OU9LS901-E01DIGITAL TAPE MEASURE

version 1.0 print date: 8/2012 Digital Tape Meter LS502-E 12 Device structureBefore using Measure keyBody measurements Wireless transmit Internet disconnection Low battery indicator Measure value User Select key Power button Coupling Tape Battery cover Data store Measurement 1. Install the data bridge. Please refer to the data bridge instruction manual. (If data bridge is already installed, skip these steps.) 2. Register for an account at www.profileplan.net and click "Create Account". Follow the instructions on screen. 34 Register device 1. Log into your account at www.profileplan.net and choose "My Account" > "Devices." 2. Enter your device’s serial number & click "Add Device." 3. If successful, the device will display as "Active." 4. See "Activate the Product" on the following pages if device does not display as synced. 56 Install batteries Activate the device Slide off the battery cover according to the arrow direction. Install 2 AA batteries according to the marks in the battery compartment. Replace the battery cover. 1. Bring the device within 3 feet of the data bridge. 2. Press the power button for 5 seconds. 78 Operating instructions See trouble shooting Move to next step 1. Power up the unit, press the select key to cycle through the measurement location options 2. Gently pull out the tape to start measuring. 3. Wrap selected body part with tape. 4. Insert the plastic end of the tape into the coupling. Press the measure key to measure and store data. 3. The screen will appear. Wait for the screen to appear. If this screen does not display, see trouble shooting. 910 Cautions Symbol meaning 6. Log into www.profileplan.net to check the results or use the mobile app. 5. The data, including those failed to be sent before, will be automatically sent to the data bridge. After the data is sent the unit will turn off automatically. If there is data failure the icon will display. To prevent the product from harming users and to prolong product life, please follow guidelines below. General instruction Forbidden Disassembly is forbidden 1112 About battery useAbout the device About daily maintenance 2 x AAA batteries are required for this product. Keep measuring at the same time of every day. For example, before you go to bed. Measure and check the data corresponding to the part you choose. Measure close to the body to avoid interference caused by clothing. Do not disassemble product if you’re not a professional. Please store in a cool, dry place. Place the product on the horizontal platform when not in use Comply to the environmental rules when disposing of this product. If the product is not used for extended periods of time remove batteries. When you insert the batteries please make sure they are in the correct position. Do not heat the batteries or expose them to flame. Do not combine old and new batteries. Do not disassemble battery charger. 1413 1. Use a damp cloth to gently clean the device.2. Dry the device after cleaning it. Cleaning 1516 Trouble shooting Symptom Solution No Display Low chargeInstall new batteries Wrong battery installation Network failure 1. Wireless communication is interrupted 2. The product is too far away from the data bridge during activation Re-activate the product within 3 feet of the data bridge Align polarity symbols (+/-) Reason/ Cause LCD error code 1718 Product is still not registered. LCD error code Wide Band failure. The data bridge’s WAN LED light flashes Check the internet connection Low battery Replace the batteries Symptom Reason/ Cause Solution When using the device, the LCD displays Go to www.profileplan.net and delete the unused device or purchase a new data bridge. Register the device (see step 1) Data bridge limit of 16 devices has been reached 1920 The wireless communication between the product and data bridge is interrupted Re-measure, keeping the data bridge within 3 feet of the product. The system can't automatically identify the measurement data and exceeds the identification range Check the network connection of the data bridge Symptom Solution When using the device, the LCD displaysWhen using the device the LCD displays The product is out of wireless transmission range Reason/ Cause 2122 Specifications The platform of the Health Center can't indicate the measurement data normally. Check network connection Symptom Solution Item Product Name Whole Size Weight Power Supply Display Mode Unit of measure Capacity Division Working Condition Storage and Transportation Condition 85 g (excluding batteries) 2 x AAA Blue film LCD Inch 2.2 in min - 59 in max 0.1 in Temperature: 32 ~ 104 ºF Temperature: -4 ~ 140 ºF Digital Tape Meter LS502-E 3 x 2.6 x 1.5 inches Parameter The measurement data is near or over the identification range. The system can’t identify Go into Device management > Product > Data authentication and assign the data manually Wide Band failure. The data bridge’s WAN LED light flashes Reason/ Cause 2324 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful inter…

Text truncated - open the document above for the full version.

Zhongshan Transtek Electronics Co., Ltd. Jin’an Road, Minzhong, Zhongshan 528441, Guangdong, China Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: OU9LS901-E01. Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram OU9LS901-E01 Block Diagram.pdf Schematics OU9LS901-E01 Schematics.pdf Operational Description OU9LS901-E01 Operational Description.pdf BOM OU9LS901-E01 BOM.pdf PCB Layout OU9LS901-E01 PCB Layout.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ----------------------------------------------- Terry Chen / Compliance Engineer Company Name: Zhongshan Transtek Electronics Co., Ltd. Tel: +86-760-8828 2982-8 Fax: +86-760-85339231 Email: [email protected]

External Photos

Type: LS502-E Digital tape measure ZHONGSHAN TRANSTEK ELECTRONICS CO.,LTD Jin’an Road, Minzhong, Zhongshan,528441,Guangdong, China FCC ID： OU9LS901-E01 Power:2 x AAA batteries MATERIAL = WATER-RESISTANT PAPER WITH SELF ADHESIVE BACKING COLOUR = BLACK GRAPHICS ON SILVER BACKGROUND SCALE: 1:1 Size: 38*7 mm

Internal Photos

SGS-CSTC Standards Technical Services Co., Ltd. 198 Kezhu Road, Scientech Park, Guangzhou Economic & Technological Development District, Guangzhou, China 510663 Telephone: +86 (0) 20 82155555 Fax: +86 (0) 20 82075059 Email: [email protected] Report No.: GZEM120700301201 Page: 1 of 28 FCC ID: OU9LS901-E01 Strong Yao Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only 1 Cover Page TEST REPORT Application No.: GZEM1207003012RF Applicant: Zhongshan Transtek Electronics Co., Ltd FCC ID: OU9LS901-E01 Product Name: Digital tape measure Product Description: Wireless Digital tape measure with 915MHz as carrier Model No.: LS502-E Standards: 47 CFR PART 15 Subpart C: 2011 section 15.249 Date of Receipt: 2012-08-10 Date of Test: 2012-08-12 to 2012-08-22 Date of Issue: 2012-09-05 Test Result : Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Report No.: GZEM120700301201 Page: 2 of 28 FCC ID: OU9LS901-E01 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 2 Version Revision Record Version Chapter Date Modifier Remark 00 2012-09-05 Original Authorized for issue by: Tested By 2012-08-12 to 2012-08-22 (Storm Shu) / Project Engineer Date Prepared By 2012-08-23 (Storm Shu) / Project Engineer Date Checked By 2012-09-05 Strong Yao/ Reviewer Date SGS-CSTC Standards Technical Services Co., Ltd. Report No.: GZEM120700301201 Page: 3 of 28 FCC ID: OU9LS901-E01 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 3 Test Summary TEST TEST REQUIREMENT TEST METHOD RESULT Field Strength of Fundamental FCC PART 15 C section 15.249 (a) ANSI C63.10: Clause 6.6 PASS Field Strength of Unwanted Emissions FCC PART 15 C section 15.249 (a) section 15.249 (d) ANSI C63.10: Clause 6.4, 6.6 and 6.7 PASS Band Edges FCC PART 15 C section 15.249 (d) ANSI C63.10: Clause 6.9.2 PASS Occupied Bandwidth FCC PART 15 …

Text truncated - open the document above for the full version.

Test Setup Photos Radiated Emission Test Setup Below 1G Above 1G: (full anechoic chamber)
