OO4-IDS1000iQ355 (X)P Personal Tag

IDE NTEC SOLUTIONS Model IDS1000 iQ355 P Personnel Tag HARDWARE USER MANUAL Proprietary Notice This document contains confidential information proprietary to IDENTEC SOLUTIONS and may not be used or disclosed to other parties in whole or in part without the prior written authorization from IDENTEC SOLUTIONS. Disclaimer and Limitation of Liability IDENTEC SOLUTIONS AG and its affiliates, subsidiaries, officers, directors, employees and agents do not make any express or implied warranties or representations with respect to such information including, without limitation, warranties as to non-infringement, reliability, suitability for a particular purpose and accuracy. IDENTEC SOLUTIONS shall not under any circumstances be liable to any person for any special, incidental, indirect or consequential damages, including without limitation, damages resulting from use of or reliance on information presented herein, or loss of profits or revenues or costs of replacement goods, even if informed in advance of the possibility of such damages. Trademarks “IDENTEC SOLUTIONS”, “Intelligent Long Range”, “ILR” and the stylized “i” are registered trademarks. “i-PORT”. “iPOINT” and “Visibility Delivered.” are trademarks of IDENTEC SOLUTIONS, Inc. and/or IDENTEC SOLUTIONS AG. Copyright Notice Copyright © 2020 IDENTEC SOLUTIONS. All rights reserved. No part of this document may be reproduced or transmitted in any form by any means, photographic, electronic, mechanical or otherwise, or used in any information storage and retrieval system, without the prior written permission of IDENTEC SOLUTIONS. Issue 1.0 / March 2020 (MOM) Subject to alteration without prior notice. Copyright © 2020 IDENTEC SOLUTIONS AG Printed in Austria Radio Frequency Compliance Statement IDENTEC SOLUTIONS is the responsible party for the compliance of the following devices: MODEL: iQ355 P Region/Country Organization Marking EUROPE: EU CE USA: FCC FCC ID OO4-IDS1000 CANADA: IC 3538A-IDS1000 The user(s) of these products are cautioned to only use accessories and peripherals approved, in advance, by IDENTEC SOLUTIONS. The use of accessories and peripherals, other than those approved by IDENTEC SOLUTIONS, or unauthorized changes to approved products, may void the compliance of these products and result in the loss of the user(s) authority to operate the equipment. European Declaration of Conformity according to RED Directive IDENTEC SOLUTIONS AG hereby declares that the device iQ355 P is in conformity with the essential requirements of Directive 2014/53/EU. The declaration of conformity can be found at: www.identecsolutions.com USA Certification FCC Part 15 compliance statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Canada Certification Licence-Exempt Radio Apparatus (ISED) This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. Appareils radio exempts de licence (ISDE) L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Radio Frequency (RF) Exposure Compliance of Radiocommunication portable apparatus This device complies with FCC and ISED Canada RF radiation exposure limits set forth for general population (uncontrolled exposure). This device must not be collocated or operating in conjunction with any other antenna or transmitter. Conformité à l’exposition aux champs RF des équipements radio portables Cet appareil est conforme aux limites FCC et ISDE Canada concernant l'exposition aux rayonnements RF établies pour le grand public. (Environnement non-contrôlé) Cet émetteur ne doit pas être co-situé ou fonctionner conjointement avec une autre antenne ou un autre émetteur. WARNING - This product should be installed by personnel trained in installation of equipment in industrial environments and meet the representative country’s National Electrical Code. Electrostatic Discharge This product contains components that are sensitive to electrostatic discharges. Please observe the special instructions for their protection. Incorrect handling can damage the unit and cause the invalidation of the warranty. Minimum safety precautions against electrostatic discharge:  Establish earth contact before you touch the unit. (For example, touch the earthing screw on the unit.) Best practice is to use an antistatic ribbon and earth yourself permanently for the time you handle the unit.  Avoid unnecessary contact with the unit connectors and assemblies inside the unit.  Do not open the unit.  Use antistatic tools for the setting of the unit. (Warning: Do not touch life-threatening voltages with these tools).  Do not store unit and components without protective packaging.  Remove unit and components from the packaging only prior to installation. These notes are not sufficient to guarantee complete protection from electrostatic discharges! We recommend the use of suitable protective equipment. IDENTEC SOLUTIONS does not accept the return of products where the regulations concerning the ESD precautions and protective packaging materials were not followed. Safety Instructions The equipment can be installed in restricted are…

Text truncated - open the document above for the full version.

IDE NTEC SOLUTIONS Model IDS1000 iQ355 XP Personnel Tag (ATEX) HARDWARE USER MANUAL Proprietary Notice This document contains confidential information proprietary to IDENTEC SOLUTIONS and may not be used or disclosed to other parties in whole or in part without the prior written authorization from IDENTEC SOLUTIONS. Disclaimer and Limitation of Liability IDENTEC SOLUTIONS AG and its affiliates, subsidiaries, officers, directors, employees and agents do not make any express or implied warranties or representations with respect to such information including, without limitation, warranties as to non-infringement, reliability, suitability for a particular purpose and accuracy. IDENTEC SOLUTIONS shall not under any circumstances be liable to any person for any special, incidental, indirect or consequential damages, including without limitation, damages resulting from use of or reliance on information presented herein, or loss of profits or revenues or costs of replacement goods, even if informed in advance of the possibility of such damages. Trademarks “IDENTEC SOLUTIONS”, “Intelligent Long Range”, “ILR” and the stylized “i” are registered trademarks. “i-PORT”. “iPOINT” and “Visibility Delivered.” are trademarks of IDENTEC SOLUTIONS, Inc. and/or IDENTEC SOLUTIONS AG. Copyright Notice Copyright © 2019 IDENTEC SOLUTIONS. All rights reserved. No part of this document may be reproduced or transmitted in any form by any means, photographic, electronic, mechanical or otherwise, or used in any information storage and retrieval system, without the prior written permission of IDENTEC SOLUTIONS. Issue 1.1 / March 2020 (MOM/FEK) Subject to alteration without prior notice. Copyright © 2020 IDENTEC SOLUTIONS AG Printed in Austria Radio Frequency Compliance Statement IDENTEC SOLUTIONS is the responsible party for the compliance of the following devices: MODEL: iQ355 XP Region/Country Organization Marking EUROPE: EU CE USA: FCC FCC ID OO4-IDS1000 CANADA: IC 3538A-IDS1000 The user(s) of these products are cautioned to only use accessories and peripherals approved, in advance, by IDENTEC SOLUTIONS. The use of accessories and peripherals, other than those approved by IDENTEC SOLUTIONS, or unauthorized changes to approved products, may void the compliance of these products and result in the loss of the user(s) authority to operate the equipment. European Declaration of Conformity according to RED Directive IDENTEC SOLUTIONS AG hereby declares that the device iQ355 XP is in conformity with the essential requirements of Directive 2014/53/EU. The declaration of conformity can be found at: www.identecsolutions.com USA Certification FCC Part 15 compliance statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Canada Certification Licence-Exempt Radio Apparatus (ISED) This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. Appareils radio exempts de licence (ISDE) L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Radio Frequency (RF) Exposure Compliance of Radiocommunication portable apparatus This device complies with FCC and ISED Canada RF radiation exposure limits set forth for general population (uncontrolled exposure). This device must not be collocated or operating in conjunction with any other antenna or transmitter. Conformité à l’exposition aux champs RF des équipements radio portables Cet appareil est conforme aux limites FCC et ISDE Canada concernant l'exposition aux rayonnements RF établies pour le grand public. (Environnement non-contrôlé) Cet émetteur ne doit pas être co-situé ou fonctionner conjointement avec une autre antenne ou un autre émetteur. ATEX Certification Equipment or protected system intended for use in potentially explosive atmosphere directive 2014/53/EU. Compliance with the essential health and safety Requirements has been assured by compliance with the following standards: EN 60079-0, EN 60079-11 IECEx Certification The electrical apparatus and any acceptable variations to it specified in the schedule of this certificate and the identified documents, was found to comply with the following standards: IEC 60079-0:2017, IEC 60079-11:2011 Special conditions for safe use – ATEX and IECEx WARNING – Maintenance is not permitted. Do not open the housing. WARNING – Electrostatic Hazard: Clean only with a damp cloth. WARNING - Electrostatic Hazard: Do not install in locations with increased electrostatic charge such as close to ventilations systems or electric drives. WARNING - This product should be installed by personnel trained in installation of equipment in Hazardous Locations and meet the representative country’s National Electrical Code. WARNING - Not to be connected to equipment that uses or generates more than 250V with respect to earth ground EPS 20 ATEX 1 028 iQ355 XP II 1G Ex ia IIC T4 Ga -40°C ≤ Ta ≤ +70°C Gas I M1 Ex ia Ma -40°C ≤ Ta ≤ +70°C Mining IECEx EPS_20.0012_000 iQ355 XP Type of Protection Ex i Marking Ex ia IIC T4 Ga Gas Ex ia Ma Mining WARNING - This product contains components that are sensitive to electrostatic discharges. Please observ…

Text truncated - open the document above for the full version.

IDENTEC SOLUTIONS AG Millennium Park 2 A-6890 Lustenau / Austria Tel: +43 (0)5577 87387-0 Fax:+43(0)5577 87387 –15 [email protected] www.identecsolutions.com Authority to Act as Agent Date: March 23 rd , 2020 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: SMEE (Mr. Laurent Chapus, ZI des Blanchisseries, F-38500 Voiron, France) is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: December 31 st , 2020 By: Mr. Karl-Heinz Feierle (Signature) (Print name) Title: VP Hardware Development On behalf of: IDENTEC SOLUTIONS AG Millennium Park 2 A-6890 Lustenau Austria ContactPhone: +43 5577 87387 0 ContactFax: +43 5577 87387 15 [email protected]

IDENTEC SOLUTIONS AG Millennium Park 2 A-6890 Lustenau / Austria Tel: +43 (0)5577 87387-0 Fax:+43(0)5577 87387 –15 [email protected] www.identecsolutions.com Request for Confidentiality Date: March 23, 2020. Subject: Confidentiality Request for FCC ID: OO4-IDS1000 IC: 3538A-IDS1000 Pursuant to FCC 47 CRF 0.457(d), the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* 3 User’s Manual IDENTEC SOLUTIONS AG has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for ISED Canada Applications: ISED currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: __________________________ __________ Mr. Karl-Heinz Feierle ______________ (Signature/Title 3 ) (Print name) VP Hardware Development IDENTEC SOLUTIONS AG Millennium Park 2, A-6890 Lustenau, Austria 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details.

FCC ID: OO4-IDS1000 IC: 3538A-IDS1000 Page 1/1 EXTERNAL PHOTOS OF TESTED EUT

FCC ID: OO4-IDS1000 IC: 3538A-IDS1000 Page 1/1 PRODUCT LABELING Equipment’s label Label’s location Packaging’s label

FCC ID: OO4-IDS1000 IC: 3538A-IDS1000 Page 1/1 INTERNAL PHOTOS OF TESTED EUT

Rapport d’essais / Test Report N° : 13324-FCC-IC-1 Page 1 / 24 COORDONNEES SMEE TEL : 04 76 65 76 50 Rue de Taille – ZI Des Blanchisseries FAX : 04 76 66 18 30 38500 VOIRON - France SAS au capital de 50 000 € / RC Grenoble B534 796 453 / SIRET 534 796 453 00015 / code APE 7490B / n° TVA : FR 59 534 796 453 FCC Test Firm Designation Number: FR0014 SED Wireless Device Testing Laboratory CAB Number: FR0004 Matériel testé : Equipment under test: IDENTEC SOLUTIONS / IDS1000 (Trademark / Marketing name or product reference) Client / Demandeur: Customer / Applicant : IDENTEC SOLUTIONS AG Millennium Park 2 A-6890 Lustenau – Austria Rapport délivré à : Issued to: IDENTEC SOLUTIONS AG Karl-Heinz Feierle Millennium Park 2 A-6890 Lustenau – Austria Référence de la proposition : Proposal number: 012020-23939 Numéro d’affaire : Work number : 13324 Date de l’essai : Date of test: Le 6 avril 2020 April 6 th , 2020 Objectif des essais : Test purpose: EMC qualification according to following standards: - CFR 47, FCC Part 15, Subpart C (Chapter 15.249 - Operation within the bands 902–928 MHz, 2400–2483.5 MHz, 5725–5875 MHz, and 24.0–24.25 GHz) - Industry Canada, RSS-Gen Issue 5 & RSS-210 Issue 10, section B.10 (Bands 902–928, 2400–2483.5 and 5725–5875 MHz) Measurement standards: ANSI C63.10 (2013) Lieu du test: Test location: SMEE, Rue de Taille 38500 VOIRON - France Test réalisé par : Test realized by: Laurent CHAPUS Conclusion : Conclusion: L’équipement satisfait aux prescriptions et essais des normes citées en référence. The appliance complies with requirements and tests of above mentioned standards. Ed. Date Modifications / Pages Written by : Visa Approved by: Visa 1 April 22, 2020 Initial Edition Laurent CHAPUS Technical Manager Regis ANCEL General Manager La copie de ce document n'est permise que sous sa forme intégrale. Ce document est le résultat d’essais effectués sur un échantillon. Il ne préjuge pas de la conformité de l’ensemble des produits fabriqués à l’objet essayé. This document shall not be reproduced, except in full. This document contains results related only to the item tested. It does not imply the conformity of the whole production to the item tested. Accréditation N° 1-6356 Portée disponible sur : Scope available on : www.cofrac.fr Page 2 / 24 Rapport d’essai / Test Report N° : 13324-FCC-IC-1 Contents 1. NORMATIVES REFERENCES ......................................................................................................... 3 2. TEST SYNTHESIS ............................................................................................................................ 4 3. EQUIPMENT UNDER TEST (EUT) ................................................................................................... 5 4. TEST CONDITIONS.......................................................................................................................... 5 5. MODIFICATIONS OF THE EUT ........................................................................................................ 5 6. SPECIAL ACCESSORIES ................................................................................................................ 5 7. MEASUREMENT UNCERTAINTY .................................................................................................... 6 8. FIELD STRENGTH CALCULATION .................................................................................................. 6 9. FIELD STRENGTH OF FUNDAMENTAL .......................................................................................... 7 10. FIELD STRENGTH OF HARMONICS ........................................................................................... 9 11. UNWANTED EMISSIONS ........................................................................................................... 12 12. OCCUPIED BANDWIDTH (99%) ................................................................................................. 22 Page 3 / 24 Rapport d’essai / Test Report N° : 13324-FCC-IC-1 1. Normatives References FCC qualification according to: Standards Applied Title ANSI C63.10 (2013) X American National Standard for Testing Unlicensed Wireless Devices CFR47, Part 15 X Telecommunication – Federal Communication Commission – Radio frequency devices, Sections 15.207 / 15.209 / 15.249 Industry Canada qualification according to: Standards Applied Title RSS-Gen (Issue 5/2019) X General Requirements and Information for the Certification of Radio Apparatus RSS-210 (Issue10/2019) X Licence-exempt Radio Apparatus: Category I Equipment, Section B.10: Devices Operating in Frequency Bands for Any Application, Band 2400-2483.5MHz. Deviation from standards: None. Page 4 / 24 Rapport d’essai / Test Report N° : 13324-FCC-IC-1 2. Test synthesis TEST Paragraph number FCC Part 15 IC RSS-210 Spec. FCC Part 15 IC RSS-210 RESULTS (comments) Conducted emissions test 15.207 (a) RSS-Gen: Issue 5, §8.8 15.207 (a) Table 4, §8.8 N/A (1) Field Strength of fundamental 15.249 (a) (c) RSS-210: Issue 9, §B.10 (a) 94dBμV/m @3m (50mV/m @ 3m) PASS Field Strength of harmonics 15.249 (a) (c) (e) RSS-210: Issue 9, §B.10 (a) 54dBμV/m @3m (0.5mV/m @ 3m) PASS Unwanted emissions outside the specified frequency band and harmonics 15.209 / 15.249 (d) (e) RSS-210: Issue 9, §B.10 (b) / RSS-Gen: Issue 5, §8.9 Whichever is less stringent, either: - 50dB below level of fundamental, or; - General field strength limits, as follow: Measure at 300m 9-490kHz: 2400μV/m/F(kHz) Measure at 30m 0.490-1.705: 24000μV/m/F(kHz) 1.705-30MHz: 30μV/m Measure at 3m 30MHz-88MHz : 40 dBμV/m 88MHz-216MHz : 43.5 dBμV/m 216MHz-960MHz : 46.0 dBμV/m Above 960MHz : 54.0 dBμV/m PASS Occupied Bandwidwth RSS-Gen: Issue 5, §6.7 BW at 99% PASS NA: Not Applicable (1): Battery operated equipment • General conclusion: Measures and tests performed on the sample of the product DENTEC SOLUTIONS / IDS1000, in configuration and description presented in this test report, show compliance with standards FCC CFR 47, PART 15, Sub…

Text truncated - open the document above for the full version.

FCC ID: OO4-ILR-IPM352UH Page 1/2 MEASUREMENT PHOTO Radiated emissions Open Aera Test Site FCC ID: OO4-ILR-IPM352UH Page 2/2 Full Anechoic chamber (Freq > 1GHz)
