OL340704070 DECT Base Station

    Subset of Installation Manual Release 6.1 - October 2007 Legal notice: Alcatel, Lucent, Alcatel-Lucent and the Alcatel-Lucent logo are trademarks of Alcatel-Lucent. All other trademarks are the property of their respective owners. The information presented is subject to change without notice. Alcatel-Lucent assumes no responsibility for inaccuracies contained herein. Copyright © 2007 Alcatel-Lucent. All rights reserved. The CE mark indicates that this product conforms to the following Council Directives: - 89/336/CEE (concerning electro-magnetic compatibility) - 73/23/CEE (concerning electrical safety) - 1999/5/CE (R&TTE) Chapter 1 Installation and Cabling  Intelligent Base Stations......................................................................1.1  Detailed description....................................................................................1.1  Safety rules..................................................................................................1.8                            0-1             0-2                  1.1Intelligent Base Stations 1.1.1Detailed description This notice describes the rules to follow for an installation comprising three or four DECT bases. For a larger installation, a preliminary study must be carried out using coverage tools. The bases are then installed according to the results of this study. 1.1.1.1CONNECTION The Alcatel-Lucent 4070 IO is designed for internal installation in the building, while the Alcatel-Lucent 4070 EO is designed for external installation. The 4070 EO IBS comes in a plastic box and is protected against temperature variation. The 2 antennae are outside the box so that they both have the same signal reception. Intelligent Base Stations (IBS) are fitted with a red LED that gives information about the state of the Base Station: -Fixed LED: 1. Software downloading 2. Initialization phase, waiting for synchronization 3. Software problem, IBS stopped. -Fast blink: There is a problem with the line. -Short ON, long OFF: Running on 1 UA link. -500ms OFF, 500ms ON: Running on 2 UA link. The IBSs can run and be powered remotely by the UA access (this is the most common configuration). But they can also be powered by a power device. This is used when there are a lot of IBSs and the system power cannot support all the connected IBSs. A base station may be connected to 1 or 2 UA links (UAI boards) and allows 3 or 6 simultaneous connections with DECT/GAP terminals. The need for three or six communication channels depends on the number of cordless stations and on the DECT traffic to be managed. In the event of a two-cable connection: -use two interfaces neighboring a UAI board -use the even-numbered interface for the master link and the other for the slave link. Both cables should have the same length. The first interface of the system’s UAI16 board should not be used since the operator station uses those points.   1                       1-1 1.1.1.2NUMBER OF USEFUL BASE STATIONS Any radio signal is subject to various propagation phenomena: attenuation, reflection and diffraction. These phenomena are related to the environment of the Alcatel-Lucent 4070 IO/EO, and affect the radio performance of the system. The effects can improve or deteriorate wave propagation. Take as an example a building with a metallic structure. A radio wave will tend to be subject to many reflections which will consequently degrade system performance. Moreover, the range of an Alcatel-Lucent 4070 IO/EO is very dependent on the amount of attenuation subjected to the radio wave across various zones. The following table gives the values of global coverage zone (cell) for an Alcatel-Lucent 4070 IO/EO under normal environmental and topological conditions: InteriorExterior Coverage area~ 50 m~ 400 m Area:~ 7,000 m 2 ~ 50 000 m 2 1.1.1.3NUMBER OF USERS PER BASE STATION Type of Base Station connection.Number of DECT users 3 channels4 6 channels12 1.1.1.4LOCATING DECT BASE STATIONS As a result of the environment and the infrastructure, certain recommendations must be taken into account for locating Alcatel-Lucent 4070 IO/EO: Chapter 1      ! " 1-2                  Recommendations for locationPossible solutions INTERIOR COVERAGE As far as possible from wallsSuspend Alcatel-Lucent 4070 IO/EO in a clear zone Do not fix directly to a metallic structureMove Alcatel-Lucent 4070 IO/EO into another zone Do not place in false ceilings or in telecom rooms Place Alcatel-Lucent 4070 IO/EO in useful zones (corridors) As far as possible from industrial machines or electrical cabinets Place 4070 IO/EO in useful zones EXTERNAL COVERAGE Place the base stations in an open space (as far as possible from buildings) Attached to pylons for example Place the base stations higher than low obstacles (trees, cars etc.) At the top of buildings on pylons for example 1.1.1.5INTERACTIONS Interactions with other features IBS DECT and IBS PWT (Personal Wireless Telecommunications) cannot run together on the same system. The first IBS plugged determines the system type (DECT or PWT). To switch from one system to another, unplug all IBSs, make a warm restart and plug in the IBSs. Interactions with other applications IBSs are fully compatible with other wireless technologies such as VOWLAN. Interactions with other software releases OmniPCX Office release 5.1 requires 4 kinds of DECT initialization: Europe, Latin America, United-States and China. See also:§IBSCONFIGURATION. 1.1.1.6LIMITS Number of IBSs: 20 IBSs per cabinet is recommended, however, the number of IBSs is only restricted by the available power. DECT link limit: 3 links on an IBS with one UA access, 6 links on an IBS with 2 UA accesses. DECT handset li…

Text truncated - open the document above for the full version.

TRL 51F047 iss02B LETTER OF AGENCY Date April 13 th 2007 TRL Compliance Ltd Long Green Forthampton Gloucester GL19 4QH UK To Whom It May Concern: We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application, is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Thank you for your attention to these matters. Yours faithfully Alcatel Business Systems Signature Full Name Rainier BALTZ

TRL 51F050 iss02B REQUEST FOR CONFIDENTIALITY I N ACCORDANCE WITH FCC RULE 0.459 Date April 13 th 2007 TRL Compliance Ltd Long Green Forthampton Gloucester GL19 4QH UK RE: Certification Application FCC ID: OL34070 To Whom It May Concern: Please be advised that the following information is to be held confidential on behalf of Alcatel-Lucent. • Schematics and parts list • Board layout information The application contains technical information which Alcatel-Lucent deems to be trade secrets and propriety. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Yours faithfully Alcatel Business Systems Signature Full Name Rainier BALTZ

4070 IO Top Overview 4070 IO Top Removed Overview 4070 EO Top Overview 4070 IO Top Open Overview 4070 IO Ex Top Overview 4070 IO Ex Top Removed Overview 4070 IO Ex Top Removed Close up 1 4070 IO Ex Top Removed Close up 2

Labels 4070 IO & EO All rights reserved. Passing on and copying of this document, use and communication of its conten ts not permitted without written authorization from Alcatel-Lucent. 4070 IO IC: 1737D-4070 FCC ID: OL34070 Complies with Part 68, FCC Rules This device complies with Part 15 of the FCC Rules and with RSS-213 of Industry of Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interferences, and (2) this device must accept any interference received, including interference that may cause undesired operation. Listed class 2 power supply is mandatory. Une alimentation listée classe 2 est nécessaire. Certificate Number: 202423 3BN66109AAJE 01 2500/000126 Made in France (E.E.C.) Labels 4070 IO & EO All rights reserved. Passing on and copying of this document, use and communication of its conten ts not permitted without written authorization from Alcatel-Lucent. 4070 EO IC: 1737D-4070 FCC ID: OL34070 Complies with Part 68, FCC Rules This device complies with Part 15 of the FCC Rules and with RSS-213 of Industry of Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interferences, and (2) this device must accept any interference received, including interference that may cause undesired operation. Listed class 2 power supply is mandatory. Une alimentation listée classe 2 est nécessaire. Certificate Number: 202423 3BN66109ABJE 01 2500/000126 Made in France (E.E.C.)

FIXED PART MAIN PCB TRACK SIDE FIXED PART MAIN PCB COMPONENT SIDE FIXED PART RF PCB TRACK SIDE ANTENNAS MOUNTED FIXED PART RF PCB TRACK SIDE ANTENNAS UNMOUNTED FIXED PART RF PCB COMPONENT SIDE ANTENNAS MOUNTED FIXED PART RF PCB COMPONENT SIDE ANTENNAS UNMOUNTED FIXED PART RF PCB COMPONENT SIDE RF CANS REMOVED FIXED PART RF PCB COMPONENT SIDE RF CANS REMOVED CLOSE UP OF RF SECTION OVER VIEW OF MAIN PCB AND RF PCB ASSEMBLED

4070 IO On Open Area Test Site 4070 IO On Open Area Test Site Close Up 4070 EO On Open Area Test Site 4070 EO ON Open Area Test Site Close Up 4070 IO Ex On Open Area Test Site 4070 IO Ex On Open Area Test Site Close Up 4070 IO Powerline Conduction
