OQ3MAP800-70SRF Power Amplifier

FCC ID: OQ3MAP800-70S A2 Appendix A FCC ID: OQ3MAP800-70S A2

FCC ID: OQ3MAP800-70S A1 Appendix A FCC ID: OQ3MAP800-70S A2 FCC ID: OQ3MAP800-70S A3 FCC ID: OQ3MAP800-70S A4 FCC ID: OQ3MAP800-70S A5 FCC ID: OQ3MAP800-70S A6 FCC ID: OQ3MAP800-70S A7 FCC ID: OQ3MAP800-70S A8 FCC ID: OQ3MAP800-70S A9 FCC ID: OQ3MAP800-70S A10 FCC ID: OQ3MAP800-70S A11 FCC ID: OQ3MAP800-70S A12 FCC ID: OQ3MAP800-70S A13 FCC ID: OQ3MAP800-70S A14 FCC ID: OQ3MAP800-70S A15 Notes: FCC ID: OQ3MAP800-70S A16 Notes: FCC ID: OQ3MAP800-70S A17 Notes: FCC ID: OQ3MAP800-70S A18 Notes: FCC ID: OQ3MAP800-70S A19 Notes:

Hi, We are submitting the exhibits that were requested by correspondence reference Number 19749, FCC ID OQ3MAP800-70S and confirmation number EA100360. If you have any questions, please contact me at [email protected]. Thank You, Bryan Broaddus

Hi, We are submitting the exhibits that were requested by correspondence reference Number 20029, FCC ID OQ3MAP800-70S and confirmation number EA100360. If you have any questions, please contact me at [email protected]. Thank You, Bryan Broaddus

FCC ID: OQ3MAP8900-70S External Photos FCC ID: OQ3MAP8900-70S

FCC ID: OQ3MAP8900-70S FCC ID LABEL RF AMPLIFIER MODEL NO. MAP800-70S VOLTAGE: 27 VDC, 31A PWR OUTPUT: 110W FCC ID: OQ3MAP800-70S SERIAL NO.__________ PARADIGM WIRELESS TECHNOLOGY MADE IN USA NOTES: Label will be constructed of 0.02 inch aluminum as shown on the equipment with permanent adhesive. All information on the label will be etched or stamped. Both methods will exceed the expected lifetime of the equipment. The label will be large enough to allow all information to be legible.

FCC ID: OQ3MAP8900-70S Internal Photos FCC ID: OQ3MAP8900-70S FCC ID: OQ3MAP8900-70S FCC ID: OQ3MAP8900-70S

FCC ID: OQ3MAP800-70S A2 Appendix A FCC ID: OQ3MAP800-70S A2

FCC ID: OQ3MAP800-70S A1 Appendix A FCC ID: OQ3MAP800-70S A2 FCC ID: OQ3MAP800-70S A3 FCC ID: OQ3MAP800-70S A4 FCC ID: OQ3MAP800-70S A5 FCC ID: OQ3MAP800-70S A6 FCC ID: OQ3MAP800-70S A7 FCC ID: OQ3MAP800-70S A8 FCC ID: OQ3MAP800-70S A9 FCC ID: OQ3MAP800-70S A10 FCC ID: OQ3MAP800-70S A11 FCC ID: OQ3MAP800-70S A12 FCC ID: OQ3MAP800-70S A13 FCC ID: OQ3MAP800-70S A14 FCC ID: OQ3MAP800-70S A15 Notes: FCC ID: OQ3MAP800-70S A16 Notes: FCC ID: OQ3MAP800-70S A17 Notes: FCC ID: OQ3MAP800-70S A18 Notes: FCC ID: OQ3MAP800-70S A19 Notes:

FCC ID: OQ3MAP800-70S A2 Appendix A FCC ID: OQ3MAP800-70S A2

FCC ID: OQ3MAP800-70S Parts List FCC ID: OQ3MAP800-70S FCC ID: OQ3MAP800-70S

FCC ID: OQ3MAP800-70S 1 Application for Certification For an RF Power Amplifier Paradigm Wireless Systems Inc. 1672 McGaw Ave. Irvine, CA 92614 RF Power Amplifier: Part # MAP800-70S FCC ID: OQ3MAP800-70S REPORT # RA054914/10100 This report was prepared in accordance with the requirements of the FCC Rules and Regulations Part 2, Subpart J, 2.1031 through 2.1057, Part 22 and Part 90 and other applicable sections of the rules as indicated herein. Prepared By: Fred Gurule DNB Engineering, Inc. 3535 W. Commonwealth Ave. Fullerton, CA 92833 12 FEBRUARY 2001 FCC ID: OQ3MAP800-70S 2 FCC ID: OQ3MAP800-70S 3 TABLE OF CONTENTS Section Title Sheet # 1.0ADMINISTRATIVE DATA3 1.1Certificatio ns a nd Q ua lificatio ns3 1.2Meas ure me nts a nd Repea tab ility Info rma tio n3 Note: Paragraph numbers in this report follow the application section numbers found in the FEDERAL COMMUNICATIONS COMMISSION Rules and Regulations, Part 2, Subpart J for Certification of electronic equipment. 2.1033 (C) (1)Application for Certification4 2.1033 (C) (2)FCC Identifier4 2.1033 (C) (3)Installation and Operating Instructions4 2.1033 (C) (4)Type of Emissions4 2.1033 (C) (10)Schematic Diagram and C ircuit Description5 2.1033 (C) (11)Equipment Identification Plate5 2.1033 (C) (12) Equipment Photographs6 - 12 2.1033 (C) (13)Digital Modulation Techniques13 2.1033 (C) (14)Test Data14 - 17 2.1033 (C) (5)Frequency Range34 2.1033 (C) (6)Operating Power34 2.1033 (C) (7)Maximum Power Allowed in Applicable part(s) of the Rules34 2.1033 (C) (8)Final RF Amplifier Input Power C haracteristics34 2.1033 (C) (9)Tune Up Procedure34 2.1046Measurement of RF Power Output13 2.1049Measurement of Occupied Bandwidth17 - 34 FIGURE 1 :BLOCK DIAGRAM (Occ up ied Ba nd wid th te sts )18 2.1051Spurious Emissions at Antenna Terminals34 - 49 FIGURE 2: BLOCK DIAGRAM (Spurious Emissions tests)36 2.1053Measurement of Field Strength of Spurious Radiation51 - 53 Table 1: Field Strength of Spurious Radiation53 2.1055Measurement of Frequency Stability54 2.1057Frequency Spectrum to be Investigated54 APPENDIX AService/Operating ManualA1 - A18 APPENDIX BSchematicsB1 – B6 FCC ID: OQ3MAP800-70S 4 1.0ADMINISTRATIVE DATA 1.1Certifications and Qualifications I certify that DNB Engineering, Inc conducted the tests performed in order to obtain the technical data presented in this application. Also, based on the results of the enclosed data, I have concluded that the equipment tested meets or exceeds the requirements of the Rules and Regulations governing this application. 1.2Measurement Repeatability Information The test data presented in this report has been acquired using the guidelines set forth in FCC Part 2.1031 through 2.1057, Part 22 and Part 90. The test results presented in this document are valid only for the equipment identified herein under the test conditions described. Repeatability of these test results will only be achieved with identical measurement conditions. These conditions include: The same test distance, EUT Height, Measurement Site Characteristics, and the same EUT System Components. The system must have the same Interconnecting Cables arranged in identical placement to that in the test set-up, with the system and/or EUT functioning in the identical mode of operation (i.e. software and so on) as on the date of the test. Any deviation from the test conditions and the environment on the date of the test may result in measurement repeatability difficulties. All changes made to the EUT during the course of testing as identified in this test report must be incorporated into the EUT or identical models to ensure compliance with the FCC regulations. Bryan Broaddus (Para. 1.1) Manager, Test Dept. DNB Engineering, Inc. Tel. (714) 870-7781 FAX (714) 870-5081 FCC ID: OQ3MAP800-70S 5 2.1033 (C) (1)Application for Certification Name of Applicant:Paradigm Wireless Systems Inc. 1672 McGaw Ave. Irvine, CA 92614 Applicant is:XManufacturer Vendor Licensee Prospective Licensee Other Name of ManufacturerParadigm Wireless Technology Description: RF Power Amplifier Part Number: MAP800-70S Anticipated Production Quantity: Multiple Units 2.1033 (C) (2)FCC Identifier FCC ID: OQ3MAP800-70S 2.1033 (C) 3)Installation and Operating Instructions Please refer to Appendix A 2.1033 (C) (4)Type of Emission N/A (CDMA Modulation) FCC ID: OQ3MAP800-70S 6 2.1033 (C) (10)Schematic Diagram and Circuit Description Please refer to Appendix B 2.1033 (C) (11)Equipment Identification Plate RF AMPLIFIER MODEL NO. MAP800-70S VOLTAGE: 27 VDC, 31A PWR OUTPUT: 110W FCC ID: OQ3MAP800-70S SERIAL NO.__________ PARADIGM WIRELESS TECHNOLOGY MADE IN USA NOTES: Label will be constructed of 0.02 inch aluminum as shown on the equipment with permanent adhesive. All information on the label will be etched or stamped. Both methods will exceed the expected lifetime of the equipment. The label will be large enough to allow all information to be legible. FCC ID: OQ3MAP800-70S 7 2.1033 (C) (11) Equipment Photographs Note: The Main Circuit Board shown in these photos has no components on the reverse side. Photo 1Main Circuit Board (Overall View) Photo 2Main Circuit Board (Detail) Photo 3External Front, Back and Side Views FCC ID: OQ3MAP800-70S 8 FCC ID: OQ3MAP800-70S 9 Photo 1Main Circuit Board (Overall View) FCC ID: OQ3MAP800-70S 10 Photo 2Main Circuit Board (Detail) FCC ID: OQ3MAP800-70S 11 FCC ID: OQ3MAP800-70S 12 FCC ID: OQ3MAP800-70S 13 Photo 3External Front, Back and Side Views FCC ID: OQ3MAP800-70S 14 FCC ID: OQ3MAP800-70S 15 2.1033 (C) (13) Digital Modulation Techniques Not Applicable 2.1033 (c) (14)Test Data Refer to 2.1046 through 2.1057 2.1046Measurement of RF Power Output Definition:For RF Amplifiers. Test Method: See FIGURE 1. Output Power is measured across a precision 50 ohm load with a Spectrum Analyzer. For the power measurement, CW (no modulation) is used. Test Results: POWER OUTP UT MEASURED AT NOMINAL VOLTAGE WAS: Frequency (MHz)Power (dBm) Power (W) 4 carriers880 48.5 71 2 carriers880 49.6 91 1…

Text truncated - open the document above for the full version.

FCC ID: OQ3MAP800-70S 51 2.1051Supplemental Data – Intermodulaton Products Definition:Intermodulation products shall be measured by injecting two carriers using the CDMA modulation mode. The frequency spectrum from the lowest frequency utilized up to the tenth harmonic shall be investigated. The two CDMA carriers were spaced 1.25 MHz apart and were injected at both the low end and high end of the band. The carriers were injected 2.5 MHz from the lower and upper band edge (two channel widths). The low end carriers were placed at 871.50 MHz and 872.50 MHz. The high end carriers were placed at 890.25 MHz and 891.50 MHz. Note that because of the nature of CDMA modulation, the discrete carriers cannot be resolved on the data plot. This is the only modulation type that will be applied to the amplifier’s RF input port. Test Method: The test setup shown in FIGURE 2 shall be utilized for this test. The amplifier’s maximum power output for two carrier operation is 90 Watts. Hence, these tests were performed at a 90 Watt power level (49.5 dBm) only. Test Results: The two-carrier CDMA drive level required to produce a 90 Watt output was established to be –14.7 dBm using a power sensor and meter. The test results shown in the following plots indicated that all intermodulation products are below the FCC limit of 43 +10*log(90W) or 62.5 dBc up to the tenth harmonic for the low end and high end carrier pairs. FCC ID: OQ3MAP800-70S 52 Customer: Paradigm Wireless Technology Test Procedure: FCC, Part 22, 90 EUT : UHF Amplifier, 869 – 894 MHz Test Specification: Intermodulation Test Model / Part #: MAP800-70S Test Engineer: John Stanford Date July 11, 2001 Customer Rep: Charlie Lipsey DESCRIPTIONMANUFACTURERMODEL # / SERIAL #CAL DUE Spectrum AnalyzerHewlett-Packard8566B/2673A0386507/02/02 Directional CouplerHP778DCal prior to test Directional CouplerHP11691Cal prior to test Attenuator (20 dB)PasternackN/ACal prior to test Attenuator (20 dB)Inmet18N50W/64671Cal prior to test Signal GeneratorMarconi2024, 112266/06802/12/02 Signal Generator (*)Agilent E4432B / U540053059 08/08/01 50 ohm load (500W) Electro Impulse LabsDA-242A/U, 7940097Reference 50 ohm load (5W)Narda370BNMReference Power Supply (*)SorensonDHP 30-50Reference Coaxial CableRG-214/UN/ACal prior to test Power Meter (*)Agilent E4418B / GB40204001 06/14/02 Power Sensor (*)Agilent8482A / 1925A0438206/15/02 Power MeterBird43PReference * - Customer furnished FCC ID: OQ3MAP800-70S 53 Plot 1 – 10-800 MHz - Low End FCC ID: OQ3MAP800-70S 54 Plot 2 – 800 MHz – 869 MHz - Low End FCC ID: OQ3MAP800-70S 55 Plot 3 – 869-894 MHz – Low End FCC ID: OQ3MAP800-70S 56 Plot 4 – 894 GHz – 2.5 GHz - Low End FCC ID: OQ3MAP800-70S 57 Plot 5 – 2.5 GHz to 5.8 GHz - Low End FCC ID: OQ3MAP800-70S 58 Plot 6 5.8 GHz to 10 GHz - Low End FCC ID: OQ3MAP800-70S 59 Plot 7 – 10-800 MHz - High End FCC ID: OQ3MAP800-70S 60 Plot 8 – 800 MHz – 869 MHz - High End FCC ID: OQ3MAP800-70S 61 Plot 9 – 869-894 MHz – High End FCC ID: OQ3MAP800-70S 62 Plot 10 – 894 GHz – 2.5 GHz - High End FCC ID: OQ3MAP800-70S 63 Plot 11 – 2.5 GHz to 5.8 GHz - High End FCC ID: OQ3MAP800-70S 64 Plot 12 - 5.8 GHz to 10 GHz - High End

FCC ID: OQ3MAP800-70S 51 FCC ID: OQ3MAP800-70S 52 FCC ID: OQ3MAP800-70S 53 FCC ID: OQ3MAP800-70S 54 FCC ID: OQ3MAP800-70S 55 FCC ID: OQ3MAP800-70S 56 FCC ID: OQ3MAP800-70S 57 FCC ID: OQ3MAP800-70S 58 2.1053Field Strength of Spurious Radiation Definition: Emissions from the equipment when connected into a non-radiating load on a frequency or frequencies which are outside an occupied band sufficient to ensure transmission of information of required quality for the class of communication desired. The reduction in the level of these spurious emissions will not affect the quality of the information being transmitted. Test Method: Per EIA RS 152-B. Connect the equipment and follow the procedure described in paragraph 2.2.1.1 and paragraph 5.0. Measure the amplitude of each spurious radiated signal through the 10 th harmonic. The level in dBuV/m is calculated on the following page. The spurious signals are then measured on the 3 meter range. Po Watts Spurious attenuation dB = 10 log _________________________ Calc. Spurious power Test Results: See TABLE on following Page. All radiated spurious emissions are below the FCC Specifications. RF Exposure The information contained in “ Evaluating Compliance with FCC Guide lines for Human Exposure to Radio frequency Electromagnetic Fields”, OET Bulletin 65; August 1997 is applicable when a radiating antenna is connected to this amplifier. Paging stations that utilize this amplifier authorized under Part 22 (Subpart E) and Part 90 are subject to routine environmental evaluation for RF exposure if an antenna is located on a rooftop and if its ERP exceeds 1000 watts. This product is certified to meet the RF exposure guidelines of OET-65 as a stand-alone RF power amplifier. The RF spurious emissions recorded when the antenna output connector is terminated into a non-radiating 50 ohm load do not exceed the 27.5 V/m limit specified for General Population/Uncontrolled Exposure in OET Bulletin 65. FCC ID: OQ3MAP800-70S 59 FCC ID: OQ3MAP800-70S 60 FCC ID: OQ3MAP800-70S 61 2.1055Measurement of Frequency Stability The EUT is a power amplifier and contains no circuitry for generating or stabilizing the RF signal. The driver will be responsible for this task. 2.1057Frequency Spectrum to be Investigated The Frequency was searched from the lowest radio frequency generated in the equipment through the 10 th harmonic of the carrier frequency.

FCC ID: OQ3MAP800-70S A12 FCC ID: OQ3MAP800-70S A13 5.2 TUNE UP PROCEDURE The MAP800-70S has no user adjustable controls and can not be “tuned up”, therefore no i nstructions are Included or available.
