OWA00GT2XGNSS Enabled Logistics Modem

DOC REVISION: 200206a DRAFT Because field operations don’t have to be chaotic GT2 Product User Guide Geoforce Inc. Document Number: HW-IS-0-0005 Guide Revision: 200206a 06-February-2020 GT2 User Guide DRAFTDRAFT 12 DOC CONTROL: HW-IS-0-0093DOC REVISION: 200206a DRAFTDRAFT Combining a cloud-based software platform with ruggedized GPS tracking devices and global satellite and cellular networks, Geoforce’s Track and Trace solutions bring control to often chaotic field operations. With over 1,300 customers tracking more than 160,000 assets in over 90 countries, the company operates the world’s largest network of connected field equipment within the oil & gas industry, and its solutions are used in many other field operations intensive industries, including agriculture, construction, mining, transportation, logistics, and rail. Headquartered in Dallas, Texas, Geoforce has R&D offices in Bozeman, Montana, sales and support offices in Houston, Texas, Denver, Colorado, Arroyo Grande, California, Macae, Brazil, Melbourne, Australia, and Calgary, Canada, and sales and service professionals in West Texas and South Louisiana. For more information, visit www.geoforce.com. This user guide is applicable to the following GT2 model codes: 1. - GENERAL STATEMENT OF WARRANTY Geoforce warrants that for one year from that date that title passes to Customer for Hardware (the “Warranty Period”), the Hardware sold will be free of defects in materials and workmanship when installed, operated, and serviced in strict accordance with Geoforce’s and the manufacturer’s requirements. Geoforce will, at its sole option and at no charge to Customer, refund, repair, or send a replacement for the Hardware to the location of initial export from a Geoforce affiliate noting Customer as the importer/ exporter of record (if outside the US). 2. - EXCEPTIONS FROM WARRANTY COVERAGE This warranty does not cover: (a) Hardware that has been tampered with or serviced without Geoforce’s authorization, (b) Hardware that has been lost or stolen through no fault of Geoforce, (c) Hardware that is designed to be consumable or (d) Hardware subjected to abuse, misuse, or neglect, or (e) Hardware that has been deemed failed due to improper operational use or mis-matched to ineffective use-case by the customer. Geoforce does not warrant that the hardware will meet customer’s needs or expectations or that any piece of hardware will work on any particular networks. ALL OTHER WARRANTIES ARE EXPRESSLY DISCLAIMED INCLUDING THE WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. 3. - ADDITIONAL WARRANTY TERMS See the fully executed Geoforce purchase agreement and Statement of Warranty for a complete statement of warranty terms. GT2c GT2C-SL-EX GT2C-SL-NE GT2s GT2S-IRD-SL-EX GT2S-IRD-SL-NE GT2h GT2H-IRD-SL-EX The Geoforce GT2 is the 4th generation GPS tracker in the proven Geoforce GT series of world-leading industrial tracking devices. The GT2 is a single-device platform available in three configurations: Satellite- only, Cellular-only, and Hybrid (Sat + Cell). All variants have a dual power system (solar plus primary battery), providing 100% global asset visibility, while operating in the world’s harshest environments. The GT2’s rigid design and manufacturing processes provide unmatched and proven durability in the field. The dual battery combination ensures a service life of 10+ years. Combining advanced wireless technologies and smart power management, the GT2 is the most rugged and reliable device family of trackers ever produced. 2.80 in 71.2 mm 6.47 in 164.2 mm 1.30 in 33.0 mm Solar Energy Harvesting LED Visual Feedback Magnetic ON/OFF switch Radio Transmitter Section Hermetically Sealed Body ABOUT THE GEOFORCE GT2ABOUT GEOFORCE APPLICABLE MODELS The information and specifications in this document are subject to change without notice. RIGHT TO CHANGE MATERIAL Copyright © 2020 Geoforce Inc. - All Rights Reserved. No portion of this media may be reproduced in any form without permission from Geoforce, except as permitted by U.S. copyright law. For permissions contact Geoforce at www.geoforce.com. COPYRIGHT NOTICE NOTICES SUMMARY OF WARRANTY TERMS The customer is solely responsible for compliance with all legal, regulatory, and safety-related requirements concerning the products and any use of Geoforce products in the customer’s applications, not withstanding any applications related information or support that may be provided by Geoforce. REGULATORY COMPLIANCE STATEMENT 34 DOC CONTROL: HW-IS-0-0093DOC REVISION: 200206a DRAFTDRAFT GT2 General Installation and Mounting Guide To ensure ideal performance it is advised to consider the following: 1. Select a mounting location that provides the best view of the sky and the sun. 2. A flat horizontal mounting position (lying flat, facing skyward) is preferred. 3. Vertical mounting orientations (solar panel side of device facing horizon) are acceptable. NOTE: These orientations may impact performance and overall battery life. 4. Mount on the flattest and hardest surface possible. 5. Select a mounting location that isolates the GT2 from damage. 6. Recommended mounting area size is 8.5” L x 3.5” W (216mm L x 90mm W). 7. Thoroughly clean the mounting area, especially if using VHB mounting. 8. DO NOT PAINT OR COVER THE GT2. NOTE: Doing so may negatively impact product performance and battery life. For installations that do not require a protective bezel, that are isolated from abuse, extreme weather, and temperatures the GT2 has a pre-installed set of VHB adhesive pads that can be used to “peel and stick” to any clean surface above 50°F (10°C). The Geoforce VHB Installation and Removal Guide MUST be followed to ensure proper adhesion to the asset. STEP 1: SELECT A MOUNTING LOCATION STEP 2: SELECT A MOUNTING METHOD Additional information on each mechnical mounting method is available on the following pages. VHB ADHESIVE MOUNTING MECHANICAL MOUNTING GT2 General Installation and Mounting Guide 1. Re…

Text truncated - open the document above for the full version.

DOC REVISION: 200501a Because field operations don’t have to be chaotic GT2 Product Regulatory Guide Geoforce Inc. Document Number: HW-IS-0-0094 Guide Revision: 200501a 01-May-2020 GT2 Product Regulatory Guide DRAFT 12 DOC CONTROL: HW-IS-0-0094DOC REVISION: 200501a Combining a cloud-based software platform with ruggedized GPS tracking devices and global satellite and cellular networks, Geoforce’s Track and Trace solutions bring control to often chaotic field operations. With over 1,300 customers tracking more than 160,000 assets in over 90 countries, the company operates the world’s largest network of connected field equipment within the oil & gas industry, and its solutions are used in many other field operations intensive industries, including agriculture, construction, mining, transportation, logistics, and rail. Headquartered in Dallas, Texas, Geoforce has R&D offices in Bozeman, Montana, sales and support offices in Houston, Texas, Denver, Colorado, Arroyo Grande, California, Macae, Brazil, Melbourne, Australia, and Calgary, Canada, and sales and service professionals in West Texas and South Louisiana. For more information, visit www.geoforce.com. This regulatory guide is applicable to the following GT2 model codes: 1. - GENERAL STATEMENT OF WARRANTY Geoforce warrants that for one year from that date that title passes to Customer for Hardware (the “Warranty Period”), the Hardware sold will be free of defects in materials and workmanship when installed, operated, and serviced in strict accordance with Geoforce’s and the manufacturer’s requirements. Geoforce will, at its sole option and at no charge to Customer, refund, repair, or send a replacement for the Hardware to the location of initial export from a Geoforce affiliate noting Customer as the importer/ exporter of record (if outside the US). 2. - EXCEPTIONS FROM WARRANTY COVERAGE This warranty does not cover: (a) Hardware that has been tampered with or serviced without Geoforce’s authorization, (b) Hardware that has been lost or stolen through no fault of Geoforce, (c) Hardware that is designed to be consumable or (d) Hardware subjected to abuse, misuse, or neglect, or (e) Hardware that has been deemed failed due to improper operational use or mis-matched to ineffective use-case by the customer. Geoforce does not warrant that the hardware will meet customer’s needs or expectations or that any piece of hardware will work on any particular networks. ALL OTHER WARRANTIES ARE EXPRESSLY DISCLAIMED INCLUDING THE WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. 3. - ADDITIONAL WARRANTY TERMS See the fully executed Geoforce purchase agreement and Statement of Warranty for a complete statement of warranty terms. GT2c GT2C-SL-EX GT2C-SL-NE GT2s GT2S-IRD-SL-EX GT2S-IRD-SL-NE GT2h GT2H-IRD-SL-EX The Geoforce GT2 is the 4th generation GPS tracker in the proven Geoforce GT series of world-leading industrial tracking devices. The GT2 is a single-device platform available in three configurations: Satellite- only, Cellular-only, and Hybrid (Sat + Cell). All variants have a dual power system (solar plus primary battery), providing 100% global asset visibility, while operating in the world’s harshest environments. The GT2’s rigid design and manufacturing processes provide unmatched and proven durability in the field. The dual battery combination ensures a service life of 10+ years. Combining advanced wireless technologies and smart power management, the GT2 is the most rugged and reliable device family of trackers ever produced. 2.80 in 71.2 mm 6.47 in 164.2 mm 1.30 in 33.0 mm Solar Energy Harvesting LED Visual Feedback Magnetic ON/OFF switch Radio Transmitter Section Hermetically Sealed Body ABOUT THE GEOFORCE GT2ABOUT GEOFORCE APPLICABLE MODELS The information and specifications in this document are subject to change without notice. RIGHT TO CHANGE MATERIAL Copyright © 2020 Geoforce Inc. - All Rights Reserved. No portion of this media may be reproduced in any form without permission from Geoforce, except as permitted by U.S. copyright law. For permissions contact Geoforce at www.geoforce.com. COPYRIGHT NOTICE NOTICES SUMMARY OF WARRANTY TERMS The customer is solely responsible for compliance with all legal, regulatory, and safety-related requirements concerning the products and any use of Geoforce products in the customer’s applications, not withstanding any applications related information or support that may be provided by Geoforce. REGULATORY COMPLIANCE STATEMENT 34 DOC CONTROL: HW-IS-0-0094DOC REVISION: 200501a Shipping and Transport Guidance TRANSPORT AND EXPORT CONTROL CODES Battery Transport and Disposal Guidance LITHIUM BATTERY REGULATORY INFORMATION Lithium Battery Cell Type ................................ Cell Chemistry ..................................................... Individual Cell Lithium Mass ........................... Cell Installation Method .................................... IATA Regulated Packing Instruction ............. ECCN - EXPORT CONTROL CLASSIFICATION NUMBER 5A991.B.3: TELECOMMUNICATION EQUIPMENT, NOT CONTROLLED BY 5A001 “TELECOMMUNICATIONS SYSTEMS, EQUIPMENT, COMPONENTS AND ACCESSORIES” US CENSUS BUREAU “SCHEDULE B” CODE 8517.62.0050: DIGITAL (MODEMS, SWITCHES, ETC.) AND RF PRODUCTS FOR WARRANTY RETURNS: 9801.10.0000 HTS/HS - INTERNATIONAL HARMONIZED TARIFF CODE 8517.62.0050: DIGITAL (MODEMS, SWITCHES, ETC.) AND RF PRODUCTS FOR WARRANTY RETURNS: 9801.10.0000 ITAR - INTERNATIONAL TRAFFIC IN ARMS REGULATIONS The Geoforce GT2 is not classified as a “defense article” or as “dual use” and does not require an export license under ITAR regulations. The GT2 has been tested and evaluated under normal operations to DO-160G guidelines for non-interference with aircraft systems during aircraft transport. Normal operations with a single installed unit are typically acceptable. For bulk shipments the GT2 is shipped in radio silence mode. NOTE: GT2 products are packaged from Geoforce in packaging acceptable fo…

Text truncated - open the document above for the full version.

Request for Permanent Confidentiality To: Federal Communications Commission - Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21048 Manufacturer/Issuer: Geoforce Inc. 5830 Granite Parkway, Suite 1200 Plano, TX 75024 Host Products: This declaration is issued under the sole responsibility of the manufacturer for: Product Brand: “Geoforce GT2” Product Marketing Names: GT2c, GT2s, GT2h Product Radio Model Codes: OWAC00, OWAS86, OWAH86 Product Description: GNSS Enabled Logistics Modem FCCID: OWA00GT2X Statement: To Whom It May Concern: In accordance with §0.457(d) and §0.459 of CFR 47, and KDB 726920, Geoforce Inc. hereby requests permanent confidentiality for documents filed under the following exhibit types: 1. Block Diagram 2. Schematic Diagrams 3. Parts List/Bill of Materials 4. Operational Description These items contain detailed system and equipment description and related information about the product which Geoforce Inc. considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Geoforce Inc. also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. We are aware that exhibit types cover letters, attestations, label document, test reports, RF exposure information (SAR and MPE reports), cannot be requested to be classified confidential and are thus subject to publication, as will be documents of all other exhibits types for which we have not requested a confidentiality classification. Signatory: Signed for on behalf of Geoforce Inc. Brandon Taylor Chief Hardware Architect – Geoforce Inc. +1-972-546-3878 Original Issue Date: Mar. 31, 2020 Last Updated: Mar. 31, 2020 DOC CONTROL: HW-RD-0-0107 Revision Code: 200331a

Request for Short-Term Confidentiality To: Federal Communications Commission - Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21048 Manufacturer/Issuer: Geoforce Inc. 5830 Granite Parkway, Suite 1200 Plano, TX 75024 Host Products: This declaration is issued under the sole responsibility of the manufacturer for: Product Brand: “Geoforce GT2” Product Marketing Names: GT2c, GT2s, GT2h Product Radio Model Codes: OWAC00, OWAS86, OWAH86 Product Description: GNSS Enabled Logistics Modem FCCID: OWA00GT2X Statement: To Whom It May Concern: In accordance with §0.457(d) and §0.459 of CFR 47, Geoforce Inc. hereby requests permanent confidentiality for documents filed under the following exhibit types until the product will be publicly announced: 1. External Photographs 2. Internal Photographs 3. User / Instruction Manual 4. Test Set-up Photographs These items contain detailed system and equipment description and related information about the product which Geoforce Inc. considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Geoforce Inc. also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. We are informed and aware of our obligation that we have to inform the involved TCB in written and in due time if we intend to market the product prior to the above specified confidentiality release date so that the short-term confidentiality classification can be reset prior to product launch. We are aware that exhibit types cover letters, attestations, label document, test reports, RF exposure information (SAR and MPE reports), cannot be requested to be classified confidential and are thus subject to publication, as will be documents of all other exhibits types for which we have not requested a confidentiality classification. Short term confidentiality period: 180 days from grant issue date. Signatory: Signed for on behalf of Geoforce Inc. Brandon Taylor Chief Hardware Architect – Geoforce Inc. +1-972-546-3878 Original Issue Date: Mar. 31, 2020 Last Updated: Mar. 31, 2020 DOC CONTROL: HW-RD-0-0108 Revision Code: 200331a

Validity of Test Results for Integrated Modules Manufacturer/Issuer: Geoforce Inc. 5830 Granite Parkway, Suite 1200 Plano, TX 75024 Host Products: This declaration is issued under the sole responsibility of the manufacturer for: Product Brand: “Geoforce GT2” Product Marketing Names: GT2c, GT2s, GT2h Product Description: GNSS Enabled Logistics Modem Declaration: Geoforce hereby declares that the test results from conducted tests applied to the radio modules noted below accurately represent the test results under the new conditions when the identified radio modules are integrated in the Geoforce host equipment. By integration of the said radio modules into the identified host equipment no changes were made to them or by external adaptation circuitry that impacts the validity of the results of the original module’s test reports; hence conducted signal measurements in the above listed reports also apply to product/models listed above. Product Marketing Name GT2c GT2s GT2h Product Host IDs FCCID: OWA00GT2X IC ID: 10540A-00GT2X FCCID: OWA00GT2X IC ID: 10540A-00GT2X FCCID: OWA00GT2X IC ID: 10540A-00GT2X Product Radio Config Model: OWAC00 OWAS86 OWAH86 Integrated Module 1 Manufacturer: Nordic Semi Model: nRF9160 FCCID: 2ANPO00HRF9160 ICID: 24529-NRF9160 Manufacturer: Iridium Model: 9603N FCCID: Q639603 ICID: 4629A-9603 Manufacturer: Nordic Semi Model: nRF9160 FCCID: 2ANPO00HRF9160 ICID: 24529-NRF9160 Integrated Module 2 Manufacturer: Zentri Model: AMW007 FCCID: 2ABPY-5B9198 ICID: 11685A-5B9198 NONE Manufacturer: Iridium Model: 9603N FCCID: Q639603 ICID: 4629A-9603 Integrated Module 3 NONE NONE Manufacturer: Zentri Model: AMW007 FCCID: 2ABPY-5B9198 ICID: 11685A-5B9198 Signatory: Signed for on behalf of Geoforce Inc. Brandon Taylor Chief Hardware Architect – Geoforce Inc. +1-972-546-3878 Original Issue Date: Mar. 31, 2020 Last Updated: Mar. 31, 2020 DOC CONTROL: HW-RD-0-0105 Revision Code: 200331a

GT2 External Photos File Document # HW-RD-0-0114 : Revision 200331a Author: Brandon Taylor Chief Hardware Architect Signature: Brandon Taylor Date: 03/31/2020 Approval: Approver Name Director of Hardware Development Signature: Troy Lanes Date: 03/31/2020 2 Geoforce Inc. Confidential Hard copy versions of this document are uncontrolled. The current revision can be verified in the Doc Control Repo. DOCUMENT # HW - RD - 0 - 0114: Revision 200331a | Geoforce Inc. Table of Contents SECTION PAGE 1. DESCRIPTION/PURPOSE..................................................................................................................................................... 4 2. SCOPE .................................................................................................................................................................................. 4 3. PROCESS, PROCEDURE, OR SPECIFICATION OWNER ......................................................................................................... 4 4. EXTERNAL PHOTO LISTING ................................................................................................................................................. 5 4.1. EXTERNAL PHOTOS – TOP SIDE .................................................................................................................................................... 5 4.2. EXTERNAL PHOTOS – BOTTOM SIDE ............................................................................................................................................... 6 5. REVISION HISTORY ............................................................................................................................................................ 7 3 Geoforce Inc. Confidential Hard copy versions of this document are uncontrolled. The current revision can be verified in the Doc Control Repo. DOCUMENT # HW - RD - 0 - 0114: Revision 200331a | Geoforce Inc. List of Figures SECTION PAGE FIGURE 1: TOP SIDE PHOTO 1 ............................................................................................................................... 5 FIGURE 2: TOP SIDE PHOTO 2 ............................................................................................................................... 5 FIGURE 3: BOTTOM SIDE PHOTO 1 ......................................................................................................................... 6 FIGURE 4: BOTTOM SIDE PHOTO 2 ......................................................................................................................... 6 List of Tables SECTION PAGE No table of figures entries found. 4 Geoforce Inc. Confidential Hard copy versions of this document are uncontrolled. The current revision can be verified in the Doc Control Repo. DOCUMENT # HW - RD - 0 - 0114: Revision 200331a | Geoforce Inc. 1. Description/Purpose Internal photo lineup of the GT2 product line. 2. Scope These photos are limited to the GT2 product line. 3. Process, Procedure, or Specification Owner This specification is owned and maintained by the Hardware Development group. 5 Geoforce Inc. Confidential Hard copy versions of this document are uncontrolled. The current revision can be verified in the Doc Control Repo. DOCUMENT # HW - RD - 0 - 0114: Revision 200331a | Geoforce Inc. 4. External Photo Listing 4.1. External Photos – Top Side FIGURE 1: TOP SIDE PHOTO 1 FIGURE 2: TOP SIDE PHOTO 2 6 Geoforce Inc. Confidential Hard copy versions of this document are uncontrolled. The current revision can be verified in the Doc Control Repo. DOCUMENT # HW - RD - 0 - 0114: Revision 200331a | Geoforce Inc. 4.2. External Photos – Bottom Side FIGURE 3: BOTTOM SIDE PHOTO 1 FIGURE 4: BOTTOM SIDE PHOTO 2 7 Geoforce Inc. Confidential Hard copy versions of this document are uncontrolled. The current revision can be verified in the Doc Control Repo. DOCUMENT # HW - RD - 0 - 0114: Revision 200331a | Geoforce Inc. 5. Revision History Rev Description Approval Date 200331a Initial Release TL 03/31/2020

GT2 Internal Photos File Document # HW-RD-0-0113 : Revision 200331a Author: Brandon Taylor Chief Hardware Architect Signature: Brandon Taylor Date: 03/31/2020 Approval: Approver Name Director of Hardware Development Signature: Troy Lanes Date: 03/31/2020 2 Geoforce Inc. Confidential Hard copy versions of this document are uncontrolled. The current revision can be verified in the Doc Control Repo. DOCUMENT # HW - RD - 0 - 0113: Revision 200331a | Geoforce Inc. Table of Contents SECTION PAGE 1. DESCRIPTION/PURPOSE..................................................................................................................................................... 4 2. SCOPE .................................................................................................................................................................................. 4 3. PROCESS, PROCEDURE, OR SPECIFICATION OWNER ......................................................................................................... 4 4. INTERNAL PHOTO LISTING ................................................................................................................................................. 5 4.1. INTERNAL PHOTOS WITH SHIELDS ................................................................................................................................................. 5 4.2. INTERNAL PHOTOS WITHOUT SHIELDS ............................................................................................................................................ 7 5. REVISION HISTORY ............................................................................................................................................................ 8 3 Geoforce Inc. Confidential Hard copy versions of this document are uncontrolled. The current revision can be verified in the Doc Control Repo. DOCUMENT # HW - RD - 0 - 0113: Revision 200331a | Geoforce Inc. List of Figures SECTION PAGE FIGURE 1: ANTENNA SIDE .................................................................................................................................... 5 FIGURE 2: COMPONENT SIDE 1 .............................................................................................................................. 5 FIGURE 3: COMPONENT SIDE 2 .............................................................................................................................. 6 FIGURE 4: COMPONENT SIDE WITHOUT SHIELDS........................................................................................................ 7 List of Tables SECTION PAGE No table of figures entries found. 4 Geoforce Inc. Confidential Hard copy versions of this document are uncontrolled. The current revision can be verified in the Doc Control Repo. DOCUMENT # HW - RD - 0 - 0113: Revision 200331a | Geoforce Inc. 1. Description/Purpose Internal photo lineup of the GT2 product line. 2. Scope These photos are limited to the GT2 product line. 3. Process, Procedure, or Specification Owner This specification is owned and maintained by the Hardware Development group. 5 Geoforce Inc. Confidential Hard copy versions of this document are uncontrolled. The current revision can be verified in the Doc Control Repo. DOCUMENT # HW - RD - 0 - 0113: Revision 200331a | Geoforce Inc. 4. Internal Photo Listing 4.1. Internal Photos with Shields FIGURE 1: ANTENNA SIDE FIGURE 2: COMPONENT SIDE 1 6 Geoforce Inc. Confidential Hard copy versions of this document are uncontrolled. The current revision can be verified in the Doc Control Repo. DOCUMENT # HW - RD - 0 - 0113: Revision 200331a | Geoforce Inc. FIGURE 3: COMPONENT SIDE 2 7 Geoforce Inc. Confidential Hard copy versions of this document are uncontrolled. The current revision can be verified in the Doc Control Repo. DOCUMENT # HW - RD - 0 - 0113: Revision 200331a | Geoforce Inc. 4.2. Internal Photos without Shields FIGURE 4: COMPONENT SIDE WITHOUT SHIELDS 8 Geoforce Inc. Confidential Hard copy versions of this document are uncontrolled. The current revision can be verified in the Doc Control Repo. DOCUMENT # HW - RD - 0 - 0113: Revision 200331a | Geoforce Inc. 5. Revision History Rev Description Approval Date 200331a Initial Release TL 03/31/2020

Radio Frequency Exposure Evaluation Report FOR: Geoforce Inc. Model Name: Geoforce GT2 Product Description: GNSS enabled logistics modem FCC ID: OWA00GT2X IC ID: 10540A-00GT2X Applied Rules and Standards: CFR Part Part1 (1.1307 &1.1310), Part 2 (2.1091), FCC KDB 447498 D01 General RF Exposure Guidance v06 ISEDC RSS-102 Issue 5 Report number: EMC_Geoforce_GT2_FCC_ISED_MPE DATE: 2020-04-17 CETECOM Inc. 411 Dixon Landing Road  Milpitas, CA 95035  U.S.A. Phone: + 1 (408) 586 6200  Fax: + 1 (408) 586 6299  E-mail: [email protected]  http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2905571 © Copyright by CETECOM Page 2 of 8 1 Assessment This RF Exposure evaluation report provides evidence for compliance of the below identified device with the RF Exposure limits for mobile devices as defined in FCC CFR Part 1 (1.1307 &1.1310), Part 2 (2.1091) and IC standard RSS-102 issue 5 under worst case conditions (measured or rated RF output power, antenna gain, distance towards human body, multiple transmitter information as presented by the applicant). In addition, maximum antenna gain or minimum distance towards the human body is calculated respectively, where relevant. The device meets the limits as stipulated by the above given FCC and IC rule parts based on available specifications for worst case conditions at 20cm distance to the body. Company Description Marketing Name Model # Geoforce Inc. GNSS enabled logistics modem Geoforce GT2 OWAC00 OWAS86 OWAH86 Report reviewed by: TCB Evaluator 2020-04-17 Compliance Cindy Li (EMC Lab Manager) Date Section Name Signature Responsible for the Report: 2020-04-17 Compliance Kevin Wang (Senior EMC Engineer) Date Section Name Signature Page 3 of 8 2 Administrative Data 2.1 Identification of the Testing Laboratory Issuing the Test Report Company Name: CETECOM Inc. Department: Compliance Street Address: 411 Dixon Landing Road City/Zip Code Milpitas, CA 95035 Country USA Telephone: +1 (408) 586 6200 Fax: +1 (408) 586 6299 EMC Lab Manger: Cindy Li Responsible Project Leader: Sangeetha Sivaraman 2.2 Identification of the Client / Manufacturer Client’s Name: Geoforce Inc. Street Address: 5830 Granite Parkway, Suite 1200 City/Zip Code Plano, TX 75024 Country United States Identification of the Manufacturer Manufacturer’s Name: Same as Client Manufacturers Address: City/Zip Code Country Page 4 of 8 3 Equipment under Assessment Marketing name: Geoforce GT2 Model No: OWAC00 OWAS86 OWAH86 HW Version : R1 SW Version : 0.4.T (Test supporting software version) Firmware Version Identification Number (FVIN): 0.4.T Hardware Version Identification Number (HVIN): R1 Product Marketing Name (PMN): Geoforce GT2 Regulatory Band:  WLAN:  Nominal band: 2400 MHz – 2483.5 MHz;  Center to center: 2412 MHz (ch 1) – 2462 MHz (ch 11), 11 channels  Bluetooth LE:  Nominal band: 2400 MHz – 2483.5 MHz;  Center to center: 2402 MHz (ch 0) – 2480 MHz (ch 39), 40 channels  Iridium:  Nominal band: 1616 MHz – 1626.5 MHz; Integrated Module Info:  WLAN:  Module name: Zentri, AMW007  FCC ID: 2ABPY-5B9198  Bluetooth LE:  Module name: Nordic, nRF52840  FCC ID: OWA00GT2X  Iridium:  Module name: Iridium 9603N  FCC ID: OWA00GT2X Antenna Type:  WLAN:  Model No.: Molex 479480001  Antenna gain: 3 dBi  Bluetooth LE:  Model No.: Molex 479480001  Antenna gain: 3 dBi Page 5 of 8  Iridium:  Model No.: TW11-0060-X  Antenna gain: 5 dBi Maximum Conducted Output Power:  WLAN: From modular grant [Watts]: 0.172 …

Text truncated - open the document above for the full version.
