OO4-ILR-IB350LWWristband Active Transponder Tag

ILR 350 Series i-B350L W, Wristband Tag Installation and Operation Manual PRELIMINARY VISIBILITY DELIVERED. PAGE 2 OF 21 Proprietary Notice This document contains confidential information proprietary to IDENTEC SOLUTIONS and may not be used or disclosed to other parties in whole or in part without prior written authorization from IDENTEC SOLUTIONS. Disclaimer and Limitation of Liability IDENTEC SOLUTIONS AG and its affiliates, subsidiaries, officers, directors, employees and agents do not make any express or implied warranties or representations with respect to such information including, without limitation, warranties as to non-infringement, reliability, suitability for a particular purpose and accuracy. IDENTEC SOLUTIONS shall not under any circumstances be liable to any person for any special, incidental, indirect or consequential damages, including without limitation, damages resulting from use of or reliance on information presented herein, or loss of profits or revenues or costs of replacement goods, even if informed in advance of the possibility of such damages. Trademarks ―IDENTEC SOLUTIONS‖, ―Intelligent Long Range‖, ―ILR‖ and the stylized ―i‖ are registered trademarks and ―i-Q‖, ―i-D‖, ―i-B‖, ―i-CARD‖, ―i-PORT‖, ―i-LINKS‖, ―Visibility Delivered‖ are trademarks of IDENTEC SOLUTIONS, Inc. and/or IDENTEC SOLUTIONS AG. Copyright Notice Copyright © 2011 IDENTEC SOLUTIONS. All rights reserved. No part of this document may be reproduced or transmitted in any form by any means, photographic, electronic, mechanical or otherwise, or used in any information storage and retrieval system, without the prior written permission of IDENTEC SOLUTIONS. Issue 1 / August 2011 – 29. September 2011 – IDENTEC SOLUTIONS AG, Millennium Park 2, 6890 Lustenau, Austria Phone: +43 5577 87387- 0, Fax: +43 5577 87387-15 E-Mail: [email protected] www.identecsolutions.com Subject to alteration without prior notice. VISIBILITY DELIVERED. PAGE 3 OF 21 © Copyright IDENTEC SOLUTIONS 2010 IDENTEC SOLUTIONS is the responsible party for the compliance of the following devices: MODELS: i-B350L W, i-B350L W-PB Region/Country Organization Marking EUROPE: EC CE USA FCC FFC ID OO4-ILR-IB350LW Canada Industry Canada IC: 3538A-IB350LW European Notification according R&TTE Directive This equipment complies to Art. 6.4 of R&TTE Directive (1999/5/EC). It is tested for compliance with the following standards: ETSI EN 300 220, ETSI EN 301 489, EN 60950 USA Notification This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The user(s) of these products are cautioned to only use accessories and peripherals approved, in advance, by IDENTEC SOLUTIONS. The use of accessories and peripherals, other than those approved by IDENTEC SOLUTIONS, or any changes or modifications not expressly approved by the party responsible for compliance could void the users’ authority to operate the equipment. The device has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. VISIBILITY DELIVERED. PAGE 4 OF 21 Contents 1 INTRODUCTION ............................................................................................................ 5 1.1 PRE PARATIONS ............................................................................................................... 5 1.2 RECOMMENDED PROCEDURE .............................................................................................. 5 1.3 SCOPE OF THIS DOCUMENT ................................................................................................ 5 1.4 RESPONSIBILITY ............................................................................................................. 5 1.5 ASSOCIATED DOCUMENTS ................................................................................................. 5 1.6 SCOPE OF DELIVERY—VISUAL INSPECTION ............................................................................ 5 2 SAFETY PRECAUTIONS ................................................................................................. 6 3 GENERAL ....................................................................................................................... 8 3.1 OPTICAL IDENTIFICATION OF THE TAG ................................................................................. 8 3.2 ACCESSORIES ................................................................................................................. 9 4 CONFIGURATION OF THE TAG .................................................................................... 10 4.1 PING RATE .................................................................................................................. 11 4.2 BURSTS WHEN PASSING A POSITION MARKER ....................................................................... 11 4.3 BURSTS TRIGGERED BY THE PUSH BUTTON .......................................................................... 11 4.4 LIMITATIONS OF THE USER DATA FIELD .............................................................................. 11 4.5 INFORMATION ON BURST SETTINGS ................................................................................... 12 5 TAG MOUNTING TECHNIQUES ....................................…

Text truncated - open the document above for the full version.

TÜV SÜD Product Service GmbH • Äußere Frühlingstr. 45 • 94315 Straubing • Deutschland Handelsregister München HRB 85742 Id.-Nr.: DE 129484267 Bankverbindung: HypoVereinsbank München Kto. 48 852 211 • BLZ 700 202 70 Aufsichtsratsvorsitzender: Dirk Eilers Geschäftsführer: Joachim Birnthaler (Sprecher) Dr. Jens Butenandt Tel: 09421-5522-0 Fax: 09421-5522-99 www.tuev-sued.de TÜV SÜD Product Service GmbH Äußere Frühlingstraße 45 94315 Straubing Deutschland PHOENIX TESTLAB GmbH Product Certification Königswinkel 10 D-32825 Blomberg Long/Short term Confidentiality Request 2012-06-09 FCC ID: OO4-ILR-IB350LW To whom it may concern, Pursuant to sections 0.457(d) and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, we hereby request long- term confidential treatment of information accompanying this application as outlined below: Schematics Parts List Block Diagram Tune-Up Info Operational Description In addition we hereby request the following exhibits contained in this application to be tempo- rarily (short-term confidentilality) withheld from the public disclosure for an initial period of days until: not applicable External Photos Test Setup Photos Internal Photos Users Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and pro- vide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457(d), disclosure of this application and all accompanying documentation will not be made before the date of the GRANT for this applica- tion. Thank you for your attention in this matter. TÜV SÜD Product Service GmbH Johann Roidt Laboratory Manager

i-B350LW Optional Configuration 8/2/2012 1.1.1 i-B350LW Optional Configuration.doc Daniel Egger Page 1/1 i-B350L Tags Optional Configuration The tag i-B350LW is offered with following options: Table of hardware configuration Tag Crystal Frequency Additional Hardware Internal Antenna Replaceble battery i-B350L W 13.346 MHz 125kHz Marker functionality X No i-B350L W-PB 13.346 MHz 125kHz Marker functionality and Push Button X No The table shows the differences of i-B350 tag family. For testing and certification purposes the i-B350L W-PB represents also i-B350L W because it is an superset of these 2 tags The tags i-B350L W and i-B350L W-PB have the same FCC ID OO4-ILR-IB350LW and for Canada IC:3538A-IB350LW.

FCC ID OO4-ILR-IB350LW IC: 3538A-IB350LW FCC ID OO4-ILR-IB350LW IC: 3538A-IB350LW

FCC ID OO4-ILR-IB350LW IC: 3538A-IB350LW

FCC ID OO4-ILR-IB350LW IC: 3538A-IB350LW

FCC ID OO4-ILR-IB350LW IC: 3538A-IB350LW FCC ID OO4-ILR-IB350LW IC: 3538A-IB350LW FCC ID OO4-ILR-IB350LW IC: 3538A-IB350LW FCC ID OO4-ILR-IB350LW IC: 3538A-IB350LW FCC ID OO4-ILR-IB350LW IC: 3538A-IB350LW FCC ID OO4-ILR-IB350LW IC: 3538A-IB350LW

Note: The test data of this report is related only to the individual item which has been tested. This report shall not be reproduced except in full extent without the written approval of the testing laboratory. Trade Register Straubing HRB 9302 V.A.T. DE 131457658 Information pursuant to Section 2(1) DL-InfoV (Germany) at www.tuev-sued.com/imprint Managing Director: Johann Roidt Phone: +49 9421 55 22-0 Fax: +49 9421 55 22-99 www.tuev-sued.de/senton TÜV SÜD SENTON GmbH Äußere Frühlingstraße 45 94315 Straubing Germany Prüfbericht / Test Report Nr. / No. 69861-04041-5 (Edition 3) Applicant: IDENTEC Solutions AG Type of equipment: Active Transponder Tag Type designation: i-B350L Wristband Order No.: 1130378 Test standards: FCC Code of Federal Regulations, CFR 47, Part 15, Sections 15.107, 15.109, 15.205, 15.207, 15.215 and 15.249 Industry Canada Radio Standards Specifications RSS-GEN Issue 3, Sections 6.2, 7.2.2, 7.2.4 and RSS-210 Issue 8, Section A2.9 (Category I Equipment) February 8, 2012 Page 1 of 49 TÜV SÜD SENTON GmbH Äußere Frühlingstraße 45 94315 Straubing Germany Phone: +49 9421 5522-0 Fax: +49 9421 5522-99 Web: www.tuev-sued.de/senton Test Report No. 69861-04041-5 (Edition 3) Page 2 of 49 Pages Table of Contents 1 Description of the Equipment Under Test (EUT) ............................................................ 3 2 Administrative Data ........................................................................................................ 4 3 Identification of the Test Laboratory ............................................................................... 5 4 Summary ........................................................................................................................ 6 5 Operation Mode and Configuration of EUT .................................................................... 7 6 Measurement Procedures .............................................................................................. 8 6.1 Bandwidth Measurements........................................................................................ 8 6.2 Radiated Emission Measurement 9 kHz to 30 MHz ................................................. 9 6.3 Radiated Emission in Fully or Semi Anechoic Room ............................................. 11 6.4 Radiated Emission at Alternative Test Site ............................................................ 13 7 Photographs Taken During Testing .............................................................................. 15 8 Test Results for Transmitter ......................................................................................... 19 8.1 Occupied Bandwidth .............................................................................................. 21 8.2 Bandwidth of the Emission ..................................................................................... 25 8.3 Designation of Emissions ....................................................................................... 27 8.4 Restricted Bands of Operation ............................................................................... 28 8.5 Radiated Emission Measurement 9 kHz to 30 MHz .............................................. 30 8.6 Radiated Emission Measurement 30 MHz to 10 GHz ........................................... 32 8.7 Exposure of Humans to RF Fields ......................................................................... 44 9 Referenced Regulations ............................................................................................... 46 10 Test Equipment List with Calibration Data .................................................................... 48 11 Revision History ........................................................................................................... 49 TÜV SÜD SENTON GmbH Äußere Frühlingstraße 45 94315 Straubing Germany Phone: +49 9421 5522-0 Fax: +49 9421 5522-99 Web: www.tuev-sued.de/senton Test Report No. 69861-04041-5 (Edition 3) Page 3 of 49 Pages 1 Description of the Equipment Under Test (EUT) General data of EUT Type designation 1 : i-B350L Wristband Parts 2 : Serial number(s): 0.777.000.004 Manufacturer: IDENTEC Solutions AG Type of equipment: Active Transponder Tag Version: As received FCC ID: OO4-ILR-IB350LW Additional parts/accessories: Technical data of EUT Application frequency range: 902 - 928 MHz Frequency range: 919 MHz, 920 MHz Operating frequency: 919 MHz, 920 MHz Type of modulation: FSK Pulse train: --- Pulse width: --- Number of RF-channels: 2 Channel spacing: 1 MHz Designation of emissions 3 : 2M82F1D Type of antenna: Integrated on printed board Size/length of antenna: 2 x 1 cm Connection of antenna: detachable not detachable Type of power supply: Battery supply Specifications for power supply: nominal voltage: 3.00 V 1 Type designation of the system if EUT consists of more than one part. 2 Type designations of the parts of the system, if applicable. 3 Also known as "Class of Emission". TÜV SÜD SENTON GmbH Äußere Frühlingstraße 45 94315 Straubing Germany Phone: +49 9421 5522-0 Fax: +49 9421 5522-99 Web: www.tuev-sued.de/senton Test Report No. 69861-04041-5 (Edition 3) Page 4 of 49 Pages 2 Administrative Data Application details Applicant (full address): IDENTEC Solutions AG Millennium Park 2, A-6890 Lustenau, Österreich Contact person: Herr Daniel Egger Order number: 1130378 Receipt of EUT: 05 October 2011 Date(s) of test: January 2012 Note(s): Report details Report number: 69861-04041-5 Edition: 3 Issue date: 08 February 2012 TÜV SÜD SENTON GmbH Äußere Frühlingstraße 45 94315 Straubing Germany Phone: +49 9421 5522-0 Fax: +49 9421 5522-99 Web: www.tuev-sued.de/senton Test Report No. 69861-04041-5 (Edition 3) Page 5 of 49 Pages 3 Identification of the Test Laboratory Details of the Test Laboratory Company name: TÜV SÜD SENTON GmbH Address: Aeussere Fruehlingstrasse 45 D-94315 Straubing Germany Laboratory accreditation: DAR-Registration No. DAT-PL-171/94-03 FCC test site registration number…
