OWDTR-0046-EP5400 UHF-H Portable Radio

HARRIS CORPORATION

Click to zoom

Application Details

Equipment Class: TNF - Licensed Non-Broadcast Transmitter Held to Face
Date of Grant: Sep 30, 2007
Application Purpose: Original Equipment
Date of Application: Sep 27, 2007
Equipment Note: P5400 UHF-H Portable Radio
Frequency Range: 440.00000000 - 512.00000000
Company: HARRIS CORPORATION
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: P5400 UHF-H Portable Radio Suite 1400 ID’s: OWDTR-0046-E/3636B-0046 Herndon, VA 20170 Standards: Part 90/RSS-119 http://www.rheintech.com Report #: 2007218 Appendix J: User Manual Please refer to the following pages for the operator’s manual and the product safety manual. 45 of 62 Operator’s Manual MM-012099-001 Rev. Ap1, Oct/07 M/A-COM P5400 Series Portable Radio MM-012099-001, Rev. A 2 MANUAL REVISION HISTORY REV DATE REASON FOR REVISION - Sep/07 Initial release. Rev. A Oct/07 M/A-COM Technical Publications would particularly appreciate feedback on any errors found in this document and suggestions on how the document could be improved. Submit your comments and suggestions to: Tyco Electronics Wireless Systems Segment M/A-COM, Inc. Fax your comments to: 1-434-455-6851 Technical Publications or 221 Jefferson Ridge Parkway e-mail us at: [email protected] Lynchburg, VA 24501 ACKNOWLEDGEMENTS The software contained in this device is copyrighted by M/A-COM, Inc. Unpublished rights are reserved under the copyright laws of the United States. This device is made under license under one or more of the following U.S. Patents: 4,590,473; 4,636,791; 5,148,482; 5,185,796; 5,271,017; 5,377,229; 4,716,407; 4,972,460; 5,502,767; 5,146,497; 5,164,986; 5,185,795. CREDITS! EDACS are registered trademarks of M/A-COM, Inc. TORX is a registered trademark of CAMCAR division of TEXTRON, Inc. All other product and brand names are trademarks, registered trademarks, or service marks of their respective holders. NOTICE! This manual covers M/A-COM products manufactured and sold by M/A-COM, Inc. This product conforms to the European Union WEEE Directive 2002/96/EC. Do not dispose of this product in a public landfill. Take it to a recycling center at the end of its life. The voice coding technology embodied in this product is protected by intellectual property rights including patent rights, copyrights, and trade secrets of Digital Voice Systems, Inc. The user of this technology is explicitly prohibited from attempting to decompile, reverse engineer, or disassemble the Object Code, or in any other way convert the Object Code into human-readable form. Repairs to this equipment should be made only by an authorized service technician or facility designated by the supplier. Any repairs, alterations, or substitution of recommended parts made by the user to this equipment not approved by the manufacturer could void the user’s authority to operate the equipment in addition to the manufacturer’s warranty. This manual is published by M/A-COM, Inc., without any warranty. Improvements and changes to this manual necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by M/A-COM, Inc., at any time and without notice. Such changes will be incorporated into new editions of this manual. No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose, without the express written permission of M/A-COM, Inc. Copyright © 2007 M/A-COM, Inc. All rights reserved. MM-012099-001, Rev. A 3 TABLE OF CONTENTS Page 1 SAFETY CONVENTIONS..................................................................................................................10 2 SAFETY TRAINING INFORMATION ............................................................................................11 2.1 RF EXPOSURE GUIDELINES .................................................................................................11 2.2 ELECTROMAGNETIC INTERFERENCE/COMPATIBILITY...............................................12 3 OPERATING TIPS ..............................................................................................................................13 3.1 EFFICIENT RADIO OPERATION ...........................................................................................13 3.1.1 Antenna Care and Replacement.....................................................................................13 3.1.2 Electronic Devices .........................................................................................................13 3.1.3 Aircraft...........................................................................................................................14 3.1.4 Electric Blasting Caps ...................................................................................................14 3.1.5 Potentially Explosive Atmospheres ...............................................................................14 4 BATTERIES .........................................................................................................................................15 4.1 CONDITIONING BATTERY PACKS......................................................................................15 4.1.1 Conditioning NiMH Battery Packs................................................................................15 4.1.2 Conditioning NiCD Battery Packs.................................................................................15 4.1.3 Additional Information ..................................................................................................16 4.2 CHARGING BATTERY PACKS ..............................................................................................16 4.2.1 Charging Guidelines ......................................................................................................16 4.3 BATTERY PACK USAGE ........................................................................................................16 4.3.1 Usage Guidelines ...........................................................................................................16 4.4 CHANGING THE BATTERY PACK .......................................................................................17 4.4.1 Removing the Battery Pack ...........…

Text truncated - open the document above for the full version.

Cover Letter(s)

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 September 26, 2007 RE: FCC ID: OWDTR-0046-E_ATCB005467 Attention: Kathy Grzovic I have a few comments on this Application. Please note that further comments may arise in response to answers provided to the questions below. 1. Please note that part 90 states that devices operating between 421-512MHz are subject to tran sient frequency behavior in accordance to 90.214. These tests do not appear to be in the report. Please explain and please provide the associated transient frequency behavior data. Alternately please provide adequate justification for not applying this test sequence. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Cover Letter(s)

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 September 26, 2007 RE: FCC ID: OWDTR-0046-E_ATCB005467 Attention: Kathy Grzovic I have a few comments on this Application. Please note that further comments may arise in response to answers provided to the questions below. 1. Please note that part 90 states that devices operating between 421-512MHz are subject to transient frequency behavior in accordance to 90.214. These tests do not appear to be in the report. Please explain and please provide the associated transient frequency behavior data. Response: Please refer to the revised test report uploaded with this response, specifically Section 12, for the transient frequency data. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

External Photos

Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: P5400 UHF-H Portable Radio Suite 1400 ID’s: OWDTR-0046-E/3636B-0046 Herndon, VA 20170 Standards: Part 90/RSS-119 http://www.rheintech.com Report #: 2007218 Appendix M: External Photographs Photograph 6: Scan Version Front View Photograph 7: System Version Front View 50 of 62 Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: P5400 UHF-H Portable Radio Suite 1400 ID’s: OWDTR-0046-E/3636B-0046 Herndon, VA 20170 Standards: Part 90/RSS-119 http://www.rheintech.com Report #: 2007218 Photograph 8: Back View 51 of 62 Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: P5400 UHF-H Portable Radio Suite 1400 ID’s: OWDTR-0046-E/3636B-0046 Herndon, VA 20170 Standards: Part 90/RSS-119 http://www.rheintech.com Report #: 2007218 Photograph 9: PTT Side Photograph 10: UDC Side 52 of 62 Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: P5400 UHF-H Portable Radio Suite 1400 ID’s: OWDTR-0046-E/3636B-0046 Herndon, VA 20170 Standards: Part 90/RSS-119 http://www.rheintech.com Report #: 2007218 Photograph 11: Top View 53 of 62

ID Label/Location Info

Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: P5400 UHF-H Portable Radio Suite 1400 ID’s: OWDTR-0046-E/3636B-0046 Herndon, VA 20170 Standards: Part 90/RSS-119 http://www.rheintech.com Report #: 2007218 Appendix K: Label & Location RF Label Location ID Label Location Photograph 1: ID Label and RF Label Locations 46 of 62 Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: P5400 UHF-H Portable Radio Suite 1400 ID’s: OWDTR-0046-E/3636B-0046 Herndon, VA 20170 Standards: Part 90/RSS-119 http://www.rheintech.com Report #: 2007218 Photograph 2: ID Label Sample Photograph 3: RF Label Sample 47 of 62

Internal Photos

Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: P5400 UHF-H Portable Radio Suite 1400 ID’s: OWDTR-0046-E/3636B-0046 Herndon, VA 20170 Standards: Part 90/RSS-119 http://www.rheintech.com Report #: 2007218 Appendix N: Internal Photographs Photograph 12: RF Shield on Radio 54 of 62 Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: P5400 UHF-H Portable Radio Suite 1400 ID’s: OWDTR-0046-E/3636B-0046 Herndon, VA 20170 Standards: Part 90/RSS-119 http://www.rheintech.com Report #: 2007218 Photograph 13: RF Shield Top View 55 of 62 Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: P5400 UHF-H Portable Radio Suite 1400 ID’s: OWDTR-0046-E/3636B-0046 Herndon, VA 20170 Standards: Part 90/RSS-119 http://www.rheintech.com Report #: 2007218 Photograph 14: RF Shield Bottom View 56 of 62 Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: P5400 UHF-H Portable Radio Suite 1400 ID’s: OWDTR-0046-E/3636B-0046 Herndon, VA 20170 Standards: Part 90/RSS-119 http://www.rheintech.com Report #: 2007218 Photograph 15: Main Board in Radio 57 of 62 Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: P5400 UHF-H Portable Radio Suite 1400 ID’s: OWDTR-0046-E/3636B-0046 Herndon, VA 20170 Standards: Part 90/RSS-119 http://www.rheintech.com Report #: 2007218 Photograph 16: Main Board Top View 58 of 62 Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: P5400 UHF-H Portable Radio Suite 1400 ID’s: OWDTR-0046-E/3636B-0046 Herndon, VA 20170 Standards: Part 90/RSS-119 http://www.rheintech.com Report #: 2007218 Photograph 17: Main Board Bottom View 59 of 62 Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: P5400 UHF-H Portable Radio Suite 1400 ID’s: OWDTR-0046-E/3636B-0046 Herndon, VA 20170 Standards: Part 90/RSS-119 http://www.rheintech.com Report #: 2007218 Photograph 18: Casting 60 of 62 Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: P5400 UHF-H Portable Radio Suite 1400 ID’s: OWDTR-0046-E/3636B-0046 Herndon, VA 20170 Standards: Part 90/RSS-119 http://www.rheintech.com Report #: 2007218 Photograph 19: Interface Board Top View 61 of 62 Rhein Tech Laboratories Client: M/A-COM, Inc. 360 Herndon Parkway Model: P5400 UHF-H Portable Radio Suite 1400 ID’s: OWDTR-0046-E/3636B-0046 Herndon, VA 20170 Standards: Part 90/RSS-119 http://www.rheintech.com Report #: 2007218 Photograph 20: Interface Board Bottom View 62 of 62

RF Exposure Info

Company: M/A-COM, Inc. Model: P5400 FCC ID: OWDTR-0046-E IC ID: 3636B-0046 DUT Type: Portable Analog/Digital UHF-H PTT Radio Transceiver Frequency Range: 440 - 512 MHz 2007 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 1 of 129 Date(s) of Evaluation Jul 31, Aug 1-2, 8-10, 2007 Test Report Serial No. 073107OW D-T845-S90U Test Report Revision No. Revision 1.0 Test Report Issue Date August 29, 2007 Description of Test(s) Specific Absorption Rate RF Exposure Category Occupational (Controlled) Certificate No. 2470.01 SAR TEST REPORT R R F F E E X X P P O O S S U U R R E E E E V V A A L L U U A A T T I I O O N N S S P P E E C C I I F F I I C C A A B B S S O O R R P P T T I I O O N N R R A A T T E E APPLICANT M/A-COM, INC. PRODUCT PORTABLE FM UHF-H PTT RADIO TRANSCEIVER MODEL(S) P5400 IDENTIFIER(S) FCC ID: OWDTR-0046-E IC ID: 3636B-0046 APPLICATION TYPE New Certification STANDARD(S) APPLIED FCC 47 CFR §2.1093 Health Canada Safety Code 6 FCC OET Bulletin 65, Supplement C (01-01) PROCEDURE(S) APPLIED Industry Canada RSS-102 Issue 2 FCC DEVICE CLASSIFICATION Licensed Non-Broadcast Transmitter Held to Face (TNF) IC DEVICE CLASSIFICATION Land Mobile Radio Transmitter/Receiver (27.41-960 MHz) RF EXPOSURE CATEGORY Occupational / Controlled Exposure TEST REPORT SERIAL NO. 073107OWD-T845-S90U TEST REPORT REVISION NO. Revision 1.0 (Initial Release) TEST REPORT ISSUE DATE August 29, 2007 Testing and Test Report ByTest Report Reviewed By TEST REPORT SIGNATORIES Cheri Frangiadakis Celltech Labs Inc. Jonathan Hughes Celltech Labs Inc. Celltech Compliance Testing & Engineering Lab TEST LAB AND LOCATION 21-364 Lougheed Road, Kelowna, B.C. V1X 7R8 Canada Tel.: 250-765-7650 Fax: 250-765-7645 TEST LAB CONTACT INFO. [email protected] www.celltechlabs.com TEST LAB ACCREDITATION(S) Certificate No. 2470.01 Company: M/A-COM, Inc. Model: P5400 FCC ID: OWDTR-0046-E IC ID: 3636B-0046 DUT Type: Portable Analog/Digital UHF-H PTT Radio Transceiver Frequency Range: 440 - 512 MHz 2007 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 2 of 129 Date(s) of Evaluation Jul 31, Aug 1-2, 8-10, 2007 Test Report Serial No. 073107OW D-T845-S90U Test Report Revision No. Revision 1.0 Test Report Issue Date August 29, 2007 Description of Test(s) Specific Absorption Rate RF Exposure Category Occupational (Controlled) Certificate No. 2470.01 DECLARATION OF COMPLIANCE SAR RF EXPOSURE EVALUATION Test Lab Information: Name CELLTECH LABS INC.Address 21-364 Lougheed Road, Kelowna B.C. V1X 7R8 Canada Company Information: Name M/A-COM, INC. Address 221 Jefferson Ridge Parkway Lynchburg, VA 24501 United States Device Description: Portable UHF-H PTT Radio Transceiver Device Model(s): P5400 Type(s): Scan System Scan P/N: RU-123550-031 S/N: T1-UH-004 Identical Prototype Device Part No.(s) & Serial No.(s) Tested: System P/N: RU-123550-032 S/N: T1-UH-003 Identical Prototype Mode(s) & Modulation Type(s): Analog FM Digital FSK Transmit Frequency Range(s): 440 - 512 MHz 4.4 W atts 36.4 dBm 440 MHz Conducted 4.3 W atts 36.3 dBm 476 MHz Conducted Max. RF Output Power Tested: 4.3 W atts 36.3 dBm 512 MHz Conducted Helical Stub 440 - 494 MHz Length: 64 mm P/N: KRE 101 1219/12 Helical Stub 470 - 512 MHz Length: 56 mm P/N: KRE 101 1219/14 Antenna Type(s) Tested: Quarter-W ave W hip 440 - 512 MHz Length: 139 mm P/N: KRE 101 1223/12 7.5V NiCd immersible non-IS P/N: BT-023406-001 7.5V NiCd immersible ISP/N: BT-023406-002 7.5V NiMH immersible non-IS P/N: BT-023406-003 7.5V NiMH immersible ISP/N: BT-023406-004 Battery Type(s) Tested: 7.5V Li-ion immersible non-IS P/N: BT-023406-005 7.5V Li-ion immersible ISP/N: BT-023406-006 Metal Belt-Clip P/N: CC23894 Leather Belt Loop and Metal Swivel Mount (P/N: KRY 101 1608/2) P/N: KRY 101 1609/1 Leather Case Kit 1: Leather Case w/o D-rings (P/N: CC-023931-001), Swivel-Mount (P/N: KRY 101 1608/2), Elastic Strap (P/N: FM-011820) and Belt Loop (P/N: KRY 101 1609/1) P/N: CC-023931-003 Leather Case Kit 2: Leather Case w/ D-rings (P/N: CC-023931-002), Swivel-Mount (P/N: KRY 101 1608/2), Elastic Strap (P/N: FM-011820) and Belt Loop (P/N: KRY 101 1609/1) P/N: CC-023931-004 Leather Case w/ D-rings, Elastic Strap (P/N: FM-011820), Shoulder Strap (P/N: CC103333V1) P/N: CC-023931-002 Nylon (black) Case (w/ swivel) and Belt Loop (P/N: KRY 101 1609/1) P/N: CC-023932-001 Body-worn Accessories Tested: Nylon “T”-Strap Holder P/N: KRY 101 1656/1 Speaker-Microphone with Antenna (SMA) P/N: MC-023933-002 Speaker-Microphone P/N: MC-023933-001 Audio Accessories Tested: Earphone for speaker/mic P/N: LS103239V1 Face-held:2.13 W/kg1g average50% Duty CycleANSI/IEEE Limit: 8.0 W /kg 1g average Max. SAR Level(s) Evaluated: Body-worn: 4.82 W/kg 1g average 50% Duty Cycle ANSI/IEEE Limit:8.0 W /kg 1g average Celltech Labs Inc. declares under its sole responsibility that this wireless portable device has demonstrated compliance with the Specific Absorption Rate (SAR) RF exposure requirements specified in FCC 47 CFR §2.1093 and Health Canada’s Safety Code 6 for the Occupational/Controlled Exposure environment. The device was tested in accordance with the measurement standards and procedures specified in FCC OET Bulletin 65, Supplement C (Edition 01-01) and Industry Canada RSS-102 Issue 2. All measurements were performed in accordance with the SAR system manufacturer recommendations. I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. This test report shall not be reproduced partially, or in full, without the prior written approval of Celltech Labs Inc. The results and statements contained in this report pertain only to the device(s) eval…

Text truncated - open the document above for the full version.

RF Exposure Info

Company: M/A-COM, Inc. Model: P5400 FCC ID: OWDTR-0046-E IC ID: 3636B-0046 DUT Type: Portable Analog/Digital UHF-H PTT Radio Transceiver Frequency Range: 440 - 512 MHz 2007 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 21 of 129 Date(s) of Evaluation Jul 31, Aug 1-2, 8-10, 2007 Test Report Serial No. 073107OW D-T845-S90U Test Report Revision No. Revision 1.0 Test Report Issue Date August 29, 2007 Description of Test(s) Specific Absorption Rate RF Exposure Category Occupational (Controlled) Certificate No. 2470.01 APPENDIX A - SAR MEASUREMENT DATA Company: M/A-COM, Inc. Model: P5400 FCC ID: OWDTR-0046-E IC ID: 3636B-0046 DUT Type: Portable Analog/Digital UHF-H PTT Radio Transceiver Frequency Range: 440 - 512 MHz 2007 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 22 of 129 Date(s) of Evaluation Jul 31, Aug 1-2, 8-10, 2007 Test Report Serial No. 073107OW D-T845-S90U Test Report Revision No. Revision 1.0 Test Report Issue Date August 29, 2007 Description of Test(s) Specific Absorption Rate RF Exposure Category Occupational (Controlled) Certificate No. 2470.01 Date Tested: 08/02/2007 Face-Held SAR - NiCd NIS Battery - Helical Stub Antenna (P/N: KRE 101 1219/12) - 476 MHz DUT: M/A-COM Model: P5400 (Scan Radio); Type: Portable UHF-H PTT Radio Transceiver; Serial: T1-UH-004 Ambient Temp: 25.2qC; Fluid Temp: 23.8qC; Barometric Pressure: 101.4 kPa; Humidity: 31% Communication System: FM UHF Frequency: 476 MHz; Duty Cycle: 1:1 RF Output Power: 4.3 Watts (Conducted) NiCd Battery, immersible, non-IS (P/N: BT-023406-001) Medium: HSL450 Medium parameters used: f = 476 MHz; ı = 0.86 mho/m; İ r = 43.3; ȡ = 1000 kg/m 3 - Probe: ET3DV6 - SN1387; ConvF(7, 7, 7); Calibrated: 16/03/2007 - Sensor-Surface: 4 mm (Mechanical Surface Detection) - Electronics: DAE4 Sn353; Calibrated: 10/07/2007 - Phantom: Side Planar; Type: Plexiglas; Serial: 161 - Measurement SW: DASY4, V4.7 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 171 Face-Held - 2.5 cm Spacing from Front of DUT to Planar Phantom - Mid Channel Area Scan (8x16x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.91 mW/g Face-Held - 2.5 cm Spacing from Front of DUT to Planar Phantom - Mid Channel Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 60.7 V/m; Power Drift = -0.0515 dB Peak SAR (extrapolated) = 4.83 W/kg SAR(1 g) = 3.07 mW/g; SAR(10 g) = 2.17 mW/g Maximum value of SAR (measured) = 3.21 mW/g Company: M/A-COM, Inc. Model: P5400 FCC ID: OWDTR-0046-E IC ID: 3636B-0046 DUT Type: Portable Analog/Digital UHF-H PTT Radio Transceiver Frequency Range: 440 - 512 MHz 2007 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 23 of 129 Date(s) of Evaluation Jul 31, Aug 1-2, 8-10, 2007 Test Report Serial No. 073107OW D-T845-S90U Test Report Revision No. Revision 1.0 Test Report Issue Date August 29, 2007 Description of Test(s) Specific Absorption Rate RF Exposure Category Occupational (Controlled) Certificate No. 2470.01 Date Tested: 08/09/2007 Face-Held SAR - NiCd IS Battery - Helical Stub Antenna (P/N: KRE 101 1219/12) - 476 MHz DUT: M/A-COM Model: P5400 (Scan Radio); Type: Portable UHF-H PTT Radio Transceiver; Serial: T1-UH-004 Ambient Temp: 23.3qC; Fluid Temp: 23.5qC; Barometric Pressure: 101.4 kPa; Humidity: 31% Communication System: FM UHF Frequency: 476 MHz; Duty Cycle: 1:1 RF Output Power: 4.3 Watts (Conducted) NiCd Battery, immersible, IS (P/N: BT-023406-002) Medium: HSL450 Medium parameters used: f = 476 MHz; ı = 0.85 mho/m; İ r = 41.9; ȡ = 1000 kg/m 3 - Probe: ET3DV6 - SN1387; ConvF(7, 7, 7); Calibrated: 16/03/2007 - Sensor-Surface: 4 mm (Mechanical Surface Detection) - Electronics: DAE4 Sn353; Calibrated: 10/07/2007 - Phantom: Side Planar; Type: Plexiglas; Serial: 161 - Measurement SW: DASY4, V4.7 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 171 Face-Held - 2.5 cm Spacing from Front of DUT to Planar Phantom - Mid Channel Area Scan (8x16x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.91 mW/g Face-Held - 2.5 cm Spacing from Front of DUT to Planar Phantom - Mid Channel Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=7.5mm, dy=7.5mm, dz=5mm Reference Value = 61.5 V/m; Power Drift = -0.500 dB Peak SAR (extrapolated) = 4.87 W/kg SAR(1 g) = 3.09 mW/g; SAR(10 g) = 2.13 mW/g Maximum value of SAR (measured) = 3.21 mW/g Company: M/A-COM, Inc. Model: P5400 FCC ID: OWDTR-0046-E IC ID: 3636B-0046 DUT Type: Portable Analog/Digital UHF-H PTT Radio Transceiver Frequency Range: 440 - 512 MHz 2007 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 24 of 129 Date(s) of Evaluation Jul 31, Aug 1-2, 8-10, 2007 Test Report Serial No. 073107OW D-T845-S90U Test Report Revision No. Revision 1.0 Test Report Issue Date August 29, 2007 Description of Test(s) Specific Absorption Rate RF Exposure Category Occupational (Controlled) Certificate No. 2470.01 Date Tested: 08/02/2007 Face-Held SAR - NiMH NIS Battery - Helical Stub Antenna (P/N: KRE 101 1219/12) - 476 MHz DUT: M/A-COM Model: P5400 (Scan Radio); Type: Portable UHF-H PTT Radio Transceiver; Serial: T1-UH-004 Ambient Temp: 25.2qC; Fluid Temp: 23.8qC; Barometric Pressure: 101.4 kPa; Humidity: 31% Communication System: FM UHF Frequency: 476 MHz; Duty Cycle: 1:1 RF Output Power: 4.3 Watts (Conducted) NiMH Battery, immersible, non-IS (P/N: BT-023406-003) Medium: HSL450 Medium parameters used: f = 476 MHz; ı = 0.86 mho/m; İ r = 43.3; ȡ = 1000 kg/m 3 - Probe: ET3DV6 - SN1387; ConvF(7, 7, 7); Calibrated: 16/03/2007 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn353; Calibrated: 10/07/2007 - Phantom: Side Planar; Type: Plexiglas; Serial: 161 - Measurem…

Text truncated - open the document above for the full version.

RF Exposure Info

Text truncated - open the document above for the full version.

Contact Information

Applicant

Thomas Camper, Jr.(Regulatory Manager)

[email protected]434-455-9367Fax: 434-455-6851

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
1	9	440 MHz - 512 MHz	4 W	16K0F3E	0.48 ppm

Confidentiality

Long Term

Grant Notes

Power listed is manufacturer's rated power. Measured power is 4.3 W. This device must transmit with a source-based time-averaging duty factor not exceeding 50%. This device must be restricted to work related operations in an Occupational/Controlled RF exposure Environment. SAR for body worn operation has been tested and meets the FCC RF exposure guidelines when used with the M/A-COM, Inc. listed accessories designated for this product. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. This transmitter may operate only with antennas as described in this filing. SAR was evaluated for body worn and held-to-face operating modes. Maximum SAR values reported are: Body 4.82 w/kg.
