OR7GP3002.4 GHz RF Wireless Optical Presentation Mouse

2 2 . . 4 4 G G H H z z R R F F W W i i r r e e l l e e s s s s O O p p t t i i c c a a l l P P r r e e s s e e n n t t a a t t i i o o n n M M o o u u s s e e User’s Manual Never point a laser beam into a person’s eyes as prolonged exposure can be hazardous to the eyes. CE and FCC Approved This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Utilizing the 2.4GHz state-of-the-art RF technology, this presentation mouse can operates within 10 meters range. The major function comes from the laser pointer as well as while performing the presentation can use the PowerPoint function. - 1 - C C A A U U T T I I O O N N Complies with DHHS Radiation Performance Standard, 21 CFR Subchapter J CAUTION: Laser radiation when open. DO NOT STARE INTO BEAM OR VIEW DIRECTLY WITH OPTICAL INSTRUMENTS. CLASS I LASER PRODUCT Specifications - 2.4GHz RF wireless transmitting technology - Patented optical trackball - Built–in laser pointer - Mouse left and right function keys - Pencil, Eraser and Black screen keys - LED indicator - Error detection ability - Auto power saving - Windows 98SE/Me/2000/XP compatible - FCC & CE approvals - Dimension: 127(L )x 50 (W) x 42(H)mm Package contents - Optical presentation mouse - USB receiver - USB extension cable - 2 AAA Alkaline batteries - Carrying pouch - User’s manual - 2 - Installation method 1. Battery Installation: push-slide the battery cover (Fig. 1). Please assure to install the batteries correctly in place and replace the cover of battery. 2. Plug the receiver into an available USB port on your computer which automatically detects and installs it. 3. Press the Setup button on the receiver to turn off the LED light. (Fig.2) 4. Hold the presentation mouse close to the receiver. Press the Connect button of the presentation mouse (Fig. 3). The receiver’s LED light blinks indicating that the set-up has been completed. - 3 - Fig. 1 Batterycover Functions The presentation mouse provides functionalities as follows: - 4 - Setup Button LED light Fig. 2 Fig. 3 Optical Trackball Laser Pointer Connect Button Mouse Left Key - 5 - Laser Key Connect Button Black screen Optical Trackball Eraser Mouse Right Key Pencil LED indicator Quick Reference 1. Insert two AAA batteries. 2. Plug the receiver into the USB port. 3. Press the “Setup” button of the receiver to off the LED light. 4. Press “Connect” button of the presentation mouse. 5. Assure the receiver’s LED light is on. 6. The device is now ready to use. 7. LED blinks indicating battery low. 8. LED turns on when holding Laser Key. **This device can be operated with either standard Alkaline batteries or rechargeable batteries. Using rechargeable batteries reduces expenses and is less harmful to the environment. Caution Do not mix Alkaline battery and Rechargeable battery at the same time to avoid the risk of battery explosion. 6MNUP300000US-A0 - 6 -

GlobLink Technology Inc. GP300 TX CKT Block Di agram 20061109 Michael Low BAT. Detect Optical Battery Sensor Set U P 2MHz MCU RF 2.4G Wake U P Sw it ch ANT Regul at or X316MHz TRANSMITTER U4 nRF2402 U1 EM7 8P4 47 R403.3K SW2 3V 2.7V U3 BL8530-271SM Q1 ,Q3 KST3 9 0 4 U4 ADNS-5 03 0 R, L KEY M KEY SW6 SW1,SW2 SW2 I.D KEY SW4 3V 3V 3V t rack ball LA SER KEY SW3,SW1 PEN,Eraser KEY C2020P Las er Module M1 Las er D6 Indicator GlobLink Technology Inc. GP300 TX CKT Block Di agram 20061109 Michael Operating Frequency: 2423-2477 MHz
