OVNAC9RFID communication between reader (i.e., ARC W55) and passive tag by using an UHF Carrier (902MHz to 928MHz)

UHF Desktop Reader Installation instruction UHF Lecteur de table Notice d’installation UHF Lector de mesa Procedimiento de instalación conforme con NOM-024 -SCFI-2013 © STid - 20 PA des Pradeaux FR13850 Gréasque - NI1148x04- Page 1 sur 7 - Ed. 28/11/2022 STid reserves the right to make change without notice, for the purpose of product improvement. Product references Characteristics Communication: USB Cable output: USB 2.0 cable – Length 1.50 m / 4.9 ft – Connector type A : Direct Current Driver installation Communication Bidirectionnal: by default, the reader is delivered in bidirectional SSCP mode. More details about reader communication are available in the protocol specification: Spec_Protocole_SSCP_UHF_INDUS-Vx.x. Keyboard emulation: the reader can be used in keyboard emulation: wedge mode. See Configuring the reader in Wedge mode. Configuring the reader in Wedge mode The readers can be configured with STid -USB Wedge Configuration tool available on download link: https://stid.com/images/UWedgeConfv110_setup.zip In this mode the reader emulates a keyboard and displays in the active window the characters received from the serial link. The reader is delivered with the default parameters in bold in the table. 1- Set the options needed (if different than the defaults). 2- Send the ‘Keyboard emulation ON’ command. Command Description of the command Options Update Put the converter in update mode. The file firmware.bin is supplied by STid. Language (set) Changes the keyboard layout. - Français (AZERTY) - English (QWERTY) Type case (set) Chooses whether the alphabetical characters are displayed on the screen in uppercase or lowercase. - Uppercase - Lowercase Numlock (set) Chooses which numerical keys are used: those on the numerical keypad or those above the alphabetical keys. - On (use numeric pad) - Off (use keyboard nb) Info (get) Shows the current configuration (version, baud rate, etc.). Timing (set) Define the time between the sending of 2 characters. between 20ms and 1s Carriage Return (set) Switches the carriage return off or on or on with release before key pressed. - Off - On - On + Released SOF (set) Add the character “ – “ at the beginning of the frame. - Off - On EOF (set) Add the character “ . “ at the end of the frame. - Off - On Reset to default Set the reader to factory default. EPC Private key (set) Set the user ID security reading mode. - Plain - Enciphered + value Private key Keyboard emulation (set) Enables / disables keyboard emulation mode. When the reader is in Keyboard emulation ON, the only command accepted is Keyboard emulation OFF. - Off (disable) - On (enable) Dimensions General tolerance following ISO NFT 58-000 standard. ARC-W45-G/U04-5AA1: 865 - 868 MHz ARC-W45-G/U04-5AA1M: 865.7 MHz Morocco ARC-W55-G/U04-5AA1: 902 - 928 MHz ARC-W55-G/U04-5AA1AU: Australia ARC-W55-G/U04-5AA1NZ: New Zealand ARC-W55-G/U04-5AA1PE: Peru ARC-W55-G/U04-5AA1PH: Philippines Windows ≥ 10: Windows automatically detects the reader as a ‘USB COMPOSITE DEVICE’ and installs the driver. Windows < 10: the driver is automatically installed with a STid Software, if no STid software are installed: - Contact [email protected] to obtain the 2 drivers files: cdc.cat and fsl_ucwxp.inf. - Connect the reader to the USB port COM of PC. - Copy the 2 files in the directory: C:\Windows\INF. US FR ES 3.15 in / 80,0 mm 1.09 in / 27,7 mm 4 .22 in / 107,1 mm UHF Desktop Reader Installation instruction UHF Lecteur de table Notice d’installation UHF Lector de mesa Procedimiento de instalación conforme con NOM-024 -SCFI-2013 © STid - 20 PA des Pradeaux FR13850 Gréasque - NI1148x04- Page 2 sur 7 - Ed. 28/11/2022 STid reserves the right to make change without notice, for the purpose of product improvement. Declaration of Compliance STid declares that the ARC-W45-G & ARC-W55-G readers is compliant to the fundamental requirements of Directive RED 2014/53/EU and Directive RoHs 2011/65/EU and Commission Delegated Directive 2015/863/EU. A copy of our declaration is available upon request send to [email protected]. This device complies with Part 15 of the FCC rules and with Innovation, Science and Economic Development Canada’s license-exempt RSS(s). Operation is subject to the following two conditions: 1) This device must not cause harmful interference. 2) This device must accept any interference received, including interference that may cause undesired operation. Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can emit radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the distance between the equipment and receiver. - Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for assistance. This equipment complies with FCC’s and ISEDC's radiation exposure limits (using RSS-102 rules) set forth for an uncontrolled environment under the following conditions: - This equipment should be installed and operated such that a minimum separation distance of 34 cm / 13.39 in is maintained between the rad…

Text truncated - open the document above for the full version.

HEADQUARTERS 20 Parc d’activités des Pradeaux 13850 Gréasque, France Tél : +33 (0)4 42 12 60 60 [email protected] S.A.S. au capital de 1 588 800 € - RCS Marseille 408 472 751 Siret 408 472 751 00044 – NAF 7112B - N° TVA FR96 408 472 751 G R É A S Q U E | P A R I S | W A R W I C K | I R V I N G | M E X I C O | D U B A I Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Gréasque (France), March 21st, 2023 Subject: Attestation Statements Part 2.911(d)(5)(i) Filing Applicant: STID FCC ID: OVNAC9 STID (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, March 21st, 2023 Sylvain POITRAT Technical Director STid

HEADQUARTERS 20 Parc d’activités des Pradeaux 13850 Gréasque, France Tél : +33 (0)4 42 12 60 60 [email protected] S.A.S. au capital de 1 588 800 € - RCS Marseille 408 472 751 Siret 408 472 751 00044 – NAF 7112B - N° TVA FR96 408 472 751 G R É A S Q U E | P A R I S | W A R W I C K | I R V I N G | M E X I C O | D U B A I Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Gréasque (France), March 21st, 2023 Subject: Attestation Statements Part 2.911(d)(5)(ii) Filing Applicant: STID FCC ID: OVNAC9 STID (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, March 21st, 2023 Sylvain POITRAT Technical Director STid

HEADQUARTERS 20 Parc d’activités des Pradeaux 13850 Gréasque, France Tél : +33 (0)4 42 12 60 60 [email protected] S.A.S. au capital de 1 588 800 € - RCS Marseille 408 472 751 Siret 408 472 751 00044 – NAF 7112B - N° TVA FR96 408 472 751 G R É A S Q U E | P A R I S | W A R W I C K | I R V I N G | M E X I C O | D U B A I Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Gréasque (France), March 21st, 2023 Subject: Attestation Statements Part 2.911(d)(5)(ii) Filing Applicant: STID FCC ID: OVNAC9 STid (“the applicant”) certifies that, as of the date of the filing of the application, STid North America is our designated U.S. agent for service of process for the above referenced FCC ID. STid accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. STid North America accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: STid North America FRN: 0033555897 Address: 6012 Campus Circle Drive. W Suite 210 Irving, Texas 75063 – United States Contact Person: Frederick R. TRUJILLO Email: [email protected] Sincerely, STid STid North America Sylvain POITRAT Frederick R. TRUJILLO

HEADQUARTERS 20 Parc d’activités des Pradeaux 13850 Gréasque, France Tél : +33 (0)4 42 12 60 60 [email protected] S.A.S. au capital de 1 588 8 00 € - RCS Marseille 408 472 751 Siret 408 472 751 00044 – NAF 7112B - N° TVA FR96 408 472 751 G R É A S Q U E | P A R I S | W A R W I C K | I R V I N G | M E X I C O | D U B A I Gréasque (France), September 30 th 20 22 Subject: RADIO Certification of ARC Applicant: STID Product (PMN): ARC Model (HVIN): W55 FCC ID: OVNAC9 IC ID: 10520A-ARCU To Whom It May Concern: We would like to submit the above product for Certification concerning FCC and ISED rules for a new single certification. Please review all required documents enclosed. This application is RFID communication between reader (i.e., ARC W55) and passive tag by using an UHF Carrier (902MHz to 928MHz). Compliance for RF exposure requirement is demonstrated in test report. If you have any queries, please do not hesitate to contact us. Regards, September 30th 2022 Sylvain Poitrat Technical Director STid

HEADQUARTERS 20 Parc d’activités des Pradeaux 13850 Gréasque, France Tél : +33 (0)4 42 12 60 60 [email protected] S.A.S. au capital de 1 588 8 00 € - RCS Marseille 408 472 751 Siret 408 472 751 00044 – NAF 7112B - N° TVA FR96 408 472 751 G R É A S Q U E | P A R I S | W A R W I C K | I R V I N G | M E X I C O | D U B A I Gréasque (France), September 30 th 20 22 Subject: RADIO Certification of ARC Applicant: STID Product (PMN): ARC Model (HVIN): W55 FCC ID: OVNAC9 To Whom I t May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Schematics Operational Descript ion Parts List W55 BlkDia.pdf” W55 Schem.pdf” W55 Opdes.pdf” W55 PartsLst.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be h armful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. If you have any queries, please do not hesitate to contact us. Regards, September 30th 2022 Sylvain Poitrat Technical Director STid HEADQUARTERS 20 Parc d’activités des Pradeaux 13850 Gréasque, France Tél : +33 (0)4 42 12 60 60 [email protected] S.A.S. au capital de 1 588 8 00 € - RCS Marseille 408 472 751 Siret 408 472 751 00044 – NAF 7112B - N° TVA FR96 408 472 751 G R É A S Q U E | P A R I S | W A R W I C K | I R V I N G | M E X I C O | D U B A I

Author : Nicolas Sogoyan external photos.docx External views Front side down side Author : Nicolas Sogoyan external photos.docx Up side Left and right side Author : Nicolas Sogoyan external photos.docx Back side

$XWKRU1LFRODV6RJR\DQ ODEHOVBVDPSOHVGRF[   >ĂďĞůƐǀŝĞǁƐ /DEHOV3ODFHPHQW    $XWKRU1LFRODV6RJR\DQ ODEHOVBVDPSOHVGRF[   /DEHOVGHWDLOV

Author : Nicolas Sogoyan internal photos .docx internal views General view pcb (2 faces) Antenna Author : Nicolas Sogoyan internal photos .docx Board “out of” the cover

Siège Social : Emitech - 3, avenue des Coudriers - Z.A. de l’Observatoire - 78180 MONTIGNY LE BX - France Siret : 344 545 645 00022 - Tél. : 33 (0)1 30 57 55 55 - Fax : 33 (0)1 30 43 74 48 - E-mail : [email protected] - URL : www.emitech.fr SAS au capital de 1 560 000 € - R.C.S. VERSAILLES 344 545 645 - APE 7112B RE-EVE-21C753-2A Ed.0 Duplication of this test report is only permitted for an integral photographic facsimile. It includes the number of pages referenced here above. This document is the result of testing a specimen or a sample of the product submitted. It does not imply an assessment of the conformity of the whole manufactured products of the tested sample. Test report issued under the responsibility of: EMITECH MONTPELLIER laboratory RF EXPOSURE TEST REPORT KDB 447498 D01 RSS-102, Issue 5 Company ...................................... : STID Address. ......................................... : 20 PARC D’ACTIVITES DES PRADEAUX 13850 GREASQUE FRANCE Test item description. .................. : UHF RFID reader Trade Mark. .................................... : STID Manufacturer................................... : STID Model/Type reference. .................... : W55 / ARC FCC ID ............................................ : OVNAC9 IC .................................................... : 10520A-ARCU Ratings. ........................................... : 4.5Vdc to 5.5Vdc Testing Laboratory ...................... : EMITECH MONTPELLIER laboratory Address. ......................................... : 145 rue de Massacan 34740 VENDARGUES FRANCE Report Reference No. .................. : RE-EVE-21C753-2A Test procedure. ............................. : FCC IC Certification Diffusion. ........................................ : Mr SOGOYAN Applicant’s name. .......................... : STID Date of issue. ................................. : March 22, 2023 Total number of pages. .................. : 9 Revision. ........................................ : 0 Modified page(s). ........................... : Creation Compiled by. .................................. : Olivier AELBRECHT Approved by (+ signature). ............ : Olivier HEYER (Laboratory Manager) RE-EVE-21C753-2A Ed.0 Page 2 on 9 REPORT INDEX: 1. GENERAL INFORMATIONS .......................................................................................................................... 3 2. REFERENCE DOCUMENT(S) ........................................................................................................................ 4 3. EQUIPMENT TECHNICAL DESCRIPTION .................................................................................................... 5 3.1. TEST CONDITIONS ................................................................................................................................... 5 3.2. EUT MARKING PLATE .............................................................................................................................. 5 3.3. EUT GENERAL VIEW ................................................................................................................................ 6 3.4. EUT MECHANICAL AND ELECTRICAL DESIGN ............................................................................................. 6 3.5. EUT INPUT/OUTPUT PORTS ...................................................................................................................... 7 3.6. SUPPORTING EQUIPMENT USED DURING TEST .......................................................................................... 8 3.7. EUT RADIO SPECIFICATIONS .................................................................................................................... 9 4. RF EXPOSURE ............................................................................................................................................... 9 REVISION HISTORY: Revision Date Modified pages Modifications 0 March 22, 2023 / Creation RE-EVE-21C753-2A Ed.0 Page 3 on 9 1. GENERAL INFORMATIONS This document submits the results of ElectroMagnetic Field (EMF) human exposure tests performed on the equipment UHF RFID reader ARC-W45-G/U04-5AA/1 (denominated hereafter E.U.T.: equipment under test) according to document(s) listed in §2 of this test report. TESTING PROCEDURE AND TESTING LOCATION: Testing Location ....................................... : EMITECH MONTPELLIER laboratory Address. ..................................................... : 145 rue de Massacan 34740 VENDARGUES FRANCE Test procedure. .......................................... : FCC IC Certification Tested by .................................................... : Olivier AELBRECHT Test supervisor ........................................... : None Date of receipt of test item ......................... : N/A Date (s) of performance of tests ................. : From May the 25th to June the 11th of 2021 APPLICANT'S GENERAL INFORMATIONS: Company name ......................................... : STID Company address. ..................................... : 20 PARC D’ACTIVITES DES PRADEAUX 13850 GREASQUE FRANCE Person(s) present during the tests. ............ : No representative for company attended the tests. Responsible. ............................................... : Mr SOGOYAN GENERAL REMARKS: The information in italics is declared by the manufacturer and is under his responsibility The test results presented in this report relate only to the object tested. The results contained in this report reflect the results for this particular model and serial number. It is the responsibility of the manufacturer to ensure that all production models meet the intent of the requirements detailed within this report. "(see Enclosure #)" refers to additional information appended to the report. "(see appended table)" refers to a table appended to the report. Throughout this report the decimal separator is point. POSSIBLE TEST CASE VERDICTS: Test case does not apply to the test object. : N/A Test …

Text truncated - open the document above for the full version.

Siège Social : Emitech - 3, avenue des Coudriers - Z.A. de l’Observatoire - 78180 MONTIGNY LE BX - France Siret : 344 545 645 00022 - Tél. : 33 (0)1 30 57 55 55 - Fax : 33 (0)1 30 43 74 48 - E-mail : [email protected] - URL : www.emitech.fr SAS au capital de 1 560 000 € - R.C.S. VERSAILLES 344 545 645 - APE 7112B RR-EVE-21C753-2A Ed.0 Duplication of this test report is only permitted for an integral photographic facsimile. It includes the number of pages referenced here above. This document is the result of testing a specimen or a sample of the product submitted. It does not imply an assessment of the conformity of the whole manufactured products of the tested sample. Test report issued under the responsibility of: EMITECH MONTPELLIER laboratory MRA US-EU Designation Number: FR0006 Canadian CAB Identifier: FR0003 RADIO TEST REPORT FCC part 15.247 RSS-247_Issue 2, February 2017 Company ....................................... : STID Address. .......................................... : 20 PARC D’ACTIVITES DES PRADEAUX 13850 GREASQUE FRANCE Test item description. .................. : UHF RFID reader Trade Mark. .................................... : STID Manufacturer................................... : STID Model/Type reference. .................... : W55 / ARC FCC ID ............................................ : OVNAC9 IC .................................................... : 10520A-ARCU Ratings. ........................................... : 4.5Vdc to 5.5Vdc Testing Laboratory ....................... : EMITECH MONTPELLIER laboratory Address. .......................................... : 145 rue de Massacan 34740 VENDARGUES FRANCE Report Reference No. ................... : RR-EVE21C753-2A Test procedure. .............................. : FCC IC Certification Diffusion. ......................................... : Mr SOGOYAN Applicant’s name. ........................... : STID Date of issue. .................................. : February 23, 2023 Total number of pages. ................... : 48 Revision. ......................................... : 0 Modified page(s). ............................ : Creation Compiled by. ................................... : Olivier AELBRECHT Approved by (+ signature). ............. : Olivier HEYER (Laboratory Manager) RR-EVE-21C753-2A Ed.0 Page 2 on 48 REPORT INDEX: 1. GENERAL INFORMATIONS .......................................................................................................................... 3 2. REFERENCE DOCUMENT(S) ........................................................................................................................ 4 3. EQUIPMENT TECHNICAL DESCRIPTION .................................................................................................... 5 3.1. TEST CONDITIONS ................................................................................................................................... 5 3.2. EUT MARKING PLATE .............................................................................................................................. 5 3.3. EUT GENERAL VIEW ................................................................................................................................ 6 3.4. EUT MECHANICAL AND ELECTRICAL DESIGN ............................................................................................. 6 3.5. EUT INPUT/OUTPUT PORTS ...................................................................................................................... 7 3.6. SUPPORTING EQUIPMENT USED DURING TEST .......................................................................................... 8 3.7. EUT RADIO SPECIFICATIONS .................................................................................................................... 9 4. EUT REQUIREMENTS FOR FCC RULES ...................................................................................................10 4.1. SUBPART A - GENERAL ..........................................................................................................................10 4.2. SUBPART B - UNINTENTIONAL RADIATORS ..............................................................................................12 5. OPINION(S) AND INTERPRETATION(S) ....................................................................................................12 6. RESULT SUMMARY .....................................................................................................................................13 7. RF EXPOSURE .............................................................................................................................................15 8. MEASUREMENT UNCERTAINTY ................................................................................................................15 9. TEST CONDITIONS AND RESULTS ...........................................................................................................16 9.1. CONDUCTED EMISSION (MEASUREMENT) .................................................................................................16 9.2. OCCUPIED BANDWIDTH ..........................................................................................................................20 9.3. 20DB BANDWIDTH, CARRIER FREQUENCY SEPARATION AND NUMBER OF HOPPING CHANNELS ..................23 9.4. RADIATED SPURIOUS EMISSIONS .............................................................................................................28 9.5. BAND-EDGE COMPLIANCE OF EMISSIONS .................................................................................................38 9.6. EFFECTIVE ISOTROPIC RADIATED POWER ................................................................................................40 9.7. MEASUREMENT OF FREQUENCY STABILITY §15.215 (C) AND RSS-GEN .................................................47 REVISION HISTORY: Revision Date Modified pages Modifications 0 February 23, 2023 / Creation RR-EVE-21C753-2A Ed.…

Text truncated - open the document above for the full version.

Information about the antenna from the website: https://www.cable-antenna.com/sale-11028844-25-25-4mm-active-rfid-patch-antenna- ceramic-patch-pcb-rfid-reader-external-antenna.html 25*25*4mm Active RFID Patch Antenna , Ceramic Patch PCB RFID Reader External Antenna Product Details: Place of Origin: China Brand Name: RY Certification: CE,ROHS Model Number: RY-915mhz-64627 Detail Information Color: White Mounting Type: Embedded,Screw,adhesive,magnetic Application: Indoor/Outdoor Gain: 2dbi Connector: No Type: Whip,puck,panel Product Description Passive indoor 25*25*4mm rfid 915mhz active ceramic patch pcb internal antenna Electrical Characteristics Antenna 1 Antenna model 25*25*4mm 2 Frequency Range 1575.42mhz 3 V.S.W.R <1.5 4 Band With@10dB ≥5MHz 5 Gain 2dbi 6 Impedance 50Ω 7 Polarization RHCP Material No Part Name SPEC 1 Antenna internal 2 RF Cable no cable no 3 RF Connector no connector Environment Condition 1 Working Temp -40°C~+85°C, 10%~95% RH 2 Storage Temp -55°C~+100°C, 10%~95% RH Product Details:

RR-EVE-21C753-2A Ed.0 modifié OHE Page 17 on 48 TEST SETUP PHOTO(S) RR-EVE-21C753-2A Ed.0 modifié OHE Page 31 on 48 TEST SETUP PHOTO(S) - EUT POSITION FOR FREQ < 1GHZ TEST SETUP PHOTO(S) - EUT POSITION FOR FREQ > 1GHZ RR-EVE-21C753-2A Ed.0 modifié OHE Page 32 on 48 TEST SETUP PHOTO(S) - FOR FREQ < 30MHZ TEST SETUP PHOTO(S) - FOR 30MHZ < FREQ < 200MHZ RR-EVE-21C753-2A Ed.0 modifié OHE Page 33 on 48 TEST SETUP PHOTO(S) - FOR 200MHZ < FREQ < 1GHZ TEST SETUP PHOTO(S) - FOR 1GHZ < FREQ RR-EVE-21C753-2A Ed.0 modifié OHE Page 41 on 48 TEST SETUP PHOTO(S)
