OO9P729WIRELESS GAMING MOUSE

Covered Equipment Certification Attestation Letter DATE: July 31, 2026 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: OO9P729 G.Tech Technology Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. This includes certifying that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. G.Tech Technology Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Sulia Li Title: Certified Associate Company Name: G.Tech Technology Ltd.

Designation of U.S. Agent for Service of Process Certification Attestation Letter DATE: 31 July 2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA FCC ID: OO9P729 ATTENTION: FCC Certification – Section 2.911(d)(7) Information G.Tech Technology Ltd. as required by section 2.911(d)(7), designate below contact located in the United States for purposes of acting as the applicant’s agent for service of process. The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation or the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Signed: Designated U.S. Agent Signed: Signed:_________________________ Signed:__________________________ Printed name: Sulia Li Printed name: Gigi Liu Title: Certified Associate Title: CEO Company Name: G.Tech Technology Ltd. FRN: 0009193962 Email: [email protected] TEL: 86-756-3393795 FAX: 86-756-3393338 Address: No.8, Jinyuan 1st Road, Tangjiawan Town High-tech Zone, Zhuhai, 519085, China Company Name: ASUS COMPUTER INTERNATIONAL FRN: 0033432428 Email: [email protected] TEL: (510) 399-9138 FAX: (510) 6084555 Address: 48720 Kato Road, Fremont, CA 94538, United States

Declaration of Authorization We Name: G.Tech Technology Ltd. Address: No.8, Jinyuan 1st Road, Tangjiawan Town, High-tech Zone City: Zhuhai, 519085 Country: China Declare that: Name Representative of agent: Stanley Wu Agent Company name: DEKRA Testing and Certification Co., Ltd. Address: No. 26, Huaya 1 st Rd., Guishan Dist., City: Taoyuan City 333411 Country: Taiwan. is authorized to apply for FCC Certification of the following product(s): Product description: WIRELESS GAMING MOUSE Type designation: P729 FCC ID: OO9P729 Trademark: ASUS on our behalf. ----------------------------------- Sulia Li / Certified Associate G.Tech Technology Ltd.

Date: July 31, 2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Confidentiality Request regarding application for certification of FCC ID: OO9P729 Pursuant to FCC 47 CFR 0.457(d) and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: Type of Confidentiality Requested Exhibit ☒ Permanent Block Diagrams ☒ Permanent Operation Description ☐ Permanent Tune up procedure ☒ Permanent Schematics ☐ Permanent BOM List The above materials contain trade secrets and proprietary information not customarily Released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Type of Confidentiality Requested Exhibit ☒ Short Term External Photos ☒ Short Term Internal Photos ☒ Short Term Test Setup Photos ☒ Short Term User’s Manual Note: Release date of short term confidentiality is Sep. 01, 2026. (FCC must be informed when marketing begins earlier.) Sincerely, Name: Sulia Li Email: [email protected] Signature:

Report No.: 2660287R-SAUSV01S-A Page: 1 of 25 Test report No.: 2660287R-SAUSV01S-A SAR Test Report Product Name WIRELESS GAMING MOUSE Trademark ASUS Model and /or type reference P729 Applicant ́s name / address G.Tech Technology Ltd. No.8, Jinyuan 1st Road, Tangjiawan Town High-tech Zone, Zhuhai, 519085, China Manufacturer ́s name ASUSTeK COMPUTER INC. FCC ID OO9P729 Applicable Standard IEEE 1528-2013 KDB 447498 D01 v06 KDB 865664 D01 v01r04 Test Result Max. SAR Measurement (1g) 2.4 GHz: 0.045 W/kg Verdict Summary IN COMPLIANCE Documented By (Supervisor / Jinn Chen) Te s t e d B y (Senior Engineer / Luke Cheng) Approved By (Assistant Manager / San Lin) Date of Receipt 2026/06/08 Date of Issue 2026/08/05 Report Version V1.0 Report No.: 2660287R-SAUSV01S-A Page: 2 of 25 INDEX Page 1. General Information ........................................................................................................ 5 1.1 EUT Description ................................................................................................. 5 1.2 Antenna List ....................................................................................................... 5 1.3 SAR Test Exclusion Calculation ......................................................................... 6 1.4 Test Environment ................................................................................................ 7 1.5 Measurement procedures................................................................................... 8 2. SAR Measurement System ............................................................................................. 9 2.1 DASY System Description .................................................................................. 9 2.2 Area Scans ....................................................................................................... 10 2.3 DASY E-Field Probe ......................................................................................... 11 2.4 DATA Acquisition Electronics (DAE) and Measurement Server ........................ 12 2.5 Robot ................................................................................................................ 13 2.6 Device Holder ................................................................................................... 13 2.7 Phantom ........................................................................................................... 14 3. Tissue Simulating Liquid .............................................................................................. 15 3.1 The composition of the tissue simulating liquid ................................................ 15 3.2 Tissue Calibration Result .................................................................................. 15 3.3 Tissue Dielectric Parameters for Phantoms ..................................................... 16 4. Measurement Procedure ............................................................................................... 17 4.1 SAR System Check .......................................................................................... 17 4.2 SAR Measurement Procedure .......................................................................... 18 5. RF Exposure Limits ....................................................................................................... 19 6. Test Equipment List ...................................................................................................... 20 7. Measurement Uncertainty ............................................................................................. 22 8. Conducted Power Measurement (Including tolerance allowed for production unit) ................................................................................................................................ 23 9. Test Results ................................................................................................................... 24 9.1 Test Results Summary ..................................................................................... 24 Appendix A. System Check Data Appendix B. Highest measurement Data Appendix C. Test Setup Photographs Appendix D. Probe Calibration Data Appendix E. Dipole & Source Calibration Appendix F. Product Photos-Please refer to the file: 2660287R-Product Photos Report No.: 2660287R-SAUSV01S-A Page: 3 of 25 Competences and Guarantees DEKRA is a testing laboratory competent to carry out the tests described in this report. In order to assure the traceability to other national and international laboratories, DEKRA has a calibration and maintenance program for its measurement equipment. DEKRA guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated in the report and it is based on the knowledge and technical facilities available at DEKRA at the time of performance of the test. DEKRA is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Test Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA. General conditions 1. The test results relate only to the samples tested. 2. The test results shown in the test report are traceable to the national/international standard through the calibration report of the equipment and evaluated measurement uncertainty herein. 3. This report must not be used to claim product endorsement by TAF or any agency of the government. 4. The test report shall not be reproduced without the written approval of DEKRA Testing and Certification Co., Ltd. 5. Measurement uncertainties evaluated for each testing system and associated co…

Text truncated - open the document above for the full version.

Report No.: 2660287R-SAUSV01S-A Page: 1 of 2 Appendix A. System Check Data Report No.: 2660287R-SAUSV01S-A Page: 2 of 2 Test Laboratory: DEKRA Date: 2026/07/07 System Performance Check_2450MHz-Head-1 Communication System: UID 0, CW; Frequency: 2450 MHz Communication System PAR: 0 dB Medium parameters used: f = 2450 MHz; σ = 1.78 S/m; ε r = 40.18; ρ = 1000 kg/m 3 Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2011) DASY Configuration: • Probe: EX3DV4 - SN7631; ConvF(8.01, 7.42, 7.22) @ 2450 MHz; Calibrated: 2026/02/20 • Sensor-Surface: 1.4mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1651; Calibrated: 2026/02/16 • Phantom: ELI V8.0; Type: QD OVA 004 AA; Serial: 2139 • Measurement SW: DASY52, Version 52.10 (4); Configuration/2450MHz_Head/Area Scan (10x10x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 16.2 W/kg Configuration/2450MHz_Head/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 101.0 V/m; Power Drift = -0.05 dB Peak SAR (extrapolated) = 23.1 W/kg SAR(1 g) = 12.3 W/kg; SAR(10 g) = 6.06 W/kg Smallest distance from peaks to all points 3 dB below = 9 mm Ratio of SAR at M2 to SAR at M1 = 55.6% Maximum value of SAR (measured) = 19.2 W/kg

Report No.: 2660287R-SAUSV01S-A Page: 1 of 3 Appendix B. Highest Measurement Data Report No.: 2660287R-SAUSV01S-A Page: 2 of 3 Test Laboratory: DEKRA Date: 2026/07/07 1_RF 2.4GHz_2.4G Wireless-2M_CH38_Back_0mm_ANT Main Communication System: UID 0, RF 2.4G; Frequency: 2478 MHz Communication System PAR: 0 dB Medium parameters used: f = 2478 MHz; σ = 1.81 S/m; ε r = 40.07; ρ = 1000 kg/m 3 Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2011) DASY Configuration: • Probe: EX3DV4 - SN7631; ConvF(8.01, 7.42, 7.22) @ 2478 MHz; Calibrated: 2026/02/20 • Sensor-Surface: 1.4mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1651; Calibrated: 2026/02/16 • Phantom: ELI V8.0; Type: QD OVA 004 AA; Serial: 2139 • Measurement SW: DASY52, Version 52.10 (4); Configuration/Flat/Area Scan (10x12x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 0.0279 W/kg Configuration/Flat/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 2.370 V/m; Power Drift = -0.02 dB Peak SAR (extrapolated) = 0.0450 W/kg SAR(1 g) = 0.021 W/kg; SAR(10 g) = 0.00921 W/kg Smallest distance from peaks to all points 3 dB below: Larger than measurement grid (> 15 mm) Ratio of SAR at M2 to SAR at M1 = 47.3% Maximum value of SAR (measured) = 0.0350 W/kg Report No.: 2660287R-SAUSV01S-A Page: 3 of 3 Test Laboratory: DEKRA Date: 2026/07/07 10_Bluetooth_BLE-1M_CH39_Back_0mm_ANT Main Communication System: UID 0, BT 1M&3M&BLE; Frequency: 2480 MHz Communication System PAR: 0 dB Medium parameters used: f = 2480 MHz; σ = 1.81 S/m; ε r = 40.05; ρ = 1000 kg/m 3 Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-201 1) DASY Configuration: • Probe: EX3DV4 - SN7631; ConvF(8.01, 7.42, 7.22) @ 2480 MHz; Calibrated: 2026/02/20 • Sensor-Surface: 1.4mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1651; Calibrated: 2026/02/16 • Phantom: ELI V8.0; Type: QD OVA 004 AA; Serial: 2139 • Measurement SW: DASY52, Version 52.10 (4); Configuration/Flat/Area Scan (10x12x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 0.0410 W/kg Configuration/Flat/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 2.544 V/m; Power Drift = -0.06 dB Peak SAR (extrapolated) = 0.0710 W/kg SAR(1 g) = 0.034 W/kg; SAR(10 g) = 0.016 W/kg Smallest distance from peaks to all points 3 dB below: Larger than measurement grid (> 15 mm) Ratio of SAR at M2 to SAR at M1 = 49% Maximum value of SAR (measured) = 0.0575 W/kg

Appendix D. Probe Calibration

Appendix E. Dipole & Source Calibration

Report No.: 2660287R-RFUSV01S-C Page: 1 of 22 Test Report No: 2660287R-RFUSV01S-C TEST REPORT FCC Rules & Regulations Product Name WIRELESS GAMING MOUSE Brand Name ASUS Model No. P729 FCC ID OO9P729 Applicant ́s Name / Address G.Tech Technology Ltd. No.8, Jinyuan 1st Road, Tangjiawan Town High-tech Zone, Zhuhai, 519085, China Manufacturer’s Name ASUSTeK COMPUTER INC. Test Method Requested, Standard FCC CFR Title 47 Part 15 Subpart C Section 15.247 Verdict Summary IN COMPLIANCE Documented By Jinn Chen Approved By Alan Chen Date of Receipt 2026/06/08 Date of Issue 2026/07/23 Report Version V1.0 Report No.: 2660287R-RFUSV01S-C Page: 2 of 22 INDEX page Competences and Guarantees ................................................................................................................................ 4 General Conditions .................................................................................................................................................. 4 Revision History ....................................................................................................................................................... 5 Summary of Test Result .......................................................................................................................................... 6 1. General Information .................................................................................................................................. 7 1.1. EUT Description ....................................................................................................................................... 7 1.2. EUT Information ....................................................................................................................................... 8 1.3. Testing Applied Standards ........................................................................................................................ 8 1.4. Testing Location Information .................................................................................................................... 9 1.5. Ambient Conditions In The Laboratory ................................................................................................... 10 1.6. Measurement Uncertainty ...................................................................................................................... 10 1.7. List of Test Equipment ............................................................................................................................ 11 2. Test Configuration of EUT ...................................................................................................................... 12 2.1. Test Condition ......................................................................................................................................... 12 2.2. Test Frequency Mode ............................................................................................................................. 12 2.3. Duty Cycle .............................................................................................................................................. 12 2.4. Measurement Configuration ................................................................................................................... 13 2.5. Tested System Details ............................................................................................................................ 14 2.6. Configuration of Tested System ............................................................................................................. 14 3. AC Power Line Conducted Emission ..................................................................................................... 15 3.1. Test Setup ............................................................................................................................................... 15 3.2. Test Limit ................................................................................................................................................ 15 3.3. Test Procedure ....................................................................................................................................... 15 3.4. Test Result of AC Power Line Conducted Emission ............................................................................... 15 4. Occupied Bandwidth & DTS Bandwidth ................................................................................................. 16 4.1. Test Setup ............................................................................................................................................... 16 4.2. Test Limit ................................................................................................................................................ 16 4.3. Test Procedures ...................................................................................................................................... 16 4.4. Test Result of Occupied Bandwidth & DTS Bandwidth .......................................................................... 16 5. Maximum Peak Conducted Output Power ............................................................................................. 17 5.1. Test Setup ............................................................................................................................................... 17 5.2. Test Limit ................................................................................................................................................ 17 5.3. Test Procedures ...................................................................................................................................... 17 5.4. Test Result of Maximum Peak Conducted Output Power ...................................................................... 17 6. Maximum Power Spectral Density ............................................................…

Text truncated - open the document above for the full version.

Report No.: 2660287R-RFUSV01S-C Page : 1 of 17 Appendix A. Test Result of AC Power Line Conducted Emission TX_4M_2440MHz_Line TX_4M_2440MHz_Neutral Report No.: 2660287R-RFUSV01S-C Page : 2 of 17 Appendix B. Test Result of Occupied Bandwidth & DTS Bandwidth Modulation Frequency (MHz) 99% Occupied Bandwidth (MHz) DTS Bandwidth (MHz) Limit (MHz) 99% Occupied Bandwidth DTS Bandwidth GFSK (4Mbps) 2404 4.18 1.84 - ≧ 0.5 2440 4.19 1.87 - ≧ 0.5 2478 4.20 2.07 - ≧ 0.5 Report No.: 2660287R-RFUSV01S-C Page : 3 of 17 For 99% Occupied Bandwidth: GFSK/4M/2404MHz/Ch1/Ant.1 GFSK/4M/2440MHz/Ch19/Ant.1 GFSK/4M/2478MHz/Ch38/Ant.1 Report No.: 2660287R-RFUSV01S-C Page : 4 of 17 For DTS Bandwidth: GFSK/4M/2404MHz/Ch1/Ant.1 GFSK/4M/2440MHz/Ch19/Ant.1 GFSK/4M/2478MHz/Ch38/Ant.1 Report No.: 2660287R-RFUSV01S-C Page : 5 of 17 Appendix C. Test Result of Maximum Peak Conducted Output Power Modulation Frequency (MHz) Maximum Peak Conducted Output Power (dBm) Limit (dBm) Result GFSK (4Mbps) 2404 6.59 30.00 Pass 2440 6.44 30.00 Pass 2478 6.63 30.00 Pass Report No.: 2660287R-RFUSV01S-C Page : 6 of 17 Appendix D. Test Result of Maximum Power Spectral Density Modulation Frequency (MHz) Maximum Power Spectral Density (dBm/3kHz) Limit (dBm/3kHz) Result GFSK (4Mbps) 2404 -13.62 8.00 Pass 2440 -14.13 8.00 Pass 2478 -13.88 8.00 Pass Report No.: 2660287R-RFUSV01S-C Page : 7 of 17 GFSK/4M/2404MHz/Ch1/Ant.1 GFSK/4M/2440MHz/Ch19/Ant.1 GFSK/4M/2478MHz/Ch38/Ant.1 Report No.: 2660287R-RFUSV01S-C Page : 8 of 17 Appendix E. Test Result of Antenna Port Conducted Emission GFSK/4M/2404MHz/Ch1/Ant.1 (Ref.) GFSK/4M/2404MHz/Ch1/Ant.1 GFSK/4M/2440MHz/Ch19/Ant.1 (Ref.) GFSK/4M/2440MHz/Ch19/Ant.1 GFSK/4M/2478MHz/Ch38/Ant.1 (Ref.) GFSK/4M/2478MHz/Ch38/Ant.1 Report No.: 2660287R-RFUSV01S-C Page : 9 of 17 GFSK/4M/2404MHz/Ch1/Ant.1(Band Edge) GFSK/4M/2478MHz/Ch38/Ant.1(Band Edge) Report No.: 2660287R-RFUSV01S-C Page : 10 of 17 Appendix F. Test Result of Radiated Emission TX_4M_2404MHz_H TX_4M_2404MHz_V TX_4M_2440MHz_H TX_4M_2440MHz_V Report No.: 2660287R-RFUSV01S-C Page : 11 of 17 TX_4M_2478MHz_H TX_4M_2478MHz_V TX_4M_2440MHz_H TX_4M_2440MHz_V Report No.: 2660287R-RFUSV01S-C Page : 12 of 17 TX_4M_2404MHz_H_Average TX_4M_2404MHz_H_Peak TX_4M_2404MHz_V_Average TX_4M_2404MHz_V_Peak Report No.: 2660287R-RFUSV01S-C Page : 13 of 17 TX_4M_2478MHz_H_Average TX_4M_2478MHz_H_Peak TX_4M_2478MHz_V_Average TX_4M_2478MHz_V_Peak Report No.: 2660287R-RFUSV01S-C Page : 14 of 17 Worst-Case Emissions Above 18 GHz TX_4M_2440MHz_H TX_4M_2440MHz_V

Report No.: 2660287R-RFUSV01S-A Page: 1 of 22 Test Report No: 2660287R-RFUSV01S-A TEST REPORT FCC Rules & Regulations Product Name WIRELESS GAMING MOUSE Brand Name ASUS Model No. P729 FCC ID OO9P729 Applicant ́s Name / Address G.Tech Technology Ltd. No.8, Jinyuan 1st Road, Tangjiawan Town High-tech Zone, Zhuhai, 519085, China Manufacturer’s Name ASUSTeK COMPUTER INC. Test Method Requested, Standard FCC CFR Title 47 Part 15 Subpart C Section 15.247 Verdict Summary IN COMPLIANCE Documented By Jinn Chen Approved By Alan Chen Date of Receipt 2026/06/08 Date of Issue 2026/07/23 Report Version V1.0 Report No.: 2660287R-RFUSV01S-A Page: 2 of 22 INDEX page Competences and Guarantees ................................................................................................................................ 4 General Conditions .................................................................................................................................................. 4 Revision History ....................................................................................................................................................... 5 Summary of Test Result .......................................................................................................................................... 6 1. General Information .................................................................................................................................. 7 1.1. EUT Description ....................................................................................................................................... 7 1.2. EUT Information ....................................................................................................................................... 8 1.3. Testing Applied Standards ........................................................................................................................ 8 1.4. Testing Location Information .................................................................................................................... 9 1.5. Ambient Conditions In The Laboratory ................................................................................................... 10 1.6. Measurement Uncertainty ...................................................................................................................... 10 1.7. List of Test Equipment ............................................................................................................................ 11 2. Test Configuration of EUT ...................................................................................................................... 12 2.1. Test Condition ......................................................................................................................................... 12 2.2. Test Frequency Mode ............................................................................................................................. 12 2.3. Duty Cycle .............................................................................................................................................. 12 2.4. Measurement Configuration ................................................................................................................... 13 2.5. Tested System Details ............................................................................................................................ 14 2.6. Configuration of Tested System ............................................................................................................. 14 3. AC Power Line Conducted Emission ..................................................................................................... 15 3.1. Test Setup ............................................................................................................................................... 15 3.2. Test Limit ................................................................................................................................................ 15 3.3. Test Procedure ....................................................................................................................................... 15 3.4. Test Result of AC Power Line Conducted Emission ............................................................................... 15 4. Occupied Bandwidth & DTS Bandwidth ................................................................................................. 16 4.1. Test Setup ............................................................................................................................................... 16 4.2. Test Limit ................................................................................................................................................ 16 4.3. Test Procedures ...................................................................................................................................... 16 4.4. Test Result of Occupied Bandwidth & DTS Bandwidth .......................................................................... 16 5. Maximum Peak Conducted Output Power ............................................................................................. 17 5.1. Test Setup ............................................................................................................................................... 17 5.2. Test Limit ................................................................................................................................................ 17 5.3. Test Procedures ...................................................................................................................................... 17 5.4. Test Result of Maximum Peak Conducted Output Power ...................................................................... 17 6. Maximum Power Spectral Density ............................................................…

Text truncated - open the document above for the full version.

Report No.: 2660287R-RFUSV01S-A Page : 1 of 22 Appendix A. Test Result of AC Power Line Conducted Emission TX_BLE2M_2440MHz_Line TX_BLE2M_2440MHz_Neutral Report No.: 2660287R-RFUSV01S-A Page : 2 of 22 Appendix B. Test Result of Occupied Bandwidth & DTS Bandwidth Modulation Frequency (MHz) 99% Occupied Bandwidth (MHz) DTS Bandwidth (MHz) Limit (MHz) 99% Occupied Bandwidth DTS Bandwidth GFSK (1Mbps) 2402 1.09 0.72 - ≧ 0.5 2440 1.10 0.72 - ≧ 0.5 2480 1.09 0.71 - ≧ 0.5 GFSK (2Mbps) 2404 2.10 1.36 - ≧ 0.5 2440 2.09 1.31 - ≧ 0.5 2478 2.09 1.31 - ≧ 0.5 Report No.: 2660287R-RFUSV01S-A Page : 3 of 22 For 99% Occupied Bandwidth: GFSK/1MH…
