OL6SK-5000Single-Mode CDMA Cellular Phone

SK Teletech Company Limited

Click to zoom

Application Details

Equipment Class: TNE - Licensed Non-Broadcast Transmitter Held to Ear
Date of Grant: Aug 04, 2002
Application Purpose: Original Equipment
Date of Application: Jun 05, 2002
Equipment Note: Single-Mode CDMA Cellular Phone
Frequency Range: 824.70000000 - 848.31000000
Company: SK Teletech Company Limited
Country: South Korea

Documents & Files

Select a file to view

Test Setup Photos

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Advanced features of IM-5000 Mobile camera: SKY with camera attached! The phone, which is equipped with a mobile camera rotating in a 360- degree arc, enables you to take a picture anytime anywhere and to save the image in order to decorate the Logo or make a video phonebook. Large 65000 Color LCD: Large 2” LCD with 65000 color display! With a wider 2” LCD and splendor 65000 color, you can enjoy a satisfactory and vivid LCD screen. 40 chord melody: More vivid melody! The phone provides diverse and more vivid music in various fields with 40- chord melody. New menu structure: More friendly SKY menu structure! Totally enhanced menu structure! With a menu structure similar to Windows Systems such as popup menu and icon display of menu, you can easily find out a required function enabling the full utilization of SKY’ diverse functions. CDMA2000 1x superhigh: SKY is a mobile phone faster than a modem. speed data communication The phone implements the CDMA 2000 1x superhigh speed communication function of 153.6Kbps with MSM5000 equipped, enabling you to navigate the wireless Internet in super high speed or to swiftly download the multimedia data. Other features: Still smart and various functions! IrDA communication, auto answering/recorder, 99 memory location numbers, stopwatch, electronic pocketbook (Calendar/scheduler, alarm, and calculator), various animations, my melody, etiquette, music bell, earphone mic, etc. IM-5000 User’s Manual Table of Contents The contents of this user’s manual are subject to change without prior notice for enhancement of product performance. Precautions for using the mobile phone........................................................................................8 Package Contents..........................................................................................................................9 Part Names and Functions...........................................................................................................10 Display Indicators........................................................................................................................12 How to activate and select menu................................................................................................13 How to use the linked menu........................................................................................................13 Using the battery.........................................................................................................................13 Cautions.................................................................................................................................13 Inserting the battery.............................................................................................................14 Battery life............................................................................................................................14 Low battery alarm.................................................................................................................15 Charging the battery.............................................................................................................16 Basic Operation Switching the phone on ...............................................................................................................17 Switching the phone off...............................................................................................................17 Making a call................................................................................................................................17 Redialing calls..............................................................................................................................17 Last number redialing...........................................................................................................17 Search call history and redial...............................................................................................18 Answering calls............................................................................................................................18 Speed dial.....................................................................................................................................19 One digit speed dial (Address 1~9) .....................................................................................19 Two digit speed dial (Address 10~99) ................................................................................19 Adjusting the volume...................................................................................................................19 Adjusting the earpiece volume.............................................................................................19 Adjusting the ringer volume .................................................................................................20 Adjusting the keypad volume ...............................................................................................20 Etiquette mode.............................................................................................................................20 Enabling Etiquette mode at standby mode...........................................................................20 Enabling Etiquette mode during the call ..............................................................................20 Hot menu......................................................................................................................................21 Check received messages....................................................................................................21 Send my number ...................................................................................................................21 Mute ...............................................................................................................…

Text truncated - open the document above for the full version.

Cover Letter(s)

April 15, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: SK Teletech Co., Ltd. FCC ID: OL6SK-5000 Part 22 Certification Gentlemen: Submitted herewith, on behalf of SK Teletech Co., Ltd. is an application for Part 22 Certification of the following Single-Mode Cellular CDMA Phone: FCC ID: OL6SK-5000 MODEL No.: SK-5000 EUT TYPE: Non-Broadcast Transmitter Held to the Ear (TNE) Tx Freq. Range: 824.70 — 848.31 Rx Freq. Range: 869.70 — 893.31 Max. RF Output Power: 0.396W ERP CDMA (25.973 dBm) Attached is the applicant’s attestation statement, measurement report (test data and test plots), RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagram (confidential), schematics & circuit description (confidential), operational description (confidential), parts list & tune-up procedure (confidential) and user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: SK Teletech Co., Ltd.
