain: 0dBi The nominal conducted output power specified: -35dBm (+/- 3dB) The nominal radiated output power (e.r.p) specified: -37.15dBm (+/- 3dB)

1 Analysis Report The equipment under test (EUT) is a portable transmitter for a Toy RC Savage operating at 27.145 MHz which is controlled by a crystal. The EUT is powered by a 9.0V 6F22 size battery. For more detail information pls. refer to the user manual. Antenna Type: Integral antenna Antenna Gain: 0dBi The nominal conducted output power specified: -35dBm (+/- 3dB) The nominal radiated output power (e.r.p) specified: -37.15dBm (+/- 3dB) Modulation Type: Pulse modulation According to the KDB 447498: T he worst-case peak radiated emission for the EUT is 57.6dBμV/m at 3m in the frequency 27.145MHz The EIRP = [(FS*D) ^2 / 30] mW= -37.63dBm The ERP = EIRP – 2.15 = -39.78 dBm which is within the production variation. The maximum conducted output power specified is -32dB m = 0.0006mW The source- based time-averaging conducted output power = 0.0006 * Duty Cycle mW= 0.00036 mW < 0.1 mW The SAR Exclusion Threshold Level for 27.145MHz when the minimum test separation distance is < 50mm: = 474 * [1 + log(100/f(MHz)]/2 = 371.2 mW Since the source-based time-averaging conducted output power is well below the SAR low threshold level, so the EUT is considered to comply with SAR requirement without testing. Transmitter Duty Cycle Calculation The duration of time period = 19.10ms Effective period of the cycle = 500μs x 10 + 1.60ms x 4 = 11.40ms DC = 11.40ms / 19.10ms = 0.5969 or 59.69% FCC ID: OGYFT5566-27

1234 A B C D 4 321 D C B A ANT C9 220P C5 100P C4 47P R6 10K R3 200K VCC+9V LEFTB RIGHTB BACKWARDB FORWARDB R4 3.3K Q2 1815Y Q1 2222 COMPANY: MODEL NO: MODEL NAME: TITLE: DRAWING NO:REV: CODE: SIZE: SHEET: DEZIGN: CHECKED: APPROVED: L2 3.3UH R5 330R C8 104 L1 7.5UH TX1 27.145MHZ R2 0R C3 2P C11 22P R1 47K TX-27MHZ 1 2 3 4 5 6 78 9 10 11 12 13 14 IC1 HEADER 7X2 L3 2.2UH C10 104 LED C6 33P D1 3V3 D4 4148 BATTERY SW

• The test results reported in this test report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results referenced from this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. • For Terms And Conditions of the services, it can be provided upon request. • The evaluation data of the report will be kept for 3 years from the date of issuance. TRF No.: FCC 15C_TX_b Intertek Testing Services Shenzhen Ltd. Kejiyuan Branch 6F, D Block, Huahan Building, Langshan Road, Nanshan District, Shenzhen, P. R. China Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Huilai Fengtai Plastics & Ironware Ltd. Application For Certification FCC ID: OGYFT5566-27 Toy RC Savage Model: FT2013C Transmitter Report No.: 130116031SZN-001 We hereby certify that the sample of the above item is considered to comply with the requirements of FCC Part 15, Subpart C for Intentional Radiator, mention 47 CFR [ 10-1-12] Prepared and Checked by: Approved by: Sign on file Harry Wu Testing Engineer Billy Li Supervisor Date: 29 January 2013 INTERTEK TESTING SERVICES Report No.: 130116031SZN-001 FCC ID: OGYFT5566-27 TRF No.: FCC 15C_TX_b i GENERAL INFORMATION Huilai Fengtai Plastics & Ironware Ltd. MODEL: FT2013C FCC ID: OGYFT5566-27 Grantee: Huilai Fengtai Plastics & Ironware Ltd. Grantee Address: Huaqing Village Xianan Town Hui Lai county, Jieyang City, Guangdong Province, China Contact Person: Allen Cai Tel: 86-663-6793444 Manufacturer: Huilai Fengtai Plastics & Ironware Ltd. Manufacturer Address: Huaqing Village Xianan Town Hui Lai county, Jieyang City, Guangdong Province, China Model: FT2013C Type of EUT: Transmitter Description of EUT: Toy RC Savage Serial Number: N/A FCC ID : OGYFT5566-27 Date of Sample Submitted: 16 January 2013 Date of Test: 29 January 2013 Report No.: 130116031SZN-001 Report Date: 29 January 2013 Environmental Conidtions: Temperature: +10 to 40°C Humidity: 10 to 90% INTERTEK TESTING SERVICES Report No.: 130116031SZN-001 FCC ID: OGYFT5566-27 TRF No.: FCC 15C_TX_b ii SUMMARY OF TEST RESULT Huilai Fengtai Plastics & Ironware Ltd. MODEL: FT2013C FCC ID: OGYFT5566-27 TEST SPECIFICATION REFERENCE RESULTS Maximum Peak Output Power 15.247(b), (c) / RSS-210 A8.4 N/A Hopping Channel Carrier Frequencies Separation (for 2.4GHz Digital) 15.247(e) / RSS-210 A8.1 N/A 20dB Bandwidth of the Hopping Channel 15.247(a) / RSS-210 A8.1 N/A Number of Hopping Frequencies 15.247(e) / RSS-210 A8.1 N/A Average Time of Occupancy of Hopping Frequency 15.247(e) / RSS-210 A8.1 N/A Anteann Conducted Spurious Emissions 15.247(d) / RSS-210 A8.5 N/A Radiated Spurious Emissions 15.247(d) / RSS-210 A8.5 N/A RF Exposure Compliance 15.247(i) / RSS-Gen 5.5 N/A Transmitter Power Line Conducted Emissions 15.207 / RSS-Gen 7.2.2 N/A Transmitter Field Strength (for 27MHz) 15.227 / RSS-310 3.8 Pass Transmitter Field Strength (for 40MHz) 15.229 / RSS-210 A2.7 N/A Transmitter Field Strength, Bandwidth and Timing Requirement (for Remote Control) 15.231(a) / RSS-210 A1.1.1 N/A Transmitter Field Strength, Bandwidth and Timing Requirement (for 433MHz) 15.231(e) / RSS-210 A1.1.5 N/A Transmitter Field Strength and Bandwidth Requirement(for 88-108MHz) 15.239 / RSS-210 A2.8 N/A Transmitter Field Strength and Bandwidth Requirement(for 902- 928MHz or 2.4GHz) 15.249 / RSS-210 A2.9 N/A Transmitter Field Strength and Bandwidth Requirement (for 49MHz) 15.235 / RSS-310 3.9 N/A Receiver / Digital Device Radiated Eissions 15.109 / ICES-003 N/A Digital Device Conducted Emissions 15.107 / ICES-003 N/A Note: 1. The EUT uses an integral antenna which, in accordance to section 15.203, is considered sufficient to comply with the pervisions of this section. 2. Pursuant to FCC part 15 Section 15.215(c), the 20 dB bandwidth of the emission was contained within the frequency band designated (mentioned as above) which the EUT operated. The effects, if any, from frequency sweeping, frequency hopping, other modulation techniques and frequency stability over excepted variations in temperature and supply voltage were considered. INTERTEK TESTING SERVICES Report No.: 130116031SZN-001 FCC ID: OGYFT5566-27 TRF No.: FCC 15C_TX_b iii Table of Contents 1.0 General Description....................................................................................... 1 1.1 Product Description .......................................................................................... 1 1.2 Related Submittal(s) Grants.............................................................................. 1 1.3 Test Methodology............................................................................................. 1 1.4 Test Facility ...................................................................................................... 1 2.0 System Test Configuration ............................................................................ 2 2.1 Justification ...................................................................................................... 2 2.2 EUT Exercising Software.................................................................................. 2 2.3 Special Accessories .....................…

Text truncated - open the document above for the full version.

Radiated Photos
