OO4-ILR-IQ8TActive Tag

FCC-ID: 004-ILR-IQ8T

Page 1 of 43 Pages EMI/EMC-TestcenterEMV-Prüfzentrum Straubing, September 21, 1999 T E S T - R E P O R T No. 55411-90508 for IQ8T-S/A Transceiver (916.65 MHz) Applicant:Identec Solutions GmbH & Co. Purpose of testing:To show compliance with FCC Code of Federal Regulations, Part 15 Subpart C, Section §15.249 Note: The test data of this report relate only to the individual item which has been tested. This report shall not be reproduced except in full extent without the written approval of the testing laboratory. FCC-ID: 004-ILR-IQ8TTest Report No. 55411-90508 Page 2 of 43 Pages EMI/EMC-TestcenterEMV-Prüfzentrum Table of Contents 1. Administrative Data ....................................................................................3 2. Summary of Test Results ...........................................................................4 3. Operation Mode of EUT..............................................................................5 4. Configuration of EUT and Peripheral Devices............................................6 4.1. Radiated Emission 30 MHz - 1 GHz (FCC §15.205.a,b, §15.209, §15.249) ..................................................................................7 4.2. Radiated Emission 1 GHz - 10 GHz (FCC §15.205.a,b, §15.209, §15.249) ..................................................................................9 5. Equipment List..........................................................................................11 6. Photographs Taken During Testing..........................................................13 7. List of Measurements ...............................................................................17 7.1. List of Measurements According To FCC Part 15 Subpart C...............18 8. Referenced Regulations ...........................................................................19 9. Test Results..............................................................................................20 FCC-ID: 004-ILR-IQ8TTest Report No. 55411-90508 Page 3 of 43 Pages EMI/EMC-TestcenterEMV-Prüfzentrum 1.Administrative Data Equipment Under Test (EUT): IQ8T-S/A Serial number:098.000.xxx.xxx Type of equipment:Transceiver (916.65 MHz) Parts/accessories:--- FCC-ID: Applicant:Identec Solutions GmbH & Co. (full address)Montafonerstraße 8 A-6780 Schruns Contract identification:--- Contact person:Mr. Wilhelm Gantner Manufacturer:Identec Solutions GmbH & Co. Receipt of EUT:August 09, 1999 Date of test:August 09, 1999 Note:During testing EUT was called "IQ8T-S/A" Test Laboratory:Senton GmbH EMI/EMC Test Center (full address):Aeussere Fruehlingstrasse 45 D-94315 Straubing Germany Contact person:Mr. Johann Roidt FCC file number:31040/SIT 1300F2 Responsible for testing:Rupert Kohlhäufl Responsible for test report:Rupert Kohlhäufl FCC-ID: 004-ILR-IQ8TTest Report No. 55411-90508 Page 4 of 43 Pages EMI/EMC-TestcenterEMV-Prüfzentrum 2.Summary of Test Results The tested sample complies with the requirements set forth in the Code of Regulations Part 15 Subpart C, Section §15.249 (intentional radiators) of the Federal Communication Commission (FCC) Johann RoidtRupert Kohlhäufl Technical ManagerTest Engineer FCC-ID: 004-ILR-IQ8TTest Report No. 55411-90508 Page 5 of 43 Pages EMI/EMC-TestcenterEMV-Prüfzentrum 3.Operation Mode of EUT EUT is transmitting continuously with modulation, supplied by battery (3.6 V DC) FCC-ID: 004-ILR-IQ8TTest Report No. 55411-90508 Page 6 of 43 Pages EMI/EMC-TestcenterEMV-Prüfzentrum 4.Configuration of EUT and Peripheral Devices Configuration of EUT EUT is configured as stand-alone device Configuration of cables of EUT Not applicable Configuration of peripheral devices connected to EUT Not applicable FCC-ID: 004-ILR-IQ8TTest Report No. 55411-90508 Page 7 of 43 Pages EMI/EMC-TestcenterEMV-Prüfzentrum 4.1. Radiated Emission 30 MHz - 1 GHz (FCC §15.205.a,b, §15.209, §15.249) Radiated emissions are measured over the frequency range from 30 MHz to 1 GHz. The bandwidth of the EMI-receiver is set to 120 kHz and the detector- function is set to CISPR quasi-peak. The test setup is made in accordance with ANSI C63.4-1992. Measurements are made in both the horizontal and vertical planes of polarization. Preliminary scans are taken in a semi-anechoic room using a spectrum analyzer with the detector function set to peak. Hand-held or body-worn devices are rotated through three orthogonal axes to determine which attitude and configuration produces the highest emission relative to the limit and therefore shall be used for final testing. All tests are performed at a test-distance of 3 meters. For final testing an open-area test-site is used. During the tests the EUT is rotated all around and the receiving-antenna is raised and lowered from 1 meter to 4 meters to find the maximum levels of emissions. The cables and equipment is placed and moved within the range of position likely to find their maximum emissions. See figure 1 for the measurement setup. Test equipment used (see equipment list for details): 01, 02, 05, 12, 38, 39, 40, 41, 58, 61, 64, 66 FCC-ID: 004-ILR-IQ8TTest Report No. 55411-90508 Page 8 of 43 Pages EMI/EMC-TestcenterEMV-Prüfzentrum test-distance 3 m 4 5 5 3 1 2 Figure 1: Measurement setup for radiated emission test below 1 GHz 1 Transmitter (EUT) 4 Measurement antenna 2 Wooden pedestal (if necessary) 5 Test receiver 3 Wooden table 6 Turn table FCC-ID: 004-ILR-IQ8TTest Report No. 55411-90508 Page 9 of 43 Pages EMI/EMC-TestcenterEMV-Prüfzentrum 4.2. Radiated Emission 1 GHz - 10 GHz (FCC §15.205.a,b, §15.209, §15.249) Radiated emissions are measured in the frequency range 1 GHz to 10 GHz. Resolution and video bandwidth of the spectrum analyzer are set to 1 MHz. Hand-held or body-worn devices are rotated through three orthogonal axes to determine which attitude and configuration produces the highest emission relative to the limit and therefore shall be used for final testing. Additional measurements are performed at critical frequencies with reduced span. E…
