ORMF5U021

Belkin Components
JBP - Part 15 Class B Computing Device Peripheral - FCC ID ORMF5U021 - Belkin Components
Click to zoom

Application Details

Equipment Class
JBP - Part 15 Class B Computing Device Peripheral
Date of Grant
Dec 28, 1999
Application Purpose
Original Equipment
Date of Application
Dec 02, 1999
Company
Belkin Components
Country
United States

Documents & Files

Select a file to view

Users Manual

β†—

Block Diagram

β†—

Cover Letter(s)

β†—

External Photos

β†—

ID Label/Location Info

β†—

Internal Photos

β†—

Test Report

β†—

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

USB HUB User’s Manual FCC COMPLIANCE STATEMENT: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. INFORMATION TO USER: This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation; if this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1.Reorient / Relocate the receiving antenna. 2.Increase the separation between the equipment and receiver. 3.Connect the equipment into an outlet on a circuit difference from that to which the receiver is connected. 4.Consult the dealer or an experienced radio/TV technician for help. CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the user’s authority to operate the equipment Table of Contents 1. About this product ..................................... 1 1.1. Introduction ............................................................................. 1 1.2. Do’s and Don’t for Usage ............................................................. 1 1.3. Packing List ............................................................................. 1 1.4. Warranty ................................................................................. 2 1.5. Features ................................................................................. 2 1.6. Identification of Features ............................................................. 2 2. Installation ................................................ 3 2.1. Location ................................................................................. 3 2.2. Power Connection ..................................................................... 3 3. Connecting ............................................... 3 3.1. Connecting to your Computer ....................................................... 3 3.2. Connecting the USB Cable ........................................................... 4 4. Initial Connection ....................................... 5 5. Trouble Shooting ........................................ 6 1 1. About this product 1.1Introduction This product confirms to USB Specification Rev. 1.0 and HID class definition Rev.1.0. It requires at least Windows 95 OSR 2.1 or Windows 98 to operate and your computer must have a USB port. The HUB topology supports up to 127 physical devices in a tired-star configuration, with each device having a maximum of 16 end points. 1.2Do’s and Don’t for Usage Here is a short summary of items to pay attention to when using this product : ❒ It is normal for some heat build-up to occur when this product is in use and it may feel warm to the touch. ❒ Do not open the case, doing so will void the warranty. ❒ Only use the AC adapter supplied with the unit. ❒ If the unit starts emitting unusual smells, sounds, or you observe smoke, unplug the unit immediately from it’s power supply. Do not continue using the unit, and contact the place you purchased the unit. ❒ When disconnecting any cable from the unit, please grasp from the plug and do not pull using the cord section as this may cause damage. ❒ It is recommended that you disconnect the power supply if the unit is not going to be used for a long period of time. ❒ Do not leave the unit in a location exposed to high humidity, high temperatures, direct sunlight, excessive dust, or excessive moisture. ❒ Do not touch the unit or cable with a wet hand, as a electric shock is possible. Should the unit become wet, unplug from it’s power source before handling. ❒ Any modifications done to modify this unit by other than authorized personnel will void the warranty, and any damage, electric shock, fire, or loss of function resulting from unauthorized modifications will not be the responsibility of the manufacturer. ❒ Back-up software data regularly. Any error or loss of data is not guaranteed when using this product. ❒ Carefully read this manual for the safe purpose before you use this product. 1.3Packing List Each unit should include the following parts : USB HUB AC Adapter USB cable Instruction manual 2 1.4Warranty This product is warranted for a period of one year after the date of purchase to be free of manufacture defects and to operate properly. During the one year period should a problem occur, please return the unit to the place of purchase, and we will replace the defective unit. 1.5Features ❒ This product confirms to USB Specification Revision 1.0 and HID Class Definition Rev.1.0. ❒ This product is plug and play compatible. ❒ A maximum of 127 devices can be supported. ❒ A maximum 5 meter connection cable can be used between two hubs. ❒ This unit can be self-powered by using the AC Adapter supplied or Bus powered. ❒ All downstream ports are supported with over current capacity. ❒ Both low speed and high speed devices are supported. ❒ LED displays indicate power on and connection to each port.  Up Stream Port USB B-type connector port for connect to the PC.  Power Socket For the AC Adapter jack connection. Please note :  Up Stream means to the PC and Down Stream means to the USB device.  USB device means, a device that confirms to USB specifications. 2.Installation 2.1 Location The best location …

Text truncated - open the document above for the full version.

ID Label/Location Info

FCC ID LABEL FORMAT AND LOCATION Applicant:BELKIN COMPONENTS FCC ID:ORMF5U021 FCC ID: ORMF5U021 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID LABEL AREA

Test Report

                                           ! "! # #   #  !!! $ % & ' ($ % & '  )'& REPORT NO:99E8075 DATE:NOVEMBER 10, 1999 EUT:4 PORT USB HUB FCC ID:ORMF5U021 0 OF 14                           !"#$ % This report shall not be reproduced except in full, without the written approval of CES. TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE..............................................1 2. PRODUCT DESCRIPTION.....................................................2 3. TESTED SYSTEM DETAILS...................................................2 4. TEST FACILITY...........................................................3 5. ACCREDITATION AND LISTING...............................................3 6. MEASUREMENT INSTRUMENTATION.............................................3 7. MEASURING INSTRUMENT CALIBRATION........................................3 8. UNITS OF MEASUREMENT....................................................4 9. ANTENNAS................................................................4 10. CLASSIFICATION OF DIGITAL DEVICE........................................4 11. RADIATED EMISSION LIMITS................................................5 12. CONDUCTED EMISSION LIMITS...............................................6 13. CONDUCTED EMISSION TEST PROCEDURE.......................................6 14. RADIATED EMISSION TEST PROCEDURE........................................6 15. AMBIENT CONDITIONS......................................................7 16. SYSTEM TEST CONFIGURATION...............................................7 17. EQUIPMENT MODIFICATIONS.................................................7 18. EUT SETUP PHOTOS............................................................8 19. TEST EQUIPMENT LIST....................................................10 20. CORRECTION FACTOR......................................................11 21. TEST RESULT SUMMARY....................................................12 APPENDICES ..................................................................14 .EXTERNAL I/O CABLE CONSTRUCTION DESCRIPTION .CONFIGURATION BLOCK DIAGRAM .CONDUCTED EMISSION PLOT .RADIATED EMISSION DATA .EUT PHOTOGRAPHS REPORT NO:99E8075 DATE:NOVEMBER 10, 1999 EUT:4 PORT USB HUB FCC ID:ORMF5U021 1 OF 14                           !"#$ % This report shall not be reproduced except in full, without the written approval of CES. !                          !""#   $ $  $%             &   & # ' #    & '              (           #    %           )( " %% '   *     # #    &    #          & +,-,+ ./ 0,1.2/3  -/+ 1/44,3.0          5 6  7" *         5 6 % 7" '()*+,((-./01(234)53(53(6*7+108/)2%( 29/2((:/29(:,/%(52%;<+:%+108/)2%(4/3'3'( :(-./:(1(2355(3<+:3'/23'($$=>;'(:(5.835+<3(53/29/23'/5:(0+:3)00873+3'( 0:+6.%35753(14'/%'4)53(53(6+287;3'(:5/1/8):(-./01(234/882+32(%(55):/870:+6.%(3'(5)1( :(5.8356.(3+0:+6.%3/+23+8(:)2%()261()5.:(1(23.2%(:3)/23/(5;     ;;                         REPORT NO:99E8075 DATE:NOVEMBER 10, 1999 EUT:4 PORT USB HUB FCC ID:ORMF5U021 2 OF 14                           !"#$ % This report shall not be reproduced except in full, without the written approval of CES. 2. PRODUCT DESCRIPTION CHASSIS TYPE PLASTIC LIST OF EACH OSC. OR XTAL. FREQ. (FREQ.>=1 MHz) Y1=6MHz CHIPSET BRAND AND PART NO. PI, TUSB2046 NUMBER OF PCB LAYERS 2 LAYERS POWER REQUIREMENTS DC 7.5V ADAPTOR/NAME/MODEL/S.N. MERRY KING, MKD-48752100 NO. OF EXTERNAL I/O CONNECTORS 5 Model Differences: Model NameDifferencesTested (Checked) F5U021 ORIGINAL MODEL NAME F5U021c ADDED FOR MARKETING PURPOSES 3. TESTED SYSTEM DETAILS The Model names for all equipment, plus descriptions of all cables used in the tested system (including inserted cards) are: External Peripheral Devices Device Type ManufacturerModel NumberSerial No.FCC ID / DoC HOST COMPUTER VIVA VIVA 686-350 HS-11 DOC MONITOR COMPAQ MV500 MT-04 DOC KEYBOARD Acer 6511-TW KB-19 JVPKBS-WIN MOUSE LOGITECH M-M35 ME-11 DZL210365 MODEM ACEEX DM-1414 MD-09 IFXDM1414 PRINTER MATSUSHITA KX-P1080  PRN-01 ACJ5Z6KX-P1080I USB KEYBOARD CHERRY MY3000 USB 4A KB-21 DOC USB JOYSTICK Microsoft SideWinder Precision Pro JOY-12 DOC USB MOUSE DEXIN A2U800A 71000772 NIYA2U800A USB MOUSE DEXIN A2U800A 71000762 NIYA2U800A USB HUB (EUT) BELKIN F5U021 N/A ORMF5U021 REPORT NO:99E8075 DATE:NOVEMBER 10, 1999 EUT:4 PORT USB HUB FCC ID:ORMF5U021 3 OF 14                           !"#$ % This report shall not be reproduced except in full, without the written approval of CES. 4. TEST FACILITY The open area test sites and conducted measurement facilities used to collect the radiated data are located at No. 199, Chung Sheng …

Text truncated - open the document above for the full version.

Contact Information

Applicant

Steven Hsu(Technology Development Manager)
310-898-1100

Technical Contact

Compliance Engineering ServicesMike C.I. Kuo
[email protected]408-752-8166

1366 Bordeaux Drive Β· Sunnyvale, California Β· United States

Non-Technical Contact

Compliance Engineering ServicesAnne Liang
[email protected]408-752-8166

Test Firm

Compliance Certification Services IncSteve Cheng
[email protected]408-463-0085Fax: 408-463-0888

Technical Specifications

#Rule PartsFrequency RangePower Output
115B--
