OU9LS802-E01BLOOD PRESSURE MONITOR

User Manual Blood Pressure Monitor LS802-E To use the monitor correctly and safely, please read the manual thoroughly. Thank you very much for selecting TRANSTEK Blood Pressure Monitor LS802-E. please keep well this manual in order to reference in future. ZHONGSHAN TRANSTEKELECTRONICES CO.,LTD Arm Type Jin’an Road, Minzhong, Zhongshan,528441,Guangdong, China Version:1.0 CATALOGUEINTRODUCTION 1 INTRODUCTION...............................................................1 Safety information LCD display signal Monitor components BEFORE YOU START..........................................................4 The Choice of power supply MEASUREMENT...............................................................5 Tie the cuff Start a measurement INFORMATION FOR USER......................................................7 Tips for measurement Maintenance ABOUT BLOOD PRESSURE.....................................................9 What are systolic pressure and diastolic pressure? What is the standard blood pressure classification? Why does my blood pressure fluctuate throughout the day? Why the blood pressure I get from the hospital is different from home? The result is different that you measuring on the different arm. TROUBLESHOOTING.........................................................11 SPECIFICATIONS.............................................................12 AUTHORIZED COPMONENT...................................................13 COMPLIED EUROPEAN STANDARDS LIST......................................13 ELECTROMAGNETIC COMPATIBILITY DESCRIPTIONS..........................14 The below signs might be in the user manual, labeling or other component. they are the requirement of standard and using. Safety information Caution:Consult accompanying documents CE Mark: conforms to essential requirements of the Medical Device Directive 93/42/EEC. Manufacturer Specifies serial number This device is intended for adult use only. This device is intended for no-invasive measuring and monitoring of arterial blood pressure. It is not intended for use on extremities other than the wrist or for functions other than obtaining a blood pressure measurement. Do not confuse self-monitoring with self-diagnosis. This unit allows you to monitor your blood pressure.Do not begin or end medical treatment based solely physician for treatment advice. If you are taking medication,consult your physician to determine the most appropriate time to measure your blood pressure. Never change a prescribed medication without consulting your physician. This unit is not suitable for continuous monitoring during medical emergencies or operations. If the cuff pressure exceeds 40 kPa (300 mmHg),the unit will automatically deflate. Should the cuff not deflate when pressures exceeds 40 kPa (300 mmHg),detach the cuff from the wrist and press the homologous button to stop inflation. To avoid measurement errors, carefully read this manual before using the product. The equipment is not AP/APG equipment and not suitable for use in the presence of a flammable anesthetic mixture with air of with oxygen or nitrous oxide. The operator shall not touch output of AC adapter and the patient simultaneously. To avoid measurement errors,Please avoid the condition of strong electromagnetic field radiated interference signal or electrical fast transient/burst signal when using the AC adaptor. The user must check that the equipment functions safely and see that it is in proper working condition before being used. The manufacturer does not require such preventive inspections by other persons. CAUTION Type B applied part Direct current DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. Authorized Representative in the European Community ECREP Thank you for selecting TRANSTEK arm type blood pressure Monitor (LS802-E). The monitor features blood pressure measurement, pulse rate measurement and auto-save the result. The design provides you with many years of reliable service. Reading taken by the LS802-E are equivalent to those obtained by a trained observer using the cuff and stethoscope auscultation method. This manual contains important safety and care information, and provides step by step instruction for using the product. Read the manual thoroughly before using the product. Features: 93.5*79mm Bright LCD display with blue backlight Maximum 60 records per user Charging measuring technology INTRODUCTIONINTRODUCTION 23 CUFF AIR HOSE AIR CONNECTOR PLUG LCD DISPLAY DC POWER SOCKET User A Guest User B BATTERY COMPARTMENT Monitor components LCD display signal List 1.Blood Pressure Monitor (LS802-E) 4.User manual3. 4*AA alkaline batteries 2.Cuff (Type B applied part) (AC2232-01) Component list of pressure measuring system 1.Cuff 2.Micro Control Unit 3.Amplifier 4.Air pipe 5.Pump 6.Valve User AUser BGuest SYMBOLDESCRIPTION Systolic blood pressureHigh pressure result Diastolic blood pressureLow pressure result EXPLANATION PulsePulse/minute User Aprovide measurement for user A, and then save the measure date automatically Guest provide measurement for guests, but not save the measurement data. User B provide measurement for user B, and then save the measure date automatically Data storage to remind the users that the measurement dates don’t upload to bridge in time Wireless transmitter the blood monitor and Bridge in communication Network connectionthe bridge not connect the network Shocking remaindingShocking will result in inaccurate Low batteryBatteries are low and need to be replaced Measurement Unit of the blood pressure Unit date (hour:minute)Currently time DeflatingCUFF air is exhausting of deflating AC adaptor BEFORE YOU START 5 4 The Choice of Battery In order to get the best effect and protect you monitor,please use the right battery and special power adapter. .Slide off the battery cover. .Install the batteries by matching the correct polarity, as shown. .Replace the cover. …

Text truncated - open the document above for the full version.

Zhongshan Transtek Electronics Co., Ltd. Jin’an Road, Minzhong, Zhongshan 528441, Guangdong, China Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: OU9LS802-E01. Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram OU9LS802-E01Block Diagram.pdf Schematics OU9LS802-E01 Schematics.pdf Operational Description OU9LS802-E01 Operational Description.pdf BOM OU9LS802-E01 BOM.pdf PCB Layout OU9LS802-E01 PCB Layout.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ----------------------------------------------- Terry Chen / Compliance Engineer Company Name: Zhongshan Transtek Electronics Co., Ltd. Tel: +86-760-8828 2982-8 Fax: +86-760-85339231 Email: [email protected]

External Photos

Dimension：62X30mm,Thickness：0.2mmDimension：23*27mm label LS802-E Colour：black text with silver background Material：adhesive label with water proof Rating:Battery powered mode: 6V AC adaptor powered mode: 100-240V~, 400mA (Can be supplied by AC adaptor model UE08WCP-060100SPA only!) ECREP Jin'an Road,Minzhong,Zhongshan,528441,Guangdong,China SN Model:LS802-E FCC ID: OU9LS802-E01 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Internal Photos

SGS-CSTC Standards Technical Services Co., Ltd. 198 Kezhu Road, Scientech Park, Guangzhou Economic & Technological Development District, Guangzhou, China 510663 Telephone: +86 (0) 20 82155555 Fax: +86 (0) 20 82075059 Email: [email protected] Report No.: GZEM120700301101 Page: 1 of 33 FCC ID: OU9LS802-E01 Strong Yao Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only 1 Cover Page TEST REPORT Application No.: GZEM1207003011RF Applicant: Zhongshan Transtek Electronics Co., Ltd FCC ID: OU9LS802-E01 Product Name: Blood pressure monitor Product Description: Wireless Blood pressure measure with 915MHz as carrier Model No.: LS802-E Standards: 47 CFR PART 15 Subpart C: 2011 section 15.249 Date of Receipt: 2012-09-13 Date of Test: 2012-09-13 to 2012-09-21 Date of Issue: 2012-10-10 Test Result : Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Report No.: GZEM120700301101 Page: 2 of 33 FCC ID: OU9LS802-E01 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 2 Version Revision Record Version Chapter Date Modifier Remark 00 2012-10-10 Original Authorized for issue by: Tested By 2012-09-13 to 2012-09-21 (Storm Shu) / Project Engineer Date Prepared By 2012-09-25 (Storm Shu) / Project Engineer Date Checked By 2012-10-10 Strong Yao/ Reviewer Date SGS-CSTC Standards Technical Services Co., Ltd. Report No.: GZEM120700301101 Page: 3 of 33 FCC ID: OU9LS802-E01 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 3 Test Summary TEST TEST REQUIREMENT TEST METHOD RESULT Field Strength of Fundamental FCC PART 15 C section 15.249 (a) ANSI C63.10: Clause 6.6 PASS Field Strength of Unwanted Emissions FCC PART 15 C section 15.249 (a) section 15.249 (d) ANSI C63.10: Clause 6.4, 6.6 and 6.7 PASS Band Edges FCC PART 15 C section 15.249 (d) ANSI C63.10: Clause 6.9.2 PASS Occupied Bandwidth FCC PART…

Text truncated - open the document above for the full version.

Test Setup Photos Radiated Emission Test Setup Below 1G Above 1G: (full anechoic chamber) Conducted Emission Test Setup
