OO4-ILR-IPUBTRFID Reader

i-PORT 350/250 USB - BT SensorSMART™ Mobile Reader User Guide i-PORT 350/250 USB - BT USER GUIDE VISIBILITY DELIVERED. PAGE 2 OF 22 Proprietary Notice This document contains confidential information proprietary to IDENTEC SOLUTIONS and may not be used or disclosed to other parties in whole or in part without the prior written authorization from IDENTEC SOLUTIONS. Disclaimer and Limitation of Liability IDENTEC SOLUTIONS AG and its affiliates, subsidiaries, officers, directors, employees and agents do not make any express or implied warranties or representations with respect to such information including, without limitation, warranties as to non-infringement, reliability, suitability for a particular purpose and accuracy. IDENTEC SOLUTIONS shall not under any circumstances be liable to any person for any special, incidental, indirect or consequential damages, including without limitation, damages resulting from use of or reliance on information presented herein, or loss of profits or revenues or costs of replacement goods, even if informed in advance of the possibility of such damages. Customer shall be solely responsible for proper selection, application, and use of Products, as well as the incorporation/integration of Products into other equipment or systems. Customer shall indemnify and hold IDENTEC SOLUTIONS harmless from and against any and all damages, liabilities, claims, or expenses (including reasonable attorneys' fees) arising out of or relating to (i) improper selection, application, installation, use or incorporation/integration of Products; or (ii) infringement of any patent, trademark, copyright or other third party interest arising out of IDENTEC SOLUTIONS' compliance with any of Customer's designs, specifications, or instructions Trademarks “IDENTEC SOLUTIONS”, “Intelligent Long Range”, “ILR” and the stylized “i” are registered trademarks and “i-CARD”, “i-PORT”, “i-LINKS”, “Visibility Delivered.” are trademarks of IDENTEC SOLUTIONS, Inc. and/or IDENTEC SOLUTIONS AG. Copyright Notice Copyright © 2015 IDENTEC SOLUTIONS. All rights reserved. No part of this document may be reproduced or transmitted in any form by any means, photographic, electronic, mechanical or otherwise, or used in any information storage and retrieval system, without the prior written permission of IDENTEC SOLUTIONS. Issue 1.0 / 06. May 2015 (EGD) Subject to alteration without prior notice. CONTACT US EUROPE HEAD OFFICE USA GERMANY NORWAY AUSTRALIA +43 5577 87387-0 IDENTEC SOLUTIONS AG IDENTEC SOLUTIONS, INC. IDENTEC SOLUTIONS IDENTEC SOLUTIONS AS IDENTEC SOLUTIONS [email protected] Millennium Park 2 Preston Plaza DEUTSCHLAND GMBH Kartheia 3 AUSTRALIA AND 6890 Lustenau 17950 Preston Rd., Suite 200 AURUM 05 / Ost 4626 Kristiansand NEW ZEALAND P/L NORTH AMERICA Austria Dallas, Texas 75252 Goldbeckstraße 5 Norway Riverview Business Park 72 +1 866 402-4211 Tel +43 5577 87387-0 USA 69493 Hirschberg Tel +47 38 00 35 30 Maribyrnong St, Footscray VIC [email protected] Fax +43 5577 87387-15 Tel +1 972 535 4439 Germany Fax +47 38 00 35 31 3011 Australia Fax +1 469 424 0404 Tel +49 6201 99 57-0 Tel +61 3 9396 8900 Fax +49 6201 99 57-99 Fax +61 3 9689 2493 i-PORT 350/250 USB - BT USER GUIDE VISIBILITY DELIVERED. PAGE 3 OF 22 Radio Frequency Compliance Statement IDENTEC SOLUTIONS is the responsible party for the compliance of the following devices: MODEL: i-PORT 350/250 USB - BT Region/Country Organization Marking EUROPE: EC CE USA: FCC FCC ID OO4-ILR-IPUBT Contains FCC ID X3ZBTMOD5 Canada: Industry Canada IC:3538A-IPUBT Contains 8828A-MOD5 The user(s) of these products are cautioned to only use accessories and peripherals approved, in advance, by IDENTEC SOLUTIONS. The use of accessories and peripherals, other than those approved by IDENTEC SOLUTIONS, or unauthorized changes to approved products, may void the compliance of these products and may result in the loss of the user(s) authority to operate the equipment. European Notification according R&TTE Directive This equipment complies to Art. 6.4 of R&TTE Directive (2006/95/EU, 2004/108/EC, 1999/5/EC). It is tested for compliance with the following standards: EN 300 220-1, ETSI EN 300 220-2, ETSI EN 301 489- 1, ETSI EN 301 489-3, EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 USA Notification This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Canada Certification This device complies with Industry Canada’s license exempt RSS’s. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Le présent appareil est conforme aux CNR d‘Industrie Canada applicables aux appareils radio exempts de licence. L‘exploitation est autorisée aux deux conditions suivantes: (1) l‘appareil ne doit pas produire de brouillage, et (2) l‘utilisateur de l‘appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d‘en compromettre le fonctionnement. i-PORT 350/250 USB - BT USER GUIDE VISIBILITY DELIVERED. PAGE 4 OF 22 This product contains components that are sensitive to electrostatic discharges. Please observe the special instructions for their protection. Incorrect handling can damage the unit and cause the invalidation of the warranty. Minimum safety precautions against electrostatic discharge: ∑ Establish earth contact before you touch the unit. (For example, touch the earthing screw on the unit.) Best practice is to use an antistatic ribbon and earth yourself permanently for the time you handle the unit. ∑ Avoid unnecessary contact with the unit connectors and assemblies inside the unit. ∑ Only open the unit if the operational settings (as describ…

Text truncated - open the document above for the full version.

Page 1 of 2 External Photos Page 2 of 2

IDENTEC SOLUTIONS AG Millennium Park2 6890 Lustenau Austria Label for Non ATEX version Label for ATEX version

Internal Photos

Prüfbericht / Test report FCC (Federal Communications Commission) Test-Firm-Registration-Number: 90870 IC (Industry Canada) Company-Number: 6155A Test site number 6155A-1 SAR Ohmstrasse 1 84160 Frontenhausen, Germany Tel.: + 49 (0) 87 32 - 63 81 Fax: + 49 (0) 87 32 - 23 45 E-mail: [email protected] Prüfbericht Nr./ Test report no.: 14/01-0047 Seite 1 von 6 Seiten Page 1 of 6 pages Prüfbericht Nr./Test report no.: 14/01-0047 Seite 2 von 7 Seiten Page 2 of 7 pages TABLE OF CONTENTS Page 1. Client Information 3 2. Equipment under Test 3 3. SAR 4 – 5 4. Photos 6 – 7 Prüfbericht Nr./Test report no.: 14/01-0047 Seite 3 von 7 Seiten Page 3 of 7 pages 1. CLIENT INFORMATION: Name: IDENTEC SOLUTIONS AG Address: Millennium Park 2, 6890 LUSTENAU, AUSTRIA Name of contact: Mr. Adalgiso Castrignano Telephone: 0043 5577 87387 64 Fax: 0043 5577 87387 15 E-mail: [email protected] 2. EQUIPMENT UNDER TEST (EUT): 2.1 Identification of the EUT Equipment: ILR Mobile Reader Model: i-Port-USB-BT Brand name: -/- Serial no.: 14031U0004 Manufacturer: IDENTEC SOLUTIONS AG Country of origin: Austria Rating: Operated with rechargeable battery, charging with 9 – 24 V DC, 50 mA or by USB. 2.2 Additional information about the EUT: Included Bluetooth module which is already certified (modular certification) with FCC ID: X3ZBTMOD5 and IC: 8828A-MOD4. The EUT is working on the frequencies: 919 MHz Broadcast (only reception) 920 MHz- Communication (transmitting/receiving of data), Frequency deviation ± 64 kHz @ 115200 bit/s 921 MHz- Wakeup (transmitting/receiving), Frequency deviation ± 20 kHz @ 19200 bit/s Prüfbericht Nr./Test report no.: 14/01-0047 Seite 4 von 7 Seiten Page 4 of 7 pages 3. SAR 3.1 SAR test exclusion threshold The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] x [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where • f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 (447498 D01 General RF Exposure Guidance v05r02) is applied to determine SAR test exclusion. Using following parameters: certified Bluetooth module: f: 921 MHz 2483.5 MHz max. channel power: 1 mW (including tolerance) 1.2 mW (including max. antenna gain) separation distance: 5 mm (worst case) 5 mm handheld exclusion threshold: 1/5 x 0.95 = 0.2 1.2/5 x 1.58 = 0.4 With the above mentioned values we get a total value of the numeric threshold of 0.6 which is far below 3 (1-g SAR) and 7.5 (10-g SAR) and the EUT is therefor excluded from SAR. Applied standards/documents 447498 D01 General RF Exposure Guidance v05r02 Prüfbericht Nr./Test report no.: 14/01-0047 Seite 5 von 7 Seiten Page 5 of 7 pages 3.2 SAR Evaluation All transmitters are exempt from routine SAR and RF exposure evaluations provided that they comply with the requirements of sections 2.5.1 or 2.5.2 of RSS-102 issue 5. SAR evaluation is required if the separation distance between the user and/or bystander and the antenna and/or radiating element of the device is less than or equal to 20 cm, except when the device operates at or below the applicable output power level (adjusted for tune-up tolerance) for the specified separation distance defined in Table 1. Using following parameters for evaluation: certified Bluetooth module: f: 921 MHz 2483.5 MHz max. channel power: 1 mW (including tolerance) 1.2 mW (including max. antenna gain) separation distance: 5 mm (worst case) 5 mm handheld Exemption limit: 16.2 mW 3.9 mW The EUT is exempted from the routine SAR, since the max. power is below the Exemption limit according to Table 1 of RSS-102 issue 5. Applied standards/documents RSS-102 issue 5, section 2.5.1 Prüfbericht Nr./Test report no.: 14/01-0047 Seite 6 von 7 Seiten Page 6 of 7 pages 4. Photos Prüfbericht Nr./Test report no.: 14/01-0047 Seite 7 von 7 Seiten Page 7 of 7 pages End of test report

Prüfbericht / Test report FCC (Federal Communications Commission) Test-Firm-Registration-Number: 90870 IC (Industry Canada) Company-Number: 6155A Test site number 6155A-1 RES Ohmstrasse 1 84160 Frontenhausen, Germany Tel.: + 49 (0) 87 32 - 63 81 Fax: + 49 (0) 87 32 - 23 45 E-mail: [email protected] Prüfbericht Nr./ Test report no.: 14/01-0047 Seite 1 von 34 Seiten Page 1 of 34 pages Prüfbericht Nr./Test report no.: 14/01-0047 Seite 2 von 34 Seiten Page 2 of 34 pages TABLE OF CONTENTS Page 1. Client Information 3 2. Equipment under Test 3 3. Conducted emission measurements 4 – 10 4. Radiated emission measurements 11 – 26 5. Bandwidth 27 – 31 6. Conclusions 32 7. Photos 33 – 34 Prüfbericht Nr./Test report no.: 14/01-0047 Seite 3 von 34 Seiten Page 3 of 34 pages 1. CLIENT INFORMATION: Name: IDENTEC SOLUTIONS AG Address: Millennium Park 2, 6890 LUSTENAU, AUSTRIA Name of contact: Mr. Adalgiso Castrignano Telephone: 0043 5577 87387 64 Fax: 0043 5577 87387 15 E-mail: [email protected] 2. EQUIPMENT UNDER TEST (EUT): 2.1 Identification of the EUT Equipment: ILR Mobile Reader Model: i-Port-USB-BT Brand name: -/- Serial no.: 14031U0004 Manufacturer: IDENTEC SOLUTIONS AG Country of origin: Austria Rating: Operated with rechargeable battery, charging with 9 – 24 V DC, 50 mA or by USB. 2.2 Additional information about the EUT: Included Bluetooth module which is already certified (modular certification) with FCC ID: X3ZBTMOD5 and IC: 8828A-MOD4. The EUT is working on the frequencies: 919 MHz Broadcast (only reception) 920 MHz- Communication (transmitting/receiving of data), Frequency deviation ± 64 kHz @ 115200 bit/s 921 MHz- Wakeup (transmitting), Frequency deviation ± 20 kHz @ 19200 bit/s Tx power setting: 0x60 Prüfbericht Nr./Test report no.: 14/01-0047 Seite 4 von 34 Seiten Page 4 of 34 pages 3. Conducted emission measurements Test site Measurements of conducted emission from EUT was made in the shielded chamber (Siemens DC-1 GHz). Detector function selection and bandwidth In conducted emissions measurement CISPR quasi-peak- and average-detector were used. The bandwidth of the detector of instrument is 9 kHz over the frequency range of 150 kHz to 30 MHz. Conducted emissions to be measured are detected in CISPR quasi-peak- and average-mode. Frequency range to be scanned For conducted emission measurements, the spectrum in the range of 150 kHz to 30 MHz was investigated. Test conditions and configuration of EUT The EUT was configured and operated in transmitting/receiving modes with a host AC adaptor (120 V~, 60 Hz / 21 V DC out), so as to find the maximum conducted emission generated from EUT. During test the peripherals were operated with rated Power (120 V~, 60 Hz). The EUT has no direct connection to the AC power line. Measurements on neutral (N)- and live (L1)-wires of the peripherals had been performed. Applied standards 47 CFR part 15 subpart B, § 15.107 Conducted limits 47 CFR part 15 subpart C, § 15.207 Conducted limits RSS-210, Issue 8 RSS-Gen, Issue 4, clause 8.8 AC Power Line Conducted Emissions Limits for Licence-Exempt Radio Apparatus ANSI C63.10-2009 / ANSI C63.10-2013, clause 6.2 Standard test method for AC power-line conducted emissions from unlicensed wireless devices Prüfbericht Nr./Test report no.: 14/01-0047 Seite 5 von 34 Seiten Page 5 of 34 pages Measurements Receiving 919 MHz: Tested on N 0 20 40 60 70 150k 300400500 8001M2M3M4M5M6 810M20M30M Level in dBμV F re q u e n c y in H z P K + _ M A X HL imit L in e _ 1 5 0 k H z -3 0 M H z_ Q P L imit L in e _ 1 5 0 k H z -3 0 M H z_ A VQ u a siP e a k A v e ra g e Frequency (MHz) MaxPeak (dBμV) QuasiPeak (dBμV) Average (dBμV) Meas. Time (ms) Bandwidth (kHz) Margin - AVG (dB) Limit - AVG (dBμV) Margin - QPK (dB) Limit - QPK (dBμV) 0.346000 43.5 34.3 3.3 1000.0 9.000 45.8 49.1 24.7 59.1 0.354000 43.3 34.2 2.9 1000.0 9.000 46.0 48.9 24.7 58.9 0.378000 43.4 33.8 2.2 1000.0 9.000 46.1 48.3 24.5 58.3 0.390000 42.7 33.3 1.8 1000.0 9.000 46.3 48.1 24.8 58.1 0.398000 42.2 32.9 1.6 1000.0 9.000 46.3 47.9 25.0 57.9 0.410000 42.6 32.5 1.3 1000.0 9.000 46.4 47.6 25.2 57.6 Tested on L1 0 20 40 60 70 150k 300400500 8001M2M3M4M5M6 810M20M30M PK+_MAXH in dBμV F re q u e n c y in H z P K + _ M A X HL imit L in e _ 1 5 0 k H z -3 0 M H z_ Q P L imit L in e _ 1 5 0 k H z -3 0 M H z_ A VQ u a siP e a k A v e ra g e Frequency (MHz) MaxPeak (dBμV) QuasiPeak (dBμV) Average (dBμV) Meas. Time (ms) Bandwidth (kHz) Margin - AVG (dB) Limit - AVG (dBμV) Margin - QPK (dB) Limit - QPK (dBμV) 0.298000 41.2 32.2 2.4 1000.0 9.000 47.9 50.3 28.1 60.3 0.334000 43.8 35.0 3.6 1000.0 9.000 45.7 49.4 24.4 59.4 0.338000 43.6 34.7 3.3 1000.0 9.000 46.0 49.3 24.6 59.3 0.346000 43.5 34.4 3.0 1000.0 9.000 46.1 49.1 24.7 59.1 0.382000 42.8 32.9 1.6 1000.0 9.000 46.6 48.2 25.3 58.2 0.430000 39.0 29.8 -0.7 1000.0 9.000 47.9 47.3 27.5 57.3 Prüfbericht Nr./Test report no.: 14/01-0047 Seite 6 von 34 Seiten Page 6 of 34 pages Receiving 920 MHz: Tested on N 0 20 40 60 70 150k 300400500 8001M2M3M4M5M6 810M20M30M Level in dBμV F re q u e n c y in H z P K + _ M A X HL imit L in e _ 1 5 0 k H z -3 0 M H z_ Q P L imit L in e _ 1 5 0 k H z -3 0 M H z_ A VQ u a siP e a k A v e ra g e Frequency (MHz) MaxPeak (dBμV) QuasiPeak (dBμV) Average (dBμV) Meas. Time (ms) Bandwidth (kHz) Margin - AVG (dB) Limit - AVG (dBμV) Margin - QPK (dB) Limit - QPK (dBμV) 0.298000 48.2 38.7 6.6 1000.0 9.000 43.7 50.3 21.6 60.3 0.302000 48.7 39.6 7.1 1000.0 9.000 43.1 50.2 20.6 60.2 0.326000 48.8 40.5 7.0 1000.0 9.000 42.5 49.6 19.0 59.6 0.334000 49.0 40.3 6.7 1000.0 9.000 42.6 49.4 19.1 59.4 0.346000 48.2 39.7 6.3 1000.0 9.000 42.8 49.1 19.4 59.1 0.350000 48.2 39.6 6.2 1000.0 9.000 42.8 49.0 19.4 59.0 Tested on L1 0 10 20 30 40 50 60 70 150k 300400500 8001M2M3M4M5M6 810M20M30M PK+_MAXH in dBμV F re q u e n c y in H z Frequency (MHz) MaxPeak (dBμV) QuasiPeak (dBμV) Average (dBμV) Meas. Time (ms) Bandwidth (kHz) Margin - AVG (dB) Limit - AVG (dBμV) Margin - QPK (dB) Limit - QPK (dBμV) 0.162000 50.7 41.1…

Text truncated - open the document above for the full version.

Attachment to Test-Report-No.: 14/01-0047 Photo(s) of test setup PKM electronic GmbH, Ohmstrasse 1, 84160 Frontenhausen Tel.: + 49 (0) 8732 – 6381 - Fax: + 49 (0) 8732 – 2345 - e-mail: [email protected] - Website: www.pkm.eu.com o:\international applications\fcc-ic-applications via tcb\identec\i-port_usb_bt fcc document\update_2015-06-15\photos test setup.docx page 1 of 3 Conducted emission measurements receving/transmitting USB connected to PC tested frequency range 150 kHz – 30 MHz EUT EUT Attachment to Test-Report-No.: 14/01-0047 Photo(s) of test setup PKM electronic GmbH, Ohmstrasse 1, 84160 Frontenhausen Tel.: + 49 (0) 8732 – 6381 - Fax: + 49 (0) 8732 – 2345 - e-mail: [email protected] - Website: www.pkm.eu.com o:\international applications\fcc-ic-applications via tcb\identec\i-port_usb_bt fcc document\update_2015-06-15\photos test setup.docx page 2 of 3 Radiated emission measurements transmitting frequency range 9 kHz – 30 MHz receving/transmitting USB connected to PC tested frequency range 30 MHz – 1000 MHz receving/transmitting USB connected to PC tested frequencies above 1 GHz (according to ANSI C63.10-2009) EUT EUT EUT Attachment to Test-Report-No.: 14/01-0047 Photo(s) of test setup PKM electronic GmbH, Ohmstrasse 1, 84160 Frontenhausen Tel.: + 49 (0) 8732 – 6381 - Fax: + 49 (0) 8732 – 2345 - e-mail: [email protected] - Website: www.pkm.eu.com o:\international applications\fcc-ic-applications via tcb\identec\i-port_usb_bt fcc document\update_2015-06-15\photos test setup.docx page 3 of 3 receving/transmitting tested frequencies above 1 GHz (according to ANSI C63.10-2013) receving/transmitting USB connected to PC EUT
