OJBAB-ACCESS-SU01UNII System

AB-ACCESS U-NII TRANSCEIVER SUBSCRIBER TERMINAL FCC ID: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. MADE IN U.K. BY ADAPTIVE BROADBAND LTD, Cambridge, England. INPUT POWER: 48VDC, 850mA. OPERATING TEMP: -20 to +50 C

Continued\.... 12 August, 1999 Mr G Czumak Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Adaptive Broadband UNII Submission Our Ref: sd\ab01 Dear Mr Czumak This letter relates to the following applications: FCC ID: OJBAB-ACCESS-SU01 Form 731 Confirmation No.: EA93980 FCC ID: OJBAB-ACCESS-AP01 Form 731 Confirmation No.: EA94138 Confidentiality Request For reasons of retaining commercial intellectual property and the associated competitive advantage, Adaptive Broadband wish the following information to be held as confidential. • Schematics, including layout data and change notes. • Technical Report, including operation and block diagram. • Internal Photographs. • Test Report as this details our on-air modulation spectrum. • User Manuals as both AP and SU will be installed by the service provider’s installation teams and not the general public. Subscriber Unit Test Report – RFI\EMCB1\RP39361A The Test Report validating PSU and reference XTAL changes to -SU01. Adaptive Broadband have reverted back to the Artesyn PSU for reasons of cost and performance, in addition they are now using a 10MHz reference XTAL oscillator instead of the original 25MHz XTAL, again, for cost and availability reasons. As such they have retested radiated emissions to 1GHz and conducted emissions to 30MHz to assure compliance is maintained - the test report we will be attaching demonstrates this. 2 of 2 Test Report Passwords As a matter of policy under or UKAS accreditation RFI only issues password protected PDF reports. This ensures that information within the reports is not accidentally or deliberately changed by third parties. I can only apologies for the inconvenience, however we will try to ensure that graphs in future reports submitted to the FCC are in landscape format, which I hope will make things easier. Yours sincerely Steve Dillingham Operations Manager, Regulatory and Technical Support Group

Continued\.... 12 August, 1999 Mr G Czumak Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Adaptive Broadband UNII Submission Our Ref: sd\ab01 Dear Mr Czumak This letter relates to the following applications: FCC ID: OJBAB-ACCESS-SU01 Form 731 Confirmation No.: EA93980 FCC ID: OJBAB-ACCESS-AP01 Form 731 Confirmation No.: EA94138 Confidentiality Request For reasons of retaining commercial intellectual property and the associated competitive advantage, Adaptive Broadband wish the following information to be held as confidential. • Schematics, including layout data and change notes. • Technical Report, including operation and block diagram. • Internal Photographs. • Test Report as this details our on-air modulation spectrum. • User Manuals as both AP and SU will be installed by the service provider’s installation teams and not the general public. Subscriber Unit Test Report – RFI\EMCB1\RP39361A The Test Report validating PSU and reference XTAL changes to -SU01. Adaptive Broadband have reverted back to the Artesyn PSU for reasons of cost and performance, in addition they are now using a 10MHz reference XTAL oscillator instead of the original 25MHz XTAL, again, for cost and availability reasons. As such they have retested radiated emissions to 1GHz and conducted emissions to 30MHz to assure compliance is maintained - the test report we will be attaching demonstrates this. 2 of 2 Test Report Passwords As a matter of policy under or UKAS accreditation RFI only issues password protected PDF reports. This ensures that information within the reports is not accidentally or deliberately changed by third parties. I can only apologies for the inconvenience, however we will try to ensure that graphs in future reports submitted to the FCC are in landscape format, which I hope will make things easier. Yours sincerely Steve Dillingham Operations Manager, Regulatory and Technical Support Group

Page 1 of 17 AB-ACCESS Technical Report FCC ID Number xxxxxxxxxxxxxx Version 0.2 20 th April 1999 Adaptive Broadband Ltd. The Westbrook Center – 1 st Floor, Block C1, Milton Road, Cambridge, England, CB4 1YQ The information contained herein is the property of Adaptive Broadband, no part may be reproduced or used except as authorized by contract or other written permission. The copyright and the foregoing restriction on reproduction and use extend to all media in which the information may be embodied. Page 2 of 17 1.GENERAL EQUIPMENT INFORMATION. ..........................................................................................................3 1.1S UMMARY OF RF P ARAMETERS . ............................................................................................................................3 1.2C ONSTRUCTION D ETAILS . ......................................................................................................................................4 2.2.1033(B)(1) FULL NAME AND ADDRESS OF THE MANUFACTURER : ......................................................4 3.2.1033(B)(2) FCC IDENTIFIER. ...............................................................................................................................4 4.2.1033(B)(3) INSTALLATION MANUAL. ..............................................................................................................4 5.2.1033(B)(4) DESCRIPTION OF DEVICE OPERATION. ....................................................................................5 6.2.1033(B)(4) DESCRIPTION OF CIRCUIT FUNCTIONS. ...................................................................................7 6.1A NTENNA ...............................................................................................................................................................7 6.2R ADIO T RANSCEIVER M ODULE . .............................................................................................................................7 6.2.1Receiver.........................................................................................................................................................8 6.2.2Transmitter. ...................................................................................................................................................8 6.2.3Oscillators. ....................................................................................................................................................8 6.2.4PSU and Interface Circuitry..........................................................................................................................9 6.3S YSTEM M OTHERBOARD ......................................................................................................................................10 6.3.1Media Access Controller (MAC) and Support Circuitry. ............................................................................10 6.3.2MODEM. .....................................................................................................................................................10 6.4D ATA C ABLE ........................................................................................................................................................12 6.5W ALL -B OX . .........................................................................................................................................................12 6.5.1Power Source. .............................................................................................................................................12 6.5.2Wall-Box Indicators. ...................................................................................................................................12 6.5.3Wall-Box PCB. ............................................................................................................................................12 7.2.1033(B)(5) BLOCK DIAGRAM............................................................................................................................13 8.2.1033(B)(5) TRANSCEIVER SCHEMATIC DIAGRAMS. ................................................................................15 9.2.1033(B)(6) TEST REPORT. ..................................................................................................................................15 10.2.1033(B)(7) PRODUCT PHOTOGRAPHS. ......................................................................................................15 11.2.1033(B)(8) PERIPHERAL EQUIPMENT. ......................................................................................................15 12.2.1033(B)(9) TRANSITIONAL PROVISIONS. .................................................................................................15 13.2.1033(B)(10) AND (11) COMPLIANCE WITH 15.247(A)(1) OR 15.121(A). ................................................15 14.STATEMENT OF CERTIFICATION................................................................................................................16 15.LIST OF ATTACHMENTS. ................................................................................................................................17 Page 3 of 17 1.General Equipment Information. This device will be marketed and manufactured by Adaptive Broadband as the ‘AB-Access’ Subscriber Unit (SU). It will operate as an intentional radiator in accordance with the U-NII requirements of FCC part 15 subpart E. Consequently the device must be authorized by grant of Certification, and will be marked with the identification number xxxxxxxxxx. This number will be located on the rear sun-shield label of the transceiver housing, and be preceded by the term “FCC ID:” in compliance with §2.1045, 2.925 and 2.926. 1.1 Summary of RF Parameters. Transmitter TypeSingle IF, Single Frequency (Time Division Duplex), see below for channels. Frequency Range5.15GHz to 5.25GHz, 5.25GHz to 5.35GHz and 5.725GH…

Text truncated - open the document above for the full version.

Radio Frequency Investigation Ltd, Ewhurst Park, Ramsdell, Basingstoke, Hampshire, RG26 5RQ, ENGLAND. Tel: +44 (0) 1256 851193 Fax: +44 (0) 1256 851192 Registered in England, No. 211 7901. Registered Office: Ewhurst Park, Ramsdell, Basingstoke, Hampshire RG26 5RQ TESTING 0644 TEST REPORT FROM RADIO FREQUENCY INVESTIGATION LTD. Test Of: Adaptive Broadband Ltd AB-ACCESS Subscriber Unit (SU) To: FCC Part 15 Subpart E: 1998 (Unlicensed National Information Infrastructure Devices) Test Report Serial No: RFI/EMCB1/RP38658A This Test Report Is Issued Under The Authority Of Brian Watson Technical Director: Checked By: Tested By:Release Version No:PDF03 Issue Date: 22 April 1999Test Date: 29 March 1999 to 02 April 1999 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. Furthermore, the date of creation must match the issue date stated above. This report may be copied in full. RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP38658A EMC DepartmentPage 2 of 60 Issue Date: 22 April 1999 Test Of:Adaptive Broadband Ltd AB-ACCESS Subscriber Unit (SU) To:F.C.C. Part 15 Subpart E: 1998 This page has been left intentionally blank. RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP38658A EMC DepartmentPage 3 of 60 Issue Date: 22 April 1999 Test Of:Adaptive Broadband Ltd AB-ACCESS Subscriber Unit (SU) To:F.C.C. Part 15 Subpart E: 1998 Table of Contents 1. Client Information......................................................................................................4 2. Equipment Under Test (EUT).....................................................................................5 3. Test Specification, Methods And Procedures..........................................................9 4. Deviations From The Test Specification.................................................................10 5. Operation Of The EUT During Testing....................................................................11 6. Summary Of Test Results........................................................................................12 7. Measurements, Examinations And Derived Results..............................................13 8. Measurement Uncertainty........................................................................................32 Appendix 1. Test Equipment Used...............................................................................33 Appendix 2. Measurement Methods............................................................................35 Appendix 3. Test Configuration Drawings..................................................................42 Appendix 4. Graphical Test Results............................................................................47 Appendix 5. Photographs of EUT.................................................................................59 RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP38658A EMC DepartmentPage 4 of 60 Issue Date: 22 April 1999 Test Of:Adaptive Broadband Ltd AB-ACCESS Subscriber Unit (SU) To:F.C.C. Part 15 Subpart E: 1998 1. Client Information Company Name: Adaptive Broadband Ltd Address: First Floor, Block C1 The Westbrook Centre Milton Road Cambridge CB4 1YQ Tel: +44-1223-713713 Fax: +44-1223-713714 Contact Name: Mr P. Simpson Tel: +44-1223-713412 E-Mail: [email protected] RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP38658A EMC DepartmentPage 5 of 60 Issue Date: 22 April 1999 Test Of:Adaptive Broadband Ltd AB-ACCESS Subscriber Unit (SU) To:F.C.C. Part 15 Subpart E: 1998 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification Of Equipment Under Test (EUT) Brand Name: AB-ACCESS Model Name or Number: Subscriber Unit (SU) Unique Type Identification: UNII Pilot Serial Number: Pre-Production 001 Country of Manufacture: UK FCC ID Number: Awaiting Certification from the FCC Date of Receipt: 26 March 1999 Brand Name: AB-ACCESS Model Name or Number: SU and AP 'Wall-Box' Unique Type Identification: RJ45 Serial Number: Pre-Production 001 Country of Manufacture: UK FCC ID Number: Awaiting Certification from the FCC Date of Receipt: 26 March 1999 Brand Name: Sinpro Electronic co. Ltd Description DC Power Supply Unit Model Name or Number: SPU50-9 Unique Type Identification: None stated by client Serial Number: 120671 Country of Manufacture: Taiwan FCC ID Number: Awaiting Certification from the FCC Date of Receipt: 26 March 1999 RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP38658A EMC DepartmentPage 6 of 60 Issue Date: 22 April 1999 Test Of:Adaptive Broadband Ltd AB-ACCESS Subscriber Unit (SU) To:F.C.C. Part 15 Subpart E: 1998 2.2. Description Of EUT AB-ACCESS is targeted at providing high speed wireless internet access in the recently assigned FCC U-NII bands between 5GHz and 6GHz. AB-ACCESS adopts a cellular structure consisting of base stations (Access Point [AP]) servicing many users. It is a fixed access, point to multipoint infrastructure. The product is targeted at the US market only. Users are equipped with wall/roof-top/chimney mounted Subscriber Units (SU) that have a line sight link back to the AP. The SU is again fitted with a high gain, directional integral antenna having a 20 degree 3dB beamwidth. Power and data (bi-directional) are routed via braid and foiled screened, quad twisted pair, Cat-5 data cable from an internally mounted wall-box (similar in construction to a telephone outlet socket) up to the SU antenna unit. Power and data status is also routed via this cable. Power is provided to the wall-box via a standard FCC approved 48V DC supply. The wall-box provides Ethernet connectivity via the RJ45 socket to the users PC. 2.3. Modi…

Text truncated - open the document above for the full version.

Radio Frequency Investigation Ltd, Ewhurst Park, Ramsdell, Basingstoke, Hampshire, RG26 5RQ, ENGLAND. Tel: +44 (0) 1256 851193 Fax: +44 (0) 1256 851192 Registered in England, No. 211 7901. Registered Office: Ewhurst Park, Ramsdell, Basingstoke, Hampshire RG26 5RQ TESTING 0644 TEST REPORT FROM RADIO FREQUENCY INVESTIGATION LTD. Test Of: Adaptive Broadband Ltd AB-ACCESS Subscriber Unit (SU) To: FCC Part 15 Subpart E: 1998 (Unlicensed National Information Infrastructure Devices) Test Report Serial No: RFI/EMCB1/RP39361A This Test Report Is Issued Under The Authority Of Brian Watson Technical Director: Checked By: Tested By:Release Version No: PDF01 Issue Date: 2 August 1999Test Date: 27 July 1999 and 30 July 1999 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. Furthermore, the date of creation must match the issue date stated above. This report may be copied in full. RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP39361A EMC DepartmentPage 2 of 30 Issue Date: 2 August 1999 Test Of:Adaptive Broadband Ltd AB-ACCESS Subscriber Unit (SU) To:F.C.C. Part 15 Subpart E: 1998 This page has been left intentionally blank. RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP39361A EMC DepartmentPage 3 of 30 Issue Date: 2 August 1999 Test Of:Adaptive Broadband Ltd AB-ACCESS Subscriber Unit (SU) To:F.C.C. Part 15 Subpart E: 1998 Table of Contents 1. Client Information......................................................................................................4 2. Equipment Under Test (EUT).....................................................................................5 3. Test Specification, Methods And Procedures........................................................11 4. Deviations From The Test Specification.................................................................12 5. Operation Of The EUT During Testing....................................................................13 6. Summary Of Test Results........................................................................................14 7. Measurements, Examinations And Derived Results..............................................15 8. Measurement Uncertainty........................................................................................18 Appendix 1. Test Equipment Used...............................................................................19 Appendix 2. Measurement Methods............................................................................20 Appendix 3. Test Configuration Drawings..................................................................23 Appendix 4. Graphical Test Results............................................................................27 Appendix 5. Photographs of EUT.................................................................................29 RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP39361A EMC DepartmentPage 4 of 30 Issue Date: 2 August 1999 Test Of:Adaptive Broadband Ltd AB-ACCESS Subscriber Unit (SU) To:F.C.C. Part 15 Subpart E: 1998 1. Client Information Company Name: Adaptive Broadband Ltd Address: First Floor, Block C1 The Westbrook Centre Milton Road Cambridge CB4 1YQ Tel: +44-1223-713713 Fax: +44-1223-713714 Contact Name: Mr P. Simpson Tel: +44-1223-713412 E-Mail: [email protected] RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP39361A EMC DepartmentPage 5 of 30 Issue Date: 2 August 1999 Test Of:Adaptive Broadband Ltd AB-ACCESS Subscriber Unit (SU) To:F.C.C. Part 15 Subpart E: 1998 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification Of Equipment Under Test (EUT) Brand Name: AB-ACCESS U-NII Transceiver Model Name or Number: Subscriber Unit (SU) Unique Type Identification: Helium Antenna Unit and Ethernet Wall-Box Serial Number: S NO HK 0085 Country of Manufacture: UK FCC ID Number: OJBAB-ACCESS-SU01 Date of Receipt: 21 July 1999 RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP39361A EMC DepartmentPage 6 of 30 Issue Date: 2 August 1999 Test Of:Adaptive Broadband Ltd AB-ACCESS Subscriber Unit (SU) To:F.C.C. Part 15 Subpart E: 1998 2.2. Description Of EUT AB-ACCESS is targeted at providing high speed wireless internet access in the recently assigned FCC U-NII bands between 5GHz and 6GHz. AB-ACCESS adopts a cellular structure consisting of base stations servicing many users – it is a fixed access, point- multipoint infrastructure. The product is targeted at the US market only. An Access Point (AP) is routed via a ‘wall-box’ to the service provider’s trunked infrastructure. The AP has an integral antenna with 60 degree 3dB beamwidth to illuminate a desired coverage area, AP units can be installed around the periphery of a tall building or on a tower for optimum coverage. Power and data (bi-directional) are routed via braid and foil screened, quad twisted pair, Cat-5 data cable from an internally mounted wall-box (similar in construction to a standard telephone outlet socket) up to the AP antenna unit, power and data status is also routed via this cable. Power is provided to the wall-box via a standard FCC approved 48V DC supply. The wall-box provides Ethernet or ATM connectivity via the RJ45 socket to the service provider’s network. Users are equipped with wall/roof-top/chimney mounted Subscriber Units (SU) that have a line of sight link back to the AP. The SU is again fitted with a directional integral antenna having a narrower 20 degree 3dB beamwidth. Power and data (bi-directional) are routed via braid and foil screened, quad twisted pair, Cat-5 data cable from an internally mounted wall-box (similar in construction to a standard telephone outlet so…

Text truncated - open the document above for the full version.

Radio Frequency Investigation Ltd, Ewhurst Park, Ramsdell, Basingstoke, Hampshire, RG26 5RQ, ENGLAND. Tel: +44 (0) 1256 851193 Fax: +44 (0) 1256 851192 Registered in England, No. 211 7901. Registered Office: Ewhurst Park, Ramsdell, Basingstoke, Hampshire RG26 5RQ TESTING 0644 TEST REPORT FROM RADIO FREQUENCY INVESTIGATION LTD. Test Of: Adaptive Broadband Ltd AB-ACCESS Subscriber Unit (SU) To: FCC Part 15 Subpart E: 1998 (Unlicensed National Information Infrastructure Devices) Test Report Serial No: RFI/EMCB1/RP39361A This Test Report Is Issued Under The Authority Of Brian Watson Technical Director: Checked By: Tested By:Release Version No: PDF01 Issue Date: 2 August 1999Test Date: 27 July 1999 and 30 July 1999 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. Furthermore, the date of creation must match the issue date stated above. This report may be copied in full. RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP39361A EMC DepartmentPage 2 of 30 Issue Date: 2 August 1999 Test Of:Adaptive Broadband Ltd AB-ACCESS Subscriber Unit (SU) To:F.C.C. Part 15 Subpart E: 1998 This page has been left intentionally blank. RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP39361A EMC DepartmentPage 3 of 30 Issue Date: 2 August 1999 Test Of:Adaptive Broadband Ltd AB-ACCESS Subscriber Unit (SU) To:F.C.C. Part 15 Subpart E: 1998 Table of Contents 1. Client Information......................................................................................................4 2. Equipment Under Test (EUT).....................................................................................5 3. Test Specification, Methods And Procedures........................................................11 4. Deviations From The Test Specification.................................................................12 5. Operation Of The EUT During Testing....................................................................13 6. Summary Of Test Results........................................................................................14 7. Measurements, Examinations And Derived Results..............................................15 8. Measurement Uncertainty........................................................................................18 Appendix 1. Test Equipment Used...............................................................................19 Appendix 2. Measurement Methods............................................................................20 Appendix 3. Test Configuration Drawings..................................................................23 Appendix 4. Graphical Test Results............................................................................27 Appendix 5. Photographs of EUT.................................................................................29 RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP39361A EMC DepartmentPage 4 of 30 Issue Date: 2 August 1999 Test Of:Adaptive Broadband Ltd AB-ACCESS Subscriber Unit (SU) To:F.C.C. Part 15 Subpart E: 1998 1. Client Information Company Name: Adaptive Broadband Ltd Address: First Floor, Block C1 The Westbrook Centre Milton Road Cambridge CB4 1YQ Tel: +44-1223-713713 Fax: +44-1223-713714 Contact Name: Mr P. Simpson Tel: +44-1223-713412 E-Mail: [email protected] RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP39361A EMC DepartmentPage 5 of 30 Issue Date: 2 August 1999 Test Of:Adaptive Broadband Ltd AB-ACCESS Subscriber Unit (SU) To:F.C.C. Part 15 Subpart E: 1998 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification Of Equipment Under Test (EUT) Brand Name: AB-ACCESS U-NII Transceiver Model Name or Number: Subscriber Unit (SU) Unique Type Identification: Helium Antenna Unit and Ethernet Wall-Box Serial Number: S NO HK 0085 Country of Manufacture: UK FCC ID Number: OJBAB-ACCESS-SU01 Date of Receipt: 21 July 1999 RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP39361A EMC DepartmentPage 6 of 30 Issue Date: 2 August 1999 Test Of:Adaptive Broadband Ltd AB-ACCESS Subscriber Unit (SU) To:F.C.C. Part 15 Subpart E: 1998 2.2. Description Of EUT AB-ACCESS is targeted at providing high speed wireless internet access in the recently assigned FCC U-NII bands between 5GHz and 6GHz. AB-ACCESS adopts a cellular structure consisting of base stations servicing many users – it is a fixed access, point- multipoint infrastructure. The product is targeted at the US market only. An Access Point (AP) is routed via a ‘wall-box’ to the service provider’s trunked infrastructure. The AP has an integral antenna with 60 degree 3dB beamwidth to illuminate a desired coverage area, AP units can be installed around the periphery of a tall building or on a tower for optimum coverage. Power and data (bi-directional) are routed via braid and foil screened, quad twisted pair, Cat-5 data cable from an internally mounted wall-box (similar in construction to a standard telephone outlet socket) up to the AP antenna unit, power and data status is also routed via this cable. Power is provided to the wall-box via a standard FCC approved 48V DC supply. The wall-box provides Ethernet or ATM connectivity via the RJ45 socket to the service provider’s network. Users are equipped with wall/roof-top/chimney mounted Subscriber Units (SU) that have a line of sight link back to the AP. The SU is again fitted with a directional integral antenna having a narrower 20 degree 3dB beamwidth. Power and data (bi-directional) are routed via braid and foil screened, quad twisted pair, Cat-5 data cable from an internally mounted wall-box (similar in construction to a standard telephone outlet so…

Text truncated - open the document above for the full version.
