OL6SK-5400Single-Mode Cellular Phone (CDMA)

SK Teletech Company Limited

Click to zoom

Application Details

Equipment Class: TNE - Licensed Non-Broadcast Transmitter Held to Ear
Date of Grant: May 22, 2003
Application Purpose: Original Equipment
Date of Application: May 22, 2003
Equipment Note: Single-Mode Cellular Phone (CDMA)
Frequency Range: 824.70000000 - 848.31000000
Company: SK Teletech Company Limited
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

SK-5400 User Manual 1 Advanced features of SK-5400 New style! Slide-up! Slide-up ! The phone implements a new style different from the existing flip and folder styles in a way to push up the top slide with one hand. You can enjoy a fancy attractiveness of slide-up style far from the common flip and folder types. 40 chord melody More vivid melody! The phone provides diverse and more vivid music in various fields with 40-chord melody. CDMA2000 1x superhigh speed data communication SK-5400 is a mobile phone faster than a modem. The phone implements the CDMA 2000 1x superhigh speed communication function of 153.6Kbps with MSM5400 equipped, enabling you to navigate the wireless Internet in super high speed or to swiftly download the multimedia data. Wireless internet You can enjoy a hundredfold realistic wireless Internet at anytime and anywhere by downloading various multimedia contents to SK-5400. Other features Still smart and various functions! IrDA communication, auto answering/recorder, 99 memory location numbers, stopwatch, electronic pocketbook (Calendar/scheduler, alarm, morning call, and calculator), various animations, my melody, etiquette, music bell, earphone mic, etc. 2 SK-5400 User’s Manual Table of Contents The contents of this user’s manual are subject to change without prior notice for enhancement of product performance. Precautions for using the mobile phone...................................................6 Package Contents.............................................................8 Part Names and Functions.....................................................................9 Display Indicators..............................................................................11 Multi-function keys.............................................................................12 Basic key usage.............................................................................................................13 Using the battery...............................................................................14 Basic operation.....................................................................................17 Switching the phone on/off.........................................................................................17 Making a call.....................................................................................17 Redialing calls...................................................................................17 Answering calls..................................................................................18 Speed dial.........................................................................................19 Functions available during a call................................................................................19 Search call history(list)................................................................................................20 Etiquette mode..................................................................................21 My Information..................................................................................22 Timers..............................................................................................22 PIM Phone Book..............................................................24 Add phonebook..................................................................................24 Speed Search.................................................................................................................26 Search by name................................................................................. 27 Search by number..............................................................................27 Edit group.........................................................................................28 Edit Speed dial..................................................................................29 Electronic dialing using Pause..............................................................30 Message Function............................................................32 Text Message....................................................................................32 Voice Message...................................................................................32 Create New Message..........................................................................33 Outbox.............................................................................................35 Delete All Messages............................................................................36 SMS Alert.........................................................................................36 www..............................................................................37 3 Sound Option.......................................................................................38 Select Ringer/Vibrate..................................................................................................38 Set Group Ring.............................................................................................................38 Setting Mambo Tone..................................................................................................38 Setting Effect Tone.....................................................................................................39 Manage My Ringer.......................................................................................................39 Set Volume....................................................................................................................39 Setting No Answer Alarm...........................................................................................40 Display Option......................................................................................41 Set Logo..........................................................................................................................41 Set Picture.........................…

Text truncated - open the document above for the full version.

Attestation Statements

21th FL, Startower 737, Yeoksam-dong, Kangnam-ku Seoul, 135-984, Korea Phone : +82-2-2112-3114 Fax : +82-2-2112-3399 April 30, 2003 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 U.S.A To whom it concern, We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1998, 21U.S.C.853(a). Sincerely, Felix JIN Manager / R&D Planning Team SK Teletech Co., Ltd. 21th FL, Startower 737, Yeoksam-dong, Kangnam-ku Seoul, 135-984, Korea Phone : +82-2-2112-3114 Fax : +82-2-2112-3399 AFFIDAVIT FOR ESN PROTECTION OF CELLULAR MOBILE TELEPHONES We hereby certify that the handheld portable cellular phone(FCC ID : OL6SK-5400) is so designed that it complies with all the requirements for ESN protection specified in Section 22.919 of the FCC Rules. a) The transmitter in service has a unique ESN. b) The ESN host component is permanently attached to a main circuit board of the mobile transmitter and the integrity of the unit operating software can not be altered. The ESN is plated from fraudulent contact and tampering. The ESN is encoded using multiplication by a polynomial and ESN data programmed in the memory with other information. c) The ESN is factory-set and can not be altered, transferred, removed or otherwise able to be manipulated. Cellular mobile equipment is specifically designed suchthat any attempt to remove, tamper with, or change the ESN chip, its logic system, or firmware original programmed by the manufacturer will render the transmitter inoperative. Sincerely, Felix JIN Manager / R&D Planning Team SKTeletechCo., Ltd.

Attestation Statements

Cover Letter(s)

May 1, 2003 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: SK TELETECH CO., LTD. FCC ID: OL6SK-5400 Part 22 Certification Gentlemen: Submitted herewith, on behalf of SK TELETECH CO., LTD., is an application for Part 22 Certification of the Single-Mode Cellular Phone (CDMA). Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report test data and plots, RF Exposure measurement report and data, FCC ID label and location, test setup photographs, internal and external photographs, block diagram (confidential), circuit diagrams & description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: SK TELETECH CO., LTD.

External Photos

ID Label/Location Info

© 2003 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

Internal Photos

SK TELETECH FCC ID: OL6SK-5400 EUT Photographs © 2003 PCTEST Lab. Single Mode Cellular Phone (CDMA) Model: SK-5400 SK TELETECH FCC ID: OL6SK-5400 EUT Photographs © 2003 PCTEST Lab. Single Mode Cellular Phone (CDMA) Model: SK-5400 SK TELETECH FCC ID: OL6SK-5400 EUT Photographs © 2003 PCTEST Lab. Single Mode Cellular Phone (CDMA) Model: SK-5400 SK TELETECH FCC ID: OL6SK-5400 EUT Photographs © 2003 PCTEST Lab. Single Mode Cellular Phone (CDMA) Model: SK-5400 SK TELETECH FCC ID: OL6SK-5400 EUT Photographs © 2003 PCTEST Lab. Single Mode Cellular Phone (CDMA) Model: SK-5400 SK TELETECH FCC ID: OL6SK-5400 EUT Photographs © 2003 PCTEST Lab. Single Mode Cellular Phone (CDMA) Model: SK-5400 SK TELETECH FCC ID: OL6SK-5400 EUT Photographs © 2003 PCTEST Lab. Single Mode Cellular Phone (CDMA) Model: SK-5400 SK TELETECH FCC ID: OL6SK-5400 EUT Photographs © 2003 PCTEST Lab. Single Mode Cellular Phone (CDMA) Model: SK-5400 SK TELETECH FCC ID: OL6SK-5400 EUT Photographs © 2003 PCTEST Lab. Single Mode Cellular Phone (CDMA) Model: SK-5400 SK TELETECH FCC ID: OL6SK-5400 EUT Photographs © 2003 PCTEST Lab. Single Mode Cellular Phone (CDMA) Model: SK-5400 SK TELETECH FCC ID: OL6SK-5400 EUT Photographs © 2003 PCTEST Lab. Single Mode Cellular Phone (CDMA) Model: SK-5400 SK TELETECH FCC ID: OL6SK-5400 EUT Photographs © 2003 PCTEST Lab. Single Mode Cellular Phone (CDMA) Model: SK-5400

RF Exposure Info

PCTEST ENGINEERING LABORATORY, INC. 6660 – B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE (SAR EVALUATION) PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR-230416200.OL6 Test Dates: April 16-18, 2003 Phone Type: Single-Mode CDMA FCC ID: OL6SK-5400 Page 1 of 30 © 2003 PCTEST Engineering Laboratory, Inc APPLICANT NAME & ADDRESS: DATE & LOCATION OF TESTING: SK TELETECH CO., LTD. Dates of Tests: April 16-18, 2003 267 Namdaemunno 5-ga, Chung-gu Test Report S/N: 22.230416200.OL6 Seoul, 100-711 KOREA Test Site: PCTEST Lab, Columbia MD U.S.A. Attn: Oh Sang-Seok, Sr. Research Engineer FCC ID: OL6SK-5400 APPLICANT: SK TELETECH CO., LTD. EUT Type: Single-Mode Cellular Phone (CDMA) Tx Frequency: 824.70 – 848.31 MHz (CDMA) Rx Frequency: 869.70 – 893.31 MHz (CDMA) Max. RF Output Power: 0.418 W ERP CDMA (26.213 dBm)/ 25.0 dBm Conducted Max. SAR Measurement: 1.19 W/kg CDMA Head SAR (Slide Up); 1.22 W/kg CDMA Body SAR (Slide Up) 1.31 W/kg CDMA Head SAR (Slide Down); 1.27 W/kg CDMA Body SAR (Slide Down) Trade Name/Model(s): SK-5400 FCC Classification: Non-Broadcast Transmitter Held to Ear (TNE) FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] Application Type: Certification Test Device Serial No.: identical prototype [S/N: 1] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-200X (Draft 6.5, January 15, 2002). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is ERP. SAR compliance for body-worn operating configuration is based on a separation distance of 1.5 cm between the back of the unit and the body of the user. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. Belt clips or holsters may not contain metallic components. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 230416200.OL6 PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR-230416200.OL6 Test Dates: April 16-18, 2003 Phone Type: Single-Mode CDMA FCC ID: OL6SK-5400 Page 2 of 30 © 2003 PCTEST Engineering Laboratory, Inc TABLE OF CONTENTS 1. INTRODUCTION ..........................................................................................3 SAR DEFINITION .........................................................................................3 2. SAR MEASUREMENT SETUP...........................................................................4 Robotic System..............................................................................................4 System Hardware...........................................................................................4 System Electronics..........................................................................................4 3. DASY3 E-FIELD PROBE SYSTEM......................................................................5 Probe Measurement System.............................................................................5 Probe Specifications.......................................................................................5 4. Probe Calibration Process................................................................................6 Dosimetric Assessment Procedure....................................................................6 Free Space Assessment....................................................................................6 Temperature Assessment.................................................................................6 5. PHANTOM & EQUIVALENT TISSUES..............................................................7 SAM Phantom................................................................................................7 Brain & Muscle Simulating Mixture Characterization..........................................7 Device Holder for Transmitters........................................................................7 6. TEST SYSTEM SPECIFICATIONS.......................................................................8 Automated Test System Specifications...............................................................8 7. DOSIMETRIC ASSESSMENT & PHANTOM SPECS..............................................9 Measurement Procedure.................................................................................9 Specific Anthropomorphic Mannequin (SAM) Specifications...............................9 8. DEFINITION OF REFERENCE POINTS............................................................10 EAR Reference Point.....................................................................................10 Handset Reference Points..............................................................................10 9. TEST CONFIGURATION POSITIONS.............................................................11 Positioning for Cheek/Touch..........................................................................11 Positioning for Ear / 15° Tilt...........................................................................12 Body Holster /Belt Clip Configurations............................................................13 10. ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS...............................................14 Uncontrolled Environment......…

Text truncated - open the document above for the full version.

RF Exposure Info

Test Report

PCTEST PT. 22 REPORT FCC CERTIFICATION Reviewed By: Quality Manager Test Report S/N: 22.230416201.OL6 Test Dates: April 16-18, 2003 Phone Type: Single Mode CDMA FCC ID: OL6SK-5400 Page 1 of 17 © 2003 PCTEST ENGINEERING LABORATORY, INC. 0 PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 22 Certification SK TELETECH CO., LTD. Dates of Tests: April 16-18, 2003 267 Namdaemunno 5-ga, Chung-gu Test Report S/N: 22.230416201.OL6 Seoul, 100-711 KOREA Test Site: PCTEST Lab, Columbia MD U.S.A. Attn: Oh Sang-Seok, Sr. Research Engineer FCC ID OL6SK-5400 APPLICANT SK TELETECH CO., LTD. Classification: Non-Broadcast Transmitter Held to Ear (TNE) FCC Rule Part(s): §22.901(d), §2 EUT Type: Single-Mode Cellular Phone (CDMA) Model: SK-5400 Tx Frequency Range: 824.70 – 848.31MHz (CDMA) Rx Frequency Range: 869.70 – 893.31MHz (CDMA) Max. RF Output Power: 0.418 W ERP CDMA (26.213 dBm) Max. SAR Measurement: 1.31W/kg CDMA Head SAR (Slide Down); 1.27W/kg CDMA Body SAR (Slide Down); 1.19W/kg CDMA Head SAR (Slide Up); 1.22W/kg CDMA Body SAR Slide Up) Emission Designator(s): 1M25F9W Test Device Serial No. Identical Prototype [S/N: 1) This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant conditions: Power output listed is ERP. SAR compliance for body- worn operating configuration is based on a separation distance of 1.5 cm between the back of the unit and the body of the user. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. Belt clips or holsters may not contain metallic components. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 230416201.OL6 PCTEST PT. 22 REPORT FCC CERTIFICATION Reviewed By: Quality Manager Test Report S/N: 22.230416201.OL6 Test Dates: April 16-18, 2003 Phone Type: Single Mode CDMA FCC ID: OL6SK-5400 Page 2 of 17 © 2003 PCTEST ENGINEERING LABORATORY, INC. TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1 SCOPE 3 2.1 INTRODUCTION 4 3.1 INSERTS 5 4.1 DESCRIPTION OF TESTS 6-7 5.1 EFFECTIVE RADIATED POWER OUTPUT 8 6.1 RADIATED MEASUREMENTS 9-11 7.1 FREQUENCY STABILITY 12-13 8.1 PLOTS OF EMISSIONS 14 9.1 LIST OF TEST EQUIPMENT 15 10.1 SAMPLE CALCULATIONS 16 11.1 CONCLUSION 17 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL / LOCATION ATTACHMENT F: TEST SETUP PHOTOGRAPHS ATTACHMENT G: EXTERNAL PHOTOGRAPHS ATTACHMENT H: INTERNAL PHOTOGRAPHS ATTACHMENT I: BLOCK DIAGRAM(S) ATTACHMENT J: OPERATIONAL / CIRCUIT DESCRIPTION ATTACHMENT K: SCHEMATIC DIAGRAM(S) ATTACHMENT L: PARTS LIST/TUNE UP PROCEDURE ATTACHMENT M: USER’S MANUAL ATTACHMENT N: SAR MEASUREMENT REPORT ATTACHMENT O: SAR TEST DATA ATTACHMENT P: SAR TEST SETUP PHOTOGRAPHS ATTACHMENT Q: DIPOLE VALIDATION ATTACHMENT R: PROBE CALIBRATION PCTEST PT. 22 REPORT FCC CERTIFICATION Reviewed By: Quality Manager Test Report S/N: 22.230416201.OL6 Test Dates: April 16-18, 2003 Phone Type: Single Mode CDMA FCC ID: OL6SK-5400 Page 3 of 17 © 2003 PCTEST ENGINEERING LABORATORY, INC. MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2.1033 General Information Applicant Name: SK TELETECH CO., LTD. Address: 267 Namdaemunro 5-ga, Chung-gu Seoul, 100-711 Korea Attention: Oh Sang-Seok, Sr. Research Engineer • FCC ID: OL6SK-5400 • Quantity: Quantity production is planned • Emission Designators: 1M25F9W • Tx Freq. Range: 824.70 – 848.31 MHz (CDMA) • Rx Freq. Range: 869.70 – 893.31 MHz (CDMA) • Max. Power Rating: 0.418 W ERP CDMA (26.213 dBm) • FCC Classification(s): Non-Broadcast Transmitter Held to Ear (TNE) • Equipment (EUT) Type: Single-Mode Cellular Phone (CDMA) • Modulation(s): CDMA • Frequency Tolerance: ± 0.00025% (2.5 ppm) • FCC Rule Part(s): §22.901(d), §2 • Dates of Tests: April 16-18, 2003 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: 22.230416201.OL6 PCTEST PT. 22 REPORT FCC CERTIFICATION Reviewed By: Quality Manager Test Report S/N: 22.230416201.OL6 Test Dates: April 16-18, 2003 Phone Type: Single Mode CDMA FCC ID: OL6SK-5400 Page 4 of 17 © 2003 PCTEST ENGINEERING LABORATORY, INC. 2.1 INTRODUCTION These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. Measurement Procedure The radiated and spurious measurements were made outdoors at a 3-meter test range (see Figure2). The equipment under test is placed on a wooden turntable 3-meters from the …

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Felix Jin(Manager)

[email protected]82-2-2112-3114Fax: 82-22-2112--3399

Technical Contact

PCTEST Engineering Lab., Inc.Randy Ortanez

[email protected]410-290-6652

6660-B Dobbin Road · Columbia, Maryland · United States

Non-Technical Contact

PCTEST Engineering Lab., Inc.Randy Ortanez

[email protected]410-290-6652

Test Firm

PCTEST Engineering Laboratory, Inc.Randy Ortanez

[email protected]410-290-6652Fax: 410-290-6654

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
1	22.901(d)	824.7 MHz - 848.31 MHz	418.00 mW	1M25F9W	2.5000000000 ppm

Confidentiality

Long Term

Grant Notes

Power output listed is ERP. SAR compliance for body-worn operating configuration is based on a separation distance of 1.5 cm between the back of the unit and the body of the user. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. Belt clips or holsters may not contain metallic components. The highest reported SAR values are - Head: 1.31 W/kg; Body: 1.27 W/kg.
