OU9LS401-E01DIGITAL PEDOMETER

LS401-E Button Indicator light Charging dot Product structure Before using 1 Install the bridge. Please refer to the bridge instruction manual. (If already install the bridge, skip the steps.) 2 Register the account and add the members. 1) Please enter into www.lifesense.com, make the free account. (If already have the account please skip the steps.) 2) Register the family account.3) RAdd a family member. 4) Select program.3 Add the device. 1) Click the device and add the device. 2) Input the serial No.3) Add the user. 4) Activate the device.5) wait for activation. 5) Successfully add. 1) Put the pedometer into the charging plate. 2) Charging with the usb cable linked to the pc. It finishes in around 1.5 hours, and shows all the indicator lights. 4 Battery charging. Successfully add! The page will be automatically closed in 3 second 1) Device should be less than 1 meter away from the bridge. 2) Long press the button for 5 sec. 3) Successfully activated after it shows you 6 green indicator lights. 5 Product’s activation. 1 Measurement and data sending. 1) Log in health care center and set a week target. Usage 4 Go to www.lifesense.com to check how many step you finished. Attention: if you change an user, please long press activation button. 2 Measure your step wherever you want. 3 Automatically transmit the data to the server when the pedometer is close enough to the bridge. Cautions 1) Daily target check Press the button, how many lights you see means how fulfill how many day’s task. 2) Weekly target check Press the button after you see the green lights, then you will see orange lights, how many of them you see means how many week task you finish. 3) Power Inquires Press the button when it shows the orange indication light. How many red lights you see means how much power the blood pressure monitor has. 4 orange lights are on and the fifth is flickering, it means you finish 4/7 for the weekly task. (all green lights show, it means you finish the daily task.) it shows 3 red light, that means, you have 3/7 battery left 5 Target and battery margin check. In order to avoid others being hurt by the product and extend its lifetime, please obey the following cautions. Symbol Meaning General Indication Forbiden don't disassemble About rechargingAbout usage Product maintenance After recharging 2-3 times, the performance can be perfect Please take the pedometer as mentioned Don’t use the pedometer where it is in strong radiation which would influence the accuracy Data can be saved for 30 days before transmitted Please don’t disassemble the product if you are not professional Put the product where it is dry and cool Put the product on a level table when you don’t use it Don’t disassemble the product after you abandon it, and obey city’s rule of environment Battery duration: 13 days During charging, it’s normal if the product is a little fever Charging within 0-40 celsius degree All green lights shows if it finishes charging The recharger is only for LS401-E pedometre Don’t store the recharger in a hot or wet place Don’t disassemble the product yourself 1 Use tissue to clean the dirt on the pedometer. 2 Dry the pedometer after clean it with soaped wiping. Clean Cautions Phenomenon No indicator light Fail activation Reason Low battery interference No account Activate too many products at the same time Weak signal to the server Methods Recharging Keep closer to the bridge Fail data uploading Product can not be recharged Fail display on weekly target and led Out of transmitting range Increasing steps are less than 100 Network error Sync the pedometer with the server Manually input the data Error of usb plug Wrongly put the pedometer into the charger base Make it more than 100 Move the products towards to the bridge. Data can be transmitted in 30m without barrier. Check network status Log on the health care system Change usb plug Re- put it as instruction Check connection between the bridge and pedometer Log on www.lifesense.com for setting Do it one by one Check network status Product Specification Items Product Name Voltage Recharging Display Steps Calories Battery grade Battery releasing Content DC 5.0V, standard usb plug 7 led lights 0-99999 steps, division 1 step 0- 9999.9k calories, division 0.1k calories 1-7 grade, division: 1 grade ≥500 times 45mAh Lipolymer battery Battery life Data capacity Transmitting range Dimension 13 days once recharging Data of 30 days 30 meters (in open place) 60x44.7x11.3mm Pedometer LS401-E Working Condition Storage and Transportation Condition Temperature: 0~40Humidity≤90% RH Temperature: -20-60Humidity≤90% RH This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. 2728 —Connect the equipmen…

Text truncated - open the document above for the full version.

Zhongshan Transtek Electronics Co., Ltd. Jin’an Road, Minzhong, Zhongshan 528441, Guangdong, China Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: OU9LS401-E01. Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram OU9LS401-E01 Block Diagram.pdf Schematics OU9LS401-E01 Schematics.pdf Operational Description OU9LS401-E01 Operational Description.pdf BOM OU9LS401-E01 BOM.pdf PCB Layout OU9LS401-E01 PCB Layout.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ----------------------------------------------- Terry Chen / Compliance Engineer Company Name: Zhongshan Transtek Electronics Co., Ltd. Tel: +86-760-8828 2982-8 Fax: +86-760-85339231 Email: [email protected]

External Photos

Digital pedometer Model: LS401-E Power: 45mAh Lipolymer battery Recharging: DC 5.0V, standard usb plug CMIIT ID:2001DP3742 1:1 Jin’an Road, Minzhong, Zhongshan,528441, Guangdong, China FCC ID OU9LS401-E01 ZHONGSHAN TRANSTEK ELECTRONICS CO.,LTD LS-401-E 29.6*15.6mm

Internal Photos

SGS-CSTC Standards Technical Services Co., Ltd. 198 Kezhu Road, Scientech Park, Guangzhou Economic & Technological Development District, Guangzhou, China 510663 Telephone: +86 (0) 20 82155555 Fax: +86 (0) 20 82075059 Email: [email protected] Report No.: GZEM120700300801 Page: 1 of 32 FCC ID: OU9LS401-E01 Strong Yao Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only 1 Cover Page TEST REPORT Application No.: GZEM1207003008RF Applicant: Zhongshan Transtek Electronics Co., Ltd FCC ID: OU9LS401-E01 Product Name: Digital pedometer Product Description: Wireless Digital pedometer measure with 915MHz as carrier Model No.: LS401-E Standards: 47 CFR PART 15 Subpart C: 2011 section 15.249 Date of Receipt: 2012-08-10 Date of Test: 2012-08-12 to 2012-08-22 Date of Issue: 2012-09-05 Test Result : Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Report No.: GZEM120700300801 Page: 2 of 32 FCC ID: OU9LS401-E01 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 2 Version Revision Record Version Chapter Date Modifier Remark 00 2012-09-05 Original Authorized for issue by: Tested By 2012-08-12 to 2012-08-22 (Storm Shu) / Project Engineer Date Prepared By 2012-08-23 (Storm Shu) / Project Engineer Date Checked By 2012-09-05 Strong Yao/ Reviewer Date SGS-CSTC Standards Technical Services Co., Ltd. Report No.: GZEM120700300801 Page: 3 of 32 FCC ID: OU9LS401-E01 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 3 Test Summary TEST TEST REQUIREMENT TEST METHOD RESULT Field Strength of Fundamental FCC PART 15 C section 15.249 (a) ANSI C63.10: Clause 6.6 PASS Field Strength of Unwanted Emissions FCC PART 15 C section 15.249 (a) section 15.249 (d) ANSI C63.10: Clause 6.4, 6.6 and 6.7 PASS Band Edges FCC PART 15 C section 15.249 (d) ANSI C63.10: Clause 6.9.2 PASS Occupied Bandwidth FCC PART 1…

Text truncated - open the document above for the full version.

Test Setup Photos Radiated Emission Test Setup Below 1G Above 1G: (full anechoic chamber) Conducted Emission Test Setup
