OPK-S680BLUETOOTH STEREO HEADSET

S680 User Manual Evogue Thunderbirds Series S680 Contents Getting Started S680 ............................................................................ 4 Charging Your Headset ........................................................................ 4 Turning on the Headset ........................................................................ 4 Pairing Your Headset ............................................................................ 5 Wearing Your Headset .......................................................................... 6 Using Your Headset .............................................................................. 7 Transferring a Call ................................................................................ 9 Connected with the last paired device .................................................. 9 Use the 3.5mm stereo music cable ...................................................... 9 Troubleshooting .................................................................................. 10 Safety information .............................................................................. 11 Care and Maintenance Headset ......................................................... 12 Product Specifications ........................................................................ 14 1 Familiar with Your Bluetooth Headset 1. Volume “+” 2. Volume “-” 3. Multi-function Button (MFB) 4. Indicator 5. Charging Jack 6. Next track key 7. Paly/Pause 8. Last track key 9. Microphone 10. Music Cable Faucet 2 S680 Tensile Display Folding Display 14 Product Specifications Bluetooth version: V4.0 + EDR Bluetooth Prefiles supported: Headset, Handsfree, A2DP and AVRCP Frequency: 2400.0 - 2483.5 MHz Nominal Charging Time: 2 -3 hours Talk Time: Up to 15 hours Music Playing Time: Up to 6 hours Standby Time: Up to 180 hours Weight: 0.42 pounds This manual is just for reference. If the specification and design of the product need to be changed, we will do it without notification. If there is some tiny difference between the picture and the real product, please take the real product as correct. Customer Service Website and Return Policy http://www.evogue.us 3 Thank you for selecting Bluetooth headset S680 The S680 lets you listen to stereo music through your Bluetooth - enabled mobile phone or music player, while ensuring you never miss a call. Use the 3.5mm music cable for wired music listening from your MP3 or PC. Folding style is more fashionable and convenient. S680 Bluetooth headset with stylish patent design, perfect construction, stereo R, L model. Let you enjoy the wonderful music. S680 Bluetooth headset is compliant with Bluetooth Version 4.0 + EDR specification, and is compatible with latest mobile phones supporting Bluetooth headset or heads free profiles. 4 Getting Started S 680 To use your S680 Stereo Bluetooth headset, please follow the steps below: 1, Ensure your Bluetooth headset is fully charged; 2, Pair your charged Bluetooth headset with a Bluetooth-enable mobile phone prior to use Bluetooth headset first time, it is suggested that you fully recharge the battery first. Charging Your Headset Rechargeable battery with Micro-USB charging option from AC power supply, PC via USB cable, the batter indicator will turn red when charging. Turning on the Headset Press and hold the MFB for 3 seconds until a "beep" is heard. About paring function, please refer to "Paring Your Headset". 13 Charging Only use the manufacturer supplied charger when charging the headset. Do not disassemble the charger as it may expose you to dangerous voltages and other risks. Incorrect reassembly can cause electric shocks when the headset is subsequently used. Do not sue the charge outdoor or in damp areas. Only charge the headset's built-in battery in accordance with the instructions contained in this user guide. Avoid charging the headset in extreme temperature conditions. Built-in Battery Do not attempt to replace the headset's battery yourself as it is built into the headset and is non-changeable. Charge the battery in accordance with the instructions supplied with this user guide. Compatibility Works with all Bluetooth-enabled phones and PDA. 12 Care and Maintena nce Headset Consider turning your headset off before placing it in your pocket or bag. If the MFB is accidentally activated, your mobile phone may place an unintended call. Do not expose the headset to liquid, moisture or humidity as it is not waterproof. Do not use abrasive cleaning solvents to clean the headset. Do not expose the headset to extreme temperature conditions. The best store temperature range is from -14 to +140°F , otherwise the life of the headset will be influenced. Do not dispose of the headset into the fire as it may cause an explosion. Do not bring your headset into contact with sharp objects as this will cause scratched and damage. Do not attempt to disassemble the headset as it dose not contain serviceable components. If you do not sue the headset for a long periods, be sure to store it in a dry place, free from extreme temperature conditions and dust. 5 Pairing Your Headset The headset works with Bluetooth-enable phones, prior to using and pairing your headset for the first time, please check if your mobile phone is Bluetooth-enable. The pairing instructions for typical Bluetooth-enable mobile phone are explained on the next page. The headset pairing procedure may vary depending on the setting of your mobile phone. Please contact the manufacture of your mobile phone or its agent further information. 1, Press the headset and the mobile phone where they are easily viewable and no more than one meter apart; 2, Ensure the headset is turned off; 3, Please press the MFB 2 second until you heard "Beep" Tone, the blue led long show, the headset being paring; 4, Activate your mobile phones' Bluetooth function, please refer to your mobile phone user guide for details; 5, Set the mobile phone to search for Bluetooth devices wi…

Text truncated - open the document above for the full version.

External Photos

FCC ID: OPK-S680 Label Label Location

Internal Photos

SZ12080056W07 Page 2 of 68 DIRECTORY 1. GENERAL INFORMATION .................................................................................................... 3 1.1. EUT Description ....................................................................................................................... 3 1.2. Test Standards and Results ........................................................................................................ 4 1.3. Facilities and Accreditations ..................................................................................................... 5 2. 47 CFR PART 15C REQUIREMENTS .................................................................................... 6 2.1. Number of Hopping Frequency ................................................................................................ 6 2.2. Peak Output Power.................................................................................................................... 9 2.3. 20dB Bandwidth ..................................................................................................................... 11 2.4. Carried Frequency Separation ................................................................................................. 18 2.5. Time of Occupancy (Dwell time) ........................................................................................... 20 2.6. Conducted Spurious Emissions ............................................................................................... 27 2.7. Band Edge ............................................................................................................................... 38 2.8. Conducted Emission ............................................................................................................... 47 2.9. Radiated Emission................................................................................................................... 50 Change History Issue Date Reason for change 1.0 Aug 31, 2012 First edition SZ12080056W07 Page 3 of 68 1. General Information 1.1. EUT Description EUT Type ............................. : Bluetooth Stereo Headset Serial No. .............................. : (n.a, marked #1 by test site) Hardware Version ................. : REV 6 Software Version .................. : Applicant .............................. : Manufacturer ........................ : 1200807 Shenzhen Kemei Wireless communication Co., Ltd. F/2, Dapengche Building, Zerong industrial park, Huangmabu, Xixiang, Baoan, Shenzhen, Guangdong 518000 China Shenzhen Kemei Wireless communication Co., Ltd. F/2, Dapengche Building, Zerong industrial park, Huangmabu, Xixiang, Baoan, Shenzhen, Guangdong 518000 China Frequency Range .................. : The frequency range used is 2402MHz - 2480MHz (79 channels, at intervals of 1MHz); The frequency block is 2400MHz to 2483.5MHz. Modulation Type .................. : Bluetooth: FHSS (GFSK(1Mbps), ∏/4-DQPSK(EDR 2Mbps), 8-DPSK(EDR 3Mbps)) Antenna Type ........................ : PCB Antenna Antenna Gain ........................ : 0dBi Note 1: The EUT is a Bluetooth Stereo Headset, it contains Bluetooth 2.1 EDR, Bluetooth 4.0 LE Dual Module operating at 2.4GHz ISM band; the frequencies allocated for the Bluetooth Module is F(MHz)=2402+1*n (0<=n<=78). The lowest, middle, highest channel numbers of the Bluetooth Module used and tested in this report are separately 0 (2402MHz), 39 (2441MHz) and 78 (2480MHz). Note 2: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Note 3: a. When power on, the EUT will scan the whole frequency until a Connection command from the other BT devices. b. When receiving the signal from the other BT devices, The EUT transmit aresponse signal. c. The other devices receive the response signal and recognize it, then send a connection command to establish the connection. d. After the connection establish successfully, the data transmission is beginning. At the same time, the both devices will shift frequencies in synchronization per a same pseudo randomly ordered list of hopping frequencies, the hopping rate is1600 times per second. This device conforms to the criteria in FCC Public Notice DA 00-705. e. The bandwidth of the receiver, which is set to a fixed width by the software. SZ12080056W07 Page 4 of 68 1.2. Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart C (Bluetooth, 2.4GHz ISM band radiators) for the EUT FCC ID Certification: No. Identity Document Title 1 47 CFR Part 15 (10-1-09 Edition) Radio Frequency Devices Test detailed items/section required by FCC rules and results are as below: No. Section in CFR 47Description Result 1 15.247(a) Number of Hopping Frequency PASS 2 15.247(b) Peak Output Power PASS 3 15.247(a) 20dB Bandwidth PASS 4 15.247(a) Carrier Frequency Separation PASS 5 15.247(a) Time of Occupancy (Dwell time) PASS 6 15.247(c) Conducted Spurious Emission PASS 7 15.247(c) Band Edge PASS 8 15.207 Conducted Emission PASS 9 15.209 15.247(c) Radiated Emission PASS NOTE: The tests were performed according to the method of measurements prescribed in DA-00-705. SZ12080056W07 Page 5 of 68 1.3. Facilities and Accreditations 1.3.1. Facilities Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L3572. All measurement facilities used to collect the measurement data are located at 3/F, Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen, 518055 P. R. China. The test site is constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22; the FCC registration number is 741109. 1.3.2. Test Environment Conditions During the measurement, the environmental conditions were within the list…

Text truncated - open the document above for the full version.

Test Setup Photos 1. CE 2.RE 3. CSE
