OVFC51213CDTri-Band CDMA Mobile Phone with Bluetooth+WiFi

1 get started Milano ™ C5121 82-A6266-1ES, Rev. 001 82-A6266-1ES_en.book Page 1 Thursday, August 11, 2011 3:56 PM DRAFT 2 Milano C5121 Get Started This manual is based on the production version of the Kyocera C5121 device. Software changes may have occurred after this printing. Kyocera reserves the right to make changes in technical and product specifications without prior notice. The Kyocera Communications Inc. (“KCI”) products described in this manual may include copyrighted KCI and third party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for KCI and third party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the KCI products may not be modified, reverse engineered, distributed or reproduced in any manner not permitted by law. Furthermore, the purchase of the KCI products shall not be deemed to grant—either directly or by implication, estoppel, or otherwise—any license under the copyrights, patents, or patent applications of KCI or any third party software provider, except for the normal, non-exclusive royalty-free license to use that arises by operation of law in the sale of a product. Kyocera is a registered trademark of Kyocera Corporation. Bluetooth trademarks are owned by Bluetooth SIG, Inc. and used by Kyocera Communications Inc. under license. microSDHC Logo is a trademark. Android, Android Market, Google Maps, Gmail, Google Talk are trademarks of Google, Inc. WnnIME OMRON SOFTWARE Co., Ltd. 2009-2011 All Rights Reserved. The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance. The Wi-Fi Alliance Member Logo is a logo of the Wi-Fi Alliance. All other trademarks are the property of their respective owners. Copyright © 2011 Kyocera Corporation. All rights reserved. Ringer Tones Copyright © 2000-2011 Kyocera Corporation. 82-A6266-1ES, Rev. 001 FCC Notice This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Accessories used with this device for body-worn operations must not contain any metallic components and must provide at least 15 mm separation distance including the antenna and the user’s body. THIS MODEL PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. Your wireless device is a radio transmitter and receiver. It is designed and manufactured to not exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg.* Tests for SAR are conducted using standard operating positions specified by the FCC with the device transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value. This is because the device is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output. 82-A6266-1ES_en.book Page 2 Thursday, August 11, 2011 3:56 PM DRAFT 3 Before a device model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the government-adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. Body-worn measurements differ among device models, depending upon availability of accessories and FCC requirements. While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure. The FCC has granted an Equipment Authorization for this model device with all reported SAR levels evaluated as in compliance with the FCC RF emission guidelines. The highest reported SAR values of this device are: WLAN mode (Part 15): Head: 0.14 W/kg; Body-worn: 0.06 W/kg Cellular CDMA mode (Part 22): Head: 0.46 W/kg; Body-worn: 0.82 W/kg PCS mode (Part 24): Head: 1.42 W/kg; Body-worn: 0.52 W/kg AWS mode (Part 27): Head: 1.38 W/kg; Body-worn: 0.56 W/kg SAR information on this model device is on file with the FCC and can be found under the Display Grant section www.fcc.gov/oet/ea/fccid after searching on the FCC ID: OVFC51213CD. Additional information on SAR can be found on the Cellular Telecommunications and Internet Association (CTIA) web-site at www.ctia.org. * In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. Bluetooth® Certification For information about C5121 Bluetooth Certification, visit the Bluetooth Qualification Program Web site at www.bluetooth.org/tpg/listings.cfm. Caution The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the warranty and user’s authority to operate the equipment. Optimize your Phone’s Performance Use the instructions in this guide to learn h…

Text truncated - open the document above for the full version.

Date: 7/16/10 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. Claire Hoque/Application Examiner of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. Claire Hoque of CCS on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Tina To, Account Representative CompTest Services, LLC

KYOCERA COMMUNICATIONS, INC. 8611 Balboa Avenue San Diego, San Diego, CA 92123 Kyocera Communications, Inc. Proprietary/Confidential 1 of 2 Date: 08/16/2011 Federal Communications Commission c/o Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538 To whom it may concern: We, the undersigned, hereby authorize the Comptest Services LLC and hereafter referred to as Comptest, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Comptest on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing Comptest as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; KYOCERA COMMUNICATIONS, INC. 8611 Balboa Avenue San Diego, San Diego, CA 92123 Kyocera Communications, Inc. Proprietary/Confidential 2 of 2 g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, ____________________________ C. K. Li Director, Design Center Kyocera Corporation c/o Kyocera Communications, Inc. (KCI) 8611 Balboa Avenue San Diego, San Diego, CA 92123

KYOCERA COMMUNICATIONS, INC. 8611 Balboa Avenue San Diego, San Diego, CA 92123 Kyocera Communications, Inc. Proprietary/Confidential Date: 08/16/2011 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for Confidentiality FCC ID: OVFC51213CD To Whom It May Concern: In accordance with §0.459 of CFR 47, KYOCERA Corporation requests confidentiality for the following items 1. Block Diagram 2. Parts List 3. Adjustment Procedure and Schematic Diagrams 4. Technical Description These items contain detailed system and equipment description and related information about the product which KYOCERA Corporation considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, KYOCERA Corporation also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Best Regards, ____________________________ C. K. Li Director, Design Center Kyocera Corporation c/o Kyocera Communications, Inc. (KCI) 8611 Balboa Avenue San Diego, San Diego, CA 92123

KYOCERA COMMUNICATIONS, INC. 8611 Balboa Avenue San Diego, San Diego, CA 92123 Kyocera Communications, Inc.. Proprietary/Confidential Date: 08/16/2011 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for Short-Term Confidentiality FCC ID: OVFC51213CD To Whom It May Concern: In accordance with §0.457 and 0.459 of CFR 47, KYOCERA Corporation requests short-term confidentiality (135 days) for the following items 1. Test Setup Photos 2. External and Internal Photos 3. User’s Manual These items contain detailed system and equipment description and related information about the product which KYOCERA Corporation considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, KYOCERA Corporation also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Best Regards, ____________________________ C. K. Li Director, Design Center Kyocera Corporation c/o Kyocera Communications, Inc. (KCI) 8611 Balboa Avenue San Diego, San Diego, CA 92123

Applicant:Kyocera FCC ID:OVFC51213CD IC #:3572A-C5121 Report #:CT-C5121-7-0711-R0 EXHIBIT 7: EXTERNAL PHOTOS © 2011 Comptest Services LLC Page 1 of 3 External Photos This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. Applicant:Kyocera FCC ID:OVFC51213CD IC #:3572A-C5121 Report #:CT-C5121-7-0711-R0 © 2011 Comptest Services LLC Page 2 of 3 External Photos This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. Applicant:Kyocera FCC ID:OVFC51213CD IC #:3572A-C5121 Report #:CT-C5121-7-0711-R0 © 2011 Comptest Services LLC Page 3 of 3 External Photos This report shall not be reproduced except in full, without the written consent of CompTest Services LLC.

FCC ID: OVFC51213CD IC #: 3572A-C5121 Label Information Page 1 of 2 Model: C5121 Exhibit 6: ID Label Format Location Phone back view Battery compartment FCC/IC Label FCC ID: OVFC51213CD IC #: 3572A-C5121 Label Information Page 2 of 2 Model: C5121 FCC declaration statement Kyocera Wireless Corp. complies with FCC rules Part 2.925(d) that the label shall be permanently affixed to the equipment and shall be readily visible to the purchaser at the time of purchase: 1) This cellular phone has limited label space on the exterior of the unit. The FCC ID label is placed in the battery compartment. 2) The batteries for these devices are designed for easy removal and that the labels will be visible whenever the batteries are removed for charging or replacement. The phone will be market without the battery installed.

Applicant:Kyocera FCC ID:OVFC51213CD IC #:3572A-C5121 Report #:CT-C5121-8-0711-R0 1 EXHIBIT 8: INTERNAL PHOTOS © 2011 Comptest Services LLC Page 1 of 8 Internal Photos This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. Applicant:Kyocera FCC ID:OVFC51213CD IC #:3572A-C5121 Report #:CT-C5121-8-0711-R0 © 2011 Comptest Services LLC Page 2 of 8 Internal Photos This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. CDMA Antenna WiFi/Bluetooth Antenna Applicant:Kyocera FCC ID:OVFC51213CD IC #:3572A-C5121 Report #:CT-C5121-8-0711-R0 © 2011 Comptest Services LLC Page 3 of 8 Internal Photos This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. Applicant:Kyocera FCC ID:OVFC51213CD IC #:3572A-C5121 Report #:CT-C5121-8-0711-R0 © 2011 Comptest Services LLC Page 4 of 8 Internal Photos This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. Applicant:Kyocera FCC ID:OVFC51213CD IC #:3572A-C5121 Report #:CT-C5121-8-0711-R0 © 2011 Comptest Services LLC Page 5 of 8 Internal Photos This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. Applicant:Kyocera FCC ID:OVFC51213CD IC #:3572A-C5121 Report #:CT-C5121-8-0711-R0 © 2011 Comptest Services LLC Page 6 of 8 Internal Photos This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. Applicant:Kyocera FCC ID:OVFC51213CD IC #:3572A-C5121 Report #:CT-C5121-8-0711-R0 © 2011 Comptest Services LLC Page 7 of 8 Internal Photos This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. Applicant:Kyocera FCC ID:OVFC51213CD IC #:3572A-C5121 Report #:CT-C5121-8-0711-R0 © 2011 Comptest Services LLC Page 8 of 8 Internal Photos This report shall not be reproduced except in full, without the written consent of CompTest Services LLC.

Applicant: Kyocera FCC ID: OVFC51213CD IC #: 3572A-C5121 Report #: CT-C5121-9-0711-R1 © 2011 Comptest Services LLC Page 1 of 41 SAR Report This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. Specific Absorption Rate (SAR) FCC 47 CFR Part 2 IC RSS-102 Issue 4 Test Report For Kyocera Corporation c/o Kyocera Communication, Inc. Product:Tri-Band CDMA Mobile Phone Model:C5121 Applicant: Kyocera FCC ID: OVFC51213CD IC #: 3572A-C5121 Report #: CT-C5121-9-0711-R1 © 2011 Comptest Services LLC Page 2 of 41 SAR Report This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. TABLE OF CONTENTS 1 SUMMARY OF TESTING................................................................................................................... 4 2 EQUIPMENT UNDER TEST INFORMATION .................................................................................... 5 3 ACCESSORIES.................................................................................................................................. 5 3.1 BODY WORN ACCESSORIES.......................................................................................................... 5 3.2 BATTERIES................................................................................................................................... 5 4 TEST CONDITIONS ........................................................................................................................... 6 4.1 TEST FACILITIES........................................................................................................................... 6 4.2 AMBIENT CONDITIONS................................................................................................................... 6 4.3 RF CHARACTERISTICS OF THE TEST SITE....................................................................................... 6 4.4 TEST SIGNAL, FREQUENCIES AND OUTPUT POWER........................................................................ 7 4.5 DEVICE TEST CONDITIONS............................................................................................................ 9 4.6 MULTIPLE TRANSMITTERS AND ANTENNAS SAR EVALUATIONS..................................................... 10 4.7 ROUTER SAR EVALUATIONS....................................................................................................... 13 4.8 HAND SAR EVALUATIONS........................................................................................................... 14 4.9 SAR TESTS IN MOUTH AND JAW REGIONS OF THE SAM PHANTOM.............................................. 14 5 DESCRIPTION OF THE TEST EQUIPMENT................................................................................... 16 5.1 DOSIMETRIC SYSTEM.................................................................................................................. 16 5.2 ADDITIONAL EQUIPMENT NEEDED IN VALIDATION.......................................................................... 18 5.3 TISSUE STIMULANTS................................................................................................................... 18 5.4 PHANTOMS DESCRIPTION............................................................................................................ 19 5.5 ISOTROPIC E-FIELD PROBE......................................................................................................... 20 6 SYSTEM VALIDATION .................................................................................................................... 21 7 DESCRIPTION OF THE TEST PROCEDURE ................................................................................. 23 7.1 TEST POSITIONS......................................................................................................................... 23 7.2 SCAN PROCEDURES................................................................................................................... 25 7.3 SAR AVERAGING METHODS........................................................................................................ 25 8 MEASUREMENT UNCERTAINTY ................................................................................................... 26 9 TEST DATA...................................................................................................................................... 27 9.1 HEAD SAR TEST RESULTS......................................................................................................... 27 9.2 BODY-WORN SAR TEST RESULTS.............................................................................................. 31 9.3 HOTSPOT BODY SAR TEST RESULTS.......................................................................................... 35 9.4 SIMULTANEOUS SAR EVALUATION.............................................................................................. 39 10 LIST OF APPENDIX..................................................................................................................... 41 Applicant: Kyocera FCC ID: OVFC51213CD IC #: 3572A-C5121 Report #: CT-C5121-9-0711-R1 © 2011 Comptest Services LLC Page 3 of 41 SAR Report This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. ATTESTATION The tested device complies with the requirements in respect of all parameters subject to the test. The test results and statements relate only to the items tested. The test equipment used was suitable for the tests performed and within manufacturer’s published specifications and operating parameters. The test methods were consistent with the methods described in the relevant standards. Product: Tri-Band CDMA Mobile Phone with Bluetooth and WLAN Model #: C5121 FCC ID: OVFC51213CD Tested in accordance with: FCC §2.1093/OET-65 Supplement C IEEE P2528/D1.2 – 2003 FCC KDB 248227 D01 v01r02 FCC KDB 648474 D01 v01r05 FCC KDB 941225 v2 IC RSS-102 Issue 4 Te…

Text truncated - open the document above for the full version.

Applicant:Kyocera FCC ID:OVFC51213CD IC#:3572A-C5121 Report #:CT-C5121-9A-0711-R0 © 2011 Comptest Services LLC Page 1 of 19 SAR Validation Plots This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. EXHIBIT 9 APPENDIX A: SAR VALIDATION PLOTS Validation for HEAD Applicant:Kyocera FCC ID:OVFC51213CD IC#:3572A-C5121 Report #:CT-C5121-9A-0711-R0 © 2011 Comptest Services LLC Page 2 of 19 SAR Validation Plots This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. Test Laboratory: Comptest/Kyocera Date: 07/28/2011 835MHz Validation @ 20dbm, Probe #3035, DAE#530, Dipole #467 Communication System: CDMA, Frequency: 835 MHz, Duty Cycle: 1:1 Medium: Head 835 MHz,Medium parameters used: f = 835 MHz; σ = 0.9 mho/m; ε r = 41.4; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Flat Section DASY4 Configuration: Probe: ES3DV3 - SN3035, ConvF(6.08, 6.08, 6.08), Calibrated: 9/9/2010 Sensor-Surface: 4mm (Mechanical Surface Detection), Electronics: DAE4 Sn675,Calibrated: 5/5/2011 Measurement SW: DASY4, V4.7 Build 80 Postprocessing SW: SEMCAD, V1.8 Build 186 Temperature: Room T = 21.8 +/- 1 deg C, Liquid T = 22.0 +/- 1 deg C 835MHz Validation/Area Scan (61x121x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 1.03 mW/g 835MHz Validation/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 34.2 V/m; Power Drift = -0.001 dB Peak SAR (extrapolated) = 1.47 W/kg SAR(1 g) = 0.960 mW/g; SAR(10 g) = 0.624 mW/g Maximum value of SAR (measured) = 1.03 mW/g 0 dB = 1.03mW/g Applicant:Kyocera FCC ID:OVFC51213CD IC#:3572A-C5121 Report #:CT-C5121-9A-0711-R0 © 2011 Comptest Services LLC Page 3 of 19 SAR Validation Plots This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. Applicant:Kyocera FCC ID:OVFC51213CD IC#:3572A-C5121 Report #:CT-C5121-9A-0711-R0 © 2011 Comptest Services LLC Page 4 of 19 SAR Validation Plots This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. Test Laboratory: Comptest/Kyocera Date: 07/20/2011 1800MHz Validation, Probe #1618, DAE #530, Dipole #220 Communication System: CW 1800Mhz, Frequency: 1800 MHz, Duty Cycle: 1:1 Medium: H1800,Medium parameters used: f = 1800 MHz; σ = 1.46 mho/m; ε r = 40; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Flat Section DASY4 Configuration: Probe: ET3DV6 - SN1618, ConvF(5.41, 5.41, 5.41), Calibrated: 8/11/2010 Sensor-Surface: 4mm (Mechanical Surface Detection), Electronics: DAE4 Sn530,Calibrated: 5/5/2011 Measurement SW: DASY4, V4.7 Build 80 Postprocessing SW: SEMCAD, V1.8 Build 186 Temperature: Room T = 21.8 +/- 1 deg C, Liquid T = 22.0 +/- 1 deg C 1800Mhz/Area Scan (41x71x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 4.14 mW/g 1800Mhz/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 52.1 V/m; Power Drift = -0.002 dB Peak SAR (extrapolated) = 6.00 W/kg SAR(1 g) = 3.56 mW/g; SAR(10 g) = 1.91 mW/g Maximum value of SAR (measured) = 4.03 mW/g 0 dB = 4.03mW/g Applicant:Kyocera FCC ID:OVFC51213CD IC#:3572A-C5121 Report #:CT-C5121-9A-0711-R0 © 2011 Comptest Services LLC Page 5 of 19 SAR Validation Plots This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. Applicant:Kyocera FCC ID:OVFC51213CD IC#:3572A-C5121 Report #:CT-C5121-9A-0711-R0 © 2011 Comptest Services LLC Page 6 of 19 SAR Validation Plots This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. Test Laboratory: Comptest/Kyocera Date: 07/15/2011 1900Mhz Validation @ 20dBm Probe 3035, DAE 675 and Dipole 5d016 Communication System: CW, Frequency: 1900 MHz, Duty Cycle: 1:1 Medium: HSL1900,Medium parameters used (interpolated): f = 1900 MHz; σ = 1.4 mho/m; ε r = 39.7; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Flat Section DASY4 Configuration: Probe: ES3DV3 - SN3035, ConvF(5, 5, 5), Calibrated: 9/9/2010 Sensor-Surface: 4mm (Mechanical Surface Detection), Electronics: DAE4 Sn675,Calibrated: 5/5/2011 Measurement SW: DASY4, V4.7 Build 80 Postprocessing SW: SEMCAD, V1.8 Build 186 Temperature: Room T = 21.8 +/- 1 deg C, Liquid T = 22.0 +/- 1 deg C 1900MHz Validation @20dBm/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 4.83 mW/g 1900MHz Validation @20dBm/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 57.5 V/m; Power Drift = -0.342 dB Peak SAR (extrapolated) = 7.13 W/kg SAR(1 g) = 3.93 mW/g; SAR(10 g) = 2.04 mW/g Maximum value of SAR (measured) = 4.43 mW/g 0 dB = 4.43mW/g Applicant:Kyocera FCC ID:OVFC51213CD IC#:3572A-C5121 Report #:CT-C5121-9A-0711-R0 © 2011 Comptest Services LLC Page 7 of 19 SAR Validation Plots This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. Applicant:Kyocera FCC ID:OVFC51213CD IC#:3572A-C5121 Report #:CT-C5121-9A-0711-R0 © 2011 Comptest Services LLC Page 8 of 19 SAR Validation Plots This report shall not be reproduced except in full, without the written consent of CompTest Services LLC. Test Laboratory: Comptest/Kyocera Date: 07/25/2011 2450MHz Validation, Probe #3036, DAE #530, Dipole #776 Communication System: CW, Frequency: 2450 MHz, Duty Cycle: 1:1 Medium: HSL2450,Medium parameters used: f = 2450 MHz; σ = 1.88 mho/m; ε r = 38.6; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Flat Section DASY4 Configuration: Probe: ES3DV3 - SN3036, ConvF(4.44, 4.44, 4.44), Calibrated: 5/11/2011 Sensor-Surface: 4mm (Mechanical Surface Detection), Electronics: DAE4 Sn530,Calibrated: 5/5/2011 Measurement SW: DASY4, V4.7 Build 80 Postprocessing SW: SEMCAD, V1.8 Build 186 Temperature: Room T = …

Text truncated - open the document above for the full version.
